Toyota CQ-TS7420K User manual

General
Power Supply DC 12V
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 3.0A (at 0.5W)
FM Stereo Radio
Frequency Range 87.50 - 108MHz
Effective Sensitivity Less than 14dB/µV
Signal to Noise Ratio More than 46dB
LW Radio
Frequency Range 153 - 279Hz
Effective Sensitivity 43dB/µV
Signal to Noise Ratio More than 42dB
MW Radio
Frequency Range 522 - 1611Hz
Effective Sensitivity 34dB/µV
Signal to Noise Ratio More than 42dB
CQ-TS7420K
AM/FM/RDS MPX ELECTRONIC
TUNING RADIO with 6-Disc CD
Changer
TOYOTA PART No. 86120-0F020
ID CODE : W58811
VEHICLE : Corolla Verso
DESTINATION : Europe
PRODUCED AFTER : Feb. 2004
CD Changer(YGFD13196)
Signal to Noise Ratio More than 65dB
Total Harmonic Distortion Less than 0.3%
Channel Separation More than 70dB
Dimensions** 178×100×136mm(W×H×D)
Weight** 2.7kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
• • •
• Above specifications comply with EIA standards.
Specifications

1 FEATUERS 2
2 SYSTEM DIAGRAM 2
3 VIEW AND CONNECTORS 3
4 WIRING CONNECTION 4
5 BLOCK DIAGRAM 5
6 TERMINALS DESCRIPTION 6
1 FEATUERS
· TOYOTA AVC-LAN
· 10-Pro Tuner Pack
· 24-station preset (18-FM, 6-AM)
· RDS (Radio Data System)
· LCD Module
7 PACKAGE AND IC BLOCK DIAGRAM 7
8 REPLACEMENT PARTS LIST 10
9 EXPLODED VIEW (Unit) 17
10 WIRING DIAGRAM 18
11 SCHEMATIC DIAGRAM 23
12 MEMO 25
· Escutcheon Color : Silver
· The corner of the view is27°
· 6-disc CD changer (in dash board)
· Compatible with Audio CD, CD-R and CD-RW
CONTENTS
Page Page
2 SYSTEM DIAGRAM
2
CQ-TS7420K

3 VIEW AND CONNECTORS
3
CQ-TS7420K

4 WIRING CONNECTION
4
CQ-TS7420K

5 BLOCK DIAGRAM
5
CQ-TS7420K

6.1. Main Block
IC601 : C2CBKH000090
Pin
No. Port Descriptions I/O (V)
FM AM CD
1 BEEP - O 0 0 0
2 NC No connection - - - -
3 NC No connection - - - -
4SW3-5 CD Mute I/O 4.8 4.9 0
5 NC No connection - - - -
6 CD-ON CD.C controller enable O 0 0 4.9
7CD-RESET CD.C reset O 4.9 5.0 5.0
8 CD-SCKM CD.C shift clock O 0 0 4.9
9 CD-SOM CD serial data input I 4.9 4.9 1.5
10 CD-SIM CD serial data output O 4.9 4.9 4.9
11 RESET Reset I 4.9 4.9 5.0
12 XT2(NC) No connection - 3.6 3.6 3.6
13 XT1 Ground I 0 0 0
14 GND Ground - 0 0 0
15 X2 Crystal oscillator
terminal - 1.8 1.8 1.8
16 X1 Crystal oscillator
terminal I 1.5 1.5 1.5
17 REGOFF Ground - 0 0 0
18 REGCPU Capacitor terminal - 3.6 3.6 3.6
19 VDD0 +5V power supply - 4.9 5.0 5.0
20 NC No connection - - - -
21 GREEN Green LED - 0 0 0
22 RED Red LED - 0 0 0
23 NC No connection - - - -
24 MODE Ground I 4.9 4.9 5.0
25 NC No connection - - - -
26 LOAD Loading Detection - 4.9 4.9 4.9
27 MODE-A Mode encoder data O 4.9 4.9 4.9
28 MODE-B Mode encoder data O 4.9 4.9 4.9
29 VOL-A Volume encoder data O 4.9 4.9 4.9
30 VOL-B Volume encoder data O 4.9 4.9 4.9
31 NC No connection - - - -
32 AUDIO-CK Audio clock O 1.5 1.5 1.5
33 AUDIO-INH Audio enable O 4.9 5.0 4.9
34 LCD-SCK LCD serial clock O 0 0 0
35 LCD-DATA LCD serial data I 4.8 4.9 4.8
36 LCD-STB LCD CE data O 0 0 0
37 LCD-REQ LCD data O 0 0 0
38 NC No connection - - - -
39 LCD-RESET LCD Reset O 0 0 0
40 GND Ground - 0 0 0
41 VDD +5V power supply - 4.9 5.0 5.0
42 - - - - - -
43 STBY Stand-by I 4.9 5.0 5.0
44 CCB-DI CCB Data input I 4.8 5.0 4.9
45 CCB-DO CCB Data output O 0.5 0.5 0.5
46 CCB-CL CCB serial clock I 4.8 5.0 4.9
47 CCB-CE CCB chip enable I 0 0 0
48 CCB-RS CCB RS O 4.9 5.0 5.0
49 CCB-BU CCB bus I 0.5 0.5 0.5
50 CCB-CNT CCB control I 4.9 0 0
51 NC No connection - - - -
52 MP - O 4.9 4.9 4.8
53 SD SD signal I 4.9 4.9 4.8
54 PLL-SDA PLL serial data I/O 4.9 4.9 4.9
55 PLL-SCL PLL serial clock O 4.9 5.0 5.0
56 ST FM stereo detection I 4.9 4.9 4.8
57 NC No connection - - - -
58 NK ON/OFF AM noise cancellor on/off - 4.8 0 0
59 NC No connection - - - -
60 TEL MUTE TEL Mute - 4.9 4.9 4.9
61 MUTE Mute - 0 0 0
62 NC No connection - - - -
63 NC No connection - - - -
64 NC No connection - - - -
65 RDS CL RDS clock O 2.4 2.4 2.4
66 RDS DATA RDS data I 2.7 2.7 2.5
Pin
No. Port Descriptions I/O (V)
FM AM CD
67 NC No connection - - - -
68 RDS MUTE RDS Mute O 5.0 5.0 0
69 NC No connection - - - -
70 NC No connection - - - -
71 NC No connection - - - -
72 NC No connection - - - -
73 TEST(FLAS
H VPP) (Ground pull-down) - 0 0 0
74 ACC-IN Temperature sensor - 0 1.4 0
75 VCONT
(VSM) Field intensity detection I 0.6 1.1 0.6
76 MP - I 0 0 0
77 NOISE FM noise detection I 1.4 0 1.4
78 NC No connection - - - -
79 NC No connection - - - -
80 NC No connection - - - -
81 NC No connection - - - -
82 VDD +5V power supply - 5.0 5.0 5.0
83 AVDD +5V power supply - 4.9 4.9 4.9
84 GND
(AVSS) Ground - 0 0 0
85 LAN IN LAN data input I 0 0 0
86 LAN OUT LAN data output O 0 0 0
87 GND Ground - 0 0 0
88 CD EJ CD Eject I 4.9 4.9 4.9
89 NC No connection - - - -
90 PACK(SW) - I 4.9 4.9 0
91 +B-DET Battery detection I 4.9 4.9 4.9
92 ACC-DET ACC detection I 4.9 4.9 4.9
93 RESET 4.2 - I 4.9 4.9 4.9
94 TSO(SUBC) CD text serial data input I 0 0 0
95 SO Serial data output O 0 0 0
96 TSI CD text serial data output O 0 0 0
97 TCK(SBCK) CD text serial clock O 0 0 0
98 TSTB CD text TSTB No I 0 0 0
99 NC No connection - - - -
100 NC No connection - - - -
6 TERMINALS DESCRIPTION
6
CQ-TS7420K

