Travis industries 864 trv User manual

864TRV Fireplace

• Operation

• Maintenance

Tested and Listed by

OMNI-Test Laboratories, Inc.

Beaverton, Oregon

Report # 028- -59-5

ANSI Z21.88b-2003

WARNING: If the information in these instructions is not follo ed exactly, a fire or

explosion may result causing property damage, personal injury or loss of life.

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or

any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical s itch; do not use any phone in your building.

• Immediately call gas supplier from a neighbor's phone. Follo the gas supplier's

instructions.

• If you cannot reach your gas supplier, call the fire department.

- Installation and service must be performed by a qualified installer, service agency or the

gas supplier.

This appliance may be installed as an OEM installation in a manufactured (mobile) home and must be

installed in accordance ith the manufacturer’s instructions and the manufactured home construction

and safety standard, Title 24 CFR, Part 3280.

This appliance is only for use ith the type(s) of gas indicated on the rating plate. A conversion kit is

supplied ith the appliance.

O ner's Manual

Mukilteo, WA 98275

2 Introduction

Travis Industries4050812100-01168_001

Introduction

We welcome you as a new owner of a 864TRV gas fireplace. This manual details operation and

maintenance of this fireplace. Please familiarize yourself with the Owner's Manual before

operating your heater and save the manual for future reference.

Important Information

No other 864 TRV gas fireplace has the same serial

number as yours. The serial number is on the listing

label that is chained to the gas control valve. This

serial number may be needed in case you require

service.

Model: 864TRV ireplace

Serial Number:

Purchase Date:

Purchased rom:

Register your arranty online at:

travis arranty.com

Or, mail your arranty card to:

Travis Industries House of ire

4800 Harbour Pointe Blvd. SW

Mukilteo, WA 98275

Save Your Bill of Sale.

To receive full warranty coverage, you will

need to show evidence of the date you

purchased your heater. Do not mail your

Bill of Sale to us.

We suggest that you attach your Bill of

Sale to this page so that you will have all

the information you need in one place

should the need for service or information

occur.

Installation Warnings

• Installation requirements are printed in the 864TRV Installation Manual (part # 100-

01173). All requirements in the installation manual must be met.

• Failure to follo all of the requirements may result in property damage, bodily injury,

or even death.

• This heater must be installed by a qualified installer ho has gone through a training

program for the installation of direct vent gas appliances.

• This appliance must be installed in accordance ith all local codes, if any; if not,

follo ANSI Z223.1 and NFPA 54(88).

• In Manufactured or Mobile Homes must conform ith Manufactured Home

Construction and Safety Standard, Title 24 CFR, Part 3280, or, hen such a standard

is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS

A225.1. This appliance may be installed in Manufactured Housing only after the home

is site located.

• The fireplace is designed to operate on natural gas, or propane (LP).

• All exhaust gases must be vented outside the structure of the living-area.

Combustion air is dra n from outside the living-area structure.

• Notify your insurance company before hooking up this fireplace.

Introduction 3

Table of Contents

Introduction and Important Information

Introduction.............................................................2

Important Information ...............................................2

Installation Warnings ................................................ 2

eatures.................................................................3

Heating Specifications ..............................................3

Safety Precautions

Safety Precautions...................................................4

Operation

Before You Begin..................................................... 6

Location of Controls .................................................6

Starting The Pilot lame............................................ 6

Starting the ireplace for the irst Time.......................8

Turning the ireplace On and Off................................ 8

Adjusting the lame Height........................................8

Adjusting the Optional Blower Speed............................9

Normal Operating Sounds..........................................9

Normal Operating Odors............................................9

Maintenance

Maintaining Your ireplace's Appearance..................... 10

Yearly Service Procedure.......................................... 10

Grill Installation and Removal .................................... 11

ace Installation and Removal................................... 12

Glass rame Removal and Installation........................ 13

Log Set Installation .................................................. 15

Glass Cleaning........................................................ 20

Troubleshooting Table ............................................... 21

How this ireplace Works.......................................... 22

Wiring Diagram........................................................ 23

Replacement Parts List ............................................ 23

Warranty

Warranty ................................................................ 24

Optional Equipment

Optional Equipment List............................................ 25

Index

Index...................................................................... 26

Features

• Works During Power Outages (millivolt system)

• Optional Thermostat or Remote Control

• Realistic "Wood ire" Look

• Optional Blower for Effective Heat Distribution

• Convenient Operating Controls

• Variable-Rate Heat Output

• Low Maintenance

Heating Specifications

Natural Gas Propane

Approximate Heating Capacity (in square feet)* 450 to 1,400 450 to 1,400

Maximum BTU Input Per Hour 31,000 31,000

Minimum BTU Output on Low 6,700 5,200

Steady State Efficiency** (with blowers on) 77.2 % 78.4 %

A UE (Annual uel Utilization Efficiency) 68.3 % 69.4 %

* Heating capacity will vary with floor plan, insulation, and outside temperature.

