Travis Industries DaVinci User manual

©TravisIndustries4/21/201617601913












DaVinci Fireplace
See Through Indoor / Outdoor
Framing and Window
Installation Instructions
These Instructions are an addendum to the
DaVinci Fireplace
Installation Manual
This addendum is only for use with the Indoor / Outdoor Window Kits, replacing
the framing dimensions section and providing addition installation instructions for
the “Extruded Aluminum Window Kit”.
Qualified Installers Only:
This unit may only be installed by qualified installers.
We recommend that the sealed glass panel be installed by a qualified
glazier or specially trained ‘Da’ Vinci installer.


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit
InstallationOrder
We strongly recommend having a qualified framer on hand while installing the exterior
window onto a DaVinci custom fireplace. This process requires very precise
measurements. A framer may be required to match the position of the fireplace to the
external framing.

MethodA:ExternalGlassFrameInstalledtoFramingFirst
a) Attachtheexternalglassframetotheexternalframing(useappropriatewindowsillprotectionaround
thewindowopening).
b) Verifytheplatformheightandhowitlinesupwiththeexternalwindowopening.Thismeasurement
mustbeprecise–double‐checkthisdimensionwiththefireplaceandthealignmenttrack.
c) Ifusinganalignmenttrack(thesteelcomponentunderthefireplaceusedtoaligncategory2units),
placeitintopositionandsecureusingonlyafewscrews.Checkthealignmentofthetracktomake
sureitwillpositionthefireplace1/8”fromtheexternalglassframe(+or–1/16”).
‐‐Ifitistooclosetotheexternalframe,thefireplacewillnotfit.
‐‐Ifitistoofarfromtheexternalframe,theexternalglassframewillnotsealtothefireplace.
Youmaywishtoplacethefireplaceonthetrackandnotateitspositiontotheexternalglassframe.If
itisnot1/8”fromtheexternalglassframe(checkall4sides)notatethedimension,removethe
fireplace,thenre‐alignthealignmenttracktothecorrectdimension.
d) Attachthebutylgaskettotheexternalglassframe.
e) Positionthefireplaceontheplatform/alignmenttrack(makesureyouinstallthefireplacefacingthe
correctdirection–thefireplacecontrolsshouldbeaccessibleafterinstallation).
f) Securetheexternalglassframetothefireplace.
g) Installtheremainingexternalglassframecomponents.

MethodB:AttachExternalGlassFrametoFireplaceFirst
a) Lineupthefireplaceplatformwiththeexternalopening.Makesuretoleavetheexternalopening
toolarge(minimum6”inalldirections).
b) Verifytheplatformheightandhowitlinesupwiththeexternalwindowopening.Thismeasurement
mustbeprecise–double‐checkthisdimensionwiththefireplaceandthealignmenttrack.
c) Attachthebutylgaskettotheexternalglassframe.
d) Securetheexternalglassframetothefireplace.
e) Positionthefireplaceontheplatform/alignmenttrack(makesureyouinstallthefireplacefacingthe
correctdirection–thefireplacecontrolsshouldbeaccessibleafterinstallation)..Beforesecuringthe
fireplace/alignmenttracktotheplatform,verifytheexternalwindowlinesupwiththeexternalwall
framingandsheathing.Youmayneedtoalterthe“front/back”alignmentslightlytoaligntheexternal
glassframe.
f) Installtheremainingexternalwallframing/sheathing(useappropriatewindowsillprotectionaround
thewindowopening).NOTE:Becausetheframeisattachedbeforetheframing,youmayneedtotuck
theframing/sheathingunderthewindowledges.
g) Installtheremainingexternalglassframecomponents.



©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit
Overview
Thismanualdetailstheframingandinstallationofthe‘Da’VinciIndoor/OutdoorSeeThrough,fireplace
modelsoutlineintable:
ViewableareawidthViewableareaheightUnitWeight
(includingwindow)
Input(BTU’s)
36.00”12.00”,20.00”,30.00”,36.00”380lbs43,500btu’s
48.00”12.00”,20.00”,30.00”,36.00”480lbs58,000btu’s
60.00”12.00”,20.00”,30.00”,36.00”580lbs72,500btu’s
72.00”12.00”,20.00”,30.00”,36.00”680lbs87,000btu’s
84.00”12.00”,20.00”,30.00”,36.00”780lbs101,500btu’s
96.00”12.00”,20.00”,30.00”,36.00”880lbs116,000btu’s
108.00”12.00”,20.00”,30.00”,36.00”980lbs130,500btu’s
120.00”12.00”,20.00”,30.00”,36.00”1080lbs145,000btu’s
*Seemanualforfullspecifications.

