Toyotomi TAN-28HIM User manual

CONTENTS
SPECIFICATION .................................................................... 1
FUNCTIONS .......................................................................... 3
SERVICE FUNCTION EXPLANATION .................................. 5
OPERATION DETAILS........................................................... 6
TROUBLESHOOTING GUIDE ............................................. 13
PERFORMANCE CURVE DIAGRAM ..................................20
ELECTRIC CIRCUIT DIAGRAM .......................................... 22
SCHEMATIC DIAGRAM
THERMISTOR RESISTANCE CHART .................................
EXPLODED VIEW (INDOOR UNIT) ....................................
EXPLODED VIEW (OUTDOOR UNIT) ................................
PARTS LIST (INDOOR UNIT) ..............................................
PARTS LIST (OUTDOOR UNIT) ..........................................
SERVICE MANUAL
ROOM AIR CONDITIONER

SPECIFICATION
– 1 –
TAG2-62HI
Unit
BTU/h
Cooling Capacity
INDOOR OUTDOOR
—
BTU/h
Heating Capacity —
L/h
phase
Moisture Removal —
Power source
Single
V230
Hz 50
OUTLET
Airflow Method
TOP VIEW
INTAKE
m/min
Air circulation (at High) Cooling ;
Heating ;
W
Electrical Data
Input
Running Current
Starting Current
Inner diameter
Length
—
—
8.0
7.0
A—
—
Cooling ;
Heating ;
9.7
8.0
Cooling ; 760
930
Heating ;
Cooling ; 970
960
Heating ;
A
inch
Piping Connection Port (Flare piping) L L
inch G G
inch
Pipe Size (Flare piping) inch
mm
Drain hose
Height
Width
Depth
—
m—
mm
Dimensions mm
mm
kg
Net Weight
3
; Half Union 1/4''
; Half Union 3/8''
L (liquid side) ; 1/4''
G (gas side) ; 3/8''
; 2-way valve 1/4''
; 3-way valve 3/8''
L (liquid side) ; 1/4''
G (gas side) ; 3/8''
9,500
19,000※
12,200
11,500
21,600※
12,500
14
0.7
8.2※
265
795
192
7.2
265
795
199
8.3
4.5 4.7
550
780
278
SIDE VIEW
TAN-28HIM TAN-32HIM
Cooling ; 1,810※
1,550※
Heating ;
Cooling ; 3.7
4.5
Heating ;
Cooling ; 4.7
4.7
Heating ;
Cooling ; 8.2※
7.0※
36
Heating ;
1.6
2.8※
2.2
※In case two indoor units are operating.

SPECIFICATION
– 2 –
TAG2-62HITAN-28HIM TAN-32HIM
Unit
Air Circulation
INDOOR OUTDOOR
Cross-flow Fan Propeller Fan
18.1FPI 16.9FPI
18 22 40
Induction (4-pole) Induction(6-pole)
W
Heat Exchanger 18.1FPI
Expansion Valve
Plate fin configuration,forced draft
Refrigerant Control Device
g (oz)
Refrigerant (R410A)
–
–
Thermostat
Air Filter
Parts Provided
Electronic Control
Type
Motor Type
Rated Output
–
1200 (42.3)
Mold-proof –
Specifications are subject to change without notice.
1 Mounting plate×2
Timer –
Real time dual ON/OFF
7-hour OFF
2 Remote controller×2
3 Battery (2 pcs.)×2
4 Remote controller holder×2
5 Screw cap (2 pcs.)×2
6 Drain elbow
7 Gum bushing (2 pcs.)
8 Air clean filter×2
Bamboo Charcoal/ Photo-catalytic anti-odor filter×1
Bio-photo Catalytic filter×1

– 3 –
FUNCTIONS
REMOTE-CONTROL TRANSMITTER
ON/OFF
Operation mode selection
COOL
DRY
HEAT
AUTOMATIC
CIRCULATION
Air flow selection
AUTOMATIC
HIGH
MEDIUM
LOW
Negative Ion
Room temperature setting
16°C〜30°C
Timer operation selection
CONTINUOUS operation
OFF
ON
Sleep
Timer / time setting
Operation stops at the set time
(OFF timer)
Operation starts at the set time
(ON timer)
0.5 〜7.0hours(Sleep timer)
Air flow direction control
Auto angle selection
Auto swing mode
Manual mode
INDOOR UNIT
INDOOR UNIT
Sensing the room temperature
Room temperature sensor (thermistor)
Time delay safety control
Restarting is inhibited for approximately
3 minutes.
Indoor fan speed control
High, Med, Low
Operation indication lamps (LED)
ELECT (GREEN or RED)
Lights up green during operation.
Lights up red when negative ions are
generated.
TIMER (YELLOW)
Timer in operation
OPERATE (GREEN)
Outdoor unit operate
Dry operation mode
Automatic fan speed control
Room temperature control
Maintains the room temperature in
accordance with the setting temperature.
Deice (defrost) control
Deicing operation automatically starts
when the heating efficiency is declined by
the ice formed in the outdoor unit.
After deicing operation, heating operation
automatically starts with “Hot start
function.”