** Efficiency rating is a product thermal efficiency rating determined under continuous

operation independent of installed system.

4 Safety Precautions

IF YOU SMELL GAS:

* Do not light any appliance

* Extinguish any open flame

* Do not touch any electrical s itch or plug or unplug anything

* Open indo s and vacate building

* Call gas supplier from neighbor's house, if not reached, call fire department

This unit must be installed b

y

a qualified installer to prevent the possibilit

y

of an

explosion. Your dealer will know the requirements in your area and can inform you

of those people considered qualified. The room heater should be inspected and

cleaned before use and at least annually by a qualified service person. More

frequent cleaning may be required due to excessive lint from carpeting, bedding

material, etc.

The instructions in this manual must be strictl

y

adhered to. Do not use makeshift

methods or compromise in the installation. Improper installation will void the

warrant

y

and safet

y

listin

g

.

For LPG only | Pout 11” W.C.

Look for this label:

If the label is present, the

heater is equipped for LP

(propane). If the label is

absent, the heater is equipped

for NG (natural gas).

This heater is either approved for natural

gas (NG) or for propane (LP). Burning the

incorrect fuel will void the warranty and

safety listing and may cause an extreme

safety hazard. Direct questions about the

type of fuel used to your dealer. Check the

label and flame adjust knob on the gas

control valve.

Ok

Contact

y

our local buildin

g

officials to obtain a permit and

information on any installation

restrictions or inspection

requirements in your area.

Notify your insurance

company of this heater as

well.

If the flame becomes soot

y

,

dark orange in color, or

extremely tall, do not operate

the heater. Call your dealer

and arrange for proper

servicing.

It is imperative that control

compartments, screens, or

circulating air passageways of

the heater be kept clean and

free of obstructions. These

areas provide the air necessary

for safe operation. ?Do not operate the heater if it is

not operating properly in any

fashion or if you are uncertain.

Call your dealer for a full

explanation of your heater and

what to expect.

Gas

Do not store or use

g

asoline or

other flammable liquids in the

vicinity of this heater.

AAAAA

AA

Do not operate if an

y

portion of

the heater was submerged in

water or if an

y

corrosion occurs.

Immediately call a qualified

service technician to inspect

the appliance and to replace

any part of the control system

and any gas control that has

been under water.

Safety Precautions 5

Do not place clothin

g

or other

flammable items on or near

the heater. Because this

heater can be controlled by a

thermostat there is a possibility

of the heater turning on and

igniting any items placed on

or near it.

AA

A

Li

g

ht the heater usin

g

the built-

in piezo igniter. Do not use

matches or any other external

device to light your heater.

Allow the heater to cool before

carrying out any maintenance

or cleaning.

The viewin

g

lass should be

opened only for lighting the

pilot or conducting service. Do

not operate with cracked,

broken, or removed glass.

An

y

safet

y

screen or

g

uard

removed for servicing must be

replaced prior to operating the

heater.

Never remove, replace, modify

or substitute any part of the

heater unless instructions are

given in this manual. All other

work must be done by a trained

technician. Don't modify or

replace orifices.

Operate the heater accordin

g

to the instructions included in

this manual.

If the main burners do not start

correctly turn the gas off at the

gas control valve and call your

dealer for service.

The pilot flame must contact

the thermopile and

thermocouple (see the

illustration to the left). If it does

not, turn the gas control valve

to "O " and call your dealer.

AA

This unit is not for use with

solid fuel

Do not place an

y

thin

g

inside

the firebox (except the

included fiber logs).

If the fiber lo

g

s become

damaged, replace with Travis

Industries log set.

This

Manual

Do not throw this manual awa

y

.

This manual has important

operating and maintenance

instructions that you will need

at a later time. Always follow

the instructions in this manual.

Children and adults should be

alerted to the hazards of high

surface temperature and

should stay away to avoid

burns or clothing ignition.

Young children should be

supervised when they are in

the same room as the heater.

Travis Industries, Inc.

g

rants

no arranty, implied or stated,

for the installation or

maintenance of your heater,

and assumes no

responsibility of any

consequential damage(s).

