TRENDnet TW100-BRF114 User manual

Table of Contents
CHAPTER 1 INTRODUCTION .............................................................................................1
TW100-BRF114 Features.................................................................................................1
Package Contents ..............................................................................................................3
Physical Details..................................................................................................................4
CHAPTER 2 INSTALLATION...............................................................................................6
Requirements.....................................................................................................................6
Procedure...........................................................................................................................6
CHAPTER 3 SETUP ................................................................................................................8
Overview ............................................................................................................................8
Configuration Program ....................................................................................................9
Setup Wizard...................................................................................................................11
LAN Screen......................................................................................................................14
Password Screen..............................................................................................................16
CHAPTER 4 PC CONFIGURATION..................................................................................17
Overview ..........................................................................................................................17
Windows Clients..............................................................................................................17
Macintosh Clients............................................................................................................32
Linux Clients....................................................................................................................32
Other Unix Systems.........................................................................................................32
CHAPTER 5 OPERATION AND STATUS.........................................................................33
Operation.........................................................................................................................33
Status Screen....................................................................................................................33
Connection Status - PPPoE ............................................................................................34
Connection Status - PPTP ..............................................................................................37
Connection Status - Telstra Big Pond............................................................................38
Connection Details - SingTel RAS.................................................................................39
Connection Details - Fixed/Dynamic IP Address .........................................................40
CHAPTER 6 INTERNET FEATURES................................................................................42
Overview ..........................................................................................................................42
Advanced Internet Screen ..............................................................................................42
Dynamic DNS (Domain Name Server)..........................................................................47
MAC Address ..................................................................................................................49
Virtual Servers.................................................................................................................50
CHAPTER 7 OTHER FEATURES AND SETTINGS........................................................54
Overview ..........................................................................................................................54
Access Control.................................................................................................................55
Remote Management ......................................................................................................61
PC Database.....................................................................................................................62
Upgrade Firmware..........................................................................................................66
Options.............................................................................................................................67
Security.............................................................................................................................68
Logs...................................................................................................................................70
Routing.............................................................................................................................72
i

ii
APPENDIX A TROUBLESHOOTING................................................................................76
Overview ..........................................................................................................................76
General Problems............................................................................................................76
Internet Access.................................................................................................................77
APPENDIX B SPECIFICATIONS........................................................................................78
TW100-BRF114...............................................................................................................78
Regulatory Approvals.....................................................................................................78
P/N: 9560ML0037
Copyright ©2003. All Rights Reserved.
Document Version: 1.0
All trademarks and trade names are the properties of their respective owners.

1
Chapter 1
Introduction
This Chapter provides an overview of the TW100-BRF114's features and ca-
pabilities.
Congratulations on the purchase of your new TW100-BRF114. The TW100-BRF114 is a
multi-function device providing the following services:
•Shared Broadband Internet Access for all LAN users.
•4-Port Switching Hub for 10BaseT or 100BaseT connections.
TW100-BRF114
Figure 1: TW100-BRF114
TW100-BRF114 Features
The TW100-BRF114 incorporates many advanced features, carefully designed to provide
sophisticated functions while being easy to use.
Internet Access Features
•Shared Internet Access. All users on the LAN or WLAN can access the Internet
through the TW100-BRF114, using only a single external IP Address. The local (invalid)
IP Addresses are hidden from external sources. This process is called NAT (Network Ad-
dress Translation).
•DSL & Cable Modem Support. The TW100-BRF114 has a 10/100BaseT Ethernet
port for connecting a DSL or Cable Modem. All popular DSL and Cable Modems are
supported. SingTel RAS and Big Pond (Australia) login support is also included.
•PPPoE, PPTP, SingTel RAS and Telstra Big Pond Support. The Internet (WAN
port) connection supports PPPoE (PPP over Ethernet), PPTP (Peer-to-Peer Tunneling Pro-
tocol), SingTel RAS and Telstra Big Pond (Australia), as well as "Direct Connection" type
services.
•Fixed or Dynamic IP Address. On the Internet (WAN port) connection, the TW100-
BRF114 supports both Dynamic IP Address (IP Address is allocated on connection) and
Fixed IP Address.
1