7 PACKAGE AND IC BLOCK DIAGRAM
7.1. Main Block
IC141 : C1EB00000061
IC181 : YEAMHA12181F
7
CQ-TS7420K

IC231 : C1BA00000345
IC651,652 : C1EB00000001
IC653 : C1EB00000017
IC201 : C2HBZF000007
8
CQ-TS7420K

IC701 : C0DBZHZ00020
IC703 : C0CBABC00138
IC704 : AN31910A-NF
IC706 : C0EBE0000174
9
CQ-TS7420K

8 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No. Part No. Part Name & Description Remarks
[E6931] Main Block
IC´s AND TRANSISTORs
IC141 C1EB00000061 IC
IC150 C0ABCB000032 IC
IC181 YEAMHA12181F IC
IC201 C2HBZF000007 IC
IC211 C0ABCB000038 IC
IC231 C1BA00000345 IC
IC501 YEAMT7ST00UL IC
IC601 C2CBKH000090 IC
IC651 C1EB00000001 IC
IC652 C1EB00000001 IC
IC653 C1EB00000017 IC
IC701 C0DBZHZ00020 IC
IC702 C0DBFHZ00001 IC
IC703 C0CBABC00138 IC
IC704 AN31910A-NF IC
IC706 C0EBE0000174 IC
IC707 C0JBAA000102 IC
IC801 C2CBJH000065 IC
IC802 B1GHCFJN0003 Transistor
PA101 YEP0PTB566B0 Electronic Tuner
Q110 B1GDCFNN0007 Transistor
Q121 YEANC323TUTX Transistor
Q131 YEANC323TUTX Transistor
Q143 B1GBCFGN0001 Transistor
Q151 B1ABCF000044 Transistor
Q152 B1ABCF000044 Transistor
Q504 B1BBCD000001 Transistor
Q552 YEAN2SK3018T Transistor
Q562 YEAN2SK3018T Transistor
Q642 B1GKCFNN0006 Transistor
Q651 B1GBCFNN0004 Transistor
Q701 YEAN2SA1757 Transistor
Q703 YEAN2SA1757 Transistor
Q707 YEAN2SA1757 Transistor
Q710 B1BBCD000001 Transistor
Q713 B1GDCFGN0001 Transistor
Q714 B1GBCFNN0009 Transistor
Q720 B1BBAF000005 Transistor
Q723 YEAN2SA1757 Transistor
Q731 2SB1073TX Transistor
Q751 B1GBCFNN0009 Transistor
Q767 YEANC114YKX Transistor
Q801 YEAN2SK1133T Transistor
Q803 YEANC114YKX Transistor
Ref.
No. Part No. Part Name & Description Remarks
Q804 YEANC114YKX Transistor
DIODEs
D101 B0ADDJ000007 Diode
D110 B0ACCK000005 Diode
D141 MA153TX Diode
D142 MA153TX Diode
D501 B0BC8R200012 Diode
D502 B0ADDJ000006 Diode
D601 B0ADDJ000006 Diode
D641 B0ACCK000005 Diode
D643 B0ACCK000005 Diode
D644 B0ACCK000005 Diode
D651 YEADRD18M2T1 Diode
D652 YEADRD18M2T1 Diode
D653 YEADRD18M2T1 Diode
D654 YEADRD18M2T1 Diode
D655 YEADRD13P2T1 Diode
D656 YEADRD13P2T1 Diode
D658 B0ACCK000005 Diode
D701 B0BC02700005 Diode
D703 YEADRB051L40 Diode
D705 B0BC3R900023 Diode
D706 B0BC9R600001 Diode
D712 B0ADDJ000007 Diode
D713 B0ACCK000005 Diode
D751 B0BC6R800004 Diode
D760 B0ADDJ000008 Diode
D761 B0ADDJ000008 Diode
D762 B0ADDJ000006 Diode
D800 B0ACCK000005 Diode
D801 B0ACCK000005 Diode
D802 B0ACCK000005 Diode
D803 B0ACCK000005 Diode
CAPACITORs
C50 YECUZ1H102KX Ceramic, 1000PF 50WV
C51 F1J1H102A394 Ceramic, 1000PF 50WV
C52 F1J1H471A390 Ceramic, 470PF 50WV
C101 YECUS1C154KX Ceramic, 0.15µF 16WV
C102 YECUS1E223KX Ceramic, 0.022µF 25WV
C103 YECUZ1E223KX Ceramic, 0.022µF 25WV
C104 ECEA1AKA101I Electrolytic, 100µF 10WV
C107 ECEA1CKA100I Electrolytic, 10µF 16WV
C109 F1H1A1050019 Ceramic, 1µF 10WV
C110 ECEA1HKAR22I Electrolytic, 0.22µF 50WV
C111 YECUS1E223KX Ceramic, 0.022µF 25WV
C112 YECUS1E223KX Ceramic, 0.022µF 25WV
C115 EEUFC1A221B Electrolytic, 220µF 10WV
C118 ECEA1HKA010I Electrolytic, 1µF 50WV
C119 YECUZ1H103KX Ceramic, 0.01µF 50WV
C120 F1J1H471A665 Ceramic, 470PF 50WV
C121 F1J1H333A395 Ceramic, 0.033µF 50WV
C123 YECUS1A105KX Ceramic, 1µF 10WV
C131 F1J1H333A395 Ceramic, 0.033µF 50WV
C133 YECUS1A105KX Ceramic, 1µF 10WV
C141 F1J1H331A665 Ceramic, 330PF 50WV
C142 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C143 F1J1H271A672 Ceramic, 270PF 50WV
C144 YECUZ1H103KX Ceramic, 0.01µF 50WV
C145 F1J1H561A672 Ceramic, 560PF 50WV
C146 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C147 F1J1H103A513 Ceramic, 0.01µF 50WV
C148 YECUS1H470JC Ceramic, 47PF 50WV
C149 F1J1H560A025 Ceramic, 56PF 50WV
C150 F1J1H122A675 Ceramic, 1200PF 50WV
C151 F1J1H152A675 Ceramic, 1500PF 50WV
C152 F1J1H103A513 Ceramic, 0.01µF 50WV
C153 ECEA1HKA4R7I Electrolytic, 4.7µF 50WV
C154 F1J1H151A672 Ceramic, 150PF 50WV
C155 YECUZ1H151JC Ceramic, 150PF 50WV
10
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
C156 F1J1H151A672 Ceramic, 150PF 50WV
C157 F1J1H151A672 Ceramic, 150PF 50WV
C158 F1J1H1020024 Ceramic, 1000PF 50WV
C159 YECUS1H100CC Ceramic, 10PF 50WV
C160 F1J1H1020024 Ceramic, 1000PF 50WV
C161 YECUS1E223KX Ceramic, 0.022µF 25WV
C162 ECEA1CKA100I Electrolytic, 10µF 16WV
C178 ECEA1AKA101I Electrolytic, 100µF 10WV
C180 YECUZ1H103KX Ceramic, 0.01µF 50WV
C181 F1H1H123A783 Ceramic, 0.012µF 50WV
C182 YECUS1E333KX Ceramic, 0.033µF 25WV
C183 YECUS1E333KX Ceramic, 0.033µF 25WV
C184 YECUS1C683KX Ceramic, 0.068µF 16WV
C186 ECEA1HKA3R3I Electrolytic, 3.3µF 50WV
C187 YECUZ1E183KX Ceramic, 0.018µF 25WV
C188 YECUS1E333KX Ceramic, 0.033µF 25WV
C189 YECUS1C224KX Ceramic, 0.22µF 16WV
C190 F1H1E103A011 Ceramic, 0.01µF 25WV
C191 F1J1H562A675 Ceramic, 5600PF 50WV
C192 YECUS1E333KX Ceramic, 0.033µF 25WV
C196 YECUZ1H102KX Ceramic, 1000PF 50WV
C201 F1J1E1050004 Ceramic, 1µF 25WV
C202 F1J1C1050013 Ceramic, 1µF 16WV
C203 YECUS1E104ZF Ceramic, 0.1µF 25WV
C204 F1J1C1050013 Ceramic, 1µF 16WV
C205 F1J1C1050013 Ceramic, 1µF 16WV
C206 F1H1H152A201 Ceramic, 1500PF 50WV
C207 ECEA1HSN2R2I Electrolytic, 2.2µF 50WV
C208 ECEA1HSN2R2I Electrolytic, 2.2µF 50WV
C209 F1H1H180A231 Ceramic, 18PF 50WV
C210 F1H1H180A231 Ceramic, 18PF 50WV
C213 F1H1H821A190 Ceramic, 820PF 50WV
C215 F1H1H821A190 Ceramic, 820PF 50WV
C219 ECEA1HSNR33I Electrolytic, 0.33µF 50WV
C220 ECEA1HSNR33I Electrolytic, 0.33µF 50WV
C221 YECUZ1H221JC Ceramic, 220PF 50WV
C222 YECUZ1H221JC Ceramic, 220PF 50WV
C225 F1J1E2240009 Ceramic, 0.22µF 25WV
C226 F1J1E2240009 Ceramic, 0.22µF 25WV
C227 F1J1E2240009 Ceramic, 0.22µF 25WV
C228 F1J1E2240009 Ceramic, 0.22µF 25WV
C229 YECUZ1H102KX Ceramic, 1000PF 50WV
C230 F1H1E4730007 Ceramic, 0.047µF 25WV
C231 ECEA1CKA100I Electrolytic, 10µF 16WV
