TravelScoot Deluxe 160 User manual

Owner's Manual
2019 Edition
Please read all important safety information before riding your TravelScoot for the first time.

2
For answers to your questions, call 1-877-339-7505
TravelScoot Parts
Please ensure that you have the following parts when you unpack your TravelScoot for the first time:
1. Carry Bag
2. Main Frame
3. Backrest
4. Seat
5. Battery
6. Tool kit and Seat Spacers
7. Battery Charger
8. Caddy
9. Front Wheel
10. Yoke
1
.
2
10
8
3
4
5
6
7
9
Please keep the original box for returns or
warranty-related shipping.

3
For answers to your questions, call 1-877-339-7505
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 4
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 5
General Safety and operating on slopes, Maneuverability, Pre-Ride Safety Check,
Indoor Use, Outdoor Use, Securing the TravelScoot
Assembling your TravelScoot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 7
Attaching the Front Wheel, Unfolding your TravelScoot, Handlebar Assembly
and Height Adjustment, Battery Installation, Seat Assembly, Installing the Fabric Caddy,
Folding your TravelScoot
Battery Charging Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 9
Additional Battery Information, Battery Information for Foreign Travel,
Battery Tips
Getting on and off your TravelScoot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 10
Operating your TravelScoot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 10
Plug in the Battery, On/Off Switch and Forward/Reverse Selector,
Throttle, Brake Levers, Parking Brakes, Seat Spacers, Turning with
your TravelScoot
Travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 11
Air Travel
Cruise Ship Travel
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 13
Cleaning Tips
Brakes, Lubrication, Tightening
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 14
Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 15
TravelScoot Components and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pg. 16

4
For answers to your questions, call 1-877-339-7505
Introduction
Congratulations on your purchase of the TravelScoot electric mobility scooter. The TravelScoot combines state-of-the-art
components with safety, comfort, and portability. We are confident the design features of the TravelScoot will provide you with the
conveniences you expect during your daily activities and travelling abroad.
This owner’s manual will provide you with valuable information about the proper use, care, and maintenance of your new
TravelScoot. Understanding how to safely operate and care for your Scooter should give you many years of trouble-free scooting.
Please take a few moments and read these instructions thoroughly to familiarize yourself with all aspects of the TravelScoot.
NOTE: This owner’s manual is based on the latest specifications and product information available at the time of publication. We
reserve the right to make technicalas well aseditorial changes as they become necessary. Any changesto ourproducts may cause
slight variations between the illustrations and explanations in this manual and the product you have purchased.
Product Support
TravelScoot Canada is the sole distributor of the TravelScoot mobility scooter in Canada. We provide support and replacement
parts for all of our products found online. If you need to contact us for support, please email or call us. Most questions or concerns
can be addressed with a phone call to us. For help with installation of our products and replacement parts, we recommend you visit
our YouTube channel at https://www.youtube.com/c/travelscootusainc.
Information Exchange
Business Cards
New TravelScoot owners discover that they quickly become the talk of the town as people will chase them down, stop them, and
bombard them with questions and requests for demonstrations. To help with this new-found popularity, we have included a stack
of business cards to help you better manage your time. We firmly believe that we have the best customers in the world. Thank you
for your kindness, generosity, and patience as youshare your experienceswith others regarding the TravelScoot. If you need more
cards, please do not hesitate to contact us for more.
TravelScoot Canada
Toll Free: 1 (877) 877-339-7505
Email: [e-mail]
www.travelscoot.com

