Toyota CQ-VS8380A User manual
General
Power Supply DC 12V (11V - 16V),
Test Voltage 13.2V
Negative Ground
Current Consumption Less than 3.0A
Power Output 17W×4
AM Radio
Frequency Range 531 - 1,602 kHz
Usable Sensitivity 25dB/µV (S/N 20dB)
FM Stereo Radio
Frequency Range 87.5 - 108.0MHz
Usable Sensitivity 6dB/µV (S/N 30dB)
SW Radio (SW1)
Frequency Range 2.940 - 7.735MHz
Usable Sensitivity 27dB/µV
SW Radio (SW2)
Frequency Range 9.500 - 21.975MHz
Usable Sensitivity 30dB/µV
CQ-VS8380A
AM/FM/SW MPX Electronic Tuning
Radio with Stereo Cassette Tape Player
PART No. : 86120-52290
ID CODE : 57416
VEHICLE : COROLLA, PRONARD, ECHO, RAV4
DESTINATION : Middle and Near East
PRODUCED AFTER : July, 2003
Cassette Player (YGFD04730)
Reproduction System 4-Track, 2-Program Stereo
Tape Speed 4.76cm/sec.
Wow and Flutter 0.09% (WRMS)
Signal to Noise Ratio More than 42dB
Separation More than 30dB
Dimensions** (W×H×D) 178×70×165mm
Weight** 1.35kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“Dolby” and the double-D symbol are trade marks of Dolby
Laboratories Licensing Corporation.
Specifications*
1 FEATUERS 2
2 SYSTEM BLOCK DIAGRAM 2
3 FRONT VIEW AND FUNCTIONS 3
4 REAR VIEW AND CONNECTORS 4
5 WIRING CONNECTION 5
6 BLOCK DIAGRAM 6
7 TERMINALS DESCRIPTION 7
·
PLL (Phase Locked Loop) synthesized tuning.
·
24-station preset (6-AM, 6-FM, 6-SW1, 6-SW2).
·
Scan tuning function.
·
Dolby noise reduction.
8 PACKAGE AND IC BLOCK DIAGRAM 8
9 REPLACEMENT PARTS LIST 10
10 EXPLODED VIEW (Unit) 14
11 WIRING DIAGRAM 15
12 SCHEMATIC DIAGRAM -1 19
13 MEMO 21
·
Electronic volume control.
·
CD changer control function.
·
Illumination color : Amber
CONTENTS
Page Page
1 FEATUERS
2 SYSTEM BLOCK DIAGRAM
2
CQ-VS8380A
3 FRONT VIEW AND FUNCTIONS
3
CQ-VS8380A
4 REAR VIEW AND CONNECTORS
4
CQ-VS8380A
6 BLOCK DIAGRAM
6
CQ-VS8380A
7.1. Main Block
IC601 : C2CBHG000067
Pin
No. Port Description I/O (V)
1 BEEP Buzzer output O 0
2 BIT3 Tape mode SW I 4.8
3 BIT2 Tape mode SW I 4.8
4 BIT1 Tape mode SW I 0
5 FIN Tape motor control O 0
6 RIN Tape motor control O 0
7 MUTE System mute O 0
8 NC No connection - -
9 NC No connection - -
10 NC No connection - -
11 RESET Reset input I 4.8
12 X2 Crystal oscillator terminal - 1.8
13 X1 Crystal oscillator terminal - 1.3
14 GND Ground - 0
15 X2 Crystal oscillator terminal - 1.7
16 X1 Crystal oscillator terminal - 1.4
17 REGOFF (Connecting to ground) - 0
18 REGCPU Not used - -
19 VDD0 +5V power supply - 5.0
20 FCONT2 Frequency control O 4.9
21 FCONT1 Frequency control O 0
22 SD B/S detection I 0
23 ST FM stereo detection I 0
