Emerson SolaHD STC-HSP Series User manual

Surge Protective Devices
STC-HSP Series

Safety Information
Important Information
Read these instructions carefully and look at the equipment to become
familiar with the device before trying to install, operate, service or maintain it.
The following special messages may appear throughout thisbulletin or on the
equipment to warn of potential hazards or to call attention to information that
clarifies or simplifies a procedure.
The addition of either symbol to a “Danger”or “Warning” safety label
indicates that an electrical hazard exists which will result inpersonal
injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messagesthat follow this
symbol to avoid possible injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderateinjury.
NOTICE
NOTICE is used to address practices not related to physical injury. The safety
alert symbol shall not be used with this signal word.
Please Note
Electrical equipment should be installed, operated, serviced, and maintained only
by qualified personnel. No responsibility is assumed by Appleton Grp LLC d/b/a
Appleton Group for any consequences arising out of the use of this material.
A qualified person is one who has skills and knowledge related to the
construction, installation, and operation of electrical equipment andhas received
safety training to recognize and avoid the hazards involved.

Page: 1
STCHSP121BT1RU
Introduction
The STCHSP121BT1RU is an advanced 3-stage hybrid, solid state power line protective device. Features
such as noise ltering, common mode and normal mode suppression, nanosecond reaction time, power line
tracking, and compression screw terminations, make this device an excellent choice in commercial
and industrial applications.
This SPD offers a replaceable fuse designed to remove the load from the line in the event the unit is overloaded
or the internal protection stops working.
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E,
NOM-029-STPS or CSA Z462.
• This equipment must only be installed and serviced by qualied electrical personnel.
• Turn o󰀨 all power supplying this equipment before working on or inside equipment.
• Always use a properly rated voltage sensing device to conrm power is o󰀨.
• Replace all devices, doors and covers before turning on power to this equipment.
• This equipment must be installed inside an enclosure and located so, as to prevent accidental contact with
terminals during maintenance or servicing.
• Connect only to 120 VAC, 15 Amp Max., single phase, three wire circuit.
• Disconnect AC source before replacing fuse. For proper operation, replace only with same type rating of fuse (3
AB,15 A/250 V).
Failure to follow these instructions will result in death or serious injury.
WARNING: This product can expose you to chemicals including DINP, which is known to the State of
California to cause cancer, and DIDP which is known to the State of California to cause birth defects or other
reproductive harm. For more information go to: www.P65Warnings.ca.gov.
NOTICE
LOSS OF SURGE SUPPRESSION
• Make certain that Surge Protective Device is disconnected from the circuit it is protecting before conducting high
potential insulation testing.
Failure to follow these instructions can result in equipment damage.
DANGER

STCHSP121BT1RU
Page: 2
Installation
1. Turn off all power supplying this equipment before working on or inside equipment.
2. Mount the STCHSP121BT1RU in a UL-approved housing. Keep all leads as short as possible.
3. Position unit within the equipment cabinet so that the fuse holder is accessible.
4. Secure the STCHSP121BT1RU using up to six screws to t 3/16 in. [4.76 mm] hole openings.
5. Make sure wiring from power sources properly connects to "LINE" side of the unit (torque to
7 in. lbs.). Wiring from protected equipment must properly connect to the "EQUIPMENT" side of the
STCHSP121BT1RU (torque to 7 in. lbs.). (See Figure 1.)
6. Connect only to 120 VAC, 15 Amp Max., single phase, three wire circuit.
7. Replace the barrier, cover/door and/or trim to the equipment.
8. Equipment may be re-energized after all the above steps are complete.
Diagnostic Operation
Indicator Status ON =
The device is installed correctly and the line side has power.
Indicator Status OFF =
Check connections, verify that the line voltage is at the point of connection; if all is correct,
then replace the device.
Fuse Replacement
1. Determine the model number – this is located on the silver UL label.
2. Ensure all power is removed from the device.
3. If the unit is catalog number STCHSP121BT1RU. the fuse holder will be located on the side of the
enclosure. (Reference Figure 1.)
4. Using a slotted screwdriver, turn the fuse cover 1/4 turn clockwise, this will free the fuse cover.
5. Remove the existing fuse and replace with same type rating of fuse (3 AB,15 A/250 V).
6. Replace all devices, doors, and covers before turning on power to the equipment.
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. See NFPA 70E,
CSA Z462, or NOM-029-STPS.
Failure to follow these instructions will result in death or serious injury.
DANGER

Page: 3
STCHSP121BT1RU
Figure 1: STCHSP121BT1RU fuse holder location
Dimensions (in. / mm.)
4.86 [123.44]
1.17
[29.72]
1.17
[29.72]
5.25 [133.35]
Holes 3/16 [4.76] DIA
2.95
[74.93]
LIGHT ON: NORMAL
LIGHT OFF: SERVICE
LINE
EQUIPMENT
AC
NEUTRAL
GROUND
AC
NEUTRAL
GROUND
STC-SLAC Series
Surge Protective Device
STC-HSP121BT1RU
EXPOSED TERMINAL DESIGN

STCHSP121BT1RU
Page: 4
General Technical Specifications
Operating Voltage 120 VAC
Clamping Voltage 200-240 VAC
Operating Current 15 A
Peak Surge Current 39 kA (8 x 20 µs)
Operating Frequency 47-63 Hz
EMI Attenuation > 40 dB (100 kHz to 100 MHz)
SPD Technology Metal Oxide Varistors (MOVs) w/ L-C Filter
Modes of Protection Line-to-Neutral, Line-to-Ground,
Neutral-to-Ground
Status Indication Power On & MOVs functional
Connection Type 3 position terminal block
w/compression screws
Terminals accept up to 14 AWG
Operating Temperature -40°C to +85°C
Dimensions (in. / mm.) Exposed Terminal Design: 1.8 x 2.9 x 5.3 in.
[46 x 75 x 133 mm.]
Weight (oz. / kg.) 10 oz. [0.28 kg.]
Certifications UL 1449 recognized
Limited warranty 5 years
Model STCHSP121BT1RU
MODEL (Former Model Name) APPLICATION
HSP121BT1RU 120VAC (L,N,G), 15Amp,
Single Phase, Exposed Terminal Design

Page: 5
STCHSP121BT1RU
Technical Support
Website: www.solahd.com
Technical Support E-Mail: [e-mail]
Toll-Free: [phone]
USA: [phone]
Warranty
Please see the “Terms & Conditions of Sale” document.
While every precaution has been taken to ensure accuracy and completeness in this manual, Appleton Grp LLC d/b/a Appleton Group
assumes no responsibility, and disclaims all liability for damages resulting from use of this information or for any errors or omissions.

STC-HSP Series
A272-332 Rev. 0 08/2020
