Toyota CQ-LS7230K User manual
General
Power Supply DC 12V (11V - 16V),
Test Voltage 26.4V
Negative Ground
Current Consumption Less than 3.0A
Power Output 20W×4ch
AM Radio
Frequency Range 531 - 1,602kHz
Usable Sensitivity 30dB(µV) (S/N 20dB)
Signal to Noise Ratio 45dB or more
FM Stereo Radio
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity 7dB/µV (S/N 30dB)
Signal to Noise Ratio 50dB or more
CQ-LS7230K
AM/FM MPX Electronic Tuning Radio
with Stereo Cassette Tape Player
PART No. : 86120-02360
VEHICLE : COROLLA
DESTINATION : INDIA
PRODUCED AFTER : Nov., 2002
Cassette Player
Reproduction System 4-Track, 2-Program Stereo
Tape Speed 4.76cm/sec.
Wow and Flutter Less than 0.09% (WRMS)
Signal to Noise Ratio 40dB or more
Dimensions** 178×50×165mm
Weight** 1.3kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“Dolby” and the double-D symbol are trade marks of Dolby
Laboratories Licensing Corporation.
Specification*
1 FEATUERS 2
2 REAR VIEW AND CONNECTORS 2
3 FRONT VIEW AND FUNCTIONS 3
4 WIRING CONNECTION 4
5 BLOCK DIAGRAM 5
6 TERMINALS DESCRIPTION 6
7 PACKAGE AND IC BLOCK DIAGRAM 7
8 ALIGNMENT INSTRUCTIONS 9
•
• •
• PLL (Phase Locked Loop) synthesized tuning.
•
• •
• 12-station preset (6-AM, 6-FM).
•
• •
• Scan tuning function.
•
• •
• Dolby B NR function.
9 ALIGNMENT POINTS 9
10 REPLACEMENT PARTS LIST 10
11 EXPLODED VIEW (Unit) 14
12 TAPE PLAYER PARTS 15
13 EXPLODED VIEW (Tape Deck) 16
14 WIRING DIAGRAM 17
15 SCHEMATIC DIAGRAM -1 23
16 SCHEMATIC DIAGRAM-2 25
•
• •
• CD changer control.
•
• •
• Electronic volume control.
•
• •
• Fix-Equalizing function.
CONTENTS
Page Page
1 FEATUERS
2 REAR VIEW AND CONNECTORS
2
CQ-LS7230K
3 FRONT VIEW AND FUNCTIONS
3
CQ-LS7230K
5 BLOCK DIAGRAM
5
CQ-LS7230K
6.1. Main Block
IC601 : C2BBGE000647
Pin
No. Port Description I/O (V)
1 LCD-CL Clock for LCD data O 0
2 LCD-DI LCD data O 0
3 SEC TIME No connection - -
4 GND Ground - 0
5 LCD.ON Not used - -
6 ILL.ON Not used - -
7 VDD +5V power supply - 5
8 SEC ON Not used - -
9~12 - Not used - -
13 M1-B Tape main motor control O 0
14 M1-A Tape main motor control O 0
15 - (Connecting tp ground) - 0
16 - (Connecting tp ground) - 0
17 POM SO Not used - -
18 ROM SI Not used - -
19 ROM CS Not used - -
20 ROM CSK Not used - -
21 LATH Data latch O 5
22 A/B Tape FF/REW switch I 0
23 /MTL Metal tape mode O 5
24 DATA Data for system power IC O 0
25 CLK Clock for system power IC O 0
26 STBY System power IC stand-by O 5
27 /MS TPS no sound detection I 0
28 MS PL/FF MS mode selection O 0
29 T.LOAD Tape loading detection I 0
30 /DOLBY Dolby control O 0
31 CAM-A/B Tape side detection I 5
32 /T.IN Tape insert detection I 0
33 GND Ground - 0
34 TE2 Tape end detection I 1.8
35 TE1 Tape end detection I 2.2
36, 37 DIV1,2 Not used - -
38 /M2F Tape solenoid control O 0.5
39 SEC LED Not used - -
40 MSM MS gain control O 0
41 /EQ Metal tape detection I 0
42 BIT3 Tape moe SW I 0
43 BIT2 Tape mode SW I 4.9
44 BIT1 Tape mode SW I 4.9
45 MUTE Mute output O 0
46 BEEP Beep output O 0
47 VOL DAT Data for electronic vol. O 0
48 VOL CLK Clock for electronic vol. O 0
49 NC No connection - -
50 TEST (+5V pull-up) - 4.2
51 MAIN Not used - -
52 PLL.DO PLL data I 4.9
53 PLL.CLK PLL clock O 0
54 PLL.DI PLL data O 0
55 PLL.CE PLL chip enabling O 0
56 LAN-OUT LAN data O 0
57 LAN-IN LAN data I 0.2
58 ST FM stereo detection I 0