Instruct ever

y

one in the house

how to shut gas off to the

appliance and at the gas main

shutoff valve. The gas main

shutoff valve is usually next to

the gas meter or propane tank

and requires a wrench to shut

off.

6 Operation

Before You Begin

• Read this entire manual before you use your new fireplace (especially the section "Safety

Precautions" on pages 4 & 5). ailure to follow the instructions may result in property damage,

bodily injury, or even death.

Location of Controls

AAAAAAAAA

Lift the control cover up and swing it

forward to access the controls.

Pilot Igniter

ON/OFF Switch

Flame Adjust Knob Gas Control Knob

An instruction card for operating

the fireplace is attached to the

inside of the fireplace here.

Replace it for easy reference.

The Pilot Flame can be

found under the right side log

.

Comfort Control

Gas Control Valve

Optional Blower Control

Optional Accent Light

Pilot Igniter The pilot igniter is used only to start the pilot. When pressed, it sends an

electrical charge to the pilot assembly. This creates a blue spark

directly next to the pilot, igniting the pilot flame.

On/Off S itch This control is used to turn the fireplace burners on and off.

Gas Control Knob This knob is used to control gas to the fireplace and for starting the pilot.

There are three positions, ON, O , & PILOT. The pointer to the left of

the knob indicates the position this knob is in.

Flame Adjust Knob This knob controls the flame height from low ("LO") to high ("HI"). The

pointer above the knob points to the position this knob is in.

Comfort Control This lever turns the rear burner on and off.

NOTE: THIS IS NOT A SHUTO VALVE.

Optional Blo er Control This knob controls the speed of the optional internal convection blower

that pushes heated air into the room.

Optional Accent Light This knob controls the optional accent lights located behind the logs.

Operation 7

Starting The Pilot Flame

The pilot flame is required to ignite the

main burners (it also plays a safety role). It

should be left on once lit. It will stay lit

unless the gas control valve is turned to

"O ". However, the pilot will go out if the

gas is shut off, the propane tank runs out (or

low) or if the stove malfunctions. If the pilot

turns off frequently, call your dealer for

information. To start the pilot follow the

directions below:

WARNING:

When lighting or re-lighting the pilot, the

glass must be removed (see page 10).

aRemove the glass (see page 10 for

details).

bPush the gas control knob in slightly and

turn it to the "O " position. The knob

will not turn from "ON" to "O " unless the

knob is depressed slightly. Wait five

minutes to let any gas that may have

accumulated inside the firebox escape.

If you smell leaking gas, follow the

directions on the cover "I YOU SMELL

GAS".

cTurn the gas control knob to the "PILOT"

position and press the knob in, this will

allow gas to flow to the pilot light. Press

the button on the pilot igniter repeatedly

until you see the pilot light.

WARNING:

If the pilot does not light after 15 seconds,

release the knob and call your dealer for

service. Do not attempt to light pilot until

service has been performed.

NOTE:

You may ish to remove the log set to gain

a better vie of the pilot (see page 15).

dKeep the gas control knob depressed for

30 seconds once it is lit.

eRelease the gas control knob. If the pilot

goes out, repeat step C. If the pilot

refuses to stay lit, call your dealer for

service. With the pilot lit, proceed to step

“f”.

fReplace the glass.

gTurn the gas control knob counter-

clockwise to "ON". The pilot is now lit

and the heater can be turned on and off.

?

AA

A

30 seconds

PILOT

IGNITER

a

b

AA

A

5 minutes

c

d

e

f

g

AA

AAA

AAAAAAA

AA

AAA

AAAAAAA

AA

AAA

AAAAAAA

AA

AAA

AAAAAAA

8 Operation

Starting the Fireplace for the First Time

• Burn the heater at a high setting with the blower off for an extended period (up to 48 hours).

This will cure the painted surfaces. Fumes from the paint curing and oil burning off the steel

will occur. This is normal. We recommend opening a window to vent the room.

• Condensation may appear on the glass each time you start the fireplace - this is normal.

• Blue Flames will occur on the fireplace when it first comes on. After fifteen minutes the flames

will turn a more realistic yellow and orange color.

• Certain installations use a remote "wall switch" to turn the fireplace on and off. If this is the

case, leave the ON/O switch "ON".

Turning the Fireplace On and Off

After the pilot has been started...

OFF

ROOM TEMP

°F

SETTEMP

TIMER

MIN

Time

Set

Time

Cancel

A

u

t

o

O

FF

O

N

A switch is provided behind

the control cover (below

the firebox).

An optional remote may be

used (see the instructions

included with the remote).

An optional wall thermostat

may be used to control the

temperature.

A wall switch may be

used to turn the

fireplace on and off.

