Travis Industries 1250 Insert User manual

1250 Wood Insert
Owner's Manual
•Masonry Fireplace Insert •Zero-Clearance (Metal)
Fireplace Insert
Save these instructions
for future reference
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may
result. For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
Travis Industries, Inc.
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
www.travisproducts.com
©Copyright 2011, T.I.
$10.00 100-01233_000
4110304 Listed
Tested to: U.L. 1482 & ULC S628

2 Introduction
© Travis Industries 100-01233 4110304
Introduction
We welcome you as a new owner of a 1250 wood-burning fireplace insert. In purchasing a 1250
fireplace insert you have joined the growing ranks of concerned individuals whose selection of an energy
system reflects both a concern for the environment and aesthetics. This insert is one of the finest
appliances the world over. This manual will explain the installation, operation, and maintenance of this
appliance. Please familiarize yourself with the Owner's Manual before operating your appliance and save
the manual for future reference. Included are helpful hints and suggestions which will make the
installation and operation of your new appliance an easier and more enjoyable experience. We offer our
continual support and guidance to help you achieve the maximum benefit and enjoyment from your
appliance.
Important Information
No other 1250 fireplace insert appliance has the same
serial number as yours. The serial number is
stamped onto the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: 1250 Fireplace Insert
Serial Number:
Purchase Date:
Purchased From:
Register your warranty online at:
traviswarranty.com
Or, mail your warranty card to:
Travis Industries House of Fire
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
Save Your Bill of Sale.
To receive full warranty coverage, you will
need to show evidence of the date you
purchased your heater. Do not mail your Bill
of Sale to us.
We suggest that you attach your Bill of Sale
to this page so that you will have all the
information you need in one place should the
need for service or information occur.

Table of Contents 3
© Travis Industries 100-01233 4110304
General Information
Introduction & Important Information.......................... 2
Safety Precautions..................................................... 4
Features & Specifications .......................................... 6
Fireplace Insert Installation
Planning The Installation............................................ 7
Preparation for Installation.................................... 7
Additional Accessories Needed for Installation..... 7
Installation Considerations ................................... 7
Additional Requirements for Canada.................... 7
Fireplace Requirements............................................. 8
Fireplace Altered Tag................................................. 8
Insert Placement Requirements................................. 9
Hearth Requirements................................................. 9
Masonry Fireplace Requirements .............................. 10
Zero-Clearance (Metal) Fireplace Requirements....... 10
Drafting Performance................................................. 11
Flue Installation.......................................................... 11
Surround Panel Installation........................................ 12
Insert with Positive Connection.................................. 14
Insert with Direct Connection (Masonry Fireplace)..... 14
Operating Your Appliance
Safety Notice.............................................................. 15
Before Your First Fire................................................. 15
Opening the Door....................................................... 15
Starting a Fire ............................................................ 17
Adjusting the Burn Rate............................................. 18
Ash Removal.............................................................. 18
Blower Operation ....................................................... 19
Re-Loading the Stove ................................................ 19
Overnight Burn........................................................... 19
Normal Operating Sounds.......................................... 19
Hints for Burning........................................................ 20
Selecting Wood.......................................................... 20
Troubleshooting ......................................................... 21
Maintaining Your Appliance
Daily Maintenance...................................................... 22
Remove Ash .............................................................. 22
Clean The Glass........................................................ 22
Monthly Maintenance................................................. 23
Door and Glass Inspection......................................... 24
Check For Creosote Buildup...................................... 23
Yearly Maintenance ................................................... 24
Touch Up Paint.......................................................... 24
Blower Cleaning......................................................... 24
Firebrick and Baffle Inspection................................... 24
Door Parts.................................................................. 25
Replacing the Glass................................................... 25
Replacing the Door Gasket........................................ 25
Replacing the Door Handle........................................ 25
Firebox Parts.............................................................. 26
Baffle Removal and Replacement.............................. 26
Air Tube Removal and Replacement ......................... 27
Warranty....................................................................... 28
Listing Information.................................................... 30
Index.............................................................................. 32

4 Safety Precautions
© Travis Industries 100-01233 4110304
The viewing door must be
closed and latched during
operation.
Smoke from this appliance may
active a smoke detector when
the door is open.
Never block free airflow through
the air vents on this appliance.
Gas
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
ASHES
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
36"
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
away from the front of the
appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Ok
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
Type
HT Clay
Liner
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.