C233 YECUZ1C104KX Ceramic, 0.1µF 16WV
C270 ECA1AM221B Electrolytic, 220µF 10WV
C271 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C272 ECEA1CKA100I Electrolytic, 10µF 16WV
C273 YECUS1E104ZF Ceramic, 0.1µF 25WV
C274 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C275 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C276 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C277 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C278 YECUS1E104ZF Ceramic, 0.1µF 25WV
C279 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C280 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C281 F1H1H100A226 Ceramic, 10PF 50WV
C282 F1H1H100A226 Ceramic, 10PF 50WV
C283 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C284 YECUS1E104ZF Ceramic, 0.1µF 25WV
C285 YECUS1E104ZF Ceramic, 0.1µF 25WV
C289 YECUS1E104ZF Ceramic, 0.1µF 25WV
C290 ECEA1CKA100I Electrolytic, 10µF 16WV
C291 YECUS1E104ZF Ceramic, 0.1µF 25WV
C292 YECUS1E104ZF Ceramic, 0.1µF 25WV
C293 YECUS1E104ZF Ceramic, 0.1µF 25WV
C294 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C295 ECEA1CKA100I Electrolytic, 10µF 16WV
C296 YECUS1E104ZF Ceramic, 0.1µF 25WV
C297 YECUS1E104ZF Ceramic, 0.1µF 25WV
C298 YECUS1E104ZF Ceramic, 0.1µF 25WV
C299 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C300 YECUZ1H102KX Ceramic, 1000PF 50WV
Ref.
No. Part No. Part Name & Description Remarks
C301 F1J1E1050004 Ceramic, 1µF 25WV
C302 F1J1C1050013 Ceramic, 1µF 16WV
C304 F1J1C1050013 Ceramic, 1µF 16WV
C305 F1J1C1050013 Ceramic, 1µF 16WV
C306 F1H1H152A201 Ceramic, 1500PF 50WV
C307 ECEA1HSN2R2I Electrolytic, 2.2µF 50WV
C308 ECEA1HSN2R2I Electrolytic, 2.2µF 50WV
C309 F1H1H180A231 Ceramic, 18PF 50WV
C310 F1H1H180A231 Ceramic, 18PF 50WV
C313 F1H1H821A190 Ceramic, 820PF 50WV
C315 F1H1H821A190 Ceramic, 820PF 50WV
C319 ECEA1HSNR33I Electrolytic, 0.33µF 50WV
C320 ECEA1HSNR33I Electrolytic, 0.33µF 50WV
C321 YECUZ1H221JC Ceramic, 220PF 50WV
C322 YECUZ1H221JC Ceramic, 220PF 50WV
C325 F1J1E2240009 Ceramic, 0.22µF 25WV
C326 F1J1E2240009 Ceramic, 0.22µF 25WV
C327 F1J1E2240009 Ceramic, 0.22µF 25WV
C328 F1J1E2240009 Ceramic, 0.22µF 25WV
C363 YECUZ1C104KX Ceramic, 0.1µF 16WV
C502 YECUZ1H102KX Ceramic, 1000PF 50WV
C521 YECUZ1H271JC Ceramic, 270PF 50WV
C522 YECUZ1H271JC Ceramic, 270PF 50WV
C531 YECUZ1H271JC Ceramic, 270PF 50WV
C532 YECUZ1H271JC Ceramic, 270PF 50WV
C600 YECUS1E104ZF Ceramic, 0.1µF 25WV
C602 F1J1C1050013 Ceramic, 1µF 16WV
C603 F1H1H180A231 Ceramic, 18PF 50WV
C604 F1H1H180A231 Ceramic, 18PF 50WV
C607 F1J1H103A700 Ceramic, 0.01µF 50WV
C609 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C611 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C612 YECUS1E104ZF Ceramic, 0.1µF 25WV
C614 F1J1H103A700 Ceramic, 0.01µF 50WV
C615 F1J1H103A700 Ceramic, 0.01µF 50WV
C640 ECEA1HKAR47I Electrolytic, 0.47µF 50WV
C641 F1J1H103A513 Ceramic, 0.01µF 50WV
C644 YECUS1C104KX Ceramic, 0.1µF 16WV
C651 F1J1H103A700 Ceramic, 0.01µF 50WV
C653 YECUS1H820JM Ceramic, 82PF 50WV
C654 YECUS1H820JM Ceramic, 82PF 50WV
C655 YECUS1H103ZF Ceramic, 0.01µF 50WV
C656 YECUS1C104KX Ceramic, 0.1µF 16WV
C657 F1J1H221A665 Ceramic, 220PF 50WV
C701 ECA1CM222B Electrolytic, 2200µF 16WV
C702 ECA1CM222B Electrolytic, 2200µF 16WV
C703 ECEA1CKA100I Electrolytic, 10µF 16WV
C704 F1J1H102A394 Ceramic, 1000PF 50WV
C705 ECEA1CKA100I Electrolytic, 10µF 16WV
C707 F2A1C2220064 Electrolytic, 2200µF 16WV
C708 ECA1CHG102B Electrolytic, 1000µF 16WV
C709 ECEA0JKA101I Electrolytic, 100µF 6.3WV
C710 ECEA1CKA100I Electrolytic, 10µF 16WV
C711 F1J1H103A700 Ceramic, 0.01µF 50WV
C712 YECUZ1E223KX Ceramic, 0.022µF 25WV
C713 EEAFC0J121H Electrolytic, 120µF 6.3WV
C714 F1H1E103A011 Ceramic, 0.01µF 25WV
C715 YECUZ1H102KX Ceramic, 1000PF 50WV
C716 ECA1CM100I Electrolytic, 10µF 16WV
C719 YECUS1C104KX Ceramic, 0.1µF 16WV
C720 YECUZ1H102KX Ceramic, 1000PF 50WV
C721 YECUS1C104KX Ceramic, 0.1µF 16WV
C725 YECUZ1H103KX Ceramic, 0.01µF 50WV
C727 YECUB1H104KX Ceramic, 0.1µF 50WV
C728 YECUB1H104KX Ceramic, 0.1µF 50WV
C738 ECA1AM221B Electrolytic, 220µF 10WV
C747 YECUZ1E223KX Ceramic, 0.022µF 25WV
C750 ECA1CM101I Electrolytic, 100µF 16WV
C751 F1J1H103A700 Ceramic, 0.01µF 50WV
C756 YECUZ1C104KX Ceramic, 0.1µF 16WV
C757 YECUZ1C104KX Ceramic, 0.1µF 16WV
C760 YECUS1C104KX Ceramic, 0.1µF 16WV
C772 ECEA1HKAR22I Electrolytic, 0.22µF 50WV
11
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
C773 ECEA1HKAR22I Electrolytic, 0.22µF 50WV
C774 YECUS1C104KX Ceramic, 0.1µF 16WV
C776 F1J1H221A665 Ceramic, 220PF 50WV
C777 F1J1H221A665 Ceramic, 220PF 50WV
C778 YECUS2A103KX Ceramic, 0.01µF 100WV
C779 F1H1H2220005 Ceramic, 2200PF 50WV
C780 F1J1H221A665 Ceramic, 220PF 50WV
C781 F1J1H221A665 Ceramic, 220PF 50WV
C782 YECUS1H820JM Ceramic, 82PF 50WV
C783 YECUS1H820JM Ceramic, 82PF 50WV
C788 YECUZ1H103KX Ceramic, 0.01µF 50WV
C789 F1H1H2220005 Ceramic, 2200PF 50WV
C790 YECUS1C823KX Ceramic, 0.082µF 16WV
C791 YECUZ1E223KX Ceramic, 0.022µF 25WV
C792 F1J1C1050013 Ceramic, 1µF 16WV
C793 YECUZ1C104KX Ceramic, 0.1µF 16WV
C794 YECUZ1H102KX Ceramic, 1000PF 50WV
C795 F1J1C1050013 Ceramic, 1µF 16WV
C796 YECUZ1C104KX Ceramic, 0.1µF 16WV
C797 YECUZ1H103KX Ceramic, 0.01µF 50WV
C798 F1J1H103A700 Ceramic, 0.01µF 50WV
C800 ECA1AM221B Electrolytic, 220µF 10WV
C803 YECUZ1H220JC Ceramic, 22PF 50WV
C804 YECUZ1H220JC Ceramic, 22PF 50WV
C805 YECUZ1C104KX Ceramic, 0.1µF 16WV
C806 YECUS1C104KX Ceramic, 0.1µF 16WV
C807 YECUS1C104KX Ceramic, 0.1µF 16WV
C808 YECUZ1H102KX Ceramic, 1000PF 50WV
C809 YECUS1C104KX Ceramic, 0.1µF 16WV
C810 F1J1H103A700 Ceramic, 0.01µF 50WV
C811 YECUS1H100CC Ceramic, 10PF 50WV
C812 F1H1E103A011 Ceramic, 0.01µF 25WV
C814 YECUS1C104KX Ceramic, 0.1µF 16WV
C816 F1J1H103A700 Ceramic, 0.01µF 50WV