59 SD B/S detection I 0
60 /RESET System reset I 3.5
61 /ILL-DET illumi. on detection I 3.5
62 +B-DET Battery level detection I 3.2
63 ACC-DET ACC level detection I 3.4
64 /T.EJECT Tape eject I 3.4
65 AN NK Not used - -
66 MODE B Not used - -
67 MODE A Not used - -
68 VDD +5V power supply - 4.9
69 X1 Crystal oscillatorv terminal - 2.4
70 X2 Crystal oscillatorv terminal - 0.6
71 GND Ground - 0
72 XT2 Not used - -
73 XT1 Not used - -
74 AVDD +5V power supply - 5
75 ACC 5V +5V power supply - 5
76 VSM Not used - -
77 MAIN-VOL Main volume level I 0
78 REO.IN (Ground pull-down) - 0
79 LCD-DO LCD data I 4.9
80 LCD-CE LCD driver enabling O 0
6.2. Display Block
IC601 : YEAMLC75853
Pin
No. Port Description I/O (V)
1-20 SEG1-20 LCD segment data O 2.6
21-28 - Not used - -
29-40 SEG29-40 LCD segment data O 2.6
41-43 COM1-3 LCD common output O 2.6
44 S41 Not used - -
45-49 KS1-6 Key scan signal O 5.2
50 KI1 Not used - -
51-54 KI2-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply - 5.2
57 VDD1 Ground through capacitor - 3.5
58 VDD2 Ground through capacitor - 1.8
59 VSS Ground - 0
60 OSC CR oscillator - 4.1
61 DO key data output O 5.2
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
6 TERMINALS DESCRIPTION
6
CQ-LS7230K
7 PACKAGE AND IC BLOCK DIAGRAM
7.1. Main Block
PA101 : YEP0PTA512B0
IC451 : YEAMLC72135C
7
CQ-LS7230K
IC201 : YEAMM62435FA
IC231 : YEAMTA8251AH
IC631 : YEAMLB1930MT
IC651 : YEAMH12187ER
IC701 : C0DBZHZ00006
8
CQ-LS7230K
IC751 : AN8065SE1
•
• •
• Power Supply Voltage : DC13.2V
•
• •
• Output Impedance : 4Ω
•
• •
• Output Power : 0.5W
•
• •
• Balance, Fader Control : center
•
• •
• Bass, Treble Control : Center
•
• •
• Dolby NR: OFF
8 ALIGNMENT INSTRUCTIONS
8.1. Alignment Conditions
Note :
Do not align the FM/AM package block. When the package block is necessary, it will be supplied already aligned at the
factory.
8.2. Dolby NR Alignment
Step Alignment Item Test Tape VTVM Connection Adjust Remarks
(1) DOLBY NR Rch RFKZ0038 TP201 VR201 Adjust for 388mV ±1.0dB
(2) DOLBY NR Lch RFKZ0038 TP301 VR301 Adjust for 388mV ±1.0dB
9 ALIGNMENT POINTS
9
CQ-LS7230K
10 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No. Part No. Part Name & Description Remarks
[E6876] Main Block
IC´s and TRANSISTORs
IC201 YEAMM62435FA IC
IC231 YEAMTA8251AH IC
IC451 YEAMLC72135C IC
IC601 C2BBGE000647 IC
IC631 YEAMLB1930MT IC
IC651 YEAMH12187ER IC
IC701 C0DBZHZ00006 IC
IC751 AN8065SE1 IC
PA101 YEP0PTA512B0 Electronic Tuner
Q241 YEANA114WKTX Transistor
Q242 B1GBCFNN0004 Transistor
Q701 YEAN2SA1757 Transistor
Q702 YEANHQ1F3PT1 Transistor
Q751 B1GBCFNN0004 Transistor
Q761 B1BBAC000007 Transistor
Q763 B1GDCFJN0004 Transistor
Q765 B1BBAC000007 Transistor
Q766 B1GDCFJN0004 Transistor
DIODEs
D201 YEADRD39M2T2 Diode
D241 B0ACCK000005 Diode
D242 B0ACCK000005 Diode
D243 B0ACCK000005 Diode
D631 MA152WATX Diode
D632 YEADSR1544TL Diode
D633 YEADSR1544TL Diode
D651 YEADRD56M2T1 Diode
D652 YEADRD56M2T1 Diode
D701 YEAD30D2FC6 Diode
D702 YEADRB051L40 Diode
D712 YEADSR1544TL Diode
D761 YEADRD91M1T2 Diode
D762 MA3068MTX Diode
CAPACITORs
C50 YECUS1H102KX Ceramic, 1000PF 50WV
C101 YECUS1E223KX Ceramic, 0.022µF 25WV
C102 F2A1A221A146 Electrolytic, 220µF 10WV
C103 YECUS1C154KX Ceramic, 0.15µF 16WV
C104 YECUS1C823KX Ceramic, 0.082µF 16WV
C105 F2A1C100A150 Electrolytic, 10µF 16WV
Ref.