5
For answers to your questions, call 1-877-339-7505
Important Safety Information
Attention! Please read this manual in full before operating your new TravelScoot for the first time.
The TravelScoot is designed for persons who have walking difficulties but who are otherwise fairly mobile. Make sure that the
TravelScoot is right for you. Persons who are confined to a wheelchair and/or require constant personal care should NOT use the
TravelScoot.
Below are some precautions, tips, and other safety considerations that will help you become accustomed to operating the
TravelScoot safely.
General Safety
•Investigate and complywith all local laws regarding personal mobility scooter use.
•As with bicycles, it is strongly recommended that you wear a helmet.
•Please note that the TravelScoot does not come equipped with anti-tipping wheels or other similar devices.
•This product is not a toy or a recreational vehicle.
•Always ensure that the power button is turned OFF and the parking brakes are engaged before getting on or off the seat
for any reason.
•To prevent misuse, remove the battery when the scooter is unattended. The battery can drain if left plugged in for
prolonged periods of time.
•Do not tow anything by the backrest.
•Do not operate at night unless adequate front and rear lights are attached.
•Avoid prolonged exposure to rain, snow, ice, salt, or standing water, whenever possible.
•Maintain and store in a clean and dry condition.
•Be aware that loose-fitting clothing can become caught in the drive tires.
•The TravelScoot should only be ridden on fairly hard-packed surfaces.
•Use your common sense. Reckless driving can result in an accident.
Take your time and soon you will be in full controlas you confidently maneuver throughdoorways, on and offelevators, and up and
down ramps.
Slopes
The center of gravity (C.G.) on an incline, such as ramps, is shifted toward the rear. Tipping over backwards is possible, but can be
easily avoided. To avoid such accidents, do the following:
•Always shift your upper body toward the handlebars in order to move your C.G. forward.
•Always twist the throttle slowly, even on level ground! The motor has high torque. Quickly twisting the throttle, causing
excessive acceleration, could tip you over backwards in extreme cases.
•Always be prepared to apply your brakes when ridingdownhill. Do not allow your scooter to go faster than you could walk
down the hill.
•Avoid starting on an incline from a full stop. Approach a ramp with reasonable speed and utilize the vehicle’s momentum.
•Approach an incline only if you are sure that you will reach the top without having to stop. If you are forced to stop along
the way, restart by shifting your upper body forward, and accelerating gently.
•When approaching an incline, do not zigzag or drive at an angle up the face of the incline. Drive your scooter straight up.
This will greatly reduce the possibility of tipping or falling.
•Never travel up or down a potentially hazardous incline (e.g., areas covered with ice, snow, cut grass, wet leaves, gravel,
etc.) Do not drive in mud unless unavoidable. Exercise caution when riding on snow.
•When driving down a ramp, release the throttle and keep both hands ready to apply the brakes to ensure a safe, controlled
descent.
•If you drive your scooter down a longer slope, continuously apply the brakes. Under nocircumstances allow it to gain more
than walking speed or you may not be able to stop quickly enough.
•Speed bumps, lowered curbs, and other slightly uneven conditions are generally no problem, but they should be taken
head on at a reduced speed. Never approach them at an angle, and observe the same precautions as on inclines. Keep in
mind that the small wheels cannot roll over objects much higher than 1 inch. Lower objects should be approached with

