1080 CF
Gas Fireplace
Tested and Listed by
OMNI-Test Laboratories, Inc.
Portland, Oregon
Report # 028- -81-5
ANSI Z21.88a-2007
• Built-In Direct Vent Fireplace
• Natural Gas or Propane
• Residential or Mobile Ho e
• Bedroo Approved
WARNING: If the infor ation in these instructions is not followed exactly, a fire or
explosion ay result causing property da age, personal injury or loss of life.
- Do not store or use gasoline or other fla able vapors and liquids in the vicinity of this or
any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• I ediately call gas supplier fro a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire depart ent.
- Installation and service ust be perfor ed by a qualified installer, service agency or the
gas supplier.
This appliance ay be installed in an after arket per anently located, anufactured ho e (USA only)
or obile ho e, where not prohibited by local codes.
This appliance is only for use with the type(s) of gas indicated on the rating plate. A conversion kit is
supplied with the appliance.
Installation Manual
Installer:After installation give this anual to the ho e-
owner and explain operation of this heater.
 Copyright 2008, T.I. $10.00 100-01193_003 4090807 4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275

2 Introduction
© Travis Industries 4090807 100-01193_003
Overview
This manual details the installation
requirements for the 1080 C fireplace. or
operating and maintenance instructions, refer to
the 1080 C Owner's Manual (part # 100-
01194).
Listing Details
This appliance was listed by OMNI Test Labs to
ANSI Z21.88 - report # 028- -81-5. The listing
label is attached to the appliance near the gas
control valve. A copy is shown to the right.
ICBO Approval
This appliance was listed by OMNI-Test
Laboratories - ICBO # TL130.
Massachusetts Approval
This manual has been submitted to the
Massachusetts Board of State Examiners of
Plumbers and Gas itters
National Fireplace Institute
Figure 1

Table of Contents 3
© Travis Industries 4090807 100-01193_003
Introduction
Overview.................................................................2
Listing Details..........................................................2
Safety Precautions
afety Precautions...................................................4
Features and Specifications
Installation Options...................................................6
pecifications..........................................................6
Dimensions.............................................................6
Installation
Packing List............................................................. 7
Additional Items Required..........................................7
Installation Overview .................................................7
Recommended Installation Procedure .........................8
Massachusetts Requirements..................................... 9
Preparing the Fireplace tand-offs.............................. 10
Fireplace Placement Requirements.............................12
Clearances...........................................................12
Raised Fireplaces .................................................12
Minimum Framing Dimensions ................................13
Framing Dimensions - Corner Installations................14
Nailing Brackets....................................................15
Gas Line Requirements.............................................16
Gas Line Connection .............................................16
Gas Inlet Pressure ................................................16
Battery Pack – Wireless Wall witch Installation ...........19
Battery Installation ................................................22
Remote ynchronization............................................23
ynchronizing the Remote and Wireless Wall witch ......................24
Using the Reset Rod to Activate the Receiver Module ......................25
Installation (continued)
Vent Requirements .................................................. 26
Approved Vent...................................................... 26
Altitude Considerations.......................................... 26
Vent Clearances................................................... 27
Vent Installation....................................................27
Approved Vent Configurations:
Horizontal Termination (1 90° Elbow) ........................29
Horizontal Termination (3 90° Elbows).......................30
Vertical Termination (0, 2, or 4 45° Elbows)...............31
Vertical Termination (2 90° Elbows) .......................... 32
Termination Requirements......................................... 33
Hearth Requirements ............................................... 34
Hearth Requirements – Recessed Hearth ................35
Facing Requirements ............................................... 36
Non-Combustible Facing........................................37
Mantel Requirements................................................ 39
Finalizing the Installation
Air hutter Adjustment.............................................. 41
Glass Frame Removal and Installation........................ 42
Log et Installation .................................................. 43
LP Conversion Instructions ....................................... 51
Fireback Installation ................................................. 56
Andiron Installation................................................... 58
Power Heat Duct Installation...................................... 59
Index
Index...................................................................... 60