TW100-BRF114 User’s Guide
Advanced Internet Functions
•Communication Applications. Support for Internet communication applications, such
as interactive Games, Telephony, and Conferencing applications, which are often difficult
to use when behind a Firewall, is included.
•Special Internet Applications. Applications which use non-standard connections or
port numbers are normally blocked by the Firewall. The ability to define and allow such
applications is provided, to enable such applications to be used normally.
•Virtual Servers. This feature allows Internet users to access Internet servers on your
LAN. The required setup is quick and easy.
•DMZ. One (1) PC on your local LAN can be configured to allow unrestricted 2-way
communication with Servers or individual users on the Internet. This provides the ability
to run programs which are incompatible with Firewalls.
•URL Filter. Use the URL Filter to block access to undesirable Web sites by LAN users.
•Internet Access Log. See which Internet connections have been made.
•VPN Pass through Support. PCs with VPN (Virtual Private Networking) software
using PPTP, L2TP and IPSec are transparently supported - no configuration is required.
LAN Features
•4-Port Switching Hub. The TW100-BRF114 incorporates a 4-port 10/100BaseT
switching hub, making it easy to create or extend your LAN.
•DHCP Server Support. Dynamic Host Configuration Protocol provides a dynamic IP
address to PCs and other devices upon request. The TW100-BRF114 can act as a DHCP
Server for devices on your local LAN and WLAN.
•Multi Segment LAN Support. LANs containing one or more segments are supported,
via the TW100-BRF114 's RIP (Routing Information Protocol) support and built-in static
routing table.
Configuration & Management
•Easy Setup. Use your WEB browser from anywhere on the LAN or WLAN for configu-
ration.
•Remote Management. The TW100-BRF114 can be managed from any PC on your
LAN. And, if the Internet connection exists, it can also (optionally) be configured via the
Internet.
•UPnP Support. UPnP (Universal Plug and Play) allows automatic discovery and confi-
guration of the TW100-BRF114. UPnP is by supported by Windows ME, XP, or later.
Security Features
•Password - protected Configuration. Optional password protection is provided to
prevent unauthorized users from modifying the configuration data and settings.
•NAT Protection. An intrinsic side effect of NAT (Network Address Translation) tech-
nology is that by allowing all LAN users to share a single IP address, the location and
even the existence of each PC is hidden. From the external viewpoint, there is no network,
only a single device - the TW100-BRF114.
•Stateful Inspection Firewall. All incoming data packets are monitored and all incom-
ing server requests are filtered, thus protecting your network from malicious attacks from
external sources.
2

Introduction
•Protection against DoS attacks. DoS (Denial of Service) attacks can flood your
Internet connection with invalid packets and connection requests, using so much band-
width and so many resources that Internet access becomes unavailable. The TW100-
BRF114 incorporates protection against DoS attacks.
Package Contents
The following items should be included:
•The TW100-BRF114 Unit
•Quick Installation Guide
•CD-ROM containing the on-line manual.
•Power Adapter
If any of the above items are damaged or missing, please contact your local dealer immediate-
ly.
3

TW100-BRF114 User’s Guide
Physical Details
Front-mounted LEDs
Figure 2: Front Panel
Power
(Green) On - Power on.
Off - No power.
Status
(Red) On - Error condition.
Off - Normal operation.
Blinking - This LED blinks during start up.
LAN For each port, there are 2 LEDs
•Link/Act (Green)
•On - Corresponding LAN (hub) port is active.
•Off - No active connection on the corresponding LAN (hub) port.
•Flashing - Data is being transmitted or received via the corres-
ponding LAN (hub) port.
•100 (Yellow)
•On - Corresponding LAN (hub) port is using 100BaseT.
•Off - Corresponding LAN (hub) port connection is using
10BaseT, or no active connection.
WAN
(Green) On - Connection to the modem attached to the WAN (Internet) port is
established.
Flashing - Data is being transmitted or received via the WAN port.
4

Introduction
5
Rear Panel
Figure 3: Rear Panel
Reset Button This button has two (2) functions:
•Reboot. When pressed and released, the TW100-BRF114 will
reboot (restart).
•Clear All Data. This button can also be used to clear ALL data
and restore ALL settings to the factory default values.
To Clear All Data and restore the factory default values:
1. Power Off.
2. Hold the Reset Button down while you Power On.
3. Keep holding the Reset Button down for five (5) seconds, until
the Red Status LED has flashed TWICE.
4. Release the Reset Button. The TW100-BRF114 is now using the
factory default values.
WAN port
(10/100BaseT) Connect the DSL or Cable Modem here. If your modem came with a
cable, use the supplied cable. Otherwise, use a standard LAN cable.
10/100BaseT
LAN connections Use standard LAN cables (RJ45 connectors) to connect your PCs to
these ports.
Note:
Any LAN port on the TW100-BRF114 will automatically function as
an "Uplink" port when required. Just connect any port to a normal
port on the other hub, using a standard LAN cable.
Power port Connect the supplied power adapter here.