Safety Precautions 5
© Travis Industries 100-01233 4110304
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not place clothing or other
flammable items on or near this
appliance.



Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
Do not make any changes to the
appliance to increase
combustion air.
Maintain the door and glass seal
and keep them in good
condition.
Do not operate this heater with
broken or missing glass.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Overfiring the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are overfiring.
This
Manual
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance,and assumes no
responsibility of any
consequential damage(s).

6 Stove Installation (for qualified installers only)
© Travis Industries 100-01233 4110304
Installation Options
•Masonry Fireplace Insert
•Zero-Clearance (Metal) Fireplace Insert
Features
•EPA Phase II Approved
•1.6 Cubic Foot Firebox Volume
•Single Operating Control
•Accepts Logs Up to 18" Long
•Steel Plate Construction (Up to 3/16”)
•Heavy Duty Refractory Firebrick
•Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 750 to 1,200
Maximum Burn Time Up to 8 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
13-1/2"
343mm
5-7/8"
150mm
20"
508mm
23-5/8"
601mm
18-5/8"
474mm
3"
77mm
a
b
Figure 1
(a) Measure side and top clearances from the top plate. Measure front clearances from the stove face
(b) Fireplace Opening
Emissions
4.4 Grams Per Hour (EPA Phase II Approved)

Fireplace Insert Installation (for qualified installers only) 7
© Travis Industries 100-01233 4110304
SAFETY NOTICE:
Please read this entire manual before you install and use your new room heater. Failure to
follow instructions may result in propertydamage, bodily injury, or even death. Contact
local building or fire officials about restrictions and installation inspection requirements in
your area.
Planning The Installation
We suggest that you have an authorized Travis Industries dealer install your fireplace insert. If you
install the fireplace insert yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this fireplace insert and
notify your insurance company before proceeding with installation.
Preparation for Installation
•Check for damage to the exterior of the fireplace insert (dents should be reported, scratches can be
fixed by applying touch up paint).
•Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The fireplace insert can be lightened by removing the firebricks and baffle - replace before operation.
Additional Accessories Needed for Installation
•Door (shipped separately)
•Surround Panels (see page12)
Installation Considerations
Installation Type Considerations
Insert with Positive Flue (Full Reline) (Page 14)
REQUIRED IN CANADA • Utilizes existing masonry or zero clearance fireplace
• Provides best draft
• Easiest to clean
Insert with Direct Connect Flue (Page 14)
NOT APPROVED IN CANADA • Utilizes existing masonry or zero clearance fireplace
• Provides good draft
• Requires fireplace block-off plate - see page 14
Additional Requirements for Canada
•Do not remove bricks or mortar from existing fireplace.
•This fireplace insert must be installed with a continuous chimney liner of 6” diameter extending from
the fireplace insert to the top of the chimney. The chimney liner must conform to the Class 3
requirements of CAN/ULC-S636, Standard for Lining Systems for Existing Masonry or Factory-Built
Chimneys and Vents, or CAN/ULC-S640, Standard for Lining Systems for New Masonry Chimneys.
•Permanently seal any opening between the masonry of the fireplace and the facing masonry.
•Fireplace insert, or surround panels, may be removed to inspect fireplace insert and fireplace.

