Traxxas 2985 User manual

4-Amp USB-C NiMH/LiPo iD Charger Instructions Covers Part #2985
HKC23089-R01 231204
Visitez Traxxas.com/manuals pour télécharger
les instructions dans votre langue.
Visite la página Traxxas.com/manuals para
descargar el instrucciones en su idioma.
Auf Traxxas.com/manuals, können Sie
anleitung in Ihrer Sprache downloaden.
Charging and discharging batteries has the potential
for re, explosion, serious injury, and property damage if not performed per
the instructions. Before use, read and follow all manufacturer’s instructions, warnings, and
precautions. Never allow anyone under the age of 18 to charge or use or handle LiPo batteries
without the supervision of a knowledgeable and responsible adult. This battery charger is
designed for use ONLY with Traxxas iD® NiMH or LiPo batteries. Legacy Traxxas High-Current
Connectors, non-Traxxas batteries, and non-Traxxas connectors are not compatible with this
charger. DO NOT try to force legacy connectors into the charge connector. DO NOT modify
the charger.
Important Warnings for users of Lithium Polymer (LiPo) batteries:
• LiPo batteries are signicantly more volatile than other rechargeable batteries.
• ONLY use a Traxxas iD® charger to charge Traxxas iD batteries. Never use NiMH or NiCad-type
chargers or charge modes to charge LiPo batteries. DO NOT charge LiPo batteries with a NiMH-
only charger. The use of a NiMH or NiCad charger or charge mode will damage LiPo batteries and
may cause re, personal injury, and/or property damage.
• NEVER charge LiPo battery packs in series or parallel. Charging LiPo packs in series or
parallel may result in improper charger cell recognition and an improper charging rate that
may lead to overcharging, cell imbalance, cell damage, and re.
• ALWAYS inspect your LiPo batteries carefully before charging. Look for any loose leads or
connectors, damaged wire insulation, damaged cell packaging, impact damage, uid leaks,
swelling (a sign of internal damage), cell deformity, missing labels, or any other damage or
irregularity. If any of these conditions are observed, do not charge or use the battery pack.
Follow the disposal instructions included with your battery to properly and safely dispose of
the battery.
• DO NOT store or charge LiPo batteries with or around other batteries or battery packs of any type,
including other LiPo batteries.
• Store and transport your battery pack(s) in a cool dry place. DO NOT store in direct sunlight.
DO NOT allow the storage temperature to exceed 140°F or 60°C, such as in the trunk of a car,
or the cells may be damaged and create a re risk.
• DO NOT disassemble LiPo batteries or cells.
• DO NOT attempt to build your own LiPo battery pack from loose cells.
Charging and handling precautions for all battery types:
• This charger is not a toy and is not intended to be used by children under the age of 14
for NiMH batteries, or under the age of 18 for LiPo batteries, without responsible adult
supervision.
• Charge only 5- to 7- cell NiMH or 2s to 3s LiPo battery packs with this charger.
• This is a Traxxas iD charger and only charges Traxxas iD batteries.
• BEFORE you charge, ALWAYS conrm that the charger is correct for the battery being
charged.
• DO NOT attempt to charge batteries that have an internal charge circuit or a protection circuit or
batteries that have missing or unreadable labels, preventing you from properly identifying the
battery type and specications.
• DO NOT let any exposed battery contacts or wires touch each other. This will cause
the battery to short circuit and create the risk of re.
• DO NOT use a non-Traxxas charger or non-iD Traxxas charger to charge Traxxas iD batteries.
• While charging or discharging, place the battery (all types of batteries) in a re retardant/re
proof container and on a non-ammable surface such as concrete.
• DO NOT charge batteries inside of an automobile. DO NOT charge batteries while driving in
an automobile.
• NEVER charge batteries on wood, cloth, carpet, or on any other ammable material.
• ALWAYS charge batteries in a well-ventilated area.
• REMOVE ammable items and combustible materials from the charging area.
• DO NOT leave the charger and battery unattended while charging, discharging, or anytime the
charger is ON with a battery connected. If there are any signs of a malfunction or in the event of
an emergency, unplug the charger from the power source and disconnect the battery from
the charger.