No. Part No. Part Name & Description Remarks
C107 YECUS1E223KX Ceramic, 0.022µF 25WV
C108 YECUS1H153KX Ceramic, 0.015µF 50WV
C121 YECUS1H183KX Ceramic, 0.018µF 50WV
C124 YECUS1E273KX Ceramic, 0.027µF 25WV
C131 YECUS1H183KX Ceramic, 0.018µF 50WV
C134 YECUS1E273KX Ceramic, 0.027µF 25WV
C151 F2A1A221A146 Electrolytic, 220µF 10WV
C152 YECUS1H471JM Ceramic, 470PF 50WV
C153 YECUS1H471JM Ceramic, 470PF 50WV
C154 YECUS1E223KX Ceramic, 0.022µF 25WV
C155 YECUS1H103KX Ceramic, 0.01µF 50WV
C157 YECUS1E223KX Ceramic, 0.022µF 25WV
C158 YECUS1E223KX Ceramic, 0.022µF 25WV
C201 F1J1C184A006 Ceramic, 0.18µF 16WV
C202 YECUS1C683KX Ceramic, 0.068µF 16WV
C203 YECUS1C683KX Ceramic, 0.068µF 16WV
C204 YECUS1H103KX Ceramic, 0.01µF 50WV
C205 YECUS1A105KX Ceramic, 1µF 10WV
C206 YECUS1E223KX Ceramic, 0.022µF 25WV
C207 YECUS1H561JM Ceramic, 560PF 50WV
C208 YECUS1A105KX Ceramic, 1µF 10WV
C211 YECUS1A105KX Ceramic, 1µF 10WV
C212 YECUS1A105KX Ceramic, 1µF 10WV
C221 YECUV1C224KX Ceramic, 0.22µF 16WV
C222 YECUV1C224KX Ceramic, 0.22µF 16WV
C230 F2A1C470A150 Electrolytic, 47µF 16WV
C231 YECUV1C124KX Ceramic, 0.12µF 16WV
C232 YECUV1C124KX Ceramic, 0.12µF 16WV
C233 YECUV1C124KX Ceramic, 0.12µF 16WV
C234 YECUV1C124KX Ceramic, 0.12µF 16WV
C243 F2A1H1R0A154 Electrolytic, 1µF 50WV
C261 F2A1A101A144 Electrolytic, 100µF 10WV
C262 YECUS1H103KX Ceramic, 0.01µF 50WV
C263 YECUS1H103KX Ceramic, 0.01µF 50WV
C264 F2A1C470A150 Electrolytic, 47µF 16WV
C265 F2A0J331A164 Electrolytic, 330µF 6.3WV
C266 YECUS1H103KX Ceramic, 0.01µF 50WV
C278 YECUS1A105KX Ceramic, 1µF 10WV
C279 YECUS1A105KX Ceramic, 1µF 10WV
C301 F1J1C184A006 Ceramic, 0.18µF 16WV
C302 YECUS1C683KX Ceramic, 0.068µF 16WV
C303 YECUS1C683KX Ceramic, 0.068µF 16WV
C304 YECUS1H103KX Ceramic, 0.01µF 50WV
C305 YECUS1A105KX Ceramic, 1µF 10WV
C307 YECUS1H561JM Ceramic, 560PF 50WV
C308 YECUS1A105KX Ceramic, 1µF 10WV
C311 YECUS1A105KX Ceramic, 1µF 10WV
C312 YECUS1A105KX Ceramic, 1µF 10WV
C321 YECUV1C224KX Ceramic, 0.22µF 16WV
C322 YECUV1C224KX Ceramic, 0.22µF 16WV
C331 YECUV1C124KX Ceramic, 0.12µF 16WV
C332 YECUV1C124KX Ceramic, 0.12µF 16WV
C333 YECUV1C124KX Ceramic, 0.12µF 16WV
C334 YECUV1C124KX Ceramic, 0.12µF 16WV
C378 YECUS1A105KX Ceramic, 1µF 10WV
C379 YECUS1A105KX Ceramic, 1µF 10WV
C451 YECUS1H150JC Ceramic, 15PF 50WV
C452 YECUS1H150JC Ceramic, 15PF 50WV
C453 YECUS1H101JM Ceramic, 100PF 50WV
C454 YECUS1H102KX Ceramic, 1000PF 50WV
C455 YECUS1C104KX Ceramic, 0.1µF 16WV
C457 YECUS1H103KX Ceramic, 0.01µF 50WV
C458 YECUS1H103KX Ceramic, 0.01µF 50WV
C459 F2A1H4R7A154 Electrolytic, 4.7µF 50WV
C601 YECUS1H270JC Ceramic, 27PF 50WV
C602 YECUS1H270JC Ceramic, 27PF 50WV
C605 YECUS1C104KX Ceramic, 0.1µF 16WV
C607 YECUS1H102KX Ceramic, 1000PF 50WV
C608 YECUS1H103KX Ceramic, 0.01µF 50WV
C619 YECUS1H101JM Ceramic, 100PF 50WV
C621 YECUS1H103KX Ceramic, 0.01µF 50WV
C624 F2A0J470A164 Electrolytic, 47µF 6.3WV
C627 YECUS1H103KX Ceramic, 0.01µF 50WV
10
CQ-LS7230K
Ref.
