TRENDnet TV-IP340PI User manual

TV-IP340PI (V1)
Quick Installation Guide

Table of Content
1 English
1. Before You Start
2. Hardware Installation and Configuration

1
1. Before You Start
Package Contents
ŸTV-IP340PI
ŸCD-ROM (Utility and User's Guide)
ŸQuick Installation Guide
ŸMounting kit
Minimum Requirements
ŸPower over Ethernet (PoE) switch (e.g. TPE-S50) or PoE Injector (e.g. TPE-113GI)
ŸA networked computer and web browser
ŸWired network
ŸNetwork cable
Free Mobile App: TRENDnet IPView Requirements
Supported Operating Systems
Android (version 2.3.3 or above)
iOS (version 5.1.1 or above)
Note: The TV-IP340PI only works with Power over Ethernet (PoE) devices that follow the IEEE
802.3af standard.

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
2
2. Hardware Installation and Configuration
1. Do not install or mount the IP camera until after you complete the installation steps below.
Temporarily place the IP camera next to your computer.
2. Insert the Utility CD-ROM into your CD-ROM drive.
3. Click Install Camera Utility.
Note: You can also download the utility at http://www.trendnet.com/support/TV-IP340PI.

3
4 After you install the Camera Utility, Run the Camera Utility program and it will automatically .
search for your cameras on the same network of your computer.
5. After the utility is done scanning. Click on the IP address section of the camera you would like
to access.
6. Once you get to the login page enter Username: admin Password: admin.

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
4
7. Once you login the camera will prompt you for a password change. Please change the default
password.
8. Now you can access the camera's configuration page for Live view and additional settings. For
more details, please refer to the User's Guide.
9. Scan the QR code below to download a free mobile app to view the camera from your IOS or
Android device. Please refer to the quick install guide for instructions on how to setup your
camera in the app from your cameras download page at www.TRENDnet.com.
Android iOS

5
Using the TV-IP340PI with a PoE switch (TPE-S50)
ŸConnect the provided network cable from the Power over Ethernet switch (e.g. TPE-S50) to
the network port on the IP Camera.
ŸConnect the switch to your network.
PoE
TV-IP340PI
Internet
Power
Switch

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
6
Mounting the camera
Note: For tips on capturing appropriate camera viewing angle, please refer to the user's guide.
1. Loosen the adjustable nut and manually position the camera as desire.
2. Place the provided template label on the wall or ceiling.
3. Drill holes at each marked position on the template. Make sure the drill bit matches the size of
the holes on the template.
4. Insert the provided screw anchors into the holes.
5. Insert the cables through the hole in the wall or ceiling.
Ceiling Mounting
Hole
HoleHole

7
6. Align the mounting bracket with the screw anchors, and then use the provided screws to
secure the camera to the mounting surface.
7. Manually adjust the zoom and focus. Using the free app, confirm the zoom and focus matches
installation requirements.
8. Refer to User's Guide for more details on installation and configuration.
Zoom
Focus

Directives:
TRENDnet hereby declare that the product is in compliance with the essential requirements and
other relevant provisions under our sole responsibility.
This product is herewith confirmed to comply with the Directives.
Product Information
Product Name:
Model Number: TV-IP340PI
Trade Name: TRENDnet
Indoor/Outdoor 2MP 1080p Varifocal PoE IR Network Camera
EMC
Person responsible for this declaration.
Date: November 11, 2016
Title: Director of Technology
Place of Issue: Torrance, California, USA
Name: Sonny Su
Signature:
EN 55022: 2010 + AC: 2011 Class A
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009
EN 61000-3-3: 2008
EN 50130-4: 2011 + A1: 2014
Directive LVD 2014/35/EU
Directive EMC 2014/30/EU
Directive RoHS 2011/65/UE
REACH Réglement (CE) N° 1907/2006
Manufacturer’s Name and Address
TRENDnet, Inc.
20675 Manhattan Place
Torrance, CA 90501 USA
Zwolsestraat 156 2587 WB
The Hague The Netherlands