2
Chapter 2
Installation
This Chapter covers the physical installation of the TW100-BRF114.
Requirements
•Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors.
•TCP/IP protocol must be installed on all PCs.
•For Internet Access, an Internet Access account with an ISP, and either of a DSL or Cable
modem (for WAN port usage)
Procedure
Figure 4: Installation Diagram
1. Choose an Installation Site
Select a suitable place on the network to install the TW100-BRF114.
Ensure the TW100-BRF114 and the DSL/Cable modem are powered OFF.
2. Connect LAN Cables
•Use standard LAN cables to connect PCs to the Switching Hub ports on the TW100-
BRF114. Both 10BaseT and 100BaseT connections can be used simultaneously.
•If required, you can connect any LAN port to another Hub. Any LAN port on the TW100-
BRF114 will automatically function as an "Uplink" port when required. Just connect any
LAN port to a normal port on the other hub, using a standard LAN cable.
6

Installation
7
3. Connect WAN Cable
Connect the DSL or Cable modem to the WAN port on the TW100-BRF114. Use the ca-
ble supplied with your DSL/Cable modem. If no cable was supplied, use a standard cable.
4. Power Up
•Power on the Cable or DSL modem.
•Connect the supplied power adapter to the TW100-BRF114 and power up.
Use only the power adapter provided. Using a different one may cause hardware damage
5. Check the LEDs
•The Power LED should be ON.
•The Status LED should flash, then turn Off. If it stays on, there is a hardware error.
•For each LAN (PC) connection, the LAN Link/Act LED should be ON (provided the PC is
also ON.)
•The WAN LED should be ON.
For more information, refer to Front-mounted LEDs in Chapter 1.

3
Chapter 3
Setup
This Chapter provides Setup details of the TW100-BRF114.
Overview
This chapter describes the setup procedure for:
•Internet Access
•LAN configuration
PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Confi-
guration.
Other configuration may also be required, depending on which features and functions of the
TW100-BRF114 you wish to use. Use the table below to locate detailed instructions for the
required functions.
To Do this: Refer to:
Configure PCs on your LAN. Chapter 4:
PC Configuration
Check TW100-BRF114 operation and Status. Chapter 5:
Operation and Status
Use any of the following Internet features:
•Advanced Setup
•Dynamic DNS
•MAC Address
•Virtual Servers
Chapter 6:
Internet Features
Configure or use any of the following:
•Access Control
•Remote Management
•PC Database
•Upgrade Firmware
•Options
•Security
•Logs
•Routing
Chapter 7:
Other Features and Settings
Where use of a certain feature requires that
PCs or other LAN devices be configured, this
is also explained in the relevant chapter.
8

Setup
Configuration Program
The TW100-BRF114 contains an HTTP server. This enables you to connect to it, and confi-
gure it, using your Web Browser. Your Browser must support JavaScript. The
configuration program has been tested on the following browsers:
•Netscape V4.08 or later
•Internet Explorer V4 or later
Preparation
Before attempting to configure the TW100-BRF114, please ensure that:
•Your PC can establish a physical connection to the TW100-BRF114. The PC and the
TW100-BRF114 must be directly connected (using the Hub ports on the TW100-BRF114)
or on the same LAN segment.
•The TW100-BRF114 must be installed and powered ON.
•If the TW100-BRF114 's default IP Address (192.168.0.1) is already used by another
device, the other device must be turned OFF until the TW100-BRF114 is allocated a new
IP Address during configuration.
Using UPnP
If your Windows system supports UPnP, an icon for the TW100-BRF114 will appear in the
system tray, notifying you that a new network device has been found, and offering to create a
new desktop shortcut to the newly-discovered device.
•Unless you intend to change the IP Address of the TW100-BRF114, you can accept the
desktop shortcut.
•Whether you accept the desktop shortcut or not, you can always find UPnP devices in My
Network Places (previously called Network Neighborhood).
•Double - click the icon for the TW100-BRF114 (either on the Desktop, or in My Network
Places) to start the configuration. Refer to the following section Setup Wizard for details
of the initial configuration process.
9