4 Safety Precautions
© Travis Industries 4090807 100-01193_003
Safety Warnings:
• Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
• This unit must be installed by a qualified installer to prevent the possibility of an explosion.
• This appliance must be installed in accordance with all local codes, if any; if not, in U.S.A. follow ANSI
Z223.1 and NFPA 54(88).
• A manufactured home (USA only) or mobile home OEM installation must conform with the
Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a
standard is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS A225.1,
or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4. This
appliance may be installed in Manufactured Housing only after the home is site located.
• All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn
from outside the living-area structure. The venting must not be connected to a chimney flue serving a
separate solid-fuel burning appliance.
• Notify your insurance company before hooking up this fireplace.
• The room heater should be inspected before use and at least annually by a qualified service person.
More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc.
• The instructions in this manual must be strictly adhered to. Do not use makeshift methods or
compromise in the installation. Improper installation will void the warranty and safety listing.
• This heater is approved for use with natural gas (NG) or propane (LP). Burning the incorrect fuel will
void the warranty and safety listing and may cause an extreme safety hazard. Direct questions about
the type of fuel used to your dealer. Check the label and flame adjust knob on the gas control valve.
• Contact your local building officials to obtain a permit and information on any installation restrictions or
inspection requirements in your area.
• If the flame becomes sooty, dark orange in color, or extremely tall, do not operate the heater. Call your
dealer and arrange for proper servicing.
• It is imperative that control compartments, screens, or circulating air passageways of the heater be
kept clean and free of obstructions. These areas provide the air necessary for safe operation.
• Do not operate the heater if it is not operating properly in any fashion or if you are uncertain. Call your
dealer for a full explanation of your heater and what to expect.
• Do not store or use gasoline or other flammable liquids in the vicinity of this heater.
• Do not operate if any portion of the heater was submerged in water or if any corrosion occurs.
• Do not place clothing or other flammable items on or near the heater. Because this heater can be
controlled by a thermostat there is a possibility of the heater turning on and igniting any items placed
on or near it.
• Light the heater using the built-in piezo igniter. Do not use matches or any other external device to
light your heater.
• Never remove, replace, modify or substitute any part of the heater unless instructions are given in this
manual. All other work must be done by a trained technician. Don't modify or replace orifices.
• The viewing glass should be opened only for lighting the pilot or conducting service.
• Any safety screen or guard removed for servicing must be replaced prior to operating the heater.

Safety Precautions 5
© Travis Industries 4090807 100-01193_003
Safety Warnings (continued):
• Allow the heater to cool before carrying out any maintenance or cleaning.
• Operate the heater according to the instructions included in this manual.
• If the main burners do not start correctly turn the gas off at the gas control valve and call your dealer for
service.
• The pilot flame must contact the thermopile and thermocouple. If it does not, turn the gas control
valve to "OFF" and call your dealer.
• This unit is not for use with solid fuel.
• Do not place anything inside the firebox (except the included fiber logs).
• If the fiber logs become damaged, replace with Travis Industries log set.
• Do not throw this manual away. This manual has important operating and maintenance instructions
that you will need at a later time. Always follow the instructions in this manual.
• Do not touch the hot surfaces of the heater. Educate all children of the danger of a high-temperature
heater. Young children should be supervised when they are in the same room as the heater.
• Due to the high temperature, the heater should be located out of traffic and away from furniture and
draperies.
• Instruct everyone in the house how to shut gas off to the appliance and at the gas main shutoff valve.
The gas main shutoff valve is usually next to the gas meter or propane tank and requires a wrench to
shut off.
• Travis Industries, Inc. grants no warranty, implied or stated, for the installation or
maintenance of your heater, and assumes no responsibility of any consequential
damage(s).

6 Features and Specifications
© Travis Industries 4090807 100-01193_003
Installation Options
• Residential or Mobile Home
• Straight or Corner Placement
• lush or Recessed ace
• Raised or loor Placement
• Internal or External Chase
• Horizontal or Vertical Vent
• Bedroom Approved
Specifications
Natural Gas Propane
Maximum BTU Input Per Hour 36,000 36,000
Minimum BTU Input on Low 20,800 23,500
Dimensions
Tabs for lifting handles
(sku 98500711)
Weight: 250 Lbs.
1-1/2" **
* Includes the required 2" clearance.
** Includes the 1-1/2" standoff below the baseplate.
*** Does not include the required 4" clearance to each side.
25"*
49.5"
12-1/4"*
37.5"
32-3/4" **
43" **
Base of ireplace
(bottom of standoffs)
27" ***
NOTE: 4" Clearance to
the Sides of the ireplace
NOTE: 2" Clearance to
the Back of the ireplace
8-5/8" Outside Diameter
41-1/2" **
5"
49-1/2" **
56-3/4" **
2"
Figure 2

