Tramex CME5 Concrete Moisture Encounter 5
Conforms to: ASTM F2659
The Tramex Concrete Moisture Encounter 5 (CME5) is a non-destructive analog moisture meter for concrete floors and
slabs providing instant and precise quantitative measurement of moisture content using Gravimetric testing as a baseline.
The CME5 also provides Carbide Method equivalent readings for concrete and other cementitious substrates as well as
comparative readings as per ASTM F2659
The Concrete Moisture Encounter detects and evaluates the moisture conditions within the slab or screed by non-
destructively measuring the electrical impedance. A low frequency electronic signal is transmitted into the material under
test via the electrodes in the base of the instrument. The strength of this signal varies in proportion to the amount of moisture
present in the material.
The Concrete Moisture Encounter determines the strength of the current and converts this to a moisture content value for
concrete slabs and a comparative value for other cementitious floor screeds, displayed on a large clear analog dial.
Features
•Non-destructive in operation with no need to probe, drill or mechanically damage the surface.
•Clear easy-to-read analogue dial.
•Instant and precise readings to a depth of approximately 20mm into the slab.
•Bluetooth connection to accompanying IOS & Android App allowing for continual development and integration of
apps and reporting.
•Hold function “freezes” meter reading when inspecting areas where the meter face is not visible, and for easy
recording of data.
•Reproducible and reliable results.
•CM Carbide Method moisture content equivalent readings.
•Spring-loaded contact pins compensate for uneven concrete and boost signal penetration.
•Rugged ergonomically designed enclosure.

BAMR (Pty) Ltd, 4 Palm Street, Newlands, 7700, South Africa
Ph: 021 683 2100, WhatsApp: [phone]
[email protected], www.bamr.co.za, www.gaugeit.co.za
Page 2 of 2
Technical Specifications
CME5 Tramex CME5 Concrete Moisture Encounter
Measuring range
Moisture Content for Concrete: 0 to 6%
Carbide Method moisture content equivalent for Concrete: 0 to 4
Carbide Method moisture content equivalent for Anhydrite: 0 to 1.9
Display Analogue
Depth of penetration 20 mm approx
Construction ABS Body
Power 2 x AALR6 ALKALINE (included)
Size 160mm x 85mm x 38mm
Weight 344g
Packing List
Tramex CME5 Concrete Moisture Encounter 5
Hard Carry Case
Batteries
Wrist Strap
Instruction Manual
How it works
The Tramex Concrete Moisture Encounter detects and evaluates
the moisture conditions within the slab or screed by non-
destructively measuring the electrical impedance.
A low frequency electronic signal is transmitted into the material
under test via the electrodes in the base of the instrument. The
strength of this signal varies in proportion to the amount of moisture
present in the material.
The Concrete Moisture Encounter determines the strength of the
current and converts this to a moisture content value or CM
Equivalent value for concrete slabs and other cementitious floor
screeds, displayed on a large clear analogue dial.
Operating Procedure
To carry out tests simply brush any dust from a smooth area of concrete and also from the electrodes, switch on the
Concrete Moisture Encounter and place it firmly onto the surface, fully compressing the spring-loaded, signal-enhancing
contacts on the base. Read the moisture content from the clear analogue dial. The Concrete Moisture Encounter is
calibrated to give percentage moisture content readings on clean, bare dust free concrete floor slabs, with a depth of
penetration of approx. 20 mm. Readings taken on concrete slabs through paint, coatings, adhesives or other materials on
the surface should be regarded as qualitative or comparative and not quantitative.