TW100-BRF114 User’s Guide
Using your Web Browser
To establish a connection from your PC to the TW100-BRF114:
1. After installing the TW100-BRF114 in your LAN, start your PC. If your PC is already
running, restart it.
2. Start your WEB browser.
3. In the Address box, enter "HTTP://" and the IP Address of the TW100-BRF114, as in this
example, which uses the TW100-BRF114 's default IP Address:
HTTP://192.168.0.1
If you can't connect
If the TW100-BRF114 does not respond, check the following:
•The TW100-BRF114 is properly installed, LAN connection is OK, and it is
powered ON. You can test the connection by using the "Ping" command:
•Open the MS-DOS window or command prompt window.
•Enter the command:
ping 192.168.0.1
If no response is received, either the connection is not working, or your
PC's IP address is not compatible with the TW100-BRF114 's IP Address.
(See next item.)
•If your PC is using a fixed IP Address, its IP Address must be within the range
192.168.0.2 to 192.168.0.254 to be compatible with the TW100-BRF114 's de-
fault IP Address of 192.168.0.1. Also, the Network Mask must be set to
255.255.255.0. See Chapter 4 - PC Configuration for details on checking your
PC's TCP/IP settings.
•Ensure that your PC and the TW100-BRF114 are on the same network seg-
ment. (If you don't have a router, this must be the case.)
10

Setup
Setup Wizard
The first time you connect to the TW100-BRF114, the Setup Wizard will run automatically.
(The Setup Wizard will also run if the TW100-BRF114's default setting are restored.)
1. Step through the Wizard until finished.
•You need to know the type of Internet connection service used by your ISP. Check
the data supplied by your ISP.
•The common connection types are explained in the tables below.
2. On the final screen of the Wizard, run the test and check that an Internet connection can be
established.
3. If the connection test fails:
•Check your data, the Cable/DSL modem, and all connections.
•Check that you have entered all data correctly.
•If using a Cable modem, your ISP may have recorded the MAC (physical) address of
your PC. Run the Wizard, and on the Cable Modem screen, use the "Clone MAC ad-
dress" button to copy the MAC address from your PC to the TW100-BRF114.
Common Connection Types
Cable Modems
Type Details ISP Data required
Dynamic
IP Address Your IP Address is allocated automatically, when you
connect to you ISP.
Usually, none.
However, some ISPs may
require you to use a particular
Hostname, Domain name, or
MAC (physical) address.
Static (Fixed)
IP Address Your ISP allocates a perma- nent IP Address to you. IP Address allocated to you, mask and gateway (if provided),
and DNS address.
Some ISP's may also require
you to use a particular Host-
name, Domain name, or MAC
(physical) address.
DSL Modems
Type Details ISP Data required
Dynamic
IP Address Your IP Address is allocated automatically, when you
connect to you ISP.
None.
Static (Fixed)
IP Address Your ISP allocates a perma- nent IP Address to you. IP Address allocated to you, mask and gateway (if provided),
and DNS address.
PPPoE You connect to the ISP only
when required. The IP address
is usually allocated automati-
cally.
User name and password.
11

TW100-BRF114 User’s Guide
PPTP Mainly used in Europe.
You connect to the ISP only
when required. The IP address
is usually allocated automati-
cally, but may be Static
(Fixed).
•PPTP Server IP Address.
•User name and password.
•IP Address allocated to
you, if Static (Fixed).
Other Modems (e.g. Broadband Wireless)
Type Details ISP Data required
Dynamic
IP Address Your IP Address is allocated automatically, when you
connect to you ISP.
Usually, none.
However, some ISP's may
require you to use a particular
Hostname, Domain name, or
MAC (physical) address.
Static (Fixed)
IP Address Your ISP allocates a perma- nent IP Address to you. IP Address allocated to you, mask and gateway (if provided),
and DNS address.
Big Pond Cable (Australia)
For this connection method, the following data is required:
•User Name
•Password
•Big Pond Server IP address
SingTel RAS
For this connection method, the following data is required:
•User Name
•Password
•RAS Plan
12