C841 F1H1C473A005 Ceramic, 0.047µF 16WV
C842 YECUZ1C104KX Ceramic, 0.1µF 16WV
C844 YECUZ1H221JC Ceramic, 220PF 50WV
C845 YECUZ1H221JC Ceramic, 220PF 50WV
C846 F1J1H221A665 Ceramic, 220PF 50WV
C847 F1J1H221A665 Ceramic, 220PF 50WV
RESISTORs
C211 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C212 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C288 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C311 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C312 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C605 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
L2 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L140 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L500 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L502 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L504 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
L512 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L521 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L531 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
L710 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R101 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R102 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R110 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω1/16W
R111 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R122 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R123 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R124 ERJ3GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω1/16W
R132 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R133 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R134 ERJ3GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω1/16W
R140 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R142 ERJ6GEYJ334 Chip, 330kΩ
ΩΩ
Ω1/10W
R145 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R147 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R148 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
Ref.
No. Part No. Part Name & Description Remarks
R150 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R151 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R152 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R153 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R154 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R155 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R156 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R157 ERJ3GEYJ183V Chip, 18kΩ
ΩΩ
Ω1/16W
R158 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R159 ERJ3GEYJ393V Chip, 39kΩ
ΩΩ
Ω1/16W
R160 ERJ6GEYJ393 Chip, 39kΩ
ΩΩ
Ω1/10W
R161 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R162 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R163 ERJ6GEYJ393 Chip, 39kΩ
ΩΩ
Ω1/10W
R164 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R165 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R166 ERJ6GEYJ224 Chip, 220kΩ
ΩΩ
Ω1/10W
R167 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R168 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R169 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R184 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R187 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω1/16W
R189 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R190 ERJ6GEYJ184 Chip, 180kΩ
ΩΩ
Ω1/10W
R194 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R195 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R196 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω1/16W
R197 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R200 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R204 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R205 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R206 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R207 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R209 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R210 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R211 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R212 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R213 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R216 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R217 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R218 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R219 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R220 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R221 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R222 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R225 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R226 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R227 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R228 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R229 ERJ3GEYJ471V Chip, 470Ω
ΩΩ
Ω1/16W
R230 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R251 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R252 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R253 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R254 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R255 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R256 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R271 ERJ6GEYJ221V Chip, 220Ω
ΩΩ
Ω1/10W
