Totevision LCD-566T User manual

The Remote control
The following figure shows a clear layout of the remote control.
Calling up a Menu display
Press the MENU button on the remote control to call up the various menu displays.
Then, use the Channel Up/Down buttons to select which item you want to access or adjust.
Display color will be changed for the selected item.
Press Volume -/+ to adjust values or activate command.
The Menu is in three pages as below. Access next page by pressing MENU button a second time.
.
MENUpage#1
CONTRAST
BRIGHTNESS
COLOR
TINT
Auto color
Select CH-/CH+ Adjust VOL-/VOL+

MENUpage#2
MENUpage#3
Adding and Skipping unwanted TV Channel
If you want to exclude any channel from the memory, press “DEL” button on the remote
control. Screen will ask you if you want to erase from memory. Or
Select unwanted channel and press menu button on the remote control two(2) times to access menu
page #2 and then select CH DELETE with CH- button and press VOL+ button.
If you want to add specific channel to the memory, select CH manual select from the
menu page #2. Then you can see all active channels
Select wanted channel with CH-/+ buttons and press VOL+ button for memory.
Menu display will disappear automatically after 15sec.However you may press MENU button for
exit.
CH AUTO SCAN
CH DELETE
CH MANUAL SELECT
TV MODE STD/HRC/IRC
Select CH-/CH+ Adjust VOL-/VOL+
INPUT select TV/AV
Mirror Left/Right
Display Up/Down
Select CH-/CH+ Adjust VOL-/VOL+

Channel Auto Scanning
Press the SCAN button on the remote control. or
Access menu page #2 and select CH Auto Scan, then, press VOL+ button.
TV Mode Selecting
Press the MODE button on the remote control to select one of AIR/STD/HRC/IRC. or
Access menu page #2 and select TV MODE and press VOL+ button to select appropriate TV mode.
AV Mode Selecting
Press the TV/AV button on the remote control to select AV input. or
Access menu page #3 and select AV mode.
Automatic Power Off
The TV will be turned off automatically if TV signal is not detected for 10 minutes.
Specification
Display: 5.6" TFT LCD active matrix Back Light: Built-in (CCFT)
Input Signal: NTSC – AIR(ch2~ch69) 125ch CATV(STD/HRC/IRC)
Dot Format: 960(H) x 234(V) dots Dot Pitch: 0.120mm(H) x 0.360mm(V)
Brightness rating: 200 cd/m2 Number of Pixels: 224,640 Dots
Pixel Configuration: Stripe Audiooutput:2W(RMS)
Power requirements : 11VDC- 27VDC Power consumption : 10 Watts
