Tower Hobbies T19017 Operator's manual

T19017
3-IN-1
Hand Blender
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small
appliances used by millions of households throughout the
UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.

3
Contents:
Thank you for purchasing this Tower 3 in 1 Hand
Blender from the Tower range
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benefits to using this Tower
appliance:
• Ergonomic design
• Perfect for creating delicious meals, sauces and
soups with ease
• Easy to clean
1. Specifications
Components and
structure
2. Technical Data
3. Important Safety
Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Recycling
8. Cleaning & Care
9. Wiring Safety
10. Warranty Information
See back page for Customer
Service Information.

4
This box contains:
Instruction Manual
Hand Blender
Accessories
1. Beaker
2. Whisk Attachment
3. Speed adjuster
4. Power button
5. Turbo button
6. Power Handle
7. Blender Attachment
8. Chopper Bowl Lid
9. Chopper Bowl
1 - Specifications:
Structure of your appliance:
3
4
5
6
7
8
9
1
2

5
Description: 3 in 1 Hand Blender
Model: T19017
Rated Voltage: 220-240V
Frequency: 50/60Hz
Power consumption: 600W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food
(LFGB section 30 & 31).
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: [phone].
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.

6
• Check that the voltage
of the main circuit
corresponds with the rating
of the appliance before
operating.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children.
• Take care when any
appliance is used near pets.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
• Children should not play
with the appliance.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Switch off at the wall socket
then remove the plug from
the socket when not in use,
before cleaning or before
changing parts and/or
accessories.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly qualified
person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments other than
those supplied is not
recommended.
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:

7
• DO NOT pull the plug out
by the cord as this may
damage the plug and/or the
cable.
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use any extension
cord with this appliance.
• DO NOT use the appliance
outdoors.
• Unplug from outlet when
not in use, before putting
on or taking off parts, and
before cleaning.
• DO NOT immerse the motor
unit into water as this would
give rise to electric shock.
• Avoid contacting moving
parts.
• Keep hands and utensils out
of container while blending
to reduce the risk of severe
injury to persons or damage
to the blender.
• Care shall be taken when
handling the sharp cutting
blades, emptying the bowl
and during cleaning.
• The appliance is intended to
be used in household and
similar applications such as
staff kitchen areas in shops,
oces and other working
environments, farm houses,
or by clients in hotels,
motels and other residential
types of environments such
as bed and breakfast type
environments.
• WARNING! Be careful if hot
liquid is poured into the
blender as it can be ejected
out of the appliance due to
sudden steaming.
• DO NOT operate the
blender with wet hands.
Make sure your hands are
dry before plugging in the
appliance.
• Make sure the blender shaft,
whisk, chopper or attached
accessory are not damaged
before using the appliance.
• DO NOT let the blades
face toward anyone while
operating the appliance.

8
• Always ensure the hand
blender, whisk or chopper
is throughly sterilised.
Use a sterilising solution
in accordance with the
solution’s manufacturer
instructions.
• NEVER blend or mix hot oil
and/or fat. Pleas follow the
processing guide.
• DO NOT touch the blades or
whisk attachment while the
appliance is plugged in and
turned on.
• DO NOT add ingredients
to the beaker or chopper
bowl while the blender is
operating.
• Make sure the ingredients
DO NOT exceed the
maximum markings on the
beaker or chopper bowl.
• DO NOT continuously
operate the blender for
too long. The motor may
overheat. If the surface
of the blender is very
hot, it may need time to
cool down. Turn off the
appliance and allow it to
cool off before using again.
• The continuous operating
time to use the blender is
15 seconds. DO NOT use
the blender to mix hard
ingredients.
• DO NOT exceed the
quantities and maximum
time indicated in the
operation guidelines or
processing guide.
• Take the attachments off
before cleaning.
• The use of attachments,
including canning jars is
NOT recommended by the
manufacturer and may
cause risk of injury and/or
damage.
• The appliance cannot be
used for chopping ice or
blending hard and dry
substance, otherwise the
blade could be blunted.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