8 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01233 4110304
Fireplace Requirements
Figure 2 shows the minimum size requirements for the type of fireplace used.
a
ce
f
b
d
h
i
j
g
Non-Combustible Hearth
Combustible Mantel
Non-Combustible Facing
Minimum
Fireplace Size Masonry Fireplace Z.C. (Metal) Fireplace
a Height (front) 20.75"528mm20.75"528mm
b Height (rear) 20.75"528mm20.75"528mm
c Width (front) 23.625"601mm25.625"651mm*
d Width (rear) 23.625"601mm25.625"651mm*
e Depth 13.5"343mm14.5"369mm*
f Hearth Depth
(includes insert
depth on hearth
plus required
hearth extension)
19"483mm (US)
- - - - - - - - - - - -
21"534mm
(Canada)
19"483mm (US)
- - - - - - - - - - - -
21"534mm
(Canada)
g Hearth Width 39.625"1007mm39.625"1007mm
h Facing Width 42.625"1083mm47.625"1210mm
i Facing Height 32"813mm32"813mm
j Mantel Height
35.5"902mm44"1118mm
Figure 2 * 1” (26mm) Clearance to fireplace walls is required for ZC Fireplaces.
Fireplace Altered Tag
Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable
method). You may wish to place it in a location where it will be covered by the surround panels.

Fireplace Insert Installation (for qualified installers only) 9
© Travis Industries 100-01233 4110304
Insert Placement Requirements
•The insert must be placed so that no combustibles are within, or can swing within (e.g. drapes,
doors), 36" (915) of the front of the insert (Figure 3 “q”).
•Insert and hearth must be installed on a level, secure floor
•The minimum clearances, facing, and hearth requirements in Figure 3 must be met. Follow the
clearances for the type of fireplace being used – (masonry or zero-clearance-metal).






























Side
Wall
Combustible Mantel
Combustible Top Facing
Non-Combustible
Hearth
Facing
q
l
k
p
x
o
n
m
Minimum
Clearances Masonry Fireplace Z.C. (Metal) Fireplace
k Sidewall 13"331mm30"762mm
l Side Facing 9.5"242mm12"305mm
m Top Facing 12"305mm12"305mm
n Mantel 15.5"394mm24"610mm
o Front Hearth
(does not
include insert
extension “x”)
16" 407mm
(US)
- - - - - - - - - - -
18” 458mm
(Canada)
16" 407mm
(US)
- - - - - - - - - - -
18” 458mm
(Canada)
p Side Hearth 8" 204mm 8" 204mm
q Front of Insert 36"
915mm 36" 915mm
x Extension Onto
Hearth 3" 77mm 3" 77mm
Figure 3
Hearth Requirements
•Must extend 16" (USA) or 18” (Canada) in front of the insert and 8" on both sides.
•Must be non-combustible and at least .018" thick (26 gauge)

10 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01233 4110304
Masonry Fireplace Requirements
CANADA ONLY:
The fireplace insert must be installed with a continuous chimney liner of 6” diameter extending from the
fireplace insert to the top of the chimney. The chimney liner must conform to the Class 3 requirement of
Can/ULC S635, Standard Lining Systems for Existing Masonry or Factory- Built Chimney & Vents, or
CAN/ULC S640, Standard for Lining Systems for New Masonry Chimneys.
•Chimney must have a clay tile liner or a stainless steel liner (positive connection).
•Entire fireplace, including chimney, must be clean and undamaged. Any damage must be repaired
prior to installation of the insert.
•Chimney height: 15' (4.5M) minimum; 33' (10M) maximum.
•Entire fireplace, including chimney, must meet local building requirements.
•The fireplace insert must be placed on a masonry hearth built to UBC standards.
Zero-Clearance (Metal) Fireplace Requirements
CANADA ONLY:
The fireplace insert must be installed with a continuous chimney liner of 6” diameter extending from the
fireplace insert to the top of the chimney. The chimney liner must conform to the Class 3 requirement of
Can/ULC S635, Standard Lining Systems for Existing Masonry or Factory- Built Chimney & Vents, or
CAN/ULC S640, Standard for Lining Systems for New Masonry Chimneys.
•Must utilize a positive (full reline) or direct connection (block-off plate)
•Must be manufactured by one of the following manufacturers:
• Marco • Majestic • Heatilator • Preway • Tempco • Superior
• Heat N Glo • Lennox • Martin • Monesson
•Entire fireplace, including chimney, must be clean and undamaged. Any damage must be repaired
prior to installation of the insert
•Entire fireplace, including chimney, must meet local building requirements
•Chimney height: 15' (4.5M) minimum; 33' (10M) maximum. Minimum cross section: 28.65 square
inches (18626 sq mm)
•The damper ("A") and grate ("B") must be removed (see Figure 4). The smoke shelf ("C"), internal
baffles ("D"), screen ("E"), and metal or glass doors ("F") may be removed (if applicable). The
masonry lining ("G"), insulation ("H"), and any structured rigid frame members (metal sides, floor, door
frame, face of the fireplace, etc. – "I") may not be removed or altered
C
B
F
I
D
E
A
G
H
Figure 4

