TradeTuff Eclipse SAL24 User manual
User Manual
Eclipse 24W Solar Light &
Booster Panel
Eclipse 24W Solar Light & Booster Panel
SPECIFICATION
INTRODUCTION
• Solar powered lights do not work without sunlight. Position light so that the solar panel is in an unshaded postition.
In areas that are short of light or after continuous days of rain, the Eclipse may only charge enough to provide the
main light as the courtesy light ceases to function when the battery level drops below 40%
• The Eclipse should be mounted in an area free of trees and shade so maximum sunlight can fall on to the panel
• The Eclipse solar light is designed to work perfectly using the integral solar panel, provided that the panel is oriented
towards the sun
• If your desired location restrics this, there is an optional extra panel and battery pack
• The Eclipse Solar Booster Panel is designed for the Winter months and areas that do not get a lot
of direct sunlight to charge the Eclipse Area Light
• The Booster Panel is made of the same high quality casing as the light and incorporates an additional
7.4V 4400mAh battery which doubles the runtime up to 20 hours on low mode 20% power or 14 hours with 20
triggers at full power
• The Booster Panel can be mounted either back to back with the Eclipse Light on a pole or separately
whichever is best to get maximum sunlight
Model No. SAL24
Wattage 24 Watt
Lumens 1800
Standby Light Lumen Output Level (±10%) 360
Light Distribution Angle (to half intensity) 100º
Lamp Color Temperature 5700k Natural White
Sensor Detection Range (approx. radius) up to 4m
Installation Height (optimum) 4m
Integral Solar Panel 6.5 Watt 12V
Battery (lithium-ion) 4400mAh @ 7.4V
Max Run Time* (8hr charge/singlepanel/20 triggers) 7 hours
Max Run Time* (8hr charge/singlepanel/20 triggers WITH booster) 14 hours
Max Run Time* (8hr charge/singlepanel/NO triggers) 11 hours
Max Run Time* (8hr charge/singlepanel/NO triggers WITH booster) 22 hours
Battery Charging Temperature Range** 0-80ºC
Battery Discharging Temperature Range -20 - 60ºC
Protection Range IPX5
Pole Diameter (OD mm) 60 - 90mm
Housing Powdercoat Aluminium with 306
stainless steel xings
Nett Luminaire Weight 2.1kg
* Max Run Time based on fully charged batteries, insucient sunshine hours may reduce run time.
** Built-in charge controller prevents inecient charging outside these parameters.
INSTALLATION
Parts included with each light tting:
1 x Eclipse 24W Solar Light
1 x Wall / Pipe Bracket
1 x Mounting Kit
• It is very important that the 2 connecting cables are attached to the light with the correct matching colour codes,
failure to do so may result in damage to the unit
• It is important that the Eclipse light tting is mounted on a pole or wall that places it in direct sunlight
• The recommended mounting height is 4-6m
• Please open the package and ensure all the part are complete
• Before installing the Eclipse, turn unit on and place the light on the ground with the solar panel facing
down and check to see that the unit illuminates to its low-light or courtesy light level. Sweep your hand
over the sensor and check the light increases it’s brightness to 100% power and stays on for a period
of time (30seconds) before returning to courtesy light. Once satised install the light
• The Eclipse is designed to be tted directly onto poles of diering sizes or, using half of the bracket, directly
onto a wall
BATTERY MANAGEMENT SYSTEM
The battery operation is digitally controlled by the built-in micro-processor and this programme ensures that as the
battery power is depleted, the tting will still operate in an ecient manner. The following table demonstrates how the
battery will perform as the % of power reduces.
100% - 60% Battery
Power
60% - 40% Battery
Power > 40% Battery Power
Full Light (PR) YES - 30 secs exposure YES - 30 secs exposure YES - 30 secs exposure
Courtesy Light YES YES NO
CLEANING THE SOLAR PANEL
Although no part of the Eclipse requires maintanence, routine cleaning of the solar panel will allow it to perform at peak
capacity. In winter, keep snow and ice from building up on the solar panel so the battery charges properly.
LIGHT DOES NOT OPERATE AT
If the Eclipse does not operate at dusk, despite observing the instructions of this manual, please try the following:
• Ensure the solar panel is not shaded or otherwise obstructed during the day
• Ensure the ON/OFF switch has been activated (i.e. In the ‘ON’ position)
Parts included with booster panel are as follows:
1 x Eclipse Booster Panel with 32.5W Li-ion battery
1 x Universal Bracket for pole mounting horizontally/vertically
(Can also be mounted direct to a wall)
4 x Sets Stainless Steel Nuts, Bolts and Locking Washers.
TradeTu, Unit 21, Western Road, Stratford-upon-Avon, Warwickshire, CV37 0AH
Email: info@tradetu.co.uk
Tel: 0800 292 2188
tradetu.co.uk
TradeTu products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship
for a period of 12 months from the date of purchase, provided that the enclosed instructions have been followed. Should you experience problems with
your TradeTu product, please return the item, complete with any chargers, to your place of purchase or contact Trade Survey direct. Your TradeTu
guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe handling, alterations, accidents or
repairs attempted or made by any personnel without prior approval from Trade Survey. Your TradeTu guarantee is not eective unless you can provide a
dated proof of purchase. Please note that this guarantee does not aect your statutory rights. If at any time, you need to dispose of this product or parts
of this product: Please note that waste electrical products, bulbs and batteries should not be disposed of with ordinary household waste. Recycle where
facilities exist. Check with your local authority for recycling advice.
GUARANTEE TERMS
BATTERY MANAGEMENT SYSTEM
This product contains lithium-ion batteries.
Lithium-ion cells and battery packs may get hot, explode or ignite and cause serious injury if exposed to extreme
conditions. Be sure to follow the safety warnings listed below:
• Do not open the Eclipse or tamper with the circuitry and battery inside
• Do not connect the positive terminal and the negative terminal of the battery pack to each other with
any metal object (such as wire)
• Do not disassemble or modify the Eclipse or the battery. Both the Eclipse and the battery contain
safety and protection devices, which, if damaged, may cause the battery to generate heat, explode
or ignite
• Do not place the battery in a microwave oven, high pressure container or induction cooker
• In the event that the battery leaks and the uid gets into your eye, do not rub the eye. Rinse well with
water and immediately seek medical care. If left untreated, the battery uid could cause damage in
the eye
