Travis Industries DVS GSR User manual


DVS GSR Dancing-Fyre Burner:
Installation Instructions (SKU96900103)


Page 1 of 4 17601694.docx — 4/13/12 © Travis Industries, Inc.
Compatibility
DVSGSRNBInsert
DVSGSNB(AU)Inbuilt
Packing List

LeftandRightEmberTrays





AirDeflector


DVSDancingFyreBurnerAssembly
Burner Installation
1. Removetheglassframe.
IfusingtheDriftwoodorFyrestonesSet(SKU94500540or94700732):
Disablethelightbyremovingthebulbandlayingthehousingflatinthefireboxcavity.Replacethescrewfromthe
lightbracketintothefireboxfloor.
 

IfusingtheTraditionalLogSet(SKU94500991)withfirebacks:
a. Bendtheaccentlightassemblytothesideandoutoftheway.
b. Installthefirebacks.Bendtheaccentlightassemblytoitsoriginalposition.
c. Installtheburnerfollowingthedirectionsbelow.




DVS GSR Dancing-Fyre Burner:
Installation Instructions (SKU96900103)


Page 2 of 4 17601694.docx — 4/13/12 © Travis Industries, Inc.
2. Installtheburnerandsideembertraysasshownbelow.
d. Makesuretheburnerisfullyseatedovertheorifices(theburnershouldbealignedallthewaytotheright).

e. Attachthesideembertraystotheburner,usingthescrewsalreadyinplace.
 

Anoverviewoftheburnerinstallationisshownbelow.



DVS GSR Dancing-Fyre Burner:
Installation Instructions (SKU96900103)


Page 3 of 4 17601694.docx — 4/13/12 © Travis Industries, Inc.
Installing the Air Deflector
IfusingtheTraditionalLogSet(SKU94500991):
NOTE:Donotdisablethelightbyremovingthebulbandlayingthehousingflatinthefireboxcavity.

a. Usetinsnipstocutoutthenotchintheairdeflectortoallowittofitaroundthelightbracket.

b. Attachtheairdeflectortotherearofthefireboxcavity,usingthescrewsalreadyinplace.Inserttheair
deflectorwiththescrewholesfacingup,sothenotchfitsaroundthelightbracket,andthentiltitbackso
thescrewholesarealignedwiththeholesprovidedinthefirebox.







DVS GSR Dancing-Fyre Burner:
Installation Instructions (SKU96900103)


Page 4 of 4 17601694.docx — 4/13/12 © Travis Industries, Inc.
IfusingtheDriftwoodorFyrestonesSet(SKU94500540or94700732):

Attachtheairdeflectortotherearofthefireboxcavity,usingthescrewsalreadyinplace(thisappliestoall
mediakitsexcepttheTraditionalLogSet(SKU94500991).
 
 

3. Installtheselectedmediaoptionkit(logorstoneset)followingtheinstructionsincludedwiththekit:
94700732StoneSet,31DVIFyre‐Stones
94500540LogSet,31DVIDriftwood
94500991LogSet,31DVITraditional