Installation (for qualified installers only) 7
© Travis Industries 4090807 100-01193_003
Packing List
• Propane Conversion Kit (orifice rate screw)
• Log Set
• Remote Control and Wireless Wall Switch
• Reset Rod
• Battery Box with 12’ Wire Lead
• Door Latch Tool
• Andiron Brackets
Additional Items Required
• 1080/36 CF Direct Vent (available only from Travis Industries – see page 26 for part numbers)
• Gas Line Equipment (shutoff valve pipe etc.)
Installation Overview
• All requirements below must be met.
Non-combustible facing -
(included) see the section
"Facing Requirements"
See the section
"Vent Requirements"
See the section
"Minimum Framing Dimensions"
AAAAAAAAA
AAAAAAAAA
AAAAAAAAA
AAAAAAAAA
AAAAAAAAA
Nailing Brackets
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
Drywall (or other
combustible)
11"
Min.
See the section
"Mantel Requirements"
See the section
"Hearth Requirements"
See the section "Control Panel
Installation"
NOTE: Control wire is 12' long.
Side
Wall
Figure 3

8 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Recommended Installation Procedure
1. Frame the opening for the fireplace. We suggest omitting the framing above the header to
allow for easier vent installation.
2. Place the fireplace in place making sure it is level and plumb. Attach using the nailing
brackets.
3. Install the vent gas line electrical connection and battery box.
4. Install the framing above the header.
5. Install the hearth (if applicable).
6. Install the included non-combustible facing.
7. Install the facing.
8. Install the mantel (if applicable).
9. Finalize the installation (see page 40).

Installation (for qualified installers only) 9
© Travis Industries 4090807 100-01193_003
Massachusetts Requirements
NOTE: The following requirements reference various Massachusetts and national codes not contained in this document.
Requirements for the Commonwealth of Massachusetts
For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in
part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent
termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and
porches, the following requirements shall be satisfied:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gasfitter shall
observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the floor level where the
gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery operated or hard
wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served
by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the
services of qualified licensed professionals for the installation of hard wired carbon monoxide detectors.
In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired
carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall
have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day
period, a battery operated carbon monoxide detector with an alarm shall be installed.
A roved Carbon Monoxide Detectors
Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be
ANSI/UL 2034 listed and IAS certified.
Signage
A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or
equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP
CLEAR OF ALL OBSTRUCTIONS”.
Ins ection
The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
Exem tions
The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
• The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54 as
adopted by the Board; and
• Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the
dwelling, building or structure used in whole or in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equi ment Venting System Provided
When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or
venting system components with the equipment, the instructions provided by the manufacturer for installation of the
equipment and the venting system shall include:
• Detailed instructions for the installation of the venting system design or the venting system components; and
• A complete parts list for the venting system design or venting system.
Gas Equi ment Venting System NOT Provided
When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the parts
for venting the flue gases, but identifies “special venting systems”, the following requirements shall be satisfied by the
manufacturer:
• The referenced “special venting system” instructions shall be included with the appliance or equipment installation
instructions; and
• The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a
parts list and detailed installation instructions.
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting
instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
See Gas Connection section for additional Commonwealth of Massachusetts requirements.

10 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Preparing the Fireplace Stand-offs
This appliance is shipped with the header and side stand-offs in the retracted position. These stand-
offs must be placed in their upright position prior to installing the fireplace
WARNING: Failure to correctly erect the stand-offs may lead to a serious fire-hazard and will void
the listing and warranty of this fireplace.
Side Stand-Offs
Bend the side stand-off until it is flat.
Remove the two screws behind the side
stand-off and place them aside.
Bend the stand-off return back until
the holes in the stand-off line up with
the holes on the side of the fireplace.
a
b
c
d
Secure the stand-off with two
screws removed earlier.
Repeat steps "a", "b", and "c"
for the opposite side.
Figure 4

Installation (for qualified installers only) 11
© Travis Industries 4090807 100-01193_003
Header Stand-Off
Rotate the header standoff until
the side braces lock into place.
Rotate the header brackets up
The notch in the side brace slides
over this screw.
a
cUn-fold the side of the header
standoff until it is flat (both sides).
Remove the screw below
the center header standoff.
Rotate the lower standoff upwards
and attach using the same screw.
b
d
Figure 5

12 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Fireplace Placement Requirements
• The fireplace requires a 4" clearance from the sides and 2” from the back of the fireplace to the
framing members. No material (insulation framing etc.) may be placed into this area.
• Fireplace must be placed in a room with a minimum 96” ceiling.
• Fireplace must be placed directly on the sub-floor or wood platform (not on linoleum or carpet).
• Fireplace must be installed on a level surface capable of supporting the fireplace and vent.
• This heater may be placed in a bedroom. Please be aware of the large amount of heat this
appliance produces when determining a location.
Clearances
• When installed walls in front of the fireplace must be a minimum 11” from the glass (5" from
the side stand-offs - see Figure 3).
• Due to the high temperature the heater should be located out of traffic and away from furniture
and draperies.
• Fireplace must be placed so the vents below and above the glass do not become blocked.
Raised Fire laces
• The fireplace (and hearth if desired) may be placed on a platform designed to support the
fireplace 250 Lbs.) and vent.
AAAAAA
AAAAAA
AAAAAA
AAAAAA
Platform
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAA
AAA
AAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAA
AAA
AAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAA
AAA
AAAA
AAAA
AAAA
Minimum 60”Fireplace
Enclosure Height.
Enclosure must also
meet 6”vent clearance.
Optional Raised Hearth
(see “Hearth Requirements”for details)
Figure 6