NOTE FOR REMOTES, THERMOSTATS, OR WALL SWITCHES:

The on/off switch on the fireplace may be required to be left in the ON or O position for the fireplace

to operate. Consult your installer or dealer for details.

• Do not place any combustible items on top of or directly in front of the fireplace, even

temporarily. The optional thermostat may start the fireplace causing a combustible item to

ignite.

• If the fireplace turns on and off frequently while using the thermostat, you may want to adjust

the flame height down until it produces just enough heat needed.

djusting the Flame Height

• Your fireplace has an adjustable flame to tailor the look and heat output to your specific needs.

It is adjusted by turning the middle dial on the gas control valve.

Flame Height

Adjustment Knob

Index Mark

Turn counter-clockwise to adjust the flame higher, clockwise to lower.

Operation 9

djusting the Optional Blower Speed

The blower helps transfer heat from the heater into the room. It will not turn on until the heater is

up to temperature (approximately 10 minutes after starting). See the illustration below for

instructions on adjusting the blower speed.

OFF

Turn the dial all the

way counter-clockwise

until it clicks off.

HIGH

The high position is all the

way counter-clockwise,

without clicking off.

LOW

Turn the dial all the

way clockwise.

Normal Operating Sounds

Gas Control Valve

As the gas control valve is turned

on and off you will hear a dull

clicking sound. This is the valve

Blower Snap Disk

This part can produce a

clicking sound as it turns

the blower on and off.

The appliance may creak with change of

temperature -- THIS IS NORMAL.

Pilot Flame

The pilot flame, which remains on,

makes a very slight "whisper" sound.

Blowers

This heater has optional blowers to push

heated air into the room. You will hear the

sound of air movement that increases as

the speed is increased.

Extinction Pops

It is not unusual, especially on Propane

(LP) appliances, to experience a "pop"

when the burner is shut off.

Normal Operating Odors

This appliance has several areas that reach high temperatures. Dust or other particles on these

areas may burn and create an odor. This is normal during start-up. You may notice the smell is

more acute if the appliance was left idle for a long period.

10 Maintenance

Maintaining Your Fireplace's ppearance

ingerprints or other marks left on the optional plated surface may become etched in place if they

are not wiped clean prior to turning the fireplace on. Clean the plated surface with denatured

alcohol and a soft cloth (with the fireplace cool). Other cleaners may leave a film that may

become etched into the surface.

Yearly Service Procedure

• ailure to inspect and maintain the fireplace may lead to improper combustion and a potentially dangerous

situation. We recommend the following procedures be done by a qualified technician.

1. Check the pilot flame. It should touch approximately 3/8" of the top of the thermopile and touch the top of

the thermocouple (see illustration below). If it does not, contact your dealer for service.

2. Shut off gas to the fireplace by turning the gas control knob to "O " (see step A under "Starting the Pilot"

on page 7). Let the fireplace cool for 15 minutes. Remove the glass (see page 10).

3. Remove the log set (NOTE: the logs are very fragile - see page 15). If severely deteriorated, replace.

Check the logs for sooting. A small amount of soot along the bottom of the logs is normal. If excessive

sooting is found, the fireplace will require adjustment. Contact your dealer.

4. Inspect the burner and remove any debris.

• Make sure the burner is not warped, cracked, or damaged.

• Check the firebox and area around the pilot to make sure there is no warping or damage.

• If any problem is found, discontinue use and contact your dealer for service.

AA

A

Check the burner holes.

Make sure the burners are not

warped or damaged.

Thermopile Pilot Hood

Thermocouple

Before Disassembly - Check the pilot flame. It

should touch the thermocouple and thermopile.

Check the walls and ceiling

of the firebox for

deterioration.

5. Replace the log set. Clean and replace the glass (see Glass Cleaning on page 20). If the glass is

damaged, replace. Make sure the gasket along the perimeter of the glass contacts the face of the firebox

and forms an air-tight seal. If it does not, re-align or replace the gasket to insure an air-tight seal.

6. Inspect the area behind the access door. Clean if necessary. Check the gas control valve and the gas

lines. If damage is found, discontinue use and contact your dealer for service. Clean the air channels,

ducts, and blower (if applicable).

7. Start the pilot and turn on the main burner. The flames should be orange/yellow and not touch the top of the

firebox. If the pilot or main burners do not burn correctly, contact your dealer for service. Monitor the

blower operation.

8. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or

deterioration is found near the vent termination.

Maintenance 11

Grill Installation and Removal

Some fireplaces have grills above and below the glass frame. These grills may be installed

following the directions below (follow in reverse to remove).

