TRASSIR TR-D6254IR15 User manual

TR-D6254IR15
Specification
TR-D6254IR15
1/2.8" CMOS 5MP
5MP(2560x1920)
4MP(2560x1440)
5MP@20fps
4MP/3MP/FullHD@25fps
1/1 ~ 1/30 000 sec
Mechanical ICR
0.005Lux (F1.3) / 0Lux(IR on)
up to 150 meters
4.9-156 mm, F1.35-F4.4
54.5˚ - 2.24˚ / 30.3˚ - 1.27˚
x32
x16
Pan: 0° ~ 360° (infinite)
Tilt: -10° ~ 90° (autoflip to 180°)
Pan: 0.1°/s ~ 300°/s
Tilt: 0.1°/s ~ 200°/s
Pan: 400°/s
Tilt: 300°/s
Yes
Real WDR (120dB)
2DNR / 3DNR
Н.265+ / Н.265 / H.264+ / H.264
up to 20Mbps
MicroSD up to 256GB
Two-way audio channel
Yes (up to 8 zones)
Yes
Yes
2 / 1
PoE+ (802.3at) / 24V AC (3A)
4
24W (IR on)
TVS 6000V
Aluminium
478.4 x 295.1 x 185.7
3900 / 7010
IP66
-40°C … +70°C
Model
Image sensor
Resolution
Frame rate
Electronic shutter speed
"Day/Night" mode
Sensitivity
IR range
Lens (мм)
Field of view (horiz./vert.)
Optical zoom
Digital zoom
Pan/Tilt Range
Manual Control Speed
Preset Speed
Auto focus
WDR
Digital noise reduction
Video compression
Bitrate
Local storage
Audio
ROI
IVS
RTC
Alarm IN/OUT
Power supply
PoE Class
Power consumption
Lightning protection
Case material
Dimensions (mm)
Weight Net/Gross (g)
Ingress protection
Working temperature
5MP IR outdoor high-speed PTZ camera
Note: read user manual before using
Website: www.trassir.com
For any inquiry: inf[email protected]
Technical support
www: helpdesk.trassir.com
mail: helpd[email protected]
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
H.265+
HEVC
120dB
150m
5MP x32
ZOOM

766-10.9.21
Key features
• Supports H.265+ codec
• Wide dynamic range (Real WDR 120dB)
• IR range up to 150 meters
• Built-in video archive (Edge Storage) – local recording
on MicroSD card* up to 256GB
• IVS: Human / Face detection; Line crossing / Intrusion detection ;
Abandoned / Missing objects detection; Autotracking; Motor vehicle /
Non-motor vehicle detection
• Two-way audio channel (1 in / 1 out)
• Alarm IN/OUT (2/1)
• TCP, IPv4/v6, HTTP, UDP, UPnP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2),
ARP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, ONVIF
protocols
• IP66 weather-tight case
• 24V AC or PoE+ power supply
• Lightning protection: TVS 6000V**
___________________________
* MicroSD card is not included into camera package
** The device must be grounded
Introduction
Congratulations on purchasing TR-D6254IR15 IP camera .
Please read User Manual before using the camera.
Manual setting of network parameters
In order to connect to the IP camera, the PC should be in the same local
network as the camera. The IP address of the camera, the PC and any
other device on the network should not match.
IP camera has the following default settings:
- IP address: 192.168.1.188
- Subnet mask: 255.255.0.0
- Gateway: 192.168.1.1
- HTTP-port: 80
- username: admin
- password: admin
PC network settings example:
- IP address: 192.168.1.10;
- Subnet mask: 255.255.0.0.
There are 3 options to set up your camera:
1. Change IP address of a camera manually.
Start your browser, connect to IP camera and enter your
username and password. Choose appropriate menu item and change
network settings of IP camera.
2. Set up camera IP address using fast configuration utility that can be
downloaded from www.trassir.com.
3. Change IP camera settings using TRASSIR professional software.
You can find detailed camera settings instructions in User Manual that
can be downloaded from trassir.com.
Attention!
The power supply should meet the following requirements: output
voltage, current, polarity, and working temperature. When using the
camera in thunderstorm conditions, make sure there is a lightning rod or
unplug the power connector.
Pay attention to the temperature requirements for IP camera operation.
Avoid using the device in excessively high or low temperatures.
Do not install the camera near heaters. Do not point the camera lens at
the sun or at bright objects as this can damage the image sensor.
Connecting
To get started with IP camera you are required to have a PC connected to
the local network with Windows installed and Internet Explorer version 8
or higher.
1. Connect IP camera to the network.
2. When the camera is connected through a switch which doesn't support
PoE, connect adapter to power jack.
Dimensions
Camera package
1. IP camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
2. User manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
3. Wall mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
4. Waterproof Coupling Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
5. Hexagon wrench . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
6. Antistatic glove . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
7. Power supply unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
153,8
185,7
283,4
309,8
47
478,4
119
160
84
115
109,4
295,1