24 PLL-DO PLL data input I 4.8
25 PLL-CLK Shift clock for PLL data O 0
26 PLL-DI PLL data output O 0
27 PLL-CE PLL chip enable O 0
28 NK ON/OFF AM noise cancellor on/off O 4.8
29 NC No connection - -
30 NC No connection - -
31 VOL-DATA Electronic volume data O 0
32 VOL-CLK Data shift clock O 0
33 LCD-CLK Data shift clock O 0
34 LCD-DO LCD data input I 4.8
35 NC No connection - -
36 LCD-CE LCD chip enable O 0
37 LCD-DI LCD data output O 0
38 VOLA Volume SW contact A I 4.8
39 VOLB Volume SW contact B I 4.8
40 GND Ground - 0
41 VDD +5V power supply - 5.0
42 NC No connection - -
43 MODEA Mode SW contact A I 0
44 MODEB Mode SW contact B I 0
45 NC No connection - -
46 NC No connection - -
47 NC No connection - -
48 NC No connection - -
49 NC No connection - -
50 NC No connection - -
51 SW/9Pro (VDD pull-up) - 5.0
52 9K/5K (Connecting to ground) - 0
53 NC No connection - -
54 NC No connection - -
55 NC No connection - -
56 CLK Power control IC clock O 0
57 STBY Power control IC stand-by O 5.0
58 LATCH Power control IC data latch O 5.0
59 DATA Power control IC data O 0
60 NC No connection - -
61 NC No connection - -
62 NC No connection - -
63 NC No connection - -
64 MSOUT TPS detection O 4.8
65 NC No connection - -
66 NC No connection - -
67 NC No connection - -
68 MS-PL/FF MS mode selection O 0
69 T.LOAD Tape loading detection I 0
70 DOLBY Dolby NR on/off O 5.0
71 NC No connection - -
72 NC No connection - -
73 TEST (GND pull-down) - 0
74 NC No connection - -
75 NC No connection - -
76 NC No connection - -
77 A/B Tape forward-reverse SW I 0
78 MTL Metal tape mode on/off O 0
79 CAM A/B Tape side detection I 0
80 MSM MS gain control O 4.9
81 NK-IN AM signal level I 0
82 VDD +5V power supply - 5.0
83 AVDD +5V power supply - 4.8
84 GND Ground - 0
85 LANIN LAN data input I 0
86 LANOUT LAN data output O 0
87 GND Ground - 0
88 NC No connection - -
89 ILL-DET ILL detection I 0
90 EQ Metal tape detection I 4.8
91 +B-DET Battery level detection I 4.9
92 ACC-DET ACC level detection I 4.9
93 TAPE-EJ Tape eject SW I 4.9
94 T.IN Tape detection I 0
95 END-B Tape end detection I 0
96 END-A Tape end detection I 0
97 NC No connection - -
98 NC No connection - -
99 NC No connection - -
100 NC No connection - -
Note 1 : Voltage measuerments are with respect to ground,
with a voltmeter (internal resistance : 10M ohms).
7.2. Display Block
IC601 : YEAMLC75853W
Pin
No. Port Description I/O (V)
1-33 SEG1-20 LCD segment data O 2.6
34-40 - Not used - -
41-43 COM1-3 LCD common output O 2.6
44 S41 Not used - -
45-49 KS1-6 Key scan signal O 5.2