AAA

AA

AAAA

A

AAA

Upper Grill Installation

Hold the grill at an angle and insert the lower

slot over the bushing on the fireplace (both

sides). You may need press on the grill to get

the tab over the bushing (this prevents the

grill from accidentally falling off).

Swing the grill upwards to engage the second

slot. You will need to lift the grill slightly to

get it over the bushing. Once in place the

grill is held in place by gravity.

Lower Grill Installation

Hold the grill at an angle and insert the lower

slot over the bushing on the fireplace (both

sides). You may need press on the grill to get

the tab over the bushing (this prevents the

grill from accidentally falling off).

Bend this the tab over on

both sides. This is the

end-stop for the lower grill,

it allows the grill to swing

forward.

Swing the grill upwards to engage

the second slot. You will need to lift

the grill slightly to get it over the

bushing. Once in place the grill is

held in place by gravity.

12 Maintenance

Face Installation and Removal

Some fireplaces have a face that fits over the glass frame. The face can be removed following the

directions below.

Phillips

Screwdriver

Four screws hold the face

in place. The screws are

accessed through the

grills on the face.

Maintenance 13

Glass Frame Removal and Installation

Warning: The appliance must be completely cool before removing the glass.

Warning: Do not strike or slam the glass.

AAAA

AA

AAAA

AA

AAAA

AA

AAAAAAAA

Based upon the face being used, either:

(a) swing the access door down and remove the top grill,

(b) remove the face (unscrew or lift off - see the

instructions included with the face for details).

Open the six latches holding the glass frame in place

(start with the bottom three) - follow the directions shown

to the right.

a

Lift the glass frame up and

pull it forward to remove.

b

Re-Attaching the Glass Frame:

a) Hang the glass frame on the firebox.

b) While holding in place, attach the upper latches

(follow the instructions to the right in reverse).

c) Lift the glass frame slightly and attach the lower latches.

NOTE: Make sure the glass frame is all the way in place - it

should be flush with the front of the fireplace when installed.

NOTE:

You may need to lift

the glass frame

while re-attaching.

Glass

Top of

Firebox

Latch

Catch

(on glass frame)

14 Maintenance

Glass Frame Removal and Installation (continued)

The latch can come loose from the latch assembly. This occurs only when it is rotated. Follow the

directions below to re-install the latch if it comes loose.

Top of

Firebox

Hold the latch at an angle and insert it into the slot on the glass frame anchor.

NOTE: this slot may be at a

different angle than illustrated.

Note how the washer on the latch fits behind the flange on the

glass frame anchor.

Glass Frame

Anchor

Once fully inserted, turn the latch until it is upright.

Latch

Maintenance 15

Log Set Installation

Rear Log Installation

Place the rear log as shown below. Make sure it is pushed all the way back on the log shelf.

The rear log has a slot that

straddles the rear burner and

pilot assembly

16 Maintenance

Right Log Installation

Place the right log as shown below.

The right log has a

curved slot that fits over

the right side gr

a

te.

The left side of the

log should be slid

back against this

led

g

e.

Maintenance 17

Left Log Installation

Place the left log as shown above.

Note how the right side of

the log comes up, but does

not cover, the burner holes..

18 Maintenance

Center Log Installation

Note how the center log rests on the center grate.

The pin on the rear log

inserts into the hole on

the center log.

Maintenance 19

Ember Installation

Place the embers along the hearth plate and burner - make sure they do not cover any burner holes

or air channels. Use the embers to cover any rivets and to make the firebox more realistic.

20 Maintenance

Glass Cleaning

The glass may be cleaned with a non-

abrasive cleaner. To clean the inside of

the glass, sim ly remove the glass frame,

lace it on a non-scratching surface, and clean

the inside surface.

If the outside surface of the glass frame

requires cleaning, follow the directions

below to remove the outer glass frame

and screen.

AAA

NOTE: The screen between the glass frame and glass is not required. It may be removed if desired.

WARNING: do not o erate the fire lace without the glass (and frame) in lace.

AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA

Use needle-nose pliers to

straighten this tab.

AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA

The screen is

sandwiched between

the inner and outer

glass frame.

Inner glass frame

Outer glass frame

NOTE: when re-attaching the outer frame,

bend the tab inwards 30°(do not over-bend)

A tab at each corner of the glass assembly holds the

inner glass frame to the outer glass frame.

With the outer glass

frame and screen

removed, the outer

surface of the glass

may be cleaned.

Travis Industries 864 TRV User manual

Popular Indoor Fireplace manuals by other brands