WindowKitContents
IdentifierDescription Quantity
A.Aluminumwindowframe.1
B.Aluminumwindowframeretainers.  4(top,bottom&2xsides)
CSealedglasspanel.1
D.Glasspanelretainerseal.1
E.3/16”Butylframe/unitseal.1
F.3/16”Butylsealedglasspanelseal.  1
G.Rubber,Sealedglasspanelrests.  4
H.Zinccoated,self‐taping#8x1”screws.  1pack







E
B
D
C
H
G
F
A
Figure1:
WindowCom
p
onents


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit



FireplacePlacementRequirements:
Fireplacemustbeinstalledonalevelsurfacecapableofsupportingthefireplaceandvent.
Fireplacemustbeplaceddirectlyonwoodornon‐combustiblesurface(notonlinoleumorcarpet).
Fireplaceshouldbelocatedoutoftrafficandawayfromfurnitureanddraperies.
Fireplacemaybeplacedinabedroom.

Clearances:
(a)ClearancetoSidesofFireplace:0”.
(b)ClearancetoBackofFireplace:0”.
(c)ClearancetoFrontofFireplace:0”.NOTE:donotcovertheglassopeningwithanymaterial.
NOTE:Sidewallsmaybeplaceddirectlytothesideofthefireplace.
(d)ClearancetoBottomofFireplace:0”(maybeplaceddirectlyonsubfloor).
Optionalwarmairblower:
Seeadditionalclearanceinstructionsincludedwithwarmaircirculationkitifinstalled.

Step1‐Framing
Figure2:
FramingDimensions.

Exampleshowstypical
framingusing2”x6”lumber
fortheoutsidewalland2”x
4”lumberfortheinnerwall.

Seechartforframing
dimensionsbaseduponunit
viewablearea.
Innerwall
,
2”x4”
Outter wall, 2
”
x 6
”
A&B=Insidedimension
C=Outsidedimension
Part1:AluminumWindowFrameInstallation


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit

Viewable
areawidth
A(width)B
(Height=12”)
B
(Height=20”)
B
(Height=30”)
B
(Height=36”)
C
(depth)
36.00”39.50”46.75”54.75”64.75”70.75”21. 1/4 ”
48.00”51.50”46.75”  54.75”  64.75”  70.75”  21. 1/4 ” 
60.00”63.50”46.75”  54.75”  64.75”  70.75”  21. 1/4 ” 
72.00”75.50”48.75”  56.75”  66.75”  72.75”  21. 1/4 ” 
84.00”87.50”48.75”  56.75”  66.75”  72.75”  21. 1/4 ” 
96.00”99.50”48.75”  56.75”  66.75”  72.75”  21. 1/4 ” 
108.00”111.50”48.75”  56.75”  66.75”  72.75”  21. 1/4 ” 
120.00”123.50”4875”  56.75”  66.75”  72.75”  21. 1/4 ” 
*Note:MeasurementsA&Bareinsidedimensions.MeasurementCisoutsidedimension






 













Beforeliftingtheunitinplace,double
check:
Baseislevel
Openingcorrectdimensions
Baseisabletotaketheweight
Baseisclearofanydebris
Controlsarefacinginside
Step2–UnitPlacement
Controlaccess
facetoinside
Insideview
Outsideview
Distancefromfaceof
fireplacetooutsideof
framing=1.5”
1.5”
Nailingflangeshould
notbesecuredatthis
point
Note:
Westronglysuggestframing
aroundfireplaceafteritisin
place.


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit

The3/16”butylsealcomessuppliedonaroll.Toattachtheseal,startatthecenterbottomoftheframeand
attach,lininguptheedgeofthetapewiththeoutsideedgeofthealuminumframelip.

Note:Makesurethebutyltapedoesnotcoveranyofthemountingholesinthealuminumframeasthiscould
causedamagetothesealbywrappingaroundthemountingscrewduringattachment.

Caution:
Butyltapeisstickyandwilladhereoncontact,takecaretoattachinthecorrectpositionbefore
applying.





‐







Butylsealattachment:
Usingdenaturedalcoholcleanaluminumframeattachmentarea(avoidfingerprints).
Startatbottomcenterofframeandapplyinglightpressure,unrollthe1/16”butyltapetoforma
continuousseal(donotremovebackingpaperatthispoint).
Checkandmakesureallmountingholesareclear.
Presstapefirmlyintoplace.


ColdClimatetip:
Ifinstallingundercoldconditionsthebutyltapemaybecomerigidandhardertohandle.Ifthisisthecase
warmthetapeslightlywithaheatgun(donotoverheat).Ifthealuminumframeiscoldittoowillbenefit
fromaslightwarmingtohelpthetapeadhere.