50 KI1 Not used - 0
51-54 KI2-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply - 5.2
57 VDD1 Ground through capacitor - 3.5
58 VDD2 Ground through capacitor - 1.8
59 VSS Ground - 0
60 OSC CR oscillator - 4.1
61 DO key data output O 5.2
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
7 TERMINALS DESCRIPTION
7
CQ-VS8380A
8 PACKAGE AND IC BLOCK DIAGRAM
8.1. Main Block
PA150 : YEP0PTY323A0
IC451 : YEAMLC72135C
8
CQ-VS8380A
PA100 : YEAU03SKM21
IC201 : C1BB00000284
IC651 : YEAMH12187ER
IC702 : YEAMLB1930MT
IC701 : C0DBZHZ00006
IC704 : AN8065SE1
9
CQ-VS8380A
9 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No. Part No. Part Name & Description Remarks
[E6868] Main Block
IC´s AND TRANSISTORs
IC201 C1BB00000284 IC
IC231 AN7561Z-WLB IC
IC261 YEAMHA12181F IC
IC451 YEAMLC72135C IC
IC601 C2CBHG000067 IC
IC651 YEAMH12187ER IC
IC701 C0DBZHZ00006 IC
IC702 YEAMLB1930MT IC
IC704 AN8065SE1 IC
PA100 YEAU03SKM21 Electronic Tuner
PA150 YEP0PTY323A0 Electronic Tuner
Q150 B1GBCFNN0014 Transistor
Q151 B1GBCFNN0014 Transistor
Q152 B1GDCFNN0010 Transistor
Q261 B1GBCFGN0004 Transistor
Q272 B1GDCFNN0010 Transistor
Q452 B1GDCFNN0010 Transistor
Q453 B1GDCFNN0010 Transistor
Q601 YEANC4081STX Transistor
Q602 YEANC4081STX Transistor
Q701 YEAN2SA1757 Transistor
Q702 2SB1398QTA Transistor
Q731 YEANFP1F3PT1 Transistor
Q733 YEANC4081STX Transistor
Q741 B1GDCFJN0011 Transistor
Q742 B1BBAC000007 Transistor
DIODEs
D150 B0ADDJ000007 Diode
D201 YEADRD39M2T2 Diode
D211 YEAD1SS355T1 Diode
D242 YEAD1SS355T1 Diode
D250 B0ADDJ000007 Diode
D271 YEAD1SS355T1 Diode
D272 YEAD1SS355T1 Diode
D311 YEAD1SS355T1 Diode
D350 B0ADDJ000007 Diode
D631 B0ADDJ000006 Diode
D632 YEADSR1544TL Diode
D651 B0BC5R600020 Diode
D652 B0BC5R600020 Diode
D701 B0BC02700005 Diode
D703 YEADRB051L40 Diode
Ref.
No. Part No. Part Name & Description Remarks
D712 YEADSR1544TL Diode
D713 YEADSR1544TL Diode
D741 B0BC8R100002 Diode
CAPACITORs
C100 YECUZ1H103KX Ceramic, 0.01µF 50WV
C101 YECUZ1E223KX Ceramic, 0.022µF 25WV
C102 YECUZ1A224KX Ceramic, 0.22µF 10WV
C103 EEUFC1A221B Electrolytic, 220µF 10WV
C104 YECUZ1H103KX Ceramic, 0.01µF 50WV
C105 ECEA1HKA010I Electrolytic, 1µF 50WV
C107 F1H1C683A043 Ceramic, 0.068µF 16WV
C108 ECEA1CKA220I Electrolytic, 22µF 16WV
C151 YECUS1C563KX Ceramic, 0.056µF 16WV
C152 YECUZ1H103KX Ceramic, 0.01µF 50WV
C153 EEUFC1A221B Electrolytic, 220µF 10WV
C155 YECUZ1H471KX Ceramic, 470PF 50WV
C159 YECUZ1C104KX Ceramic, 0.1µF 16WV
C160 YECUZ1E223KX Ceramic, 0.022µF 25WV
C161 YECUZ1H103KX Ceramic, 0.01µF 50WV
C162 YECUZ1E223KX Ceramic, 0.022µF 25WV
