TRENDnet TEG-S240TX - DATA SHEETS User manual

TRENDnet's TEG-S240TX is a high performance 24-port rack
mountable Copper Gigabit Switch. With auto-negotiation
technology, the TEG-S240TX automatically negotiates between
10Base-T, 100Base-TX and 1000Base-T network speeds, as well
as half and full duplex modes. The Auto-MDIX feature on each port
automatically detects and adjusts connection type with either
straight-through or crossover cable. Providing simple migration,
scalability, and flexibility to handle new applications and data types,
TRENDnet's TEG-S240TX is a highly reliable and cost effective
solution for high-speed network applications.
TEG-S240TX
24-Port 10/100/1000Mbps Copper Gigabit
Switch
TEG-S240TX
rev:09.20.2006
• 24 10/100/1000Mbps Auto Negotiation and Auto-MDIX Ethernet Ports
Full/Half duplex transfer mode for each port (full duplex mode for 1000Base-T only)
Store and Forward switching method
20Gbps Backplane
Integrated address Look-Up Engine, supports 32k absolute MAC Address
Supports 2 Mbytes RAM for data buffering
Extensive Front Panel Diagnostic LEDs
Broadcast Storm protection
IEEE 802.3x flow control for full-duplex
Back Pressure flow control for half-duplex
Standard 19” rack-mount size
5-year Warranty
•
•
•
•
•
•
•
•
•
•
•
FEATURES
BENEFITS
Performance:
Top performance for gigabit network solutions.
Easy Upgrade:
Current Ethernet workgroups are able to upgrade to Fast Ethernet by changing adapters and hubs without
changing switches.
Flexibility:
All ports automatically negotiate 10/100/1000 Mbps network speed, half/full-duplex mode, and Auto-MDIX;
easy uplink with any port.
Cost Effective:
Provide 10/100/1000Mbps of Fast Ethernet at an affordable rate.

Topology
Power Consumption
Protocol
Cabling
Data Transfer Rate
Data RAM Buffers
Filtering Address Table
Dimensions (W x H x D)
Weights
Humidity
Temperature
Certifications
• IEEE 802.3 10Base-T, 802.3u 100Base-TX and 802.3ab 1000Base-T
• CSMA/CD
• Fast Ethernet: 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
• 100~240VAC 50/60Hz, Internal Universal Switching Power, 55 Watts. Max.
• Operating: 0° ~ 40° C (32° ~ 104°F). ; Storage: -10° ~ 70° C (14° ~ 158°F)
• FCC, CE
• Star
• Ethernet: Cat. 3, 4, 5, UTP/STP. EIA/TIA-568 100 ohm, 100 meters max.
• Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
• 440 x 210 x 44 mm (17.3 x 8.27x 1.73 inch) (W x H x D)
• 2MB per device
• 32K entries per device
• Power, Link/Act, 1000M, 100M
• 10% ~ 90% (non-condensing)
• 3Kg (6.6 lb)
• Fast Ethernet: Cat. 5, UTP/STP, EIA/TIA-568 100 ohm, 100 meters max.
• Gigabit Ethernet: Cat.5 or better, UTP/STP, EIA/TIA-568 100ohm, 100 meters max.
• Gigabit Ethernet: 2000Mbps (Full-Duplex)
Diagnostic LEDs
LAN Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
24-Port 10/100/1000Mbps Copper Gigabit Switch
TEG-S240TX
