TRENDnet TK-1603R User manual

TK-803R
TK-1603R
Quick Installation Guide

Table of Contents
Table of Contents
Version 10.27.2006
English .....................................................................................................
Specifications ............................................................................................
Troubleshooting .........................................................................................
1
1
2
4
31
32
1. Before You Start
2. How to Install .....................................................................................
3. Operation ...........................................................................................
................................................................................

System Requirements
Application
TK-803R/TK-1603R
Quick Installation Guide
Rack mount kit
AC Power Adapter (9V DC, 1A)
PS/2 or USB Keyboard
PS/2 or USB Mouse
VGA Compatible Monitor
KVM cables
Windows 98SE/ME/2000/2003 Server, Linux, and Mac
Package Contents
1. Before You Start
English
1
8/16 Ports Rack Mount
USB KVM Switch
(TK-803R/TK-1603R)
PC 2PC 4PC 6PC 8
Monitor
USB or PS/2
Mouse
USB or PS/2
Keyboard
PC 1PC 3PC 5PC 7

2. How to Install
English
2
1. Turn OFF all computers and their
peripherals, and then disconnect all
power cords.
4. Connect the included AC Power
Adapter to the KVM switch and
then to a power outlet.
2. Use the KVM cables to connect
each computer to the KVM switch.
3. Connect the shared PS/2 or USB
keyboard, monitor, and PS/2 or
USB mouse to the KVM switch's
Console Port. (TK-1603R shown)

English
3
5. Turn ON the connected computers
one-by-one and wait until each
computer's desktop appears.
7. Carefully position the switch onto
the rack. Align the bracket to the
screw holes on the rack, then use
the screws provided with the
equipment rack to mount the
switch.
The KVM Switch can be mounted in an EIA standard-size, 19-inch rack, which
can be placed in a wiring closet with other equipment.
Note: If you would like to mount the KVM switch to a EIA 19” equipment rack,
install the included mounting brackets to the sides of the KVM switch, secure
them with the screws provided, and then mount the KVM switch to the
equipment rack with the hardware provided by the equipment rack
manufacturer.
Rack Mount
6. Attach the mounting brackets to
both sides of the switch and secure
them with the provided screws.
Your installation is now complete.

English
4
3. Operation
Note: To switch between computers, you can use the front-panel push buttons
or the Hot Key commands.
LED Indicators
Red LED light: KVM cable is
connected and PC is powering the
KVM switch.
Green LED light: Indicates the
selected PC port is active, whether
the computer is turned on or off.
Push Buttons
Press the push buttons to switch
between computers.
Hot-Key Commands
A keyboard hot-key command consists of three keystrokes:
Hot-Key command = ScrLk + ScrLk + Command key(s)
After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.
You then have another 2 seconds to press a command key. If you do not press
a key within 2 seconds, the switch will exit hot-key mode.

To select a specific PC port:
For TK-803R
Select PC =
For example, to Select Port 1 on the TK-803R you hit the following key
sequence:
Select PC =
For TK-1603R
Select PC =
MAC USERS
Standard PC Keyboard to MAC Keyboard mapping information:
For example, to select Port 1 on the TK-1603R you hit the following key
sequence:
Select PC =
To select port 10 on the TK-1603, hit the following key sequence:
Select PC =
ScrLk ScrLk 1
+ +
ScrLk ScrLk Y
+ +
ScrLk ScrLk 10
+ + +
ScrLk ScrLk YZ
+ + +
ScrLk ScrLk 01
+ + +
English
5
ScrLk ScrLk C
+ + = CD/DVD drive
eject key
ScrLk ScrLk F10
+ + =
ScrLk ScrLk F11
+ + =
ScrLk ScrLk F12
+ + =
F13
F15
F14
For a list of all the Hot-Key commands, please see the Quick Reference Sheet.