C200 YECUZ1H103KX Ceramic, 0.01µF 50WV
C201 ECEA0JKA331I Electrolytic, 330µF 6.3WV
C202 F1H1C683A043 Ceramic, 0.068µF 16WV
C203 F1H1C683A043 Ceramic, 0.068µF 16WV
C204 YECUZ1H103KX Ceramic, 0.01µF 50WV
C205 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C206 F1H1C473A005 Ceramic, 0.047µF 16WV
C207 F1J1H1020024 Ceramic, 1000PF 50WV
C208 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C209 ECEA1HKSR33I Electrolytic, 0.33µF 50WV
C211 ECEA1HKA010I Electrolytic, 1µF 50WV
C212 ECEA1HKA010I Electrolytic, 1µF 50WV
C213 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C221 ECEA1CKS100I Electrolytic, 10µF 16WV
C222 ECEA1CKA100I Electrolytic, 10µF 16WV
C235 YECUS1C224KX Ceramic, 0.22µF 16WV
C236 YECUS1C224KX Ceramic, 0.22µF 16WV
C237 YECUS1C224KX Ceramic, 0.22µF 16WV
C238 YECUS1C224KX Ceramic, 0.22µF 16WV
C241 ECEA1CKA101I Electrolytic, 100µF 16WV
C242 ECEA1HKA010I Electrolytic, 1µF 50WV
C250 YECUZ1E223KX Ceramic, 0.022µF 25WV
C251 YECUZ1H682KX Ceramic, 6800PF 50WV
C252 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C261 EEAFC1A390H Electrolytic, 39µF 10WV
C262 YECUZ1H103KX Ceramic, 0.01µF 50WV
C263 ECEA1HBD010I Electrolytic, 1µF 50WV
C264 ECEA1HKA3R3I Electrolytic, 3.3µF 50WV
C265 YECUZ1C333KX Ceramic, 0.033µF 16WV
C266 F1H1C683A043 Ceramic, 0.068µF 16WV
C267 YECUZ1C333KX Ceramic, 0.033µF 16WV
C268 YECUZ1C333KX Ceramic, 0.033µF 16WV
C269 YECUZ1A124KX Ceramic, 0.12µF 10WV
C290 YECUZ1C333KX Ceramic, 0.033µF 16WV
C291 YECUZ1H472KX Ceramic, 4700PF 50WV
C292 ECEA1AKA101I Electrolytic, 100µF 10WV
C293 YECUZ1H103KX Ceramic, 0.01µF 50WV
C294 YECUZ1A224KX Ceramic, 0.22µF 10WV
C295 YECUZ1H102KX Ceramic, 1000PF 50WV
C296 YECUZ1H103KX Ceramic, 0.01µF 50WV
C300 YECUZ1H103KX Ceramic, 0.01µF 50WV
C301 ECEA0JKA470I Electrolytic, 47µF 6.3WV
C302 F1H1C683A043 Ceramic, 0.068µF 16WV
C303 F1H1C683A043 Ceramic, 0.068µF 16WV
C304 YECUZ1H103KX Ceramic, 0.01µF 50WV
C305 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C307 F1J1H1020024 Ceramic, 1000PF 50WV
C308 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C309 ECEA1HKSR33I Electrolytic, 0.33µF 50WV
C311 ECEA1HKA010I Electrolytic, 1µF 50WV
C312 ECEA1HKA010I Electrolytic, 1µF 50WV
10
CQ-VS8380A
Ref.
No. Part No. Part Name & Description Remarks
C313 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C321 ECEA1CKS100I Electrolytic, 10µF 16WV
C322 ECEA1CKA100I Electrolytic, 10µF 16WV
C335 YECUS1C224KX Ceramic, 0.22µF 16WV
C336 YECUS1C224KX Ceramic, 0.22µF 16WV
C337 YECUS1C224KX Ceramic, 0.22µF 16WV
C338 YECUS1C224KX Ceramic, 0.22µF 16WV