6
For answers to your questions, call 1-877-339-7505
moderate speed. If you are at a stop and one of the wheels is blocked by such an object, do not apply the throttle. Doing so
may result in tipping over, or abrupt acceleration, once the blocked wheel breaks free.
Maneuverability
•Practice riding in large, open areas, free of pedestrians, vehicles, and obstacles.
•Doorways can be a real nuisance, especially when they are spring-loaded. If possible, ask a nearby person to hold the door
open. Avoid using your feet to hold doors open while passing through them. Instead, power off the scooter and push it
through the door.
•Always slow down before changing direction or making hard turns.
•The TravelScoot is designed for use by one person only. Carrying passengers may affect the center of gravity and may
cause the TravelScoot to tip or fall.
•Do not start from a standstill with the front wheel sharply turned.
•If you tow by hand (your left hand), keep in mind you can only operate one brake (the right brake). Be sure to drive slowly
and do not lean against the backrest.
Pre-Ride Safety Check
Get to know the feel of your TravelScoot and its capabilities. We recommend you perform a safety check before each use to ensure
your TravelScoot operates smoothly and safely. Please check the following:
•Battery connectors are connected.
•Battery is sufficiently charged.
•Locking pins are fully engaged.
•Brakes are working properly.
•Parking brakes are disengaged before use.
•No wiring is wrapped around the steering column.
The TravelScoot is a handicapped mobility device. As such, you are permitted to use it wherever pedestrian traffic is permitted.
Before driving on public streets, be sure to check local laws as regulations may vary.
Indoor Use
In general, you are permitted to use the TravelScoot inside buildings such as airports, shopping malls, stores, theatres, etc.
However, you are obligated to adjust your speed to match walking traffic. Do not ride on escalators!
Outdoor Use
You can drive across short sections of grass or gravel surfaces as long as they are level and reasonably firm. Approach them with
moderate speed. Dependingon your weight, you may not be able to restart on these types of surfaces from a stop. Prolonged riding
under such conditions could quickly exhaust your battery.
The electricmotor, wiring, connectors,batteries,and controlson the TravelScootcan bedamaged ifexposedto water.Avoid driving
through large puddles. If you cannot avoid puddles, cross them at an extremely low speed in order to avoid splashing water on the
controller andmotor. Once indoors, dry your scooter with a towel and usea hairdryerto apply warmair toall electrical connections
to dry thoroughly. See the Maintenance section of this manual for further maintenance.
Securing the TravelScoot
The TravelScoot does not come with a lock and key. Due to its ultra-light weight, a key would not prevent a thief from stealing the
scooter and running off with it. Any locksmith could makea key for the scooter, negating the purpose of including a lock. Therefore,
it is recommended that you buy a simple chain or cable type bicycle lock to be placed around either rear fork on the TravelScoot.

7
For answers to your questions, call 1-877-339-7505
Assembling your TravelScoot
Each TravelScoot has been test-driven before shipment. The wheels may show signs of that brief test drive.
Setting up your TravelScoot initially may require a little time. Be patient. With practice, you’ll be able to do it in no time at all. For a
video of this setup, please type in the following address into your search bar: https://youtu.be/wFGhS9gDuWg or just go to our
YouTube channel.
Attaching the Front Wheel
Unfolding your TravelScoot
To unfold your TravelScoot, ensure the rear wheels are resting on the ground. If the rear wheels are not fully supported on the
ground, the locking pins will be difficult to push in.
a. Reach underneath the steering column and compress one of the two locking pins.
b. Partially unfold the trailing arm.
c. Repeat this step for the other trailing arm.
d. Lift the steering column upwards until both trailing arms lock into place with an audible “click”.
e. Make sure that both trailing arms are locked in place (this is an important safety check).
Handlebar Assembly and Height Adjustment
a. Insert the hand grips into the T-handle atop the steering column. Make sure the spring-loaded buttons lock into the
corresponding holes. NOTE: The handgrips are not separable on the Shopper model.
b. With the scooter unfolded and on its wheels, locate the steering column clamp. Loosen it and adjust the handlebar
height to your liking, and lock in place.
c. Ensure that the On/Off Switch, mounted on the left side of the handlebars, is in the “OFF” position.
Attach the front wheel to the main frame of the TravelScoot by inserting it into the steering
column. Make sure that the spring-loaded button locks into the corresponding hole. If you
are met with resistance, raise the handlebars slightly and try again.
Note: The front wheel is permanently attached on the Shopper model.