R272 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R274 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R276 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R281 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R304 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R305 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R306 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R307 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R309 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R310 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R311 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R312 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R313 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R316 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/16W
R317 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
12
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
R318 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R319 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R320 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R321 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R322 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R325 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R326 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R327 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R328 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R351 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R352 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R353 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R354 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R355 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R356 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R504 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R505 ERJ3GEYJ561V Chip, 560Ω
ΩΩ
Ω1/16W
R513 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R515 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω1/16W
R516 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω1/16W
R521 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R522 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R531 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R532 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R600 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R602 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R604 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R605 ERJ3GEYJ221V Chip, 220Ω
ΩΩ
Ω1/16W
R607 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R610 ERJ3GEYJ274V Chip, 270kΩ
ΩΩ
Ω1/16W
R615 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R618 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω1/16W
R619 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R620 ERJ6GEYJ474 Chip, 470kΩ
ΩΩ
Ω1/10W
R621 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R622 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R623 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R625 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R628 ERJ3GEYJ101V Chip, 100Ω
ΩΩ
Ω1/16W
R630 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R631 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R633 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R635 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R636 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R638 ERJ3GEYJ101V Chip, 100Ω
ΩΩ
Ω1/16W
R639 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R641 ERJ3GEYJ563V Chip, 56kΩ
ΩΩ
Ω1/16W
R643 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R644 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R646 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R648 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R650 ERG1SJ680E Metal Oxid, 68Ω
ΩΩ
Ω1W
R651 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R652 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R653 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R654 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R655 ERG1SJ101E Metal Oxid, 100Ω
ΩΩ
Ω1W
R656 ERG1SJ101E Metal Oxid, 100Ω
ΩΩ
Ω1W
R657 ERJ6GEYJ271 Chip, 270Ω
ΩΩ
Ω1/10W
R658 ERJ6GEYJ391 Chip, 390Ω
ΩΩ
Ω1/10W
R659 ERJ6GEYJ391 Chip, 390Ω
ΩΩ
Ω1/10W
R660 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R661 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R662 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R696 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R703 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R704 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R705 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R706 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R707 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R711 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R712 ERJ6RED274V Metal Film, 270kΩ
ΩΩ
Ω1/10W
R716 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
Ref.
No. Part No. Part Name & Description Remarks
R717 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
R718 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R720 ERJ3GEYJ471V Chip, 470Ω
ΩΩ
Ω1/16W
R727 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R728 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R729 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R730 ERJ6GEYJ680 Chip, 68Ω
ΩΩ
Ω1/10W
R741 ERJ6GEYJ1R0V Chip, 1Ω
ΩΩ
Ω1/10W
R742 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R744 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R750 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω1/16W
R751 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R753 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R758 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R760 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R761 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R762 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R763 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R764 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R765 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R766 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R767 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R788 ERJ3RED274V Metal Film, 270kΩ