– 4 –
FUNCTIONS
Hot-start control (heating)
The indoor fan stops until the evaporator
piping temperature will be reached.
Overload protection
Anti-freezing control for the
evaporator
Compressor will be stopped when the
evapolator’s piping temperature is below
2°C for one minute.
Compressor will be restarted when the
evaporator’s piping temperature is above
2°C.
Airflow direction control
When ON/OFF BUTTON is pressed, the
vertical louver will move to the adequate
positions for each operation automatically.
Manual operation.
The louver starts vertical swing with a
push of the LOUVER BUTTON. Push the
LOUVER BUTTON once again to stop
the louver at the desired position while
swinging.
Auto recovery function
If there is any power failure during
operation, operation status before power
failure is memorized.
3〜4 minutes after power recovery, the
unit restarts automatically with previous
operation status memorized.
(3 〜4 minutes is protective time for
compressor.)
Attention
Because of Auto recovery function, if
shutting off the power supply during
operation, the unit may restart
irrespective your intention when turning
on the power supply next time.
If the unit is not to be used for a long
time, shut off the power supply after
terminating all operation with remote
controller.
OUTDOOR UNIT
Compressor overload protector
When overheating of the compressor is
detected, protector (OHR) stops the
operation of the compressor.
When high current supplied to the
compressor is detected, the main
controller stops the operaiton of outdoor
unit including compressor
3 min. forced operation control
Once the compressor is activated, it does
not stop for 3 minutes.
In case of termination of this operation,
push the ON/OFF button on remote
controller.
Inverter control
Inverter control reduce the ON/OFF times
of compressor, so can keep the room
temperature changeless during
operation.
Electricity consumption
Inverter control can operate with less
electricity consumption than normal air
conditioner.

– 5 –
SERVICE FUNCTION EXPLANATION
Emergency Operation
• Use this operation only when the remote controller is out of order or lost.
•When the emergency operation switch is pressed, beep starts once, which
means the start of this operation.
• In this operation, the system automatically selects the operation modes, cooling
(or heating when available) according to the room temperature, as follows.
• It is not possible to operate in dry mode.
Test Operation
Test operation switch is same as emergency one.
• Use this operation only for testing the performance of the machine in the condition
where the room temperature is less than 16°C.
• Continue to press the test operation switch for more than 5 seconds.
After you hear twice beep, release your finger from the switch: the cooling
operation starts with the air flow speed “HI.”
• If the test operation switch is pressed more than 10 seconds, it doesn’t work.
• After 30 minutes, test operation ends automatically.
When two indoor units used in the same room, interference of the signals may happen. To avoid this, alternative
signal model B can be selected by the following. (Ex-factory setting is mode A)
• Remote controller side : Have “J1” on the PC board short-circuited by soldering.
• Indoor unit side : Cut “R13” on the PC board.
(Each Operations Details)
EMERGENCY AND TEST OPERATION
Beep
Twice beep
<Remote control unit> <Indoor unit>
Receive
Ex-factory setting (Mode A) Ex-factory setting (Mode A)
Cut R13 on the PC board (Mode B)
Have "J1"on the PC
board short-circuited
by soldering (Mode B)
Receive
Not receive
Not receive
J1
Soldering
J1
Temperature
ABOVE 23°C
BELOW 23°C
COOLING
HEATING
26°C
23°C
CONTINUOUS
CONTINUOUS
AUTOMATIC
AUTOMATIC
Operation
mode Designated temperature Timer mode Air flow
HOW TO RELEASE EMERGENCY AND TEST OPERATION
INTERFERENCE PREVENTION OF SIGNALS FROM THE REMOTE CONTROLLERS
• In case of releasing during those operations, you can either push emergency operation switch once more or
apply operation using remote control.
You will hear a beep sound and emergency/ test operation is released.
• If you release the operation by remote control, operation will continue as setting of the remote control
automatically.