8
For answers to your questions, call 1-877-339-7505
Battery Installation
a. Place the batteryinto the Velcro-lined batterytray between the rear wheels of the scooter with thebattery plug facingthe
rear-left wheel.
b. Connect the battery plug to the corresponding plug on the TravelScoot motor.
c. Secure the battery with the two Velcro straps. The ends are to remain loose.
Seat Assembly
It is recommended that you keep the seat post inserted in the yoke as far as possible while still at a comfortable height. The higher
the seat is mounted, the more your C.G. will be affected. When adjusting the seat height, do not raise the seat higher than 2.5 inches
or the combined height of the seat spacers. To assemble the seat:
a. With the lever clamp(s) open, insert the yoke into the receptacles next to the battery tray.
b. Note that one stem of the yoke is narrower. This stem canonly fit into the right receptacle.
c. Insert both stems fully into the two receptacles at the same time and push firmly into place.
d. Once yoke is in place, tighten the lever clamp(s).
e. Install the seat in the top of the yoke and tighten the seat clamp.
f. Insert the backrest elbow into the back of the seat, depress the spring lock, and slide in place until the spring lock is
through to the other side. It may be easier to perform this step before installing the seat.
g. The lever clamps may need to be adjusted from time to time to hold the seat and the yoke in place. Test to make sure the
seat is secure in the yoke and that the yoke is secure in the receptacles (if lever is too tight or too loose, remove the seat
post and adjust).
h. The backrest on the TravelScoot can be adjusted for your comfort. Simply loosen the two bolts holding the backrest
cushion to the backrest stem. Move the cushion to the desired height and re-tighten the bolts.
Note: The above instructions are for initial setup. Many customers find it unnecessary to disassemble the seat assembly after
initial setup, and prefer to remove the whole seat assembly by releasing the clamps at the base of the yoke.

9
For answers to your questions, call 1-877-339-7505
Installing the Fabric Caddy
Note: Individualswho need a space to step throughin order to safely get on and off the TravelScoot may wish to leave off the Caddy.
Folding your TravelScoot
•Ensure that the power button located on the left handlebar is in the “OFF” position.
•Release the steering column clamp, lower the steering column to the desire height, then tighten the steering clamp.
•Remove the seat assembly by releasing the clamp(s) holding the yoke.
•With the seat assembly removed, disconnect the battery by squeezing the battery connector buttons, then loosen the
Velcro straps and remove the battery.
•With all three wheels touching the ground, locate and depress one of the two locking pins.
•Grasp the steering column and wheel on the side you released the locking pin and move toward the unlocked trailing arm,
allowing it to fold slightly.
•Repeat this step with the other trailing arm, moving both trailing arms towards the steering column until you hear two
audible “clicks”.
For help packing the TravelScoot into the duffel bag, please type the following address into your internet browser’s search bar:
https://youtu.be/QwHpO2zb0bE.
Battery Charging Procedures
The battery smart charger supplied with your TravelScoot is proprietary to your lithium-ion battery. Do not attempt to use it with
other batteries. To charge the battery:
•Plug the power cord into an AC outlet, then plug it into the battery charger.
•You should see a solid red light with three quick blinking green lights. The solid red light means you are getting power.
•Plug the charger into the battery.
•You will now see either two solid red lights (indicating that the battery is charging), or you will see one red light and one
green light (indicating that the battery is fully charged).
Additional Battery Information
Unlike many scooter batteries, the TravelScoot lithium-ion battery has no memory effect while charging. This means that the
battery can be charged, or “topped off”, at any time. Likewise, the charging process canbe interrupted at any time without affecting
the battery. Typical charging time for a completely discharged battery is 4 to 6 hours.
Note: We recommend unplugging the battery charger from the AC outlet when not in use.
The Fabric Caddy is ideal for carrying light-weight items such as jackets,
cameras, etc. To fasten the fabric caddy to your TravelScoot:
1) Align the Velcro straps on the fabric caddy with the corresponding six
Velcro rings on the TravelScoot trailing arms and secure firmly.
2) Make sure to check Velcro straps regularly.