ΩΩ
Ω1/16W
R789 ERJ3RBD332V Metal Glaze, 3.3kΩ
ΩΩ
Ω1/16W
R790 ERJ3RBD392V Metal Glaze, 3.9kΩ
ΩΩ
Ω1/16W
R792 ERJ3RBD223V Metal Glaze, 22kΩ
ΩΩ
Ω1/16W
R793 ERJ6RBD393V Metal Film, 39kΩ
ΩΩ
Ω1/10W
R794 YER816R4702D Metal Glaze, 47kΩ
ΩΩ
Ω1/16W
R795 YER816R4702D Metal Glaze, 47kΩ
ΩΩ
Ω1/16W
R796 D1BB15030001 Metal Film, 150kΩ
ΩΩ
Ω1/16W
R797 ERJ3RBD104V Metal Glaze, 100kΩ
ΩΩ
Ω1/16W
R798 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R799 ERJ3RBD223V Metal Glaze, 22kΩ
ΩΩ
Ω1/16W
R801 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R803 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R804 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R807 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R810 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R811 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R819 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R820 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R823 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R825 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R826 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R827 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R828 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R830 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R833 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R834 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R836 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R840 YER816R4702D Metal Glaze, 47kΩ
ΩΩ
Ω1/16W
R841 ERJ3GEYJ471V Chip, 470Ω
ΩΩ
Ω1/16W
R843 ERJ3RED274V Metal Film, 270kΩ
ΩΩ
Ω1/16W
R846 ERJ6GEYJ152 Chip, 1.5kΩ
ΩΩ
Ω1/10W
R854 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R855 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R861 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R863 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R864 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R865 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R868 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R873 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R895 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
CONNECTORs
CN501 YEAE012763 Connector, 14P
CN502 K1MN06B00129 Connector, 6P
CN600 K1MN10B00062 Connector, 10P
CN602 YEAEBM07BSRS Connector, 7P
CN701 K1FA116B0023 Connector, 10P+6P
CN702 K1FA112B0017 Connector, 12P
CN703 K1FA120B0009 Connector, 20P
13
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
CN704 K1FA108B0011 Connector, 8P
CN801 K1MN20A00020 Connector, 20P
CN901 K1KA12B00105 Connector, 12P
CN902 K1KA12B00105 Connector, 12P
COILs
L1 J0JCC0000030 Coil
L143 YELT03N220JT Coil
L144 YELTBLM2A102 Coil
L151 J0JCC0000030 Coil
L191 YELTBLM21A10 Coil
L271 J0JCC0000053 Coil
L272 J0JCC0000053 Coil
L273 J0JCC0000053 Coil
L274 YELTBLM2B601 Coil
L275 J0JCC0000053 Coil
L276 G1C220K00010 Coil
L277 J0JAC0000013 Coil
L278 J0JAC0000013 Coil
L279 J0JAC0000013 Coil
L513 J0JCC0000030 Coil
L601 YELTBLM21A10 Coil
L602 YELTBLM21A10 Coil
L603 YELTBLM21A10 Coil
L604 YELTBLM21A10 Coil
L640 YELTBLM2B222 Coil
L701 G0A111J00003 Coil
L751 YELTBLM32A06 Coil
L752 YELTBLM21A10 Coil
L801 YELT03N100KT Coil
L803 J0JCC0000030 Coil
L804 J0JCC0000030 Coil
L805 J0JCC0000030 Coil
L806 J0JCC0000030 Coil
L841 YELT03N100KT Coil
R208 YELTBLM2B601 Coil
CRYSTALs
XL140 YEXL49U0433T Crystal Oscillator
XL271 H0D168500001 Crystal Oscillator
XL601 H0D123500002 Crystal Oscillator
XL802 YEXL5F10000T Crystal Oscillator
NETWORK RESISTORs
R103 D1H84724A024 Network Resistor
R273 D1H410320002 Network Resistor
R277 D1H81024A024 Network Resistor
R506 D1H856140002 Network Resistor
R507 D1H83324A024 Network Resistor
R552 D1H410220001 Network Resistor
R553 D1H456320001 Network Resistor
R601 D1H82224A024 Network Resistor
R603 D1H84724A024 Network Resistor
R608 D1H422220001 Network Resistor
R609 D1H82224A024 Network Resistor
R612 D1H82224A024 Network Resistor
R613 D1H81024A024 Network Resistor
R614 D1H81024A024 Network Resistor
R616 D1H81024A024 Network Resistor
R617 D1H410220001 Network Resistor
R624 D1H81024A024 Network Resistor
R626 D1H81024A024 Network Resistor
R627 D1H81024A024 Network Resistor
R629 D1H410220001 Network Resistor
R632 D1H81024A024 Network Resistor
R647 D1H410220001 Network Resistor
R802 D1H81024A024 Network Resistor
R816 D1H81024A024 Network Resistor
R821 D1H81024A024 Network Resistor
R822 D1H84724A024 Network Resistor
Ref.
No. Part No. Part Name & Description Remarks
R835 D1H410220001 Network Resistor
R851 EXBV8V102JV Network Resistor
R856 D1H81024A024 Network Resistor
R857 D1H847340001 Network Resistor
R867 D1H81024A024 Network Resistor
R874 D1H410220001 Network Resistor
R883 D1H81024A024 Network Resistor
R888 D1H410220001 Network Resistor
R890 D1H410220001 Network Resistor
R892 D1H410220001 Network Resistor
R899 D1H410220001 Network Resistor
FILTERs
BPF51 YEXC07T009 Filter
Z53 J0LM00000001 Noise Filter
ZL655 YECCL51R206T EMI Filter
ZL656 YECCL51R206T EMI Filter
[E9266] Display/Volume/Tuner Block
IC´s AND TRANSISTORs
Q970 B1GBCFGN0004 Transistor
DIODEs
D900 B3ABB0000171 Diode
D903 B3ABB0000171 Diode
D905 B3ABB0000171 Diode
D908 B3ABB0000171 Diode
D910 B3ABB0000171 Diode
D913 B3ABB0000171 Diode
D915 B3ABB0000171 Diode
D918 B3ABB0000171 Diode
D920 B3ABB0000171 Diode
D921 B3ABB0000171 Diode
D922 B3ABB0000171 Diode
D925 B3ABB0000171 Diode
D926 B3ABB0000171 Diode
D927 B3ABB0000171 Diode
