564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 1 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
Packing List
Burner Assembly
Grate Assembly
Log Set
Intake Restrictor

Air Deflectors, NG and LP
(2) Andiron Clips
(2) Rivets for burner
Burner Support Bracket
Bag of embers
Installation Tips
If using propane (LP), convert the appliance before installing the burner.
Make sure to have the firebacks for the appliance on hand. They will be
installed during burner installation.
Installation Warnings
The logs are fragile, especially after being exposed to heat.
Make sure the gas control valve is OFF and the heater is cool before
servicing.
Failure to position the parts in accordance with these diagrams or failure to
use only parts specifically approved with this appliance may result in
property damage or personal injury.
The burner must be correctly positioned before installing the logs. Make sure
the burner is fully seated and the pilot is properly aligned.
Andiron Clips
NOTE: Two andiron clips are included for
those installations using andirons. See the
directions to the right to install.
5/32 Hex
Wrench
11/32" Nutdriver
a
b
c

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 2 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
Log Set Installation
1. Remove both accent lights from the brackets and place them on the firebox floor, as shown below.
2. Install the burner support bracket, as shown below.
NOTE: The notch in the bracket faces inward.
3. Install the intake restrictor as shown below. Use the screws pre-installed on the rear wall of the firebox. The
intake restrictor is located behind the accent lights, on the rear wall of the firebox. Set the intake restrictor to
the correct setting for the vent configuration; see the owner’s manual for details.

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 3 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
4. Install the firebacks as shown below.
Place the rear fireback in place.
Remove the clip located on the
firebox ceiling near the front (both
sides). The side fireback clip has
a keyhole slot. It can be removed
by loosening the screw and
sliding the clip out.
Place the side firebacks
in place.
a
c
Replace the clips removed in
firebacks.
e
d
Place the fireback
so the vertical grout line on
the edge of the fireback is
facing the rear.
b
1/4” Nutdriver
NOTE:
Place the floor firebacks in place. step “a” to secure the side

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 4 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
5. Replace the Accent Lights. The fireplace should now look as shown below.
6. Install the burner inside the firebox.
7. Install the grate on top of the burner. Note how the grate slides into metal clips on the sides of the burner.

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 5 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
8. Install the correct air deflector as shown below. Note how the dimple inserts into a slot on the burner (“a”).
Figure 1: Deflector Replacement
9. Install the rivets on the burner as shown below.
Figure 2: Rivets Placement
a
NG LP a
NLL
NG
NLL
LP

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 6 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
10. Install the Rear Log onto the 2 pins at the rear of the firebox, as shown below. The log rests against the back
wall or fireback.
NOTE: NG and LP configurations require different log placement settings. For NG pull the rear log forward for
maximum glow. For LP push the rear log to the back to avoid sooting.
Figure 3: Rear Log Location Figure 4: Rear Log Installed
Figure 5: Rear Log – Top View Figure 6: Rear Log - Bottom View
11. Install the Left Log onto the 2 pins at the left of the firebox, as shown below. Note how the pin and metal post
insert into the holes on the log.
Figure 7: Left Log Location Figure 8: Left Log Installed
Figure 9: Left Log – Top View Figure 10: Left Log - Bottom View

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 7 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
12. Install the Right Log onto the 2 pins at the right of the firebox, as shown below. Note how the two pins on the
burner insert into the holes on the log.
Figure 11: Right Log Location Figure 12: Right Log Installed
Figure 13: Right Log – Top View Figure 14: Right Log - Bottom View
13. Install the Center Ember Chunk as shown below. Note how the pin inserts into the hole on the log.
Figure 15: Center Ember Chunk Location Figure 16: Center Ember Chunk Installed
Figure 17: Center Ember Chunk - Top View Figure 18: Center Ember Chunk - Bottom View

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 8 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
14. Install the Right Log Chunk as shown below. Note how it rests on the grate and fireback.
Figure 19: Right Log Chunk Location Figure 20: Right Log Chunk Installed
Figure 21: Right Log Chunk – Top View Figure 22: Right Log Chunk - Bottom View
15. Install the Left Log Chunk as shown below. Note how the flat portion of the log rests on the grate.
Figure 23: Left Log Chunk Location Figure 24: Left Log Chunk Installed
Figure 25: Left Log Chunk – Top View Figure 26: Left Log Chunk - Bottom View

564 HO Ember-Fyre Burner and Log Set
Installation Instructions (sku 96900116)
Page 9 of 9 17601655 — 11/14/12 © Travis Industries, Inc.
16. Install the Right Twig as shown below. Note how the flat side of the twig fits on the right log and the pin on the
rear log.
Figure 27: Right Twig Pin Figure 28: Right Twig Installed
Figure 29: Right Twig – Top View Figure 30: Right Twig -- Bottom View
17. Remove the embers from their bag and place them around the front of the firebox, as shown below.
Figure 31: Embers Placed