9
1. Clean the stick blender by holding it in a cup half filled with water and turn on
for a few seconds.
2. Important: Blades are very sharp, handle with care.
3. Never assemble, disassemble or clean when the product is connected to the
mains supply.
4. Dispose of the packaging in a responsible manner
5. Note: Turbo Button - The turbo speed equals the maximum of the adjustable
speed setting.
1. Cut your ingredients into small cubes.
2. Remove the protective cover from the blade of the blender shaft, and clean
the shaft and beaker.
3. Place the ingredients into a suitable container or, the supplied chopper bowl
or food beaker.
4. Fit the power handle inside the blender shaft, turn and lock until you hear a
slight click. The marks on the power handle and blender shaft should now be
aligned with each other. Note: Check that the power cord is not damaged.
5. Plug the appliance into the power outlet and choose your desired speed
setting whilst holding the power handle steadily. Switch the blender on by
holding and pressing the power button.
6. Hold the container firmly.
7. Lower the blender into the container.
8. Press and hold the power button on the hand blender. To blend the
ingredients move the appliance slowly up and down in circles.
9. To stop the blender, take your finger off the power button.
10. To switch to a different blender attachment by fitting the power handle inside
the blender shaft. Turn and lock until you hear a slight click. The markings on
the power handle and blender shaft should now be aligned with each other. If
this is the case, the blender shaft is locked correctly.
Note: If the blender gets blocked, first stop and unplug it before clearing.
After use, unplug and dismantle the appliance.
Always switch off and unplug the appliance before cleaning. Please refer to the
Cleaning and Care section.
Using the Chopper:
1. Remove the protective cover from the blade of the chopper.
2. Clean the lid, blade unit and the chopper bowl.
3. Fix the blade unit in the chopper bowl and fill the bowl with food (no more
than the indicated max level).
4. Fit the power handle inside the chopper, turn and lock until you hear a slight
click. The marks on the power handle and chopper should now be aligned
with each other. Note: Check the power cord is not damaged.
4 - Before First Use
5 - Using Your Appliance

10
5. Plug the appliance into the power outlet and choose your desired speed
setting whilst holding the power handle steadily. Switch the blender on by
holding and pressing the power button.
6. Hold the chopper bowl firmly.
7. Press and hold the power button to blend your ingredients using the chopper.
8. When finished, release the power button and unplug the blender from the
outlet.
Note: If the chopper get blocked first stop and unplug it before clearing.
After use, unplug and detach the power handle and lid, take the blade out of the
bowl by holding the plastic shaft, then pour out the food.
Always switch off the blender and unplug it before cleaning. Refer to the
Cleaning and Care section.
WARNING! DO NOT touch the edges of the blade since they are sharp!
Using the Whisk:
1. Clean the whisk, whisk head and beaker.
2. Insert the whisk into the whisk head until you hear a slight click.
3. Fit the power handle inside of the whisk head, turn and lock until you hear a
slight click. The marks on the power handle and the whisk head should now
be aligned with each other. Note: Make sure the power cord is not damaged.
4. Fill the beaker with food. Do not exceed the max level.
5. Plug in the blender and choose your desired speed setting, whilst holding the
power handle steadily. Switch on the appliance by pressing and holding the
power button.
6. To prevent splashing, use the low speed setting when you begin mixing your
ingredients.
7. Immerse the whisk completely into the ingredients, and blend them moving
the appliance slowly up and down in circles.
8. When finished, release the power button and unplug it the outlet.
WARNING! Never blend hot oil, fat or meat.
Note: If the whisk gets blocked, first stop and unplug it before clearing.
After use, unplug and detach the whisk from the power handle.
Always switch off the blender and unplug it before cleaning. Refer to the
Cleaning and Care section.
WARNING! Make sure the blender is switched off when switching attachments.
WARNING! DO NOT come into contact with moving parts while blending. AVOID
touching the blades or attachments when the appliance is turned on to avoid
injury.
Rest Times:
• Do not operate the hand blender for more than 1 minute at a time, otherwise
it will become very hot and can become damaged.
• Do not exceed 15 seconds running time of the unit without blending
ingredients.
• Do not exceed 1 minute running time when operating under high speed.
• Allow the appliance to rest for a minimum of 2 minutes between blending
cycles.

11
The hand blender
Food Speed Max. time Max. quantity
soups,
milk
vegetables,
mayonnaise
sauces,
strawberry
lower speed 30 seconds 200g
carrot pieces
(size 15mm x
15mm x 15mm)
higher speed 10 seconds
500g
Note: take 200g
Carrot pieces
per 300g water.
The chopper
beef pieces (size
20mm x 20mm
x20mm), almonds
high speed 30 seconds 200g
The egg-fork
cream, egg whites higher speed 3 minutes 150g
• If you accidentally do run the hand blender for longer than any of the stated
times, unplug it and leave it to fully cool to room temperature before re-using.
Tips: Poultry bones can not be cut using these blades.
• Roughly chop all your ingredients before blending for best results.
• Move your hand blender in a gentle up and down movement.
• Start blending at the lowest setting before blending with the highest speed
setting.
• The hand blender can be used for:
Blending fluids, e.g. dairy products, sauces, fruit juices, soups, mixed drinks and
shakes.
Mixing soft ingredients, e.g. pancake batter or mayonnaise.
Pureeing cooked ingredients, e.g. for making baby food.
• The chopper can be used for chopping beef (less than 200g), nuts, breads,
vanilla, onions, e.g.
• The whisk can be used for beating egg whites and cream.
Processing guide:

12
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to
information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling
6 - Troubleshooting
Questions Answers
The mixture splashes
up when I blend.
This can happen due to the powerful blades of the hand blender.
Try placing the end of the blender shaft into your mixture before
turning it on, to minimise splash. You can also use a larger or deeper
bowl or jug.
My mixture is not
blending.
Try chopping your ingredients into smaller pieces.
How long can I use
the blender for
before it needs to
rest?
Do not exceed 1 minute running time when operating under high
speed.
Allow the appliance to rest for a minimum of 2 minutes between
blending cycles.
Can I switch the
blender on when it
is not being used to
blend?
You can run the blender without actually blending ingredients,
but do not exceed 15 seconds running time without blending
ingredients.
Can I use the stick
blender to crush ice?
No, you cannot use the blender to crush ice as this can blunt the
blades.

13
1. Unplug the appliance and allow it to cool down before cleaning.
2. Wash the blade under running water, without the use of abrasive cleaner or
detergents. Do not immerse the detachable blender shaft in water because
the lubrication on the bearing may wash away.
3. Wipe the motor unit with a damp cloth.
4. Never immerse it in water for cleaning as an electric shock may occur.
5. Make sure that the appliance is cleaned after every use.
Beaker:
• The beaker can be washed in water with a cleaning agent.
• Wash and rinse thoroughly with water and then dry.
Blender Shaft:
• The blender shaft can be washed in water with a cleaning agent.
• Wash and rinse it thoroughly with water and then dry.
• Reattach the protective cover to the blade.
Chopper:
• Do not immerse the chopper into water or any other liquid, or use abrasives.
The lid unit of the chopper can ONLY be wiped with a damp cloth and then
dried.
• The bowl and the blade can be washed in water with the cleaning agent.
• Wash and rinse the chopper bowl and rinse it thoroughly with water and then
dry it.
• Reattach the protective cover to the blade.
Whisk:
• The whisk head can only be wiped with a damp cloth and dried.
• Never wash and rinse the whisk head in water or use abrasives.
• The whisk attachment can be washed in water with a cleaning agent.
• Wash and rinse the whisk thoroughly in water and then dry it.
IMPORTANT: Allow to dry fully after cleaning before using again.
DO NOT use the appliance if damp. Ensure the appliance is completely clean and
dry before storing.
To store your appliance:
1. Unplug power cord from the power outlet and clean as above.
2. Allow the appliance to dry fully.
3. Store in a dry place out of direct sunlight.
8 - Cleaning & Care

14
9 - Wiring Safety for UK Use Only
WARNING:
This appliance is double insulated.
Do not connect any wire to the earth terminal.
IMPORTANT
As the colours in
the mains lead of
this appliance may
not correspond
with the coloured
markings identifying
the terminals in your
plug, please proceed
as follows:
The wires in the mains lead are coloured
in accordance with the following code:
Blue neutral [N] Brown
live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral
and must be connected to the terminal
marked [N] or coloured black.
The wire coloured brown is the live wire
and must be connected to the terminal
marked [L] or coloured red.
On no account must either the brown
or the blue wire be connected to the
[EARTH] terminal .
Always ensure that the cord grip is
fastened correctly.
The plug must be fitted with a fuse
of the same rating already fitted and
conforming to BS 1362 and be ASTA
approved.
If in doubt consult a qualified electrician
who will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead
and should the fuse need replacing,
you must use an ASTA approved one
(conforming to BS 1362 of the same
rating).
If in doubt, consult a qualified
electrician who will be pleased to do
this for you.
If you need to remove the plug –
disconnect it from the mains – and
then cut it off of the mains lead and
immediately dispose of it in a safe
manner. Never attempt to reuse the
plug or insert it into a socket outlet as
there is a danger of an electric shock.

15
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty materials
of workmanship, the faulty products must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a
receipt.
• The product must be installed and
used in accordance with the
instructions contained in this
instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear,
damage, misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire
only.
The standard one year guarantee is only
extended to the maximum available for
each particular product upon registration
of the product within 28 days of purchase.
If you do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and
register with us online. Alternatively, call
our customer registration line on
[phone].
Please note that length of extended
warranty offered is dependent on product
type and that each qualifying product
needs to be registered individually in order
to extend its warranty past the standard
1 year.
Extended warranty is only valid with proof
of purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty

thank you!
We hope you enjoy your appliance for many years. As a thank you for
purchasing one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team:
[phone]
1217.V1
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