10
For answers to your questions, call 1-877-339-7505
Battery Info for Foreign Travel
The TravelScoot’s lithium-ion battery charger is universal, and will operate on 100-200 VAC, 50/60 Hz. This allows it to be used
internationally in conjunction with a plug adaptor which can be purchased as an accessory.
Battery Tips
•Disconnect the battery whennot using your TravelScoot.
•Do not expose battery to excessive heat or cold.
•Avoid excessive exposure to water.
•Do not drop.
•If the battery is completely discharged, plug it in for 8 hours.
•Store the battery in a cool, dry place when not in use.
•Monitor the battery indicator lights, located on the throttle, to best gauge your personal battery consumption. Remember
that each light represents 1/3 of the battery’s total charge. Consumption will vary depending on how much you travel on
uneven terrain.
•If possible, try to avoid total discharge of the battery. Repeatedly fully draining the battery can shorten its lifespan.
Getting On and Off your TravelScoot
Before getting on or off your scooter, please ensure that the parking brakes are engaged and the power is off. Be sure to center
your weight on the TravelScoot for support if you are getting on or off.
Operating your TravelScoot
Plug in the Battery
Plug the battery connector into the black plastic receptacle at the front of the left-rear wheel fork (unplug by pressing both sides
of the battery connector).
On/Off Switch and Forward/Reverse Selector
Throttle
The throttle is located on the inside half of the right-hand grip. To get used to operating the throttle, turn the twist-grip slowly and
smoothly, similar to a motorcycle. Turning the throttle too quickly can result in unexpected acceleration or even tipping over. The
throttle on the TravelScoot has an electronic delay from the moment you turn until power is applied. This safety feature prevents
uncontrolled acceleration.
The TravelScoot features battery charge indicator lights, located on the throttle display. There are two green lights and one red
light, each light representing 1/3 of the battery’s total charge. It is a good idea to monitor how soon each light goes out so as to better
estimate howlong your battery will last.Keep in mind thatthe terrain overwhich you travel will greatly determine overall mileage.
The On/Off switch and forward/reverse selector are found on the left handlebar. To turn the
scooter on, simply press the red button. Repeat to turn the scooter off.
As a safety measure, always check the forward/reverse selector to ensure you are traveling in
the desired direction before engaging the throttle. Positionthe selector upwards togo forwards,
and downwards to go backwards.

11
For answers to your questions, call 1-877-339-7505
Brake Levers
The TravelScoot does not have automatic brakes. Instead, it uses band brakes. Band brakes are very effective, even on downhill
grades. Each rear wheel has its own band brake that is controlled by the corresponding lever. For maximum stopping power, both
brake levers must be applied. Safety dictates, however, that while driving downhill, to never exceed a speed faster than you could
walk. Caution is also advised on steeper uphill grades when forced to stop. The band brakes are less effective when rolling
backwards. Therefore, it is advisable to avoid riding up or down steep inclines and, instead, get off and push the TravelScoot to a
more level location. Do not apply the throttle while engaging the brakes. This could result in tipping.
Parking Brakes
Seat Spacers
Turning with your TravelScoot
Left turns: Because the drive motor is located on the left-rear wheel ofthe TravelScoot, left turns from astopped position are only
possible with the front wheel turned no more than 45 degrees. If you attempt to accelerate from a stopped position with the front
wheel turned more than 45 degrees to the left, this will result in blocking the drive and “pushing” the front wheel. If this is done on
any sort of uneven terrain, it could result in an uncontrolled situation. Turning left with the front wheel less than 45 degrees still
provides an adequate amount of maneuverability similar to that of a four-wheeled scooter. However, when already in motion,
tighter turns are possible.
Right Turns: Right turns on the TravelScoot are where its agility and nimbleness really shine through. Right turns of up to 90
degrees from a stopped position are possible, but be sure to use very little throttle when doing so. The TravelScoot virtually turns
on the spot. Practicing your turns on the TravelScoot willbe invaluable in situations where there maynot be much room such as on
elevators or in public restrooms. You will learn to approach these confined spaces so that you can exit with a right turn.
Travel
Air Travel
Policies and handling practices differ from one airline to another. We recommend that you contact your airline’s Special Needs
Coordinator, or equivalent, well in advance for specific information regarding air travel for passengers with mobility devices.
Request your approval confirmation in writingif possible. Do not expect each airline agent to be familiar with the many policies and
regulations that pertain to mobility devices.
Note: The TravelScootwas designed with airtravel in mind.Customers havebeen travelling byair using the TravelScoot since 2004.
Both brake levers areequipped with aparking brake. Itis strongly advisedto use
the parking brakes before getting off or on your scooter, on slopes, or uneven
terrain. To engage, squeeze the brake lever with one hand while simultaneously
using your other hand’s index finger to press the parking brake lever in. The
parking brake lever is “set” when you feel a click on one of the two settings (low
or high). To disengage, simply squeeze the brake lever until the parking brake
lever releases.
Included with your TravelScoot are two seat spacers (1 inch and 1.5 inches). They are to be used to
raise the seat up to two and a half inches to maintain seat height. Once the desired height has been
determined, the spacers can be attached to the seat post using adhesive tape, Loctite, silicone,
epoxy, etc. When attaching the yoke, ensure that there are no gaps between the seat spacers and
the yoke.