C350 YECUZ1E223KX Ceramic, 0.022µF 25WV
C351 YECUZ1H682KX Ceramic, 6800PF 50WV
C352 ECEA1HBD2R2I Electrolytic, 2.2µF 50WV
C451 YECUZ1H220JC Ceramic, 22PF 50WV
C452 YECUZ1H270JC Ceramic, 27PF 50WV
C453 F1H1H101A231 Ceramic, 100PF 50WV
C454 YECUZ1H102KX Ceramic, 1000PF 50WV
C455 YECUZ1C104KX Ceramic, 0.1µF 16WV
C456 YECUZ1H103KX Ceramic, 0.01µF 50WV
C457 YECUZ1H103KX Ceramic, 0.01µF 50WV
C458 YECUZ1H103KX Ceramic, 0.01µF 50WV
C459 ECEA1HKA4R7I Electrolytic, 4.7µF 50WV
C460 YECUZ1H103KX Ceramic, 0.01µF 50WV
C601 YECUZ1H220JC Ceramic, 22PF 50WV
C602 YECUZ1H220JC Ceramic, 22PF 50WV
C603 F1H1H101A231 Ceramic, 100PF 50WV
C604 F1H1H820A231 Ceramic, 82PF 50WV
C605 F1H1H470A231 Ceramic, 47PF 50WV
C606 YECUZ1H390JC Ceramic, 39PF 50WV
C607 YECUZ1H103KX Ceramic, 0.01µF 50WV
C609 F1H0J1050010 Ceramic, 1µF 6.3WV
C611 YECUZ1C104KX Ceramic, 0.1µF 16WV
C613 YECUZ1C104KX Ceramic, 0.1µF 16WV
C615 YECUZ1C104KX Ceramic, 0.1µF 16WV
C651 YECUZ1H103KX Ceramic, 0.01µF 50WV
C701 ECA1CM222B Electrolytic, 2200µF 16WV
C702 ECA1CM222B Electrolytic, 2200µF 16WV
C703 EEUFC1A221B Electrolytic, 220µF 10WV
C707 YECUZ1A224KX Ceramic, 0.22µF 10WV
C708 YECUZ1H221JC Ceramic, 220PF 50WV
C709 EEAFC0J121H Electrolytic, 120µF 6.3WV
C710 ECA1CM102B Electrolytic, 1000µF 16WV
C711 YECUS1C104KX Ceramic, 0.1µF 16WV
C713 EEAFC0J560H Electrolytic, 56µF 6.3WV
C718 ECEA1AKS101I Electrolytic, 100µF 10WV
C725 YECUZ1C104KX Ceramic, 0.1µF 16WV
C733 F1J1H103A513 Ceramic, 0.01µF 50WV
C771 YECUS1C224KX Ceramic, 0.22µF 16WV
C772 YECUS1C224KX Ceramic, 0.22µF 16WV
C774 F1J1H103A513 Ceramic, 0.01µF 50WV
C775 F1J1H1020024 Ceramic, 1000PF 50WV
C776 YECUS1C104KX Ceramic, 0.1µF 16WV
C777 F1J1H221A665 Ceramic, 220PF 50WV
C778 F1J1H221A665 Ceramic, 220PF 50WV
C779 F1J1H221A665 Ceramic, 220PF 50WV
C780 F1J1H221A665 Ceramic, 220PF 50WV
C781 F1J1H103A513 Ceramic, 0.01µF 50WV
C782 F1J1H103A513 Ceramic, 0.01µF 50WV
C784 F1J1H221A665 Ceramic, 220PF 50WV
C786 F1J1H221A665 Ceramic, 220PF 50WV
RESISTORs
R100 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R101 ERJ3GEYJ220V Chip, 22Ω
ΩΩ
Ω1/16W
R102 ERJ3GEYJ823V Chip, 82kΩ
ΩΩ
Ω1/16W
R103 ERJ3GEYJ224V Chip, 220kΩ
ΩΩ
Ω1/16W
R105 ERJ3GEYJ153V Chip, 15kΩ
ΩΩ
Ω1/16W
R106 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R107 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R150 ERJ3GEYJ184V Chip, 180kΩ
ΩΩ
Ω1/16W
R151 ERJ3GEYJ101V Chip, 100Ω
ΩΩ
Ω1/16W
R152 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R153 ERJ3GEYJ333V Chip, 33kΩ
ΩΩ
Ω1/16W
R154 ERJ3GEYJ823V Chip, 82kΩ
ΩΩ
Ω1/16W
R155 ERJ3GEYJ563V Chip, 56kΩ
ΩΩ
Ω1/16W
Ref.