No. Part No. Part Name & Description Remarks
C651 YECUV1H221JM Ceramic, 220PF 50WV
C652 YECUV1H221JM Ceramic, 220PF 50WV
C653 YECUS1H103KX Ceramic, 0.01µF 50WV
C688 YECUS1H103KX Ceramic, 0.01µF 50WV
C689 YECUS1H103KX Ceramic, 0.01µF 50WV
C699 YECUS1C104KX Ceramic, 0.1µF 16WV
C701 EEUFC1C222B Electrolytic, 2200µF 16WV
C702 F2A1C221A152 Electrolytic, 220µF 16WV
C703 F2A1C100A150 Electrolytic, 10µF 16WV
C707 YECUS1H103KX Ceramic, 0.01µF 50WV
C709 F2A1C101A150 Electrolytic, 100µF 16WV
C710 F2A1C1020029 Electrolytic, 1000µF 16WV
C711 F2A1C470A150 Electrolytic, 47µF 16WV
C712 F2A1C470A150 Electrolytic, 47µF 16WV
C713 F2A1C470A150 Electrolytic, 47µF 16WV
C718 F2A1C101A150 Electrolytic, 100µF 16WV
C721 ECQV1H104B46 Plastic Film, 0.1µF 50WV
C723 ECQV1H104B46 Plastic Film, 0.1µF 50WV
C724 YECUV1C224KX Ceramic, 0.22µF 16WV
C725 YECUV1C224KX Ceramic, 0.22µF 16WV
C751 YECUS1H103KX Ceramic, 0.01µF 50WV
C754 YECUS1H103KX Ceramic, 0.01µF 50WV
C771 YECUV2A102KX Ceramic, 1000PF 100WV
C772 YECUV2A102KX Ceramic, 1000PF 100WV
C773 YECUV2A102KX Ceramic, 1000PF 100WV
C774 YECUV2A102KX Ceramic, 1000PF 100WV
C775 YECUV2A102KX Ceramic, 1000PF 100WV
C776 YECUV2A102KX Ceramic, 1000PF 100WV
C777 YECUV2A102KX Ceramic, 1000PF 100WV
C778 YECUV2A102KX Ceramic, 1000PF 100WV
C781 YECUV1H221JM Ceramic, 220PF 50WV
C782 YECUV1H221JM Ceramic, 220PF 50WV
C784 YECUV2A103KX Ceramic, 0.01µF 100WV
C785 YECUV2A103KX Ceramic, 0.01µF 100WV
C786 YECUV1H221JM Ceramic, 220PF 50WV
C787 YECUV1H221JM Ceramic, 220PF 50WV
C801 F2A1A101A144 Electrolytic, 100µF 10WV
C802 F2A0J470A164 Electrolytic, 47µF 6.3WV
C803 YECUS1C104KX Ceramic, 0.1µF 16WV
C804 YECUS1C104KX Ceramic, 0.1µF 16WV
RESISTORs
C122 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C123 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
C132 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
C133 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
J31 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
J51 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
J203 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
J207 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
J451 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
J452 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R101 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R102 ERJ6GEYJ392 Chip, 3.9kΩ
ΩΩ
Ω1/10W
R103 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R104 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R105 ERJ6GEYJ153 Chip, 15kΩ
ΩΩ
Ω1/10W
R120 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R121 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R122 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R131 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R132 ERJ6GEYJ822 Chip, 8.2kΩ
ΩΩ
Ω1/10W
R151 ERJ6GEYJ823 Chip, 82kΩ
ΩΩ
Ω1/10W
R152 ERJ6GEYJ333 Chip, 33kΩ
ΩΩ
Ω1/10W
R153 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R154 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R155 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R156 ERJ6GEYJ101 Chip, 100Ω
ΩΩ
Ω1/10W
R157 ERJ6GEYJ124 Chip, 120kΩ
ΩΩ
Ω1/10W
R158 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R159 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R201 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
Ref.