12
For answers to your questions, call 1-877-339-7505
TIP: Battery documentation for air travel can be found online at https://www.travelscoot.com/air-travel-with-an-electric-
mobility-scooter.html.
At the Airport
At the security checkpoint you can usually bypass the waiting crowd by asking for assistance. Security may ask you whether or not
you can stand. To avoid being subjected to a body search, stand up, if possible, and walk the few feet through the x-ray frame. They
will perform a security check on your scooter. After you are cleared you can drive your TravelScoot to the gate.
At the check-in desk, remain seated so that an employee will understand that you have walking problems. Your attendant at the
boarding gate will give you your “Gate Delivery” tags for your scooter. While you wait to board your plane, be sure to listen for the
pre-boarding announcement for people with disabilities and families with small children. They are asked to board before the rest
of the passengers so that baggage handlers have enough time to store medical equipment and strollers in the luggage
compartment. Therefore, we suggest that you arrive to the airport early.
Once at the door of the airplane, lower your handlebars, remove the battery, and hand the scooter over to the baggage attendant.
Do not fold up your scooter orremove the seat assembly! Scooter components willget lost ifnot kept together. We suggest covering
the handlebars of the scooter with padding or the TravelScoot Travel Set to protect the controls from possible damage due to
careless baggage handlers.
International Air Transport Association (IATA) Lithium Guidance Battery Document
The following documentation consists of the most recent regulations relating toAirline Travel with Lithium-ion batteries. If you are
travelling by air, bring this manual with you or photocopy this page, as not all airline representatives may be familiarwith the most
up-to-date battery regulations.
Air Travel Regulations
Regulations regarding travelling with a mobility scooter change from time to time. Below are the key points for air travel with a
battery powered mobility scooter:
•The mobility scooter battery must not exceed 300 Wh.
•One spare battery not exceeding 300 Wh. or two spares not exceeding 160 Wh may also be carried.
•Batteries must be removed from the mobility aid according to the manufacturer’s instructions.
•The battery must be protected from damage (e.g. by placing it in a protective pouch provided by the passenger.
•Batteries must be carried in the passenger cabin.
•The pilot-in-command must be informed of the location of the batteries.
IATA Lithium Battery Guidance Document Section 2.3.3.2 (excerpt)
Lithium-ion battery powered wheelchairs or other similar mobility aids for use by passengers whose mobility is restricted by
either a disability, their health or age, or a temporary mobility problem (e.g. broken leg), are permitted in air transport but subject
to the following conditions:
(a) the batteries must be of a type which meets the requirements of each test in the UN Manual of Tests and Criteria, Part III,
subsection 38.3;
(b) the operator must verify that:
(1) battery terminals are protected from short circuits, e.g. by being enclosed within a battery container,
(2) the battery must be securely attached to the wheelchair or mobility aid; and
(3) electrical circuits have been inhibited.
(c)the mobility aids must be carried in a manner such that theyare protected from being damaged by themovement of baggage,
mail, or other cargo;
(d)where a battery-powered or other similar mobility aid is specifically designed to allow its battery(ies) to be removed by the
user (e.g. collapsible)