Installation (for qualified installers only) 13
© Travis Industries 4090807 100-01193_003
Minimum Framing Dimensions
NOTE: Do not build into this area - it must be left clear to
provide adequate clearance for the vent. A maximum 3-1/2”
depth is allowed in this 14”wide area centered along the front
of the fireplace.
14”Min.
50”
3.5”Max.
56-3/4”
25”
Minimum 60”Fireplace
Enclosure Height.
Enclosure must also meet
6”vent clearance.
Figure 7

14 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Framing Dimensions - Corner Installations
A typical 45° installation uses the framing dimensions shown in the illustration below (NOTE: all
clearances still apply).
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
59"
(approximate)
AAAAAAAAAAA
AAAAAAAAAAA
AA
AA
AAAAAAAAAAA
Minimum 2"
Clearance
AAAA
AAAA
AAAA
AAAA
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
21.25"
(approximate)
Figure 8

Installation (for qualified installers only) 15
© Travis Industries 4090807 100-01193_003
Nailing Brackets
Use screws or nails to
secure the fireplace to the
framing with the six nailing
brackets.
1
2
3
4
5
6
7
Figure 9

16 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
as Line Requirements
MASSACHUSETTS INSTALLATIONS - WARNING:
THIS PRODUCT MUST BE INSTALLED BY A LICENSED PLUMBER OR GAS FITTER WHEN INSTALLED WITHIN
THE COMMONWEALTH OF MASSACHUSETTS.
OTHER MASSACHUSETTS CODE REQUIREMENTS:
• Flexible connector must not be longer than 36 inches.
• Shutoff valve must be a “T” handle gas cock.
• Only direct vent sealed combustion products are approved for bedrooms or bathrooms.
• Fireplace dampers must be removed or welded in the open position prior to the installation of a fireplace insert or gas
log.
• A carbon monoxide (CO) detector is required in the same room as the appliance.
• The gas line must be installed in accordance with all local codes if any; if not follow ANSI 223.1 and the
requirements listed below.
• The fireplace and gas control valve must be disconnected from the gas supply piping during any pressure
testing of that system at test pressures in excess of 1/2 psig. For pressures under 1/2 psig isolate the
gas supply piping by closing the manual shutoff valve.
• Leak test all gas line joints and the gas control valve prior to and after starting the fireplace.
• This fireplace is designed either for natural gas or for propane (but not for both). Check the sticker on the top of
the gas control valve to make sure the correct fuel is used (see illustration on page 4).
• An additional shut-off valve is required. It must be accessible and within 6’of the fireplace.
Gas Line Connection
• Installation must be performed by a qualified installer service agency or the gas supplier (In Massachusetts
a licensed plumber/gasfitter).
• A shutoff valve is built into the fireplace. It is located on the left side of the fireplace and acts as the gas
inlet connection. After installing the gas line (and testing) remove the cover plate shown below and turn the
gas shutoff valve to “ON”.
The gas inlet is located
5.5" above the base of
the fireplace.
7"
4"
Built-In Shut-off Valve
Gas Line
(1/2" M.P.T.)
Shutoff Valve
Gas Inlet
LEFT SIDE OF
FIREPLACE
Figure 10
Gas Inlet Pressure Standard Input Pressure
Natural Gas 7" W.C. (1.74 kPA)
Propane 13" W.C. (2.73 kPA)
• If the pressure is not sufficient make sure the piping used is large enough the supply regulator is
adequately adjusted and the total gas load for the residence does not exceed the amount supplied.
• The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank) should
supply gas at the suggested input pressure listed above. Contact the local gas supplier if the regulator is at
an improper pressure.