No. Part No. Part Name & Description Remarks
R202 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R203 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R204 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R205 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R206 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R209 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R221 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R222 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R231 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R232 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R233 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R234 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R253 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R254 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R279 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R281 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R282 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R301 ERJ6GEYJ682 Chip, 6.8kΩ
ΩΩ
Ω1/10W
R303 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R304 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R321 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R322 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R331 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R332 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R333 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R334 ERJ6GEYJ2R2 Chip, 2.2Ω
ΩΩ
Ω1/10W
R353 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R354 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R379 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R381 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R382 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R451 ERJ6GEYJ152 Chip, 1.5kΩ
ΩΩ
Ω1/10W
R452 ERJ6GEYJ152 Chip, 1.5kΩ
ΩΩ
Ω1/10W
R453 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R454 ERJ6GEYJ152 Chip, 1.5kΩ
ΩΩ
Ω1/10W
R455 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R456 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R457 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R458 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R459 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R600 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R601 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R602 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R606 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R607 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R608 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R609 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R615 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R617 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R622 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R623 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R626 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R627 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R633 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R634 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R635 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R636 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R651 ERG1SJ101E Metal Oxid, 100Ω
ΩΩ
Ω1W
R652 ERG1SJ101E Metal Oxid, 100Ω
ΩΩ
Ω1W
R653 ERG1SJ680E Metal Oxid, 68Ω
ΩΩ
Ω1W
R686 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R687 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R688 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R689 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R691 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R696 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R701 ERDS1FVJ1R5 Carbon, 1.5Ω
ΩΩ
Ω1/2W
R702 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R707 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R751 ERJ6RED274V Metal Film, 270kΩ
ΩΩ
Ω1/10W
R752 ERJ6RBD273V Metal Film, 27kΩ
ΩΩ
Ω1/10W
R753 ERJ6RBD472V Metal Film, 4.7kΩ
ΩΩ
Ω1/10W
R754 ERJ6RBD433V Metal Film, 43kΩ
ΩΩ
Ω1/10W
11
CQ-LS7230K
Ref.
No. Part No. Part Name & Description Remarks
R755 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R762 ERJ8GEYJ561V Chip, 560Ω
ΩΩ
Ω1/8W
R764 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/8W
R768 ERJ6RBD473V Metal Film, 47kΩ
ΩΩ
Ω1/10W
R769 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R770 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R783 ERJ8GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/8W
CONNECTORs
CN631 YEAE9604S17S Connector, 17P
CN632 YEAE0110TKAG Connector, 10P
CN701 YEAE012462 Connector, 10P+6P
CN702 YEAE012463 Connector, 12P
CN901 YEAE0105MX Connector, 5P
CN902 YEAE0105MX Connector, 5P
CN903 YEAE0105MX Connector, 5P
COILs
L50 G1C3R3J00003 Coil
L105 G1C1R0J00003 Coil
L451 YELT03N101JT Coil
L601 YELTBLM21A10 Coil
L602 YELTBLM21A10 Coil
L603 YELTBLM21A10 Coil
L604 YELT03N101JT Coil
L701 G0A151J00005 Coil
CRYSTALs
XL451 H0D720400003 Crystal
XL601 YEXL49U0629T Crystal
NEON TUBE
Z51 J0LE00000004 Neon Tube
NETWORK RESISTORs
R661 EXBV8V102JV 1kΩ
ΩΩ
Ω
R663 EXBV8V102JV 1kΩ
ΩΩ
Ω
R664 EXBV8V102JV 1kΩ
ΩΩ
Ω
R665 EXBV8V102JV 1kΩ
ΩΩ
Ω
R667 EXBV8V102JV 1kΩ
ΩΩ
Ω
R668 EXBV8V102JV 1kΩ
ΩΩ
Ω
R669 EXBV8V102JV 1kΩ
ΩΩ
Ω
R670 EXBV8V102JV 1kΩ
ΩΩ
Ω
[E8094] Fix-EQ. Block
IC´s and TRANSISTORs
IC1 YEAMPC4570T1 IC
IC2 YEAMTA2062FL IC
IC3 YEAMPC4570T1 IC
IC61 YEAMPC4570T1 IC
IC62 YEAMTA2062FL IC
CAPACITORs
C1 YECUS1C104KX Ceramic, 0.1µF 16WV
C2 YECUS1C104KX Ceramic, 0.1µF 16WV
C3 YECUS1H681JM Ceramic, 680PF 50WV
C4 YECUS1H822KX Ceramic, 8200PF 50WV
C8 YECUS1E223KX Ceramic, 0.022µF 25WV
C9 YECUS1H822KX Ceramic, 8200PF 50WV
C11 YECUS1C474KX Ceramic, 0.47µF 16WV
C12 YECUS1C823KX Ceramic, 0.082µF 16WV
C13 YECUS1H472KX Ceramic, 4700PF 50WV
C14 YECUS1H561KX Ceramic, 560PF 50WV
C21 YECUS1C104KX Ceramic, 0.1µF 16WV
C22 YECUS1C104KX Ceramic, 0.1µF 16WV
Ref.