No. Part No. Part Name & Description Remarks
R156 ERJ3GEYJ433V Chip, 43kΩ
ΩΩ
Ω1/16W
R157 ERJ3GEYJ563V Chip, 56kΩ
ΩΩ
Ω1/16W
R158 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω1/16W
R159 ERJ3GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/16W
R160 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R161 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R200 ERJ6GEYJ152 Chip, 1.5kΩ
ΩΩ
Ω1/10W
R201 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω1/16W
R203 ERJ3GEYJ333V Chip, 33kΩ
ΩΩ
Ω1/16W
R204 ERJ3GEYJ331V Chip, 330Ω
ΩΩ
Ω1/16W
R205 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω1/16W
R206 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω1/16W
R207 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R211 ERJ3GEYJ183V Chip, 18kΩ
ΩΩ
Ω1/16W
R212 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R221 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R222 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R225 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R226 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R235 ERJ6GEYJ223 Chip, 22kΩ
ΩΩ
Ω1/10W
R237 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R238 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R250 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R251 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R252 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R261 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R262 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R263 ERJ3GEYJ123V Chip, 12kΩ
ΩΩ
Ω1/16W
R264 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R265 ERJ3GEYJ184V Chip, 180kΩ
ΩΩ
Ω1/16W
R266 ERJ3GEYJ273V Chip, 27kΩ
ΩΩ
Ω1/16W
R267 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R268 ERJ3GEYJ332V Chip, 3.3kΩ
ΩΩ
Ω1/16W
R269 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω1/16W
R271 ERJ8GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/8W
R301 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω1/16W
R303 ERJ3GEYJ333V Chip, 33kΩ
ΩΩ
Ω1/16W
R304 ERJ3GEYJ331V Chip, 330Ω
ΩΩ
Ω1/16W
R305 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω1/16W
R306 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω1/16W
R307 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R311 ERJ3GEYJ183V Chip, 18kΩ
ΩΩ
Ω1/16W
R312 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R321 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R322 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R335 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R336 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R337 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R338 ERJ8GEYJ2R2V Chip, 2.2Ω
ΩΩ
Ω1/8W
R350 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R351 ERJ3GEYJ562V Chip, 5.6kΩ
ΩΩ
Ω1/16W
R352 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R451 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R452 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R453 ERJ3GEYJ272V Chip, 2.7kΩ
ΩΩ
Ω1/16W
R454 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω1/16W
R455 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R456 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R457 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/16W
R458 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R459 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R460 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R461 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R600 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R601 ERJ3GEYJ684V Chip, 680kΩ
ΩΩ
Ω1/16W
R602 ERJ3GEYJ221V Chip, 220Ω
ΩΩ
Ω1/16W
R604 ERJ3GEYJ184V Chip, 180kΩ
ΩΩ
Ω1/16W
R605 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R608 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R609 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R610 ERJ3GEYJ182V Chip, 1.8kΩ
ΩΩ
Ω1/16W
R611 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R612 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
11
CQ-VS8380A
Ref.
No. Part No. Part Name & Description Remarks
R617 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R618 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R619 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R624 ERJ6RED274V Metal Film, 270kΩ
ΩΩ
Ω1/10W
R625 ERJ6RBD433V Metal Film, 43kΩ
ΩΩ
Ω1/10W
R627 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R632 ERJ3GEYJ102V Chip, 1kΩ
ΩΩ
Ω1/16W
R633 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R634 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R636 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R638 ERJ6RBD273V Metal Film, 27kΩ
ΩΩ
Ω1/10W
R639 ERJ6RBD472V Metal Film, 4.7kΩ
ΩΩ
Ω1/10W
R674 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R675 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω1/16W
R676 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R677 ERJ3GEYJ104V Chip, 100kΩ
ΩΩ
Ω1/16W
R691 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R692 ERJ8GEYJ101V Chip, 100Ω
ΩΩ
Ω1/8W
R701 ERDS1FVJ1R0T Carbon, 1Ω
ΩΩ
Ω1/2W
R702 ERJ8GEYJ222V Chip, 2.2kΩ
ΩΩ
Ω1/8W
R707 ERJ8GEYJ471V Chip, 470Ω
ΩΩ
Ω1/8W
R734 ERJ8GEYJ103V Chip, 10kΩ
ΩΩ
Ω1/8W
R735 ERJ6GEYJ123 Chip, 12kΩ
ΩΩ
Ω1/10W
R736 ERJ3GEYJ473V Chip, 47kΩ
ΩΩ
Ω1/16W
R737 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R738 ERJ6GEYJ473 Chip, 47kΩ
ΩΩ
Ω1/10W
R742 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R770 ERJ8GEY0R00V Chip, 0Ω
ΩΩ
Ω1/8W
R775 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R776 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R777 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R778 ERJ8GEYJ683V Chip, 68kΩ
ΩΩ
Ω1/8W
R779 ERG1SJ680E Metal Oxid, 68Ω
ΩΩ
Ω1W
CONNECTORs
CN631 YEAE9604S17S Connector 17P
CN701 YEAE012462 Connector 10P+6P
CN702 YEAE012463 Connector 12P
CN801 YEAE012406 Connector 10P
CN901 K1KA14B00082 Connector 14P
COILs
L100 YELT03NR68MT Coil
L102 YELT03N330JT Coil
L103 YELT03N330JT Coil
L451 YELT03N101JT Coil
L601 YELTBLM21A10 Coil
L602 YELTBLM21A10 Coil
L603 YELTBLM21A10 Coil
L701 G0A111J00003 Coil
CRYSTALs
XL451 YEXL49U0450T Crystal Oscillator
XL601 H0A327200080 Crystal Oscillator
XL602 YEXLCSA1258M Crystal Oscillator
NETWORK RESISTORs
R606 EXBV8V102JV Network Resistor
R607 EXBV8V102JV Network Resistor
R613 EXBV8V102JV Network Resistor
R614 EXBV8V102JV Network Resistor
R615 EXBV8V102JV Network Resistor
R620 EXBV8V102JV Network Resistor
R622 EXBV8V102JV Network Resistor
R626 EXBV8V102JV Network Resistor
R628 EXBV8V102JV Network Resistor
R629 EXBV8V102JV Network Resistor
R630 EXBV8V102JV Network Resistor
Ref.