13
For answers to your questions, call 1-877-339-7505
(e) the battery must be removed. The wheelchair / mobility aid may then be carried as checked baggage without restriction;
(f) the battery must be protected from short circuit by insulating the terminals (e.g. by taping over exposed terminals);
(g) the removed battery must be protected from damage (e.g.) by placing each battery in a protective pouch. The battery must
be carried in the passenger cabin;
(h) removal of thebattery from the device must be performedby following the instructions of the manufacturer or device owner;
(i) the battery must not exceed 300 Wh
(j) a maximum of one spare battery not exceeding 300 Wh or two spares each not exceeding 160 Wh may be carried; and
(k)the pilot-in-command must be informed of the location of the mobility aid with an installed battery or the location of the
lithium battery when removed and carried in the cabin.
(l) It is recommended that passengers make advance arrangements with each operator.
Cruise Ship Travel
Ahoy TravelScoot! The TravelScoot is the number one choice for travelers venturing out to sea. With its compact size and
maneuverability, the TravelScoot seems custom-built for cruising.
In Your Cabin
Let's face it, cruising is a fantastic way to see the world, but the cabins can be a little on the small side. For safety reasons, cruise
lines prohibit you from leaving your mobility scooter outside your room in the hall. You must store it inside your cabin. With other
scooters, this can be a real nuisance as you try to maneuver around an already small space. With the TravelScoot, however, you
can fold it up and store it in a closet, in a corner of your cabin, or park it right under the desk in your room.
On the Ship
Most cruise ships nowadays seem to be the size of a small city! Exploring the ship can be adventurous but tiring. Quite often
there are many different levels on these ships which can pose a problem for someone with difficulties getting around. The
TravelScoot makes small work of these vast ships. Whether you are scooting to the pool, on the Lido deck, or to theFiesta deck
for an evening of fine dining at a formal dinner, the TravelScoot will take you wherever you want to go.
On-Shore Excursions
Exploring the many different ports and excursions a cruise ship has to offer is a wonderful way to travel the world. In some ports,
cruise ships have to anchor offshore and tender the passengers to shore. Most cruise lines won't allow mobility devices over 50
lbs./22.7kg on these tenders. But at a mere 34 lbs./15.87kg, the TravelScoot is no problem.
Maintenance
Due to the innovative design of the TravelScoot, it is nearly maintenance free. A small tool kit is included with the scooter which
can be used to tighten the bolts of your scooter. It is recommended that you follow the stepsbelow every six months (or as needed)
to ensure that your scooter performs flawlessly for years to come.
Cleaning Tips
Keeping your TravelScoot clean and dry is important. Remove dust and dirt from the frame components with a mild dish soap
solution or water-resistant silicone spray (preferred). Do not use abrasive or alkaline cleaners as these will attack the finish.
Using a microfiber cloth, wipe any accumulated moisture from the frame and components after riding in damp conditions. These
simple measures will help maintain the reliability and safety of your TravelScoot. For more on cleaning and maintaining the
TravelScoot, check out our videos on YouTube.
Brakes
The brakes can be adjusted at three different locations:
•At the hand brake lever
•Cable conduit (front of rear-wheel fork)
•At the band brake itself (8mm wrench required).

14
For answers to your questions, call 1-877-339-7505
Lubrication
For lubrication we recommend a dry, water-resistant silicone or Teflon spray. Avoid oils and greases as they attract dirt. Light
lubrication should be applied periodically to the following areas:
•Steering column
•Locking pins
•Trailing arm hinge bolts
•Lever clamp pivot points
•Junction area
*All wheel bearings are sealed and do not require lubrication.
Tightening
Please inspect the following fasteners:
•Rear left axle nut (make sure this is as tight as possible)
•Seat and backrest screws
Specifications
Dimensions:
Folded
Unfolded
Length = 33.5 inches/85 cm
Length = 37 inches/94 cm
Width = 12 inches/30 cm
Width = 23 inches/58 cm
Height = 10 inches/25 cm
Height = between 27 and 39 inches/68 cm and 99 cm
Weight
30 lbs.
Maximum Speed
6.0 mph/9.6 kph
Distance per charge
For individuals with an average weight of 180 lbs./80 kg
(Operating on flat surfaces. Hills will decrease distance)
274 Wh Battery
16-18 miles/25-28 km
151 Wh Battery
10-12 miles/16-19 km
Warranty Weight Limit
340 lbs./154 kg
Motor
24V, 200 Watt DC
Tire Size
Front 8”x2”/20x5 cm, Rear 8”x 2.5”/18.6 cm x 7 cm
Charger
100/240VAC, 50/60Hz 24VDC/2Ah
Charging Time
~6-8 hours
Brakes
Band brakes on both rear wheels with dual parking
brakes
Drive
Rim motor inside the rear left wheel