– 6 –
OPERATION DETAILS
TIMER OPERATION
ON Timer operation
•Press the ON/OFF switch. Right after replacing new batteries, set the present time in advance.
•Set the “ON Time” : Press the “TIME ADJ” button twice.
Adjust the time with the “ , ” button.
Press the “TIME ADJ” button twice.The setting of “ON Time” is completed and the present time appears on the
LCD.
•Set the “ON Timer” : Press the Timer fixing button “ON”.
OFF Timer operation
•Press the ON/OFF switch. Right after replacing new batteries, set the present time in advance.
•Set the “OFF Time” : Press the “TIME ADJ” button 3 times.
Adjust the time with the “ , ” button.
Press the “TIME ADJ” button once.The setting of “OFF Time” is completed and the present time appears on the
LCD.
•Set the “OFF Timer” : Press the Timer fixing button “OFF”.
Sleep Timer operation
•Press the “SLEEP” button during the operation.
•Set the operating period by pressing the “SLEEP” button until the period designated appears on the LCD.
Timer Cancellation
•ON/OFF Timer : Press the Timer fixing button “ON”(On Timer) and/or “OFF”(Off Timer) once again.
•Sleep Timer : Press the “SLEEP” button until the operating period on the LCD disappears.
AIRFLOW DIRECTION CONTROL
Vertical adjustment
When ON/OFF switch is pressed, the vertical louver will move to the adequate positions for each operation
automatically.
Swing of air flow
If air flow direction switch is pressed once, the vertical louver will move within the range of figures.
Fixing the flow direction
If air flow direction switch is pressed again, the vertical louver will be fixed and that position is memorized.
From the next operation the louver will be set at previous position automatically.
Notes :
•In Swing Mode, the louver automatically moves up and down within the certain range, as the illustration below.
•There is two different ranges of louver swinging; one is of cooling & dry mode operation and the other is of
heating operation.
Level
Approx.10 degrees
Approx.65 degrees
Standard Position
Approx.10
Approx.50
Approx.65
(Cooling/Dry)
(Heating)
degrees
degrees
degrees
Level
Swing of Air Flow
Cooling
Dry
Heating

– 7 –
OPERATION DETAILS
TIME DELAY SAFETY CONTROL FUNCTION - FOR PROTECTION OF COMPRESSOR
•Compressor will not restart, in any operation modes, for 3 minutes after its stop.
•Compressor does not stop during the first 2 minutes of its operation even if the room temperature reaches to
the designated temperature, except changing setting temperature.
TAN-28HIM
TAN-32HIM
one indoor unit operation
★1
50.0Hz
60.0Hz
★2
20.0Hz
20.0Hz
two indoor units operation 85.3Hz 20.0Hz
-1˚C
MAX MAX
★1★1
MIN★2MIN★2
-0.3˚C
0Hz
Frequency of
Designated
compressor
temperature
Room temperature
COOLING MODE OPERATION
•The compressor will stop when operational frequency reached the minimum frequency and that condition has
been kept for 2 minutes and the room temperature becomes 1°C lower than it was set.
•When two indoor units are operating simultaneously, even if only another room temperature reachs the designated
temperature, the compressor does not stop.
The expansion valve of another cycle is closed completely to stop refrigerant flow.
•The compressor will re-start when room temperature becomes 0°C higher than it was set.

– 8 –
OPERATION DETAILS
DRY MODE OPERATION
•Compressor stops when the room temperature fall to 0.3°C lower than the designated temperature
continuously for 2 minutes.
•Compressor restarts when room temperature rises to the designated temperature.
•The operating frequency of the compressor is determined according to the room temperature
(see the diagram below).
TAN-28HIM
TAN-32HIM
one indoor unit operation
★1
50.0Hz
60.0Hz
★2
20.0Hz
20.0Hz
two indoor units operation 85.3Hz 20.0Hz
Indoor fan Selected
speed Selected speedstop
3min.
Super
low
MAX MAX
0
Hz
Frequency of
compressor
Designated
temperature
Room temperature
★1★1
MIN★2MIN★2
-1˚C
-0.3˚C

– 9 –
OPERATION DETAILS
TAN-28HIM
TAN-32HIM
one indoor unit operation
★1★2
two indoor units operation
60.0Hz
70.0Hz
20.0Hz
20.0Hz
85.3Hz 20.0Hz
20sec.
+4.0
MAX
★1
MAX
★1
MIN★2MIN★2
+5.0
0Hz
Super
Low
Frequency of
compressor
Designate Fan blowLow Super lowLow Low Designated Fan blow
Designated
temperature
Room temperature
Stop
Temperature,
indoor heat
exchanger
Indoor fan
35˚C
30˚C
15˚C
HEATING MODE OPERATION
•The compressor will stop when operational frequency reached the minimum frequency and that condition has
been kept for 2 minutes and the room temperature becomes 5.0°C higher than it was set.
•When two indoor units are operating simultaneously, even if only another room temperature reachs the designated
temperature, the compressor does not stop.
•The compressor will re-start when room temperature becomes 4.0°C higher than it was set.
NOTICE
Warm air comes out from one of the indoor units during circulation or negative ion mode when the other indoor
unit is in heating operation.