• DO NOT operate the charger in a cluttered space, or place objects on top of the charger or
battery. DO NOT cover the ventilation holes in the charger case.
• If any battery or battery cell is damaged in any way, DO NOT charge, discharge, or use the battery.
• Keep a Class D re extinguisher nearby in case of re.
• DO NOT disassemble, crush, pierce, short circuit, or expose the batteries to ame or other source
of ignition. Toxic materials could be released. If eye or skin contact occurs, ush with water.
• If a battery gets hot to the touch during the charging process (temperature greater than 110°F /
43°C), immediately disconnect the battery from the charger and discontinue charging.
• Allow the battery pack to cool o between runs (before charging).
• ALWAYS unplug the charger and disconnect the battery when not in use.
• ALWAYS unplug the battery from the electronic speed control when the model is not in use and
when it is being stored or transported.
• DO NOT disassemble the charger.
• REMOVE the battery from your model or device before charging.
• DO NOT expose the charger to water or moisture. For indoor use only.
• DO NOT use an adapter of any kind or modify or change the battery plug/connector.
• ALWAYS store battery packs safely out of the reach of children or pets. Children should
always have adult supervision when charging and handling batteries.
• Nickel-Metal Hydride (NiMH) batteries must be recycled or disposed of properly.
• Always proceed with caution and use good common sense at all times.
Australia: This charger may be used by persons (including children over 14 years old) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if
they have been given supervision or instruction concerning use of the charger in a safe
way and understand the hazards involved. Do not allow children to play with the charger.
Children require adult supervision while using this charger.
WARNING! CAUTION! DANGER!
FCC Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
ISED compliance statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
IC Radiation Exposure statement
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
FIRE HAZARD!
TRAXXAS.com
Traxxas, 6250 Traxxas Way, McKinney, TX 75070, Phone: [phone], Fax: [phone], e-mail: [email protected]
If you have questions or need technical assistance, call Traxxas at
(1-888-872-9927) (U.S. residents only)

For indoor use only when using
AC power adapters.
DO NOT expose the charger
to water or moisture.
CAUTION: SHOCK HAZARD!
Power on
iD LED
iD LED
LiPo Battery connected
LED flashes green while charging
LiPo Battery connected
LED solid green when charging is complete
NiMH Battery connected
LED flashes green while charging
NiMH Battery connected
LED solid green when charging is complete
CHARGE PROGRESS
x1 1 green flash 0 - 25% charged
x2 2 green flashes 25% - 50% charged
x3 3 green flashes 50% - 75% charged
x4 4 green flashes 75% or more charged
Solid green LED 100% charged
STATUS LED INDICATION MEANING
Solid Red LED Ready for charging
Slowly Flashing Green LED Charging (see Charge Progress chart)
Solid Green LED Battery fully charged
Flashing Red LED Charger error
Operation
1. Plug the USB-C cable into a USB-C power
source. The red STATUS LED will turn on,
indicating that power is connected.
2. Connect a Traxxas iD NiMH or LiPo battery to the charger
to begin charging. The blue iD LED will turn on, indicating
that Traxxas iD has been detected.
3. The STATUS LED will ash green during
charging. The number of ashes indicates
charge progress.
4. When the STATUS LED is solid
green, charging is complete.
Sample USB-C
AC adapter shown.
Clearing errors
If there is a problem with the battery or the power adapter,
the charger’s STATUS LED will flash red. See error codes and
recommended solutions below. If the error code repeats or will
not clear, contact Traxxas Customer Support.
Limited Warranty Information
Traxxas electronic components are warranted to be free from defects in materials and workmanship for a period
of 30 days from the date of purchase.
Limitations: Any and all warranty coverage does not cover replacement of parts and components damaged
by abuse, neglect, improper or unreasonable use, crash damage, water or excessive moisture, chemical
damage, improper or infrequent maintenance, accident, unauthorized alteration or modification or items
that are considered consumable. Traxxas will not pay for the cost of shipping or transportation of a defective
component to us. This warranty is limited to the charger only and does not cover batteries, vehicles and
other accessories used in conjunction with the charger.