Step3–Attach3/16”ButylSeal
Startattachingat
centerbottom
Lineedgeoftapeup
withedgeofframe
Donotcover
mountingholes


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit

Attachingthealuminumframetounitusingthesuppliedzinccoated,self‐taping#8x1”screws
















 


Step4–AttachingtheAluminumFrametotheUnit
Attachthealuminumframetothe
unitusingthesuppliedself‐taping
#8screws.
Removethebackingtapefrom
3/16”Butyltape.
Lineuptheinsideedgeofthe
framewiththeinsideedgeofthe
unit(theopeningsizeisthesame
forviewableunitareaasthe
internaldimensionofthe
aluminumframe).
Careshouldbetakentocarefully
aligntheframetotheunitasthe
butyltapewilladhereupon
contact.
Lineupedgeofunitopeningwith
insideedgeofextrusion
Cleanunitsurface.
Checkalignmentofaluminumframe
beforeremovingbackingtape.
Setdriveondrillratchettoavoidstripping
theself‐tapingscrews.
Attachself‐tapscrewslightlyatfirst,then
tightenusinghandscrewdriver.


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit






















Step5–Attach2”x6”FrontCrossMembers
Attach2”x6”crossmembers.
Faceofcrossmembersshould
beflushtothesidetimber
facingandtightagainsttheunit
face.
Slotthecrossmembersinto
thechannelformedbetween
theunitandthealuminum
extrusion.
Step6–Attachinsulation,3/8”outersheathing&vapourbarrier
Attach11/2”rigidfoam
insulation(Rvalue=5.78R)
intothecavitiesonthetop
andbottomfaceofthe
unit.
Attach3/8”outersheathing.
Typically3/8”particleboardor
similar.
3/8”Sheathingfitsinchannel
betweenextrusionand2x6.
Attachvapourbarriertoouter
sheathingmakingsuretooverlap
thealuminumextrusionandseal
withvapourbarriertape.
Unit.
2x6.
3/8”Sheathing.
Vapourbarrier
Aluminumextrusion.


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit












Note:TheglasspanelmaybeinstalledintothealuminumframeatanytimefollowingcompletionofStep4.It
isunderstoodthattherequiredcontractorsmaynotbeavailabletocompletetheouterwallfinishing.

Forclaritytheprocessofinstallingthesealedglassframeisshownwiththeframeinviewonly,itisassumed
theframehasbeenattachedtotheunitreadytoreceivethesealedglasspanel.
















Step7–Attachfinalfinishingmaterial
Attachfinalfinishing(example
showscedarsiding).
Thisslotsintothefront
channeloftheextrusion.
Part2:SealedGlassPanelInstallation
Step8–Attach3/16”ButylSeal
Apply3/16”Butyltoaluminumextrusion,
aswiththe3/16”butylstartfromthe
middlebottomandworkroundapplyinga
firmevenpressure.
Lineupthe3/16”butylwiththe
insideedgeoftheextrusion


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit
3
4
2
1

Placeintherubberblockrestsforthe
sealed
p
anel
Lietheedgeofthesealedglass
panelontherubberblocks.
Note:Avoidcontactwithbutyl
sealasyoumaydamageitby
draggingtheseal.
Pushthesealedpanelagainstthe
butylrubberseal.
Usewedgingtoolstofirmlylocatethe
sealedpanelinposition.
Wedgingtools
Aluminumextrusion
3/8”Butylseal
Glasspanel
Step9–AttachSealedGlass
Step10–AttachSealedGlassPanelRetainers
Placeintheglasspanelretainers.
Note:Foreaseofinstallationthey
shouldbeplacedintheorder
shown
Locateretainerswithtabfacing
downandlocatedintoslot
betweenglassandextrusion.


©TravisIndustries4/21/201617601913
Indoor/OutdoorUnit

























Step11–AttachGlassPanelRubberSeal
Theglasspanelrubberretainerisplacedpushed
intothegapbetweentheretainerandtheglass
panel.
TheRubbersealshouldbecuttolengthallowing
forshrinkageovertime.Itisrecommendedthat
therubberbecutI.00”longerthantherequired.
Installinthefollowingorder:
Bottom.
Top.
Left&rightsides.
Thesealisatightfit,toaidapplicationitis
recommendedthatamildsoapsolutionbespray
aroundtheareathesealislocated.
Startfromoneendandcompressthesealto
allowforthe1.00”oversize.
Lubricatesealwith
soa
p
solution
Add1.00”to
requiredlength
Positionsealas
indicated
Seallocatedin
positionbetweenglass
p
anelandretainer