No. Part No. Part Name & Description Remarks
C23 YECUS1E223KX Ceramic, 0.022µF 25WV
C24 YECUS1C474KX Ceramic, 0.47µF 16WV
C26 YECUS1C224KX Ceramic, 0.22µF 16WV
C27 YECUS1E223KX Ceramic, 0.022µF 25WV
C29 YECUS1H392KX Ceramic, 3900PF 50WV
C30 YECUS1E333KX Ceramic, 0.033µF 25WV
C31 YECUS1H561KX Ceramic, 560PF 50WV
C61 YECUS1C104KX Ceramic, 0.1µF 16WV
C62 YECUS1C104KX Ceramic, 0.1µF 16WV
C63 YECUS1H681JM Ceramic, 680PF 50WV
C64 YECUS1H822KX Ceramic, 8200PF 50WV
C68 YECUS1E223KX Ceramic, 0.022µF 25WV
C69 YECUS1H822KX Ceramic, 8200PF 50WV
C71 YECUS1C474KX Ceramic, 0.47µF 16WV
C72 YECUS1C823KX Ceramic, 0.082µF 16WV
C73 YECUS1H472KX Ceramic, 4700PF 50WV
C74 YECUS1H561KX Ceramic, 560PF 50WV
C81 YECUS1C104KX Ceramic, 0.1µF 16WV
C82 YECUS1C104KX Ceramic, 0.1µF 16WV
C83 YECUS1E223KX Ceramic, 0.022µF 25WV
C84 YECUS1C474KX Ceramic, 0.47µF 16WV
C86 YECUS1C224KX Ceramic, 0.22µF 16WV
C87 YECUS1E223KX Ceramic, 0.022µF 25WV
C89 YECUS1H392KX Ceramic, 3900PF 50WV
C90 YECUS1E333KX Ceramic, 0.033µF 25WV
C91 YECUS1H561KX Ceramic, 560PF 50WV
RESISTORs
R1 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R2 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R3 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R4 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R5 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R6 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R8 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R9 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R10 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R21 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R22 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R23 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R24 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R25 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R26 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R28 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R61 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R62 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R63 ERJ6GEYJ104 Chip, 100kΩ
ΩΩ
Ω1/10W
R64 ERJ6GEYJ103 Chip, 10kΩ
ΩΩ
Ω1/10W
R65 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R66 ERJ6GEYJ222 Chip, 2.2kΩ
ΩΩ
Ω1/10W
R68 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R69 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
R70 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R81 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R82 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R83 ERJ6GEYJ563 Chip, 56kΩ
ΩΩ
Ω1/10W
R84 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
R85 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R86 ERJ6GEYJ332 Chip, 3.3kΩ
ΩΩ
Ω1/10W
R88 ERJ6GEYJ272 Chip, 2.7kΩ
ΩΩ
Ω1/10W
CONNECTORs
CN1 YEAE0107ISK Connector, 7P
CN2 YEAE0108ISK Connector, 8P
[E9064] Display Block
IC´s and TRANSISTORs
IC901 YEAMLC75853 IC
12
CQ-LS7230K
Ref.
No. Part No. Part Name & Description Remarks
DIODEs
D910 YEADSEC1401T Diode
D913 YEADSEC1401T Diode
D914 YEADSEC1401T Diode
D915 YEADSEC1401T Diode
D916 YEADSEC1401T Diode
D917 YEADSEC1401T Diode
D918 YEADSEC1401T Diode
D919 YEADSEC1401T Diode
D920 YEADSEC1401T Diode
D921 YEADSEC1401T Diode
D922 YEADSEC1401T Diode
D923 YEADSEC1401T Diode
D924 YEADSEC1401T Diode
D925 YEADSEC1401T Diode
D926 YEADSEC1401T Diode
D927 YEADSEC1401T Diode
D928 YEADSEC1401T Diode
D929 YEADSEC1401T Diode
D930 YEADSEC1401T Diode
D931 YEADSEC1401T Diode
D932 YEADSEC1401T Diode
D933 YEADSEC1401T Diode
D934 YEADSEC1401T Diode
CAPACITORs
C901 YECUS1H473KX Ceramic, 0.047µF 50WV
C902 YECUS1H473KX Ceramic, 0.047µF 50WV
C903 YECUS1H821JM Ceramic, 820PF 50WV
C904 YECUS1H103KX Ceramic, 0.01µF 50WV
C905 YECUS1H103KX Ceramic, 0.01µF 50WV
C906 YECUS1C104KX Ceramic, 0.1µF 16WV
RESISTORs
R901 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R911 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R912 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R913 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R914 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R915 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R916 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R917 ERJ6GEYJ331 Chip, 330Ω
ΩΩ
Ω1/10W
R918 ERJ6GEYJ121 Chip, 120Ω
ΩΩ
Ω1/10W
R919 ERJ6GEYJ121 Chip, 120Ω
ΩΩ
Ω1/10W
R920 ERJ6GEYJ121 Chip, 120Ω
ΩΩ
Ω1/10W
R923 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
CONNECTORs
CN904 YEAE0105MP Connector, 5P
CN905 YEAE0105MP Connector, 5P
CN906 YEAE0105MP Connector, 5P
SWITCHEs
SW901 EVQPJU04K Switch
SW902 EVQPJU04K Switch
SW903 EVQPJU04K Switch
SW904 EVQPJU04K Switch
SW905 EVQPJU04K Switch
SW906 EVQPJU04K Switch
SW907 YEAS09245 Switch
SW908 YEAS09245 Switch
SW909 EVQ24704K Switch
SW910 YEAS09245 Switch
SW911 YEAS09245 Switch
SW912 YEAS09245 Switch
SW913 EVQPJU04K Switch
SW914 EVQPJU04K Switch
SW915 YEAS09245 Switch
Ref.