Fireplace Insert Installation (for qualified installers only) 11
© Travis Industries 100-01233 4110304
Drafting Performance
This appliance relies upon natural draft to operate. External forces, such as wind, barometric pressure,
topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.),
may adversely affect draft. Travis Industries can not be responsible for external forces leading to less
than optimal performance.
Leveling Bolt Installation
Two leveling bolts are included to level the insert if the fireplace has a stepped-up hearth. To install, raise
the rear of the insert up and insert the leveling bolts into the holes in the rear corners of the insert. Adjust
the bolts until they extend the same height as the hearth steps up. After the insert is installed, fine-tune
the leveling bolts to level the insert.






This distance is the
hearth step-up. The
leveling bolts should
stick out this far from the
base of the insert.
Fireplace
Hearth
The leveling bolts go
into the holes at the
rear corners of the
insert.
Figure 5
Flue Installation
•The flue must be 6” diameter and a minimum 24 gauge black steel.
•Use a starter section and screws to secure the flue to the insert.

12 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01233 4110304
Surround Panel Installation
Rectangular Panels:
SURROUND PANEL SIZE HEIGHT WIDTH
8" 28-1/4" 718mm 40-1/8" 1020mm
10" 30-1/4" 769mm 44-1/8" 1121mm
Installation Instructions
1. With the insert 12” from the fireplace, install the side surround panels (see the directions below).
Attach the side surround
panels with the included
screws.
ANSWER ONLY:
Remove and discard the
button plugs from both sides
of the insert.
HINT:
Pre-thread the holes on the
insert with the screws.
2. Adjust the position of the side panels so they are: 1) flush with the bottom of the insert; 2) both the
same distance back from the front of the insert; 3) perpendicular to the floor (use the top panel, if
necessary, to judge alignment). Tighten the screws that hold the side panels in place.

Fireplace Insert Installation (for qualified installers only) 13
© Travis Industries 100-01233 4110304
3. Place the insert into the fireplace and connect the flue (if using a positive or direct connection). Install
the top panel and trim following the directions below.
"L" Bracket
Right Side
Trim
Top Trim
Optional Trim Installation:
Insert one leg of each "L" bracket into the top
and side trim piece. Align the trim to form a
precise corner, then tighten the two set
screws with a small standard screwdriver.
Slide the trim over the panels. Place the
spring clips behind the panels at the locations
shown. This keeps the trim tight against the
panel.
Micro (1/16”)
Standard
Screwdriver

Install the top panel so the tabs insert
into the joggle clips on the top panel
Top
Panel







Spring
Clips
Optional Knock-Out
An optional knock-out is provided on both
sides if the power cord is routed behind the
surround panel.
Insulation Installation (used to seal fireplace enclosure)
1. With the insert drawn 6" from the fireplace, glue the insulation strip included with the insert to the
back of the panels using RTV silicon or stove gasket cement. The insulation should be installed so it
overlaps the fireplace opening to form a seal between the panels and the fireplace face. Let the
silicon or cement dry.
2. Push the insert into the fireplace, allowing the insulation to form a seal between the panels and the
fireplace. Use a screwdriver to tuck any exposed insulation behind the panels.