No. Part No. Part Name & Description Remarks
NEON TUBE
Z100 J0LE00000004 NEON LAMP
[E9395] Display Block
IC
IC901 YEAMLC75853W IC
DIODEs
D901 B3ACB0000067 Diode
D902 B3ACB0000067 Diode
D903 B3ACB0000067 Diode
D904 B3ACB0000067 Diode
D905 B3ACB0000067 Diode
D906 B3ACB0000067 Diode
D907 B3ACB0000067 Diode
D908 B3ACB0000067 Diode
D909 B3ACB0000067 Diode
D910 B3ACB0000067 Diode
D911 B3ACB0000067 Diode
D912 B3ACB0000067 Diode
D913 B3ACB0000067 Diode
D914 B3ACB0000067 Diode
D915 B3ACB0000067 Diode
D916 B3ACB0000067 Diode
D917 B3ACB0000067 Diode
D918 B3ACB0000067 Diode
D931 MA8100LMTX Diode
D932 MA8100LMTX Diode
D933 MA8100LMTX Diode
D934 MA8100LMTX Diode
D935 MA8100LMTX Diode
D936 MA8100LMTX Diode
D937 MA8100LMTX Diode
D938 MA8100LMTX Diode
D939 MA8100LMTX Diode
D951 B3ACB0000067 Diode
D952 B3ACB0000067 Diode
D953 B3ACB0000067 Diode
D954 B3ACB0000067 Diode
D955 B3ACB0000067 Diode
D956 B3ACB0000067 Diode
D957 B3ACB0000067 Diode
D958 B3ACB0000067 Diode
D959 B3ACB0000067 Diode
D960 B3ACB0000067 Diode
D961 B3ACB0000067 Diode
D962 B3ACB0000067 Diode
D963 B3ACB0000067 Diode
D964 B3ACB0000067 Diode
D965 B3ACB0000067 Diode
D966 B3ACB0000067 Diode
D967 B3ACB0000067 Diode
D968 B3ACB0000067 Diode
D969 B3ACB0000067 Diode
D970 B3ACB0000067 Diode
D971 B3ACB0000067 Diode
D972 B3ACB0000067 Diode
CAPACITORs
C901 F1J1H181A672 Ceramic, 180PF 50WV
C902 F1J1H181A672 Ceramic, 180PF 50WV
C903 F1J1H181A672 Ceramic, 180PF 50WV
C904 F1J1H181A672 Ceramic, 180PF 50WV
C905 F1J1H103A513 Ceramic, 0.01µF 50WV
C906 YECUS1E473KX Ceramic, 0.047µF 25WV
C907 YECUS1E473KX Ceramic, 0.047µF 25WV
C908 F1J1H821A672 Ceramic, 820PF 50WV
C909 F1J1H103A513 Ceramic, 0.01µF 50WV
12
CQ-VS8380A
Ref.