No. Part No. Part Name & Description Remarks
SW916 YEAS09245 Switch
SW917 YEAS09245 Switch
LCD
LCD1 YEXDCM1192 LCD
COIL
L901 YELT03N101JT Coil
LAMPs
PL901 YEALFAAG007 Pilot Lamp
PL902 YEALFAAG007 Pilot Lamp
VARIABLE RESISTORs
VR901 EWVSCB002B24 Variablr resistor
Mechanical Parts
MISCELLANEOUS
AE2 YEAES17A047A Flat Cable, 17P
ANT1 YEAA10066 Antenna Receplacle
1YEFA031440C Upper Cover
2YEFA05662 Bottom Cover
3YEFA07397A Front Plate
4YEFA09478 Side Plate (R)
5YEFA09479 Side Plate (L)
6YEFA131255 Cover, LCD
7YEFC027752 Escutcheon Ass´y
8YEFE02267A Knob, VOL
9YEP0PT9064Y9 PCB w/Components RTL
10 YEFF01815B Heat Sink
11 YEFK06741B Holder, LCD
13 YEFV011782 Insulator
14 YEFV021546 Optical Shade
15 YEFX0011706B Transparent Plate
16 YEFX0011709 Transparent Plate
17 YEFX0213797 Bracket, GND
18 YEFX0213887A Bracket, Connector
19 YEFX0213049A Bracket, PCB
20 YEFX0213909 Bracket, Q701
21 YEFX0213919 Bracket, GND
22 YEFX0213942A Bracket, ANT
23 YEFX0214169 Bracket, Deck
24 YEP0PT8094K9 PCB w/Components RTL
25 YEP0PT6876Y9 PCB w/Components RTL
30 YEJS05024 Screw, 3 mm * 16mm
31 YEJS06185 Screw, 2.6mm * 3.5mm
32 YEJT03009 Tapping Screw, 3mm * 8mm
33 YEJT03131 Tapping Screw, 2.6mm * 5mm
34 YEJT03141 Tapping Screw, 3mm * 8mm
35 XTB2+6GFX Tapping Screw, 2mm * 6mm
36 XTB3+8FFX Tapping Screw, 3mm * 8mm
13
CQ-LS7230K
12 TAPE PLAYER PARTS
Ref.
No. Part No. Part Name & Description Remarks
[8790A] Tape Dolby Block
ICs AND TRANSISTORs
IC1 C1BB00000100 IC
Q401 YEANC114YKT Transistor
CAPACITORs
C201 YECUS1H331JM Ceramic, 330PF 50WV
C202 YECUS1H331JM Ceramic, 330PF 50WV
C204 YECUS1H123KX Ceramic, 0.012µF 50WV
C205 YECUS1E333KX Ceramic, 0.033µF 25WV
C206 YECUS1C104KX Ceramic, 0.1µF 16WV
C301 YECUS1H331JM Ceramic, 330PF 50WV
C302 YECUS1H331JM Ceramic, 330PF 50WV
C304 YECUS1H123KX Ceramic, 0.012µF 50WV
C305 YECUS1E333KX Ceramic, 0.033µF 25WV
C306 YECUS1C104KX Ceramic, 0.1µF 16WV
C401 ECA1CSA220I Electrolytic, 22µF 16WV
C402 ECEA1AKS330I Electrolytic, 33µF 10WV
C403 YECUV2A103KX Ceramic, 0.01µF 100WV
C404 YECUS1E333KX Ceramic, 0.033µF 25WV
C405 ECA1HSAR33I Electrolytic, 0.33µF 50WV
C406 YECUS1H472KX Ceramic, 0.0047µF 50WV
C407 ECEA1CKS100I Electrolytic, 10µF 16WV
C409 YECUS1H472KX Ceramic, 0.0047µF 50WV
C501 YECUV1E334ZF Ceramic, 0.33µF 25WV
RESISTORs
R201 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R202 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R207 ERJ8GEYJ181V Chip, 180Ω
ΩΩ
Ω1/8W
R301 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R302 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R307 ERJ6GEYJ181 Chip, 180Ω
ΩΩ
Ω1/10W
R402 ERJ6GEYJ183 Chip, 18kΩ
ΩΩ
Ω1/10W
R403 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R404 ERJ8GEYJ334V Chip, 330kΩ
ΩΩ
Ω1/8W
R405 ERJ8GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω1/8W
R406 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R408 ERJ8GEYJ223V Chip, 22kΩ
ΩΩ
Ω1/8W
R409 ERJ6GEYJ273 Chip, 27kΩ
ΩΩ
Ω1/10W
R501 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
CONNECTORs
CN1 YEAE012385 Connector, 17P
CN3 YEAESLW05R1 Connector, 5P
SWITCHes
SW1 K0J1CB00001 Switch
SW2 YEAS07174 Switch
SW3 YEAS08042 Switch
VARIABLE RESISTORs
VR201 EVNDXAA00B13 Variable Resistor
VR301 EVNDXAA00B13 Variable Resistor
[E8791] Tape Reel Block
PHOTOCOUPLERs
TE1 YEADRPI221 Photocoupler
TE2 YEADRPI221 Photocoupler
CAPACITORs
C1 YECUS1H471JM Ceramic, 470PF 50WV
C2 YECUS1H471JM Ceramic, 470PF 50WV
C3 YECUS1H471JM Ceramic, 470PF 50WV
RESISTORs
R1 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R2 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R3 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
Ref.
