TRENDnet TK-403KR User manual

TRENDnet’s TK-403KR 4-port KVM encompasses all your
multimedia and multitasking needs into one cost effective solution.
Manage multiple PC’s effectively while enjoy audio-rich features
with one set of monitor, keyboard, mouse, microphone, and
speakers.
TK-403KR
4-Port Audio KVM Switch
TEW-503PI (07-28-2005) TK-403KR
rev:01.17.2007
• 4-Port PS/2 Audio KVM Switch with Audio and Microphone switching
• PS/2 style keyboard and mouse control
• Simultaneous/Independent Switching of Audio-Microphone and PC channel
• Supports Microsoft IntelliMouse, IntelliMouse Explorer, Logitech NetMouse and more
• Additional advanced support for High-End Logitech Wired/Wireless/Optical Mice
• High Quality of up to 2048 x 1536 VGA Resolution
• Direct Channel Selection and Operation using Push Buttons or Hot-Key Commands
• Mouse Reset Hot-Key Support for non-PnP OS such as WinNT 4.0 and Linux
• Auto-Scan Mode for monitoring PCs and Beeping Sound for Switching Confirmation
• Supports DOC, Windows 95/98(SE)/ME/2000/XP, Linux and more
• Plug & Play and Hot-Pluggable
• EIA-19” (1U) Rack-Mountable (kit included)
• 2-Year Warranty
FEATURES
BENEFITS
Integration Friendly:
Does not require driver/software for the installation and operation.Switch between PCs with the push button
or Hot-Key operation.
Flexible:
Hot-Plug feature, add PCs or remove connected PCs without powering off the KVM switch or the other Pcs.
Cost Effective:
Manage two PCs with single keyboard, monitor, mouse and speakers/microphone. Save on equipment
cost, utility, and space.
Performance:
Support High Quality 2048 x 1536 resolution

PC Port Connector
Auto Scan Intervals
Console Ports Connector
Cable
4 sets of Audio
KVM Cable(1.8m/6ft)
Keyboard/Mouse Emulation
Display Resolution
Dimensions
Humidity
Certifications
Power
Temperature
• Push Buttons or Hot-Key Commands
• PS/2 Keyboard 6-pin Mini Din (Female) + Audio
• 5~100 seconds (default 5 seconds)
• Bus-Powered, Optional Adapter : 9V DC, 500mA (not included)
• Operating: 0°~ 40°C (32°~ 104°F)
• To KVM: PS/2 Keyboard 6-pin Mini Din (Male) , PS/2 Mouse 6-pin Mini Din (Male) , VGA HDB 15-pin (Male)
• To PC: PS/2 Keyboard 6-pin Mini Din (Male) , PS/2 Mouse 6-pin Mini Din (Male), VGA HDB 15-pin (Male),
Audio connector (Male) , Microphone connector (Male)
• PS/2
• 1 x PS/2 Keyboard 6-pin Mini Din (Female)
• 1 x PS/2 Mouse 6-pin Mini Din (Female)
• 255 x 117.5 x 45mm (10 x 4.6 x 1.8 inches)
• 2048 x 1536
• 0 ~ 90%RH, Non-Condensing
• FCC, CE
• Storage: -20°~ 60°C (-4°~ 140°F)
PC Selection
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
4-Port Audio KVM Switch
TK-403KR
RELATED PRODUCTS
PACKAGE CONTENTS
TK-206i 2-Port USB KVM Switch
• Multi-Language User’s Guide
• Rack Mount Kit
• 4-Port Audio KVM Switch
• 4 Sets of Audio KVM Cables
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
• 1 x VGA HDB 15-pin (Female)
• 1 x 3.5mm Audio in/out jack
• 1 x 3.5mm Microphone in/out jack
• 4 x PS/2 Mouse 6-pin Mini Din (Female) + Microphone
• 4 x VGA HDB 15-pin (Female)
Weight • 1000 g (35.2 oz.)
TK-210K 2-Port USB and PS/2 KVM Switch with Audio
(TK-403KR)
Keyboard Mouse
LCD Monitor
4-Port Rack Mount
KVM Switch with Audio
Speaker
Microphone
Audio/Microphone Cable
VGA Cable
PS/2 Cable PC 4
VGA
PS/2
Audio/Microphone
PC 3
VGA
PS/2
PS/2
VGA
PC 2
PS/2
VGA
PS/2
PS/2
VGA
PC 1
PS/2
VGA
PS/2
Audio/Microphone Audio/Microphone
Audio/Microphone
VGA
PS/2
PS/2
PS/2
VGA
PS/2 PS/2
VGA
PS/2