15
For answers to your questions, call 1-877-339-7505
Terms and Conditions
OUR WARRANTY AND RETURN POLICY IS AS FOLLOWS:
WARRANTY
Your new TravelScoot is covered by our 2-year warranty, starting from the delivery date. The warranty does not cover
normal wear-and-tear or use by persons weighing more than 340 lbs.
LIMITED WARRANTY
This limited warranty is the only warranty for your TravelScoot. There are no other expressed or implied warranties.
The only uses for this product are described in this manual. The limited warranty extends only to the original owner
and is not transferable to anyone else. This limited warranty covers all parts of the TravelScoot and is effective only if:
•The product is completely and correctly assembled.
•The product is used under normal conditions for its intended purpose.
•The product receives all necessary maintenance and adjustments.
The TravelScoot electric mobility scooter is designed for general transportation and recreational use only. This limited
warranty does not cover normal wear and tear, normal maintenance items, nor any damage, failure or loss caused by
improper assembly, maintenance, adjustment, storage or use of the TravelScoot. This limited warranty is void if the
product is ever:
•Used in any manner contrary to the instructions in this Owner’s Manual.
•Modified in any way.
•Ridden by more than one person at a time.
•The unit is used for commercial purposes (rental, public use etc.)
•Operated with a battery not supplied or recommended by TravelScoot.
The manufacturer of the TravelScoot is not liable for incidental or consequential loss nor damage, due directly or
indirectly, from the use of this product. The TravelScoot is warranted for two years from the date of delivery. The
manufacturer will replace, without charge to you, any component found to be defective within the warranty period.
RETURNS
1. Contact TravelScoot Canada to obtain an RMA number
To return a product, you can obtain a Return Merchandise Authorization (RMA) number by contacting
TravelScoot Canada. Just call us toll free at: 877-339-7505. All returns must be made within 14 days after the
RMA number is issued. The customer is responsible for all return shipping costs. Shipping costs will be
deducted from the purchase amount.
2. Use the shipping label provided by TravelScoot Canada and save a copy
You will receive an email confirming the RMA number. This email will include a prepaid return shipping label.
Use the shipping label you have received and follow the shipping instructions set out in the email to ship the
product back to TravelScoot Canada. We are unable to process returned products sent using an alternate
carrier or shipping label. Retain a copy of the shipping label with the applicable tracking number for your
records.
3. Return the product within 14 days of the RMA issue
TravelScoot Canada must receive the returned item within 14 calendar days after an RMA number has been

16
For answers to your questions, call 1-877-339-7505
issued Make sure you pack the product in the same manner it was received. All contents (including
accessories and Owner’s manual) need to be included. When returning a product under the 14-day return
policy, the product must be returned in its original TravelScoot packaging.

17
For answers to your questions, call 1-877-339-7505
TravelScoot Components & Controls
1. Throttle
2. Battery Status Indicator
3. Bell
4. On/Off Switch
5. Forward/Reverse Selector
6. Steering Column Clamp
7. Cane Holder
8. Basket Railing
9. Foot Peg
10. Locking Pin
11. Trailing Arm
12. Drive Motor (inside hub)
13. Battery Charging Port
14. Brake Band
15. Seat Clamps
16. Seat Elbow
1
2
3
4
5
6
7
10
11
12
13
14
15
9
8
16

TravelScoot is a registered trademark of TravelScoot International Ltd.
Patent #7207407
TravelScoot is designed in Germany and distributed in Canada by:
TravelScoot Canada
Date: 01/2019