No. Part No. Part Name & Description Remarks
R4 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/8W
R5 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/8W
R6 ERJ8GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/8W
R7 ERJ8GEYJ821V Chip, 820Ω
ΩΩ
Ω1/8W
R8 ERJ8GEYJ821V Chip, 820Ω
ΩΩ
Ω1/8W
CONNECTORs
CN2 YEAE0110TKCR Connector, 10P
JP3 YGAJ071387A CORD W/Connector
SWITCHes
SW4 YEAS07174 Switch
SW5 EVQWJE001 Rotary Switch
Mechanical Parts
MISCELLANEOUS
1YGFX0052472 Lock Plate Spring
2YGFX0052454 Spring
3YGFX0462100 Cassette Holder (U) Ass´y
4YGFX0462104 Cassette Holder(L)
5YGFA011830 Head Chassis Ass´y
6YGFX234194 Cam
7YGFX0052427 Back Tension Spring
8YGFX209271 Reel (R) Ass´y
9YGFX0052471 Holding Spring
10 YGJW04131 Washer
11 YGFX0052475 Rack Plate Spring
12 YGFX0031035 Rack Plate
13 YGFA011827 Main Chassis Ass´y
14 YGFX0052444 EQ Lever Spring
15 YGFW062546 Shaft
16 YGP0PT8790A1 Dolby P.C.B. Ass´y
17 YGP9FZ2973 Head Ass´y
18 YGFX0462105 Lever
19 YGFX0052478 Vibration-proof Spring
20 YGFX0052477 Spring
21 YGFX239470 Cassette Guid Plate
22 YGFX0462097 PRO Change Plate
23 YGFX0031031 Idler Gear Plate (F) Ass´y
24 YGP0FX3845 Main Motor Ass´y
25 YGFX0052474 Rack Return Spring
26 YGFX218305 Pinch Roller (F) Ass´y
28 YGFX0031033 Idler Gear Plate (R) Ass´y
29 YGFX0462102 Rack Return Link
30 YGFW062600 Rack Return Link Shaft
31 YGFX218306 Pinch Roller (R) Ass´y
32 YGFX213213 Flywheel Ass´y
33 YGFX0031001 Drive Gear (2)
34 YEFX003753B Play Idler Gear
35 YGFX014075 Lock Ling
36 YGFX003970 Gear
37 YGJT03250 Gear Shaft
38 YGFX0052446 Idler Gear Plate Spring
39 YGFX0031030 Worm Gear
40 YGP0FX3846 Loading Motor Ass´y
41 YGFX030102 Worm Gear Stopper
42 YGFX0031026 Drive Gear (3)
43 YGFA011851 Drive Chassis Ass´y
44 YGP0PT8791A0 Reel P.C.B. Ass´y
46 YGFX209270 Reel (F) Ass´y
47 YGFX0052473 Pinch Roller Spring
50 YGFX003971 PRO Change Gear
52 YEFR03083 Belt
54 YGFX0031029 Drive Gear
61 YEJE01004 E-Ring
62 YEJE01036 E-Ring
64 XYN2+C8FX Screw, 2 x 8mm
65 YEJT03167 Screw
66 YEJS06097A Screw, 2 x 2.5mm
67 YEJT03271 Screw
15
CQ-LS7230K
14.3. Main Block (Bottom View)
[E-6876][Bottom View]
CQ-LS7230K MAIN
19
CQ-LS7230K
This manual suits for next models
1
Table of contents
Other Toyota Car Receiver manuals
Toyota
Toyota AUDIO 1-DIN User manual
Toyota
Toyota RAV4 (RHD) - MMC User manual
Toyota
Toyota GENUINE AUDIO AVENSIS T25 User manual
Toyota
Toyota PC601-00027 User manual
Toyota
Toyota CQ-VS8180A User manual
Toyota
Toyota Auris TAS200 2012 User manual
Toyota
Toyota Premium ICE User manual
Toyota
Toyota CQ-VS8380A User manual
Toyota
Toyota RSE User manual
Toyota
Toyota RAV4 (RHD) - MMC User manual
Toyota
Toyota Prius V 2014 User manual
Toyota
Toyota Ice User manual
Toyota
Toyota Solara 2005 User manual
Toyota
Toyota CQ-SS0070F User manual
Toyota
Toyota CQ-LS8180A User manual
Toyota
Toyota Ice User manual
Toyota
Toyota RAV4 (LHD) User manual
Toyota
Toyota 00016-00950 User manual
Toyota
Toyota AUX-TOY3 Instruction Manual
Toyota
Toyota Aygo LHD User manual