D930 B3ABB0000171 Diode
D931 B3ABB0000171 Diode
D932 B3ABB0000171 Diode
D933 B3ABB0000171 Diode
D936 B3ABB0000171 Diode
D937 B3ABB0000171 Diode
D938 B3ABB0000171 Diode
D940 B3ABB0000171 Diode
D941 B3ABB0000171 Diode
D942 B3ABB0000171 Diode
D943 B3ABB0000171 Diode
D945 B3ABB0000171 Diode
D946 B3ABB0000171 Diode
D947 B3ABB0000171 Diode
D948 B3ABB0000171 Diode
D951 B3ABB0000171 Diode
D952 B3ABB0000171 Diode
D953 B3ABB0000171 Diode
D954 B3ABB0000171 Diode
D961 B3ABB0000171 Diode
D962 B3ABB0000171 Diode
D963 B3ABB0000171 Diode
D964 B3ABB0000171 Diode
D965 B3ABB0000171 Diode
D966 B3ABB0000171 Diode
D967 B3ABB0000171 Diode
D968 B3ABB0000171 Diode
D970 YEADSEC2484C Diode
D971 YEADSEC2484C Diode
D991 MA8056LMHTX Diode
D992 MA8056LMHTX Diode
D993 MA8056LMHTX Diode
14
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
D994 MA8056LMHTX Diode
D995 MA8056LMHTX Diode
D996 MA8056LMHTX Diode
D997 MA8056LMHTX Diode
D998 MA8056LMHTX Diode
D999 MA8056LMHTX Diode
CAPACITORs
C901 YECUZ1H221JC Ceramic, 220PF 50WV
C902 YECUZ1H221JC Ceramic, 220PF 50WV
C903 YECUZ1H221JC Ceramic, 220PF 50WV
C904 YECUZ1H221JC Ceramic, 220PF 50WV
C951 F1J1H103A513 Ceramic, 0.01µF 50WV
C953 F1J1H103A513 Ceramic, 0.01µF 50WV
C990 F1H1E103A011 Ceramic, 0.01µF 25WV
C991 F1H1E103A011 Ceramic, 0.01µF 25WV
C992 F1H1E103A011 Ceramic, 0.01µF 25WV
C993 F1H1E103A011 Ceramic, 0.01µF 25WV
C994 F1H1E103A011 Ceramic, 0.01µF 25WV
C995 YECUZ1H221JC Ceramic, 220PF 50WV
C996 YECUZ1H221JC Ceramic, 220PF 50WV
C997 YECUZ1H221JC Ceramic, 220PF 50WV
C998 YECUZ1H221JC Ceramic, 220PF 50WV
C999 YECUZ1H221JC Ceramic, 220PF 50WV
RESISTORs
R900 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R903 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R905 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R908 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R910 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R913 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R915 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R918 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R920 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R921 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R922 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R925 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R926 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R927 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R931 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R932 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R933 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R936 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R937 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R938 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R940 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R941 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R942 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R943 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R945 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R946 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R947 ERJ6GEYJ751V Chip, 750Ω
ΩΩ
Ω1/10W
R948 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R951 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R952 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R953 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R954 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R961 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R962 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R963 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R964 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R965 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R966 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R967 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R968 ERJ6GEYJ821 Chip, 820Ω
ΩΩ
Ω1/10W
R970 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R971 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R974 ERJ6GEYJ122 Chip, 1.2kΩ
ΩΩ
Ω1/10W
R990 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R991 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
Ref.
No. Part No. Part Name & Description Remarks
R992 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
R993 ERJ8GEYJ331V Chip, 330Ω
ΩΩ
Ω1/8W
CONNECTORs
CN903 K1KB10A00114 Connector, 10P
CN904 K1KB10A00114 Connector, 10P
CP901 YEAETKCF12XE Connector, 12P
CP902 YEAETKCF12XE Connector, 12P
CP903 K1KA10A00369 Connector, 10P
CP904 K1KA10A00369 Connector, 10P
COILs
L991 J0JAC0000013 Coil
L992 J0JAC0000013 Coil
L993 J0JAC0000013 Coil
L994 J0JAC0000013 Coil
L995 J0JAC0000013 Coil
L996 J0JAC0000013 Coil
L997 J0JAC0000013 Coil
L998 J0JAC0000013 Coil
L999 J0JAC0000013 Coil
SWITCHes
SW900 EVQP1905M Switch
SW903 EVQP1905M Switch
SW905 EVQP1905M Switch
SW908 EVQP1905M Switch
SW910 EVQP1905M Switch
SW913 EVQP1905M Switch
SW915 EVQP1905M Switch
SW918 EVQP1905M Switch
SW920 EVQP1D05M Switch
SW921 EVQP1905M Switch
SW922 EVQP1905M Switch
SW926 EVQP1905M Switch
SW927 EVQP1905M Switch
SW930 EVQP1D05M Switch
SW931 EVQP1905M Switch
SW932 EVQP1905M Switch
SW933 EVQP1905M Switch
SW936 EVQP1905M Switch
SW937 EVQP1905M Switch
SW938 EVQP1905M Switch
SW940 EVQP1905M Switch
SW941 EVQP1905M Switch
SW942 EVQP1905M Switch
SW943 EVQP1905M Switch
SW945 EVQP1905M Switch
SW946 EVQP1905M Switch
SW947 EVQP1905M Switch
SW948 EVQP1905M Switch
SW951 EVQP1905M Switch
SW952 EVQP1905M Switch
SW953 EVQP1905M Switch
SW954 EVQP1905M Switch
VARIAVLE RESISTORs
VR901 K0N130C00012 Variablr resistor
VR902 K0N118C00003 Variablr resistor
LCD
LCD1 L5DZAHE00003 LIQUID CRYSTAL DISPLAY
15
CQ-TS7420K