No. Part No. Part Name & Description Remarks
RESISTORs
R901 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R902 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R903 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R904 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R905 ERJ6GEYJ681 Chip, 680Ω
ΩΩ
Ω1/10W
R906 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R907 ERJ6GEYJ102 Chip, 1kΩ
ΩΩ
Ω1/10W
R908 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R909 ERJ6GEYJ561 Chip, 560Ω
ΩΩ
Ω1/10W
R911 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R912 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R913 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R914 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R915 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R916 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R917 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R918 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R919 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R920 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R921 ERJ6GEYJ471 Chip, 470Ω
ΩΩ
Ω1/10W
R922 ERJ6GEYJ472 Chip, 4.7kΩ
ΩΩ
Ω1/10W
R923 ERJ6GEYJ683 Chip, 68kΩ
ΩΩ
Ω1/10W
R991 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω1/10W
CONNECTOR
CN902 YEAETKCF14XS Connector 14P
COIL
L901 YELT03N101JT Coil
LCD
LCD901 L5AAALB00020 LCD
VARIAVLE RESISTORs
VR901 K0N130C00003 Variablr resistor
VR902 K0N130C00002 Variablr resistor
Mechanical Parts
MISCELLANEOUS
ANT100 YEAA10066 Antenna Receplacle
AE1 YEAES10B090A Flat Cable, 10P
AE2 K9ZZ00000881 Flat Cable, 17P
1YEFX0214624 Bracket, Deck
2YEFX0011942A Transparent Plate
3YEFV021613A Optical Shade
4YEFA131416 Cover, LCD
5YEP0PT9395A0 Display PCB w/Component RTL
6YEFV011933 Insulator
7YEFA031440C Upper Cover
8YEFF01960 Heat Sink
9YEFA09633 Side Plate (L)
10 YEFA09634 Side Plate (R)
11 YEFA07463 Front Plate
13 YGFC028142 Escucheon Ass´y
14 YEFR07109 Rubber Contact
15 YEFE02313 Knob, VOL
16 YEFE02314 Knob, TONE
17 YEFA05662 Bottom Cover
18 YEFX0213919 Bracket, GND
19 YEFX0213942A Bracket, ANT
20 YEFX0214623 Bracket, Connector
21 YEFX0213909 Bracket, Q701
22 YEFX0213797 Bracket, GND
23 YEP0PT6868A0 Main PCB w/Component RTL
Ref.
No. Part No. Part Name & Description Remarks
31 XSB26+5FX Screw, M2.6x5mm
32 YEJT03009 Screw, M3x8mm
33 YEJT03013 Tapping Screw,
34 YEJT03131 Tapping Screw, M2.6x5mm
35 YEJT01103 Tapping Screw,
36 XTB2+6GFX Tapping Screw, M2x6mm
37 XTB3+6FFX Tapping Screw, M3x6mm
38 XTB3+8FFX Tapping Screw, M3x8mm
13
CQ-VS8380A
11.3. Main Block (Bottom View)
[E-6868A][Bottom View]
CQ-VS8380A MAIN P.C.B
17
CQ-VS8380A
18
CQ-VS8380A
Table of contents
Other Toyota Car Receiver manuals
Toyota
Toyota Avensis RHD User manual
Toyota
Toyota AUX-TOY3 Instruction Manual
Toyota
Toyota CQ-ES0370A User manual
Toyota
Toyota Premium ICE User manual
Toyota
Toyota Audio 2001 Avensis Verso User manual
Toyota
Toyota JBL Premium sound User manual
Toyota
Toyota Aygo LHD User manual
Toyota
Toyota CQ-SS0070F User manual
Toyota
Toyota CQ-VS8180A User manual
Toyota
Toyota CQ-TS7420K User manual
Toyota
Toyota CQ-LS8180A User manual
Toyota
Toyota 2008 Camry User manual
Toyota
Toyota CQ-LS7230K User manual
Toyota
Toyota Ice User manual
Toyota
Toyota GENUINE AUDIO AVENSIS T25 User manual
Toyota
Toyota Display Audio system User manual
Toyota
Toyota Ice User manual
Toyota
Toyota 4RUNNER BROCHURE 2011 User manual
Toyota
Toyota Auris TAS200 2012 User manual
Toyota
Toyota CQ-ES0360A User manual