Traxxas Lifetime Electronics Limited Warranty
After the expiration date of the warranty period, Traxxas will repair electronic components for a flat rate. Please
visit Traxxas.com/support for a current schedule of warranty costs and fees. The covered repairs are limited to
non-mechanical components that have NOT been subjected to abuse, misuse, or neglect. Products damaged by
intentional abuse, misuse, or neglect may be subject to additional charges.
LED INDICATION MEANING SOLUTION
Power source error Disconnect battery and USB-C power
source. Check power source for
compatibility.
Battery voltage is too
high or too low
Disconnect and discontinue use of
battery.
The charger timer has
expired
Disconnect battery. If battery is hot,
discontinue charger use. If battery
is not hot, reconnect to continue
charging (this may happen when
connected to a low output power
source).
The internal charger
temperature is too high
Disconnect charger and allow charger
to cool.
The detected battery
does not match the
charger conguration
Disconnect battery; battery is not
compatible with the charger.
Battery connected to
charger before USB-C
power supplied.
Disconnect battery; wait for solid red
LED on charger before reconnecting
battery.
Legacy or non-Traxxas
iD battery detected or
Traxxas iD error
Disconnect battery; battery is not
compatible with the charger.
Charger has detected
an internal error
Disconnect battery and power adapter.
Discontinue charger use.
x1
x2
x3
x4
x5
x6
x7
iD LED INDICATION MEANING
Solid Blue LED iD detected; the battery will begin charging
LED Off iD not detected; the battery will NOT charge
About the Traxxas iD®USB-C NiMH/
LiPo Charger
The Traxxas #2985 USB-C NiMH/LiPo Battery Charger features
exclusive Traxxas innovations that make charging batteries
easier and safer than ever. It features fast charging and
advanced peak detection to optimize every charge. A USB-C
power source, such as a portable power bank (battery source)
or AC power adapter, and power cable (sold separately) are
required for use.
TERMS OF USE - The buyer assumes all risk associated with
using this product. Traxxas, its aliates, manufacturers,
distributors, and retail partners cannot control the use,
application, charging or installation of this product and shall
not be held responsible for any accident, injury to persons,
or damage to property resulting from the use of this product.
Read and follow all provided instructions, information, and
warnings. After reading all provided information, if you do not
agree with these terms and conditions and are not prepared to
accept complete liability for the use of this product, return this
product immediately in new/unused condition to your place of
purchase. Your hobby dealer absolutely cannot accept product
for return or exchange if it has been used in any way.
If you have any questions, call Traxxas Customer Support at
1-888-TRAXXAS (1-888-872-9927), outside the US at +1-972-
549-3000, or e-mail [email protected]om.
Part No. Description
2912* Power adapter, AC, USB-C (45W)
2916* Power cable, USB-C, 100W (high output)
Recommended Power Adapter and Cable
Charging Tips
• The charger MUST be connected to USB-C power BEFORE
connecting the battery. If the battery is connected before
connecting to USB-C power, the charger will show an error (red
LED flashes 6 times and repeats). To correct, unplug the battery
and the charger. Plug in the charger to USB-C power, and then
connect the battery to be charged.
• The charger requires 10W or greater output from the USB-C
power source to operate.
• The charge output current varies depending on the available
power from the USB-C power source. To ensure the maximum
charge rate, use a USB-C power source rated at 45 watts (capable
of 2.25 amps at 20 volts) and compatible with Quick Charge 3.0
(QC 3.0) or greater standard input voltage. Traxxas USB-C AC Power
Adapter (part #2912) and Power Cable (part #2916) are designed
to deliver the full charge output from the charger.
Note: It is normal for the charger to become warm while
charging at the maximum charge rate. If the charger is not in a
cool, well-ventilated area, the charge rate will be automatically
reduced to prevent the charger from overheating.
*Sold separately
Battery Compatibly
NiMH Traxxas iD Batteries 5-Cell 6-Cell 7-Cell
LiPo Traxxas iD Batteries 2-Cell 3-Cell