Installation (for qualified installers only) 17
© Travis Industries 4090807 100-01193_003
Required Electrical Connection
Make sure power to the heater has been turned off prior to installation (disable the breaker).
Do not connect 110-120 VAC to the gas control valve or the on/off circuit on this fireplace.
This fireplace utilizes 110 VAC to power the receiver module and intermittent pilot system. A
separate battery box is included to provide power for the adjustable flame height and in case of
power outages (see “Battery Pack – Wireless Wall Switch Installation” on page 19 for details).
• The electrical line to the grounded receptacle inside the fireplace must be installed by a
qualified installer and must meet all local codes. The fireplace must be properly grounded in
accordance with local codes (or ANSI/NFPA 70-1987).
• Make sure the household breaker is shut off prior to working on any electrical lines.
• The fireplace must be properly grounded in accordance with local codes (or ANSI/NFPA 70-1987)
• The electrical line must be a min. 14 gauge and supply 120 Volts at 60 Hz (2 Amps)
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause
improper and dangerous operation.
• Attach an electrical line to the receptacle inside the control box (see the illustration below).
Make sure to connect the ground wire to the grounding tab on the receptacle (this grounds the
fireplace).
Grounded 110V
Power Supply
Attacfh the electrical line
including the grounding wire
to this receptacle.
These wires are for the
optional accent light.
Control Box
Cover Plate
Romex Connector

18 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Accent Light Electrical Connection
Make sure power to the heater has been turned off prior to installation (disable the breaker).
Do not connect 110-120 VAC to the gas control valve or the on/off circuit on this fireplace.
• The electrical line must be installed by a qualified installer and must meet all local codes.
• The optional accent light requires a 110v circuit wired through a junction box to the fireplace.
See the illustration below for details.
Junction Box
(not supplied)
Insulated Wire (Romex)
Do not route the wires over the top
of the fireplace.
Power Supply
(110v ac)
Cover Plate on Control Box
(see instructions below)
Rheostat (included)
Cover Plate (included) Knob (included)
Wiring Schematic
Rheostat Junction Box Accent Lights
Power Supply
Hot
(black)
Common
(white)
Ground
(green)
Hot
(black)
Common
(white)
Ground
(green)
Fireplace Junction Box
Accent
Light
Molex
Connector
The wiring for the accent light is best installed
prior to drywall installation around the fireplace.
All electrical connections must be made by a
qualified installer and must meet all local codes.
Remove one of the knock-outs on the cover
plate and pass the wiring through the cover
plate (use the romex connector included with
the accent light). Attach the hot and common
wire from the accent light switched power
supply to the black and white wire leading from
the molex connector. Attach the ground wire to
the grounding tab on the receptacle.
Fireplace Power Supply
(attached to receptacle)
Control Box
Cover Plate
Romex
Connectors
Accent Light Switched
Power Supply

Installation (for qualified installers only) 19
© Travis Industries 4090807 100-01193_003
Battery Pack – Wireless Wall Switch Installation
• The control panel must be mounted inside a junction box in a location that may be reached by
the 12’ long battery pack and DCMD wires (see Figure 11).
Staple the two wires near the junction
box. This prevents the wires from
slipping out of the junction box while
the batteries are replaced. Take care
to prevent damage to wires.
PRESSTO OPEN
LatchingSolenoid DC Motor Drive
Junction Box
(not supplied)
Battery
Pack
Wireless
Wall
Switch*
Cover
Plate
Battery Pack Wires (4)
DCMD Wires (2)
Receiver
Module
Gas Control
Valve
Wire Length = 12'
* The wireless wall switch may be located at a
separate location. An additional cover plate would be
required for the battery back junction box.
Do not route the wires over the top
of the fireplace.
Figure 11

20 Installation (for qualified installers only)
© Travis Industries 4090807 100-01193_003
Ste s for Installing the Battery Pack and Wall Switch
1. Connect the battery pack wire harness to the receiver module where it is marked “AUX” (see
Figure 12 – item “a”). At this time make sure the continuous pilot switch is set to “OFF” and the
remote switch is set to “REMOTE” on the receiver module (see Figure 12 – item “b”). You may
also wish to verify the wires leading from the receiver are fully attached.
2. Connect the DCMD wires (red and red/black) to the two wires (red and black) exiting the motor
assembly on the gas control valve (see Figure 12 – item “c”).
PRESS TO OPEN
POWER
AUX
Learn
Continuous
Pilot
Off/On Remote/Off ADJ
SI
Battery Box Wires (DC Motor Drive) - 12' Length
Black, Brown, Red, and Orange wires
DCMD Wires (DC Motor Drive) - 12' Length
Red and Black/Red wires (w quick connects)
White
Green
Orange
White
Main Burner Control Wires
Pilot Flame Control Wires
Sensor ("S")
Wire (White)
Not
Used
Battery Box
Gas Control Valve
Receiver
Module
Pilot Assembly
Make sure continuous pilot
is set to "OFF" and remote
is set to "REMOTE".
a
b
c
Igniter ("I") Wire
(Orange - with
fiberglass
insulation)
AC Adapter
(wire orientation does not matter)
Figure 12