14 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01233 4110304
Insert with
Positive
Connection
REQUIRED IN
CANADA.





















Figure 6
Insert with Direct
Connection
(Masonry
Fireplace)
NOT ALLOWED IN
CANADA.
A block-off plate or
other non-combustible
sealing device (e.g.
damper adapter) is
required. It must seal
the chimney to insure
smoke does not enter
the home while
providing the chimney
system with sufficient
draft.


















Figure 7

Operating Your Appliance 15
© Travis Industries 100-01233 4110304
Safety Notice
If this appliance is not properly installed, a house fire may result. For your safety, follow the installation
directions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
Read and follow all of the warnings on pages 4 and 5 of this manual.
Before Your First Fire
Verify the Installation
Before starting the stove, verify that the stove is properly installed and all of the requirements in this
manual have been followed.
Keep all flammable materials 36" away from the front of the stove (drapes, furniture, clothing, etc.).
Curing the Paint
This heater uses a heat-activated paint that will emit some fumes while
starting the first fire. Open doors and windows to the room to vent these
fumes. This typically lasts two to four hours. You may also notice oil burning
off of the interior of the heater. This rust-stopping agent will soon dissipate.
Door Gasket - The door gasket might adhere to the paint on the front of the
heater. Leave the door slightly ajar for the first fire and be careful when
opening the door after the first fire.








2 to 4 hours
Over-Firing the Stove
This stove was designed to operate at a high temperature. But due to differences in vent configuration,
fuel, and draft, this appliance can be operated at an excessive temperature. If the stove top or other area
starts to glow red, you are over-firing the stove. Shut the air control down to low and allow the stove to
cool before proceeding.
Over-firing may lead to damage of plated surfaces. If you are uncertain of over-firing conditions, we
suggest placing a stove thermometer (e.g. Rutland® Model 710) directly over the door on the stove top -
temperatures exceeding 800° are generally considered over-firing and will void the warranty.

16 Operating Your Appliance
© Travis Industries 100-01233 4110304
Opening the Door
The door becomes hot during use. Use a glove to open the door if the handle is hot.
To prevent smoke from entering the room, open the door a small amount and let air enter the firebox.
Rotate
the door
handle.
Swing
the door
open.

Operating Your Appliance 17
© Travis Industries 100-01233 4110304
Starting a Fire
Since the dawn of time man has debated the best way to start a fire. Some use the boy-scout "tee-pee",
some prefer the "tic-tac-toe" stack. Either way, review the hints and warnings below to ensure proper fire
starting.
•Make sure the air control is pushed in. If additional air is needed, open the doors 1/4" during the first
five minutes of start-up.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start
or "freshen up" a fire in this stove. Keep all such liquids well away from the stove while it is in use.
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. Do not place such fuel
within space heater installation clearances or within the space required for charging and ash removal.
If using a firestarter, use only products specifically designed for stoves - follow the manufacturer's
instructions carefully.
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
If the smoke does not pass up the chimney, ball up one sheet of newspaper, place it in the center of the
firebox and light it. This should start the chimney drafting (this eliminates "cold air blockage").
Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning
rapidly, place a few larger pieces of wood onto the fire.
Starting a “Top-Down Fire”
One particularly successful method for starting a fire is to
stack several large pieces of wood in the center of the stove
(see the illustration to the right). Then place a several wads
of newspaper in the center with kindling on top. When you
light the newspaper this “top-down” fire will burn its way to
the center, igniting the larger pieces. With some practice,
this method should work for you.

18 Operating Your Appliance
© Travis Industries 100-01233 4110304
Adjusting the Burn Rate
Use the air control slider to control the burn rate of the stove. See the illustration below for details.
Low Burn
(air control closed)
High Burn
(air control open)
Use the air control to
change the burn rate.




