TRENDnet TE100-S16R Installation and operation manual

TE100-S16R
TE100-S24R
Quick Installation Guide

Table of Contents
Table of Contents
Version 01.24.2007
Français .....................................................................................................
Technical Specifications .............................................................................
Troubleshooting ..........................................................................................
1
1
2
4
6
1. Avant de commencer .........................................................................
2. Installation du matériel .......................................................................

Configuration du système
1. Avant de commencer
Français
1
Application
Un câble réseau RJ-45
Un ordinateur avec un adaptateur réseau correctement installé
La prise secteur doit être située à un maximum de 1,82 mètres du Switch
Contenu de l'emballage
Guide d'installation rapide
Kit de montage
TE100-S16R/TE100-S24R
Cordon d'alimentation
Vérifiez la présence d'une source de ventilation adéquate autour du Switch
pour une dissipation efficace de la chaleur
Ne placez pas d'objets lourds sur le Switch
Rack EIA standard de 19 pouces ou une surface plane pouvant supporter
le poids du boîtier
16/24 Ports 10/100Mbps Fast Ethernet Switch
(TE100-S16R or TE100-S24R)
10/100Mbps Multi-Port
Print Server
(TE100-P21)
Printers
Workstations with PCI Adapter
(TE100-PCIWN)
Laptop with PC Card
(TE100-PCBUSR)
Server with PCI Adapter
(TE100-PCIWA)
Cable/DSL
Modem Router
Internet
10/100Mbps

Français
2
2. Installation du matériel
2. Branchez un câble réseau CAT-5
RJ-45 de l'ordinateur vers un port
Ethernet disponible du
.TE100-S16R/TE100-S24R
1. Branchez le Cordon
d'alimentation à l'arrière du
TE100-S16R/TE100-S24R et à une
prise de courant.

Français
3
1. Attachez les supports de montage
des deux côtés du châssis et fixez-
les avec les vis fournies.
2. Avec précautions, installez le
boîtier dans l'armoire. Alignez les
supports sur les trous des vis du
rack, utilisez ensuite les vis
fournies avec le rack du matériel
pour fixer le boîtier.
Montage du rack
Le boîtier peut être installé dans un rack EIA standard de 19 pouces qui peut
être placé dans une armoire de répartition avec les autres équipements.

4
Standards IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Protocol CSMA/CD
Data Transfer Rates
Ethernet:
10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
Fast Ethernet:
100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
Network Cables Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT-5, 5e , 6
Number of Ports
TE100-S16R: 16 x 10/100Mbps
Auto-negotiation, Auto-MDIX ports
TE100-S24R: 24 x 10/100Mbps
Auto-negotiation, Auto-MDIX ports
General
Topology
LEDs
Star
Power, Link/Activity, 100Mbps
Technical Specifications
Transmission Method Store-and-forward
MAC Address Table
RAM Buffer
SSRAM
8Kbytes Entries Per Device
2Mbits
1.25Mbits
MAC Address Learning Automatic update
Performance

5
Power 100-240VAC. 50/60Hz. Internal Power Supply
Power Consumption TE100-S16R: 5.9Watts (Max)
TE100-S24R: 7.5Watts (Max)
Temperature Operating: 0 ~ 50 C, Storage: -20 ~ 70 C° ° ° °
Dimensions (L x W x H) 280 x 180 x 45 mm
Weight TE100-S16R: 1.45kg
TE100-S24R: 1.54kg
Physical and Environmental
Humidity
Certification
Operating: 10% ~ 90%, Storage:5% ~ 90%
CE, FCC

6
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
After connecting the Switch to a power outlet, the LEDs do not turn
on.
Check the connection of the external power adapter to the
TE100-S16R/TE100-S24R and the power outlet. Also check that the power
outlet is receiving power.
When I connect a computer to the Switch's port, the LNK/ACT LED
turns on, but the 100Mbps LED remains off.
When the 100Mbps LED remains off, the computer's connection speed
is 10Mbps.
After I connect my PCs to the Switch, I am unable to share files.
First, check the LEDs on the Switch. Make sure the LINK/ACT LED is
on. Second, check the network cable. The minimum length of the cable is
1.5 meters and the maximum length of the cable is 100 meters. Third,
disable any software firewall program. Fourth, verify that you have file
sharing enabled. Please contact your Operating System support for more
information.
After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple
computers. You need to get an Internet router such as the
TW100-S4W1CA.
If you still encounter problems or have any questions regarding the
TE100-S16R/TE100-S24R please contact TRENDnet's Technical Support
Department.