Setup
Home Screen
After finishing or exiting the Setup Wizard, you will see the Home screen. When you connect
in future, you will see this screen when you connect. An example screen is shown below.
Figure 5: Home Screen
Navigation & Data Input
•Use the menu bar on the top of the screen, and the "Back" button on your Browser, for
navigation.
•Changing to another screen without clicking "Save" does NOT save any changes you may
have made. You must "Save" before changing screens or your data will be ignored.
On each screen, clicking the "Help" button will
display help for that screen.
From any help screen, you can access the list of all
help files (help index).
13

TW100-BRF114 User’s Guide
LAN Screen
Use the LAN link on the main menu to reach the LAN screen. An example screen is shown
below.
Figure 6: LAN Screen
Data - LAN Screen
TCP/IP
IP Address IP address for the TW100-BRF114, as seen from the local LAN. Use
the default value unless the address is already in use or your LAN is
using a different IP address range. In the latter case, enter an unused IP
Address from within the range used by your LAN.
Subnet Mask The default value 255.255.255.0 is standard for small (class "C")
networks. For other networks, use the Subnet Mask for the LAN
segment to which the TW100-BRF114 is attached (the same value as
the PCs on that LAN segment).
DHCP Server •If Enabled, the TW100-BRF114 will allocate IP Addresses to PCs
(DHCP clients) on your LAN when they start up. The default (and
recommended) value is Enabled.
•If you are already using a DHCP Server, this setting must be
Disabled, and the existing DHCP server must be re-configured to
treat the TW100-BRF114 as the default Gateway. See the follow-
ing section for further details.
•The Start IP Address and Finish IP Address fields set the values
used by the DHCP server when allocating IP Addresses to DHCP
clients. This range also determines the number of DHCP clients
supported.
See the following section for further details on using DHCP.
Buttons
Save Save the data on screen.
Cancel The "Cancel" button will discard any data you have entered and reload
the file from the TW100-BRF114.
14

Setup
DHCP
What DHCP Does
A DHCP (Dynamic Host Configuration Protocol) Server allocates a valid IP address to a
DHCP Client (PC or device) upon request.
•The client request is made when the client device starts up (boots).
•The DHCP Server provides the Gateway and DNS addresses to the client, as well as
allocating an IP Address.
•The TW100-BRF114 can act as a DHCP server.
•Windows 95/98/ME2000/XP and other non-Server versions of Windows will act as a
DHCP client. This is the default Windows setting for the TCP/IP network protocol. How-
ever, Windows uses the term Obtain an IP Address automatically instead of "DHCP
Client".
•You must NOT have two (2) or more DHCP Servers on the same LAN segment. (If your
LAN does not have other Routers, this means there must only be one (1) DHCP Server on
your LAN.)
Using the TW100-BRF114 's DHCP Server
This is the default setting. The DHCP Server settings are on the LAN screen. On this screen,
you can:
•Enable or Disable the TW100-BRF114 's DHCP Server function.
•Set the range of IP Addresses allocated to PCs by the DHCP Server function.
You can assign Fixed IP Addresses to some devices
while using DHCP, provided that the Fixed IP Addresses
are NOT within the range used by the DHCP Server.
Using another DHCP Server
You can only use one (1) DHCP Server per LAN segment. If you wish to use another DHCP
Server, rather than the TW100-BRF114 's, the following procedure is required.
1. Disable the DHCP Server feature in the TW100-BRF114. This setting is on the LAN
screen.
2. Configure the DHCP Server to provide the TW100-BRF114 's IP Address as the Default
Gateway.
To Configure your PCs to use DHCP
This is the default setting for TCP/IP under Windows 95/98/ME/NT4.0/2000/XP.
See Chapter 4 - Client Configuration for the procedure to check these settings.
15

TW100-BRF114 User’s Guide
16
Password Screen
The password screen allows you to assign a password to the Firewall Router.
Figure 7: Password Screen
Once you have assigned a password to the Firewall Router (on the Password screen above)
you will be prompted for the password when you connect, as shown below. (If no password
has been set, this dialog will not appear.)
Figure 8: Password Dialog
•Leave the "User Name" blank.
•Enter the password for the Firewall Router, as set on the Password screen above.