Approximate Air Control Settings
Overnight Burn Fully out to 9/32" open
Medium Burn 9/32" to 5/16" open
Medium High Burn 5/16" to 7/16" open
High Burn 7/16" open to pushed fully in
The air control becomes hot during operation - use gloves or a tool to prevent burns.
The air control may take several minutes to influence the burn rate. When making adjustments, you
may wish to let the stove burn for 10 minutes to gauge performance.
Ash Removal
ASHES
Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes
should be placed on a noncombustible floor or on the ground, away from all combustible
materials, pending final disposal. If the ashes are disposed of by burial in soil or otherwise locally
dispersed, they should be retained in the closed container until all cinders have thoroughly
cooled.

Operating Your Appliance 19
© Travis Industries 100-01233 4110304
Blower Operation
The blower will turn on once the stove is up to temperature. This is typically 15 to 30 minutes after
starting the fire. Follow the directions below to alter the blower speed.
OFF
Turn the dial all the way counter-
clockwise until it clicks off.
BLOWER
CONTROL











LO
OFF HI
HIGH
The high position is all the way counter-
clockwise, without clicking off.
BLOWER
CONTROL











LO
OFF HI
LOW
Turn the dial all the
way clockwise.
BLOWER
CONTROL











LO
OFF HI
The blower may be used to affect heat output (i.e.: to reduce heat output, turn the blower down).
Route the power cord in a location where it will not come in contact with the appliance or become hot.
Re-Loading the Stove
Follow the directions below to minimize smoke spillage while re-loading the stove.
1 Open the air control all the way (push it in).
2 Open the door slightly. Let the airflow inside the firebox to stabilize before opening the doors fully.
3 Load wood onto the fire.
Overnight Burn
Follow the steps below to achieve an overnight burn.
1 Move the air control to high burn and let the stove become hot (burn for approximately 15 minutes).
2 Load as much wood as possible. Use large pieces if possible.
3 Let the stove burn on high for 15 minutes to keep the stove hot, then turn the air control to low.
4 In the morning the stove should still be hot, with embers in the coal bed. Stir the coals and load
small pieces of wood to re-ignite the fire, if desired.
Differences if chimney height and draft may lower overall burn times.
Normal Operating Sounds
Creaks and Clicks:
The 3/16" and 5/16" steel may creak or click when
the stove heats up and cools down - this is normal.
Blower Sounds:
The blower will make a slight "humm" as it
pushes air through the stove.

20 Operating Your Appliance
© Travis Industries 100-01233 4110304
Hints for Burning
•Get the appliance hot before adjusting to low burn
•Use smaller pieces of wood during start-up and high burns to increase temperature
•Use larger pieces of wood for overnight or sustained burns
•Stack the wood tightly together to establish a longer burn
•Leave a bed of ashes (1/2" deep) to allow for longer burns
•Be considerate of neighbors & the environment: burn dry wood only
•Burn small, intense fires instead of large, slow burning fires when possible
•Learn your appliance's operating characteristics to obtain optimum performance
Selecting Wood
•Dry Wood is Key
•Dry wood burns hot, emits less
smoke and creates less creosote.
•Testing Wood Moisture
•Split wood stored in a dry area will
be fully dry within a year. This
insures dry wood. If purchasing
wood for immediate use, test the
wood with a moisture meter. Some
experienced wood burners can
measure wood moisture by
knocking pieces together and
listening for a clear "knock" and not
a "thud".
Wet
Wood
Leads
To Leads
To
Dry
Wood
Leads
To Leads
To
Less
Heat More Heat
More Smoke
and Creostoe Less Smoke and Creostoe
Why Dry Wood is Key
Wet wood, when burned, must release water stored within the wood. This cools the fire, creates
creosote, and hampers a complete burn. Ask any experienced wood burner and he or she will agree: dry
wood is crucial to good performance.
Wood Cutting and Storage
Cut wood to length and
chop into quarters. Store the wood off the ground in a
covered area. Allow for airflow
around the wood to dry the wood.
Air Flow
Air Flow
Air Flow