Ref.
No. Part No. Part Name & Description Remarks
Mechanical Parts
MISCELLANEOUS
AE1 K9ZZ00001062 Flat Cable, 20P
AE2 K9ZZ00001061 Flat Cable, 14P
AE3 K9ZZ00001063 Flat Cable, 6P
ANT1 YEAA10091 Antenna Receptacle
AT1 YEAT03346A Terminal
AT2 YEAT03346A Terminal
AT3 YEAT03346A Terminal
1YEFA031909 Upper Cover
2YEFX0216097A Bracket,Deck Front
3YEFX0215255 Fix Earth
4YEFV012250 Insulator, Display Block
6YEFA07638A Front Plate
7YEP0PT6931Y9 Main PCB w/Component RTL
8YEFV03508 Magnetic Shield, PA101
9YEFX0216100 Bracket, ANT1
10 YEFX0216173 Bracket, Q701,703,707,723
11 YEFX0215071 Bracket, IC231
12 YEFF011122 Heat Sink
14 YEP0PT9266Y9 Display, Volume, Tuner PCB
w/Component RTL
15 YEFX9993026 Clip
16 YGFE02458 Knob, Vol, Tuner
17 YGFC027911C Escutcheon Ass´y
19 YEFM031360 Laser Seal
20 YEFA012083A Chassis, Main Block
22 YEFX0216099 Bracket, Rear
23 YEFX9993107A Bracket, Left Side
24 YEFA012085A Bottom Cover
51 YEJS05035 Screw
52 YEJS06303 Screw
53 YEJT01103 Screw
54 YEJT03015 Screw
55 YEJT03289 Tapping Screw
56 YEJT03312 Screw
58 XTB2+6GFX Screw, M2x6
59 XTB3+6FFX Screw, M3x6
16
CQ-TS7420K

9 EXPLODED VIEW (Unit)
17
CQ-TS7420K

10 WIRING DIAGRAM
10.1. Main Block (Top View)
18
CQ-TS7420K

10.2. Main Block (Bottom View)
19
CQ-TS7420K

10.3. Display/Volume/Tuner Block (Top View)
20
CQ-TS7420K