Command Hot-Keys Description
Front-Panel
Buttons
Quick Reference Sheet for TK-803R/TK-1603R
Select PC
Next lower channel
Autoscan
Next higher channel
Autoscan with
Programmable
Delay Time
Autoscan Beep
Sound On/Off
Mouse/Keyboard
Reset KVM
Restore to Factory
Defaults
Define Hotkey
Sequence
(default = ScrLK +
ScrLK)
Stop Autoscan
ScrLk ScrLk
+ +
(Arrow up)
ScrLk ScrLk
+ +
(Arrow down)
ScrLk ScrLk
+ + B
ScrLk ScrLk
+ + END
ScrLk ScrLk
+ + R
ScrLk ScrLk
+ + S
Press any key on keyboard
Select the active PC channel
Press the Push Button
for a specific port to
switch to that port
Select the next lower PC
channel
Autoscan through every
connected channel for quick
screen browsing of each
channel
Select the next higher PC
channel
Autoscan through every
connected channel for quick
screen browsing of each
channel in intervals of X
seconds
Toggle On/Off beep sound
during Autoscan mode.
Resets Mouse/Keyboard
Restore to Factory Defaults
Select the hotkey preceding
sequence among 5 options
Terminate Autoscan activityPress any button
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
ScrLk ScrLk Y
+ +
(YZ)= 2-digit channel number
TK-803R
TK-1603R
ScrLk ScrLk YZ
+ + +
Y = Scroll Lock, Caps Lock, Esc, F12 or
Num Lock
ScrLk ScrLk HY
+ + +
(X) = 0~9
1 = 10 seconds
2 = 20 seconds
3 = 30 seconds
4 = 40 seconds
5 = 50 seconds
6 = 60 seconds
7 = 70 seconds
8 = 80 seconds
9 = 90 seconds
0 = 100 seconds
ScrLk ScrLk SX
+ + +
English
6
Note: If you have defined a different hotkey preceding sequence key (e.g. Caps
Lock, Esc, F12), press that button instead of scroll lock. For example, if you
want to turn off beep and have defined the hotkey preceding sequence key as
F12, press F12 + F12 + B.

7
Port Selection: Push Button and Hot-Key Commands
Keyboard State:
Power:
Saved and restored
LED Segment: Per Port : PC Link (Green) ; PC Active (Red)
Management: TK-803R: 8 computers
TK-1603R: 16 computers
Console Port Connectors:
1 x USB keyboard Type A
1 x USB mouse Type A
1 x PS/2 keyboard 6-pin mini din female
1 x PS/2 mouse 6-pin mini din female
1 x VGA HDB 15-pin female
PC Port Connectors:
(all female)
TK-803R: 8 x VGA HDB 15-pin
TK-1603R: 16 x VGA HDB 15-pin
VGA Resolution: 2048 x 1536
Specifications
Weight: TK-803R : 1.84 kg (4.05 lbs)
TK-1603R : 2.04 kg (4.5 lbs)
0ºC ~ 40ºC (32ºF ~104ºF)Operating Temperature:
-20ºC ~ 60ºC (-4ºF ~ 140ºF)Storage Temperature:
0%~90%, Non-Condensing
Humidity:
FCC and CECertifications:
Auto-Scan Intervals: 10 ~ 100 seconds
PS/2 Interface Power
USB Interface Power
External AC Power Adapter : 9V DC, 1A
Size (19" Rack mount):
Dimensions:
1RU
405 x 163 x 44 mm (15.94 x 6.42 x 1.74 in.)

8
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Q6:
A6:
Do I need to use the included external AC adapter?
It is recommended that you use the included external AC adapter with the
TK-803R/TK-1603R KVM switch.
I have the KVM switch connected properly, but my USB keyboard and mouse
don't work.
First, make sure your USB port is working properly by testing it with your other
USB devices. Second, once you confirm that the USB port is functional, please
reboot your computers, and try to use the KVM switch again. Third, if your
computer is running Windows 98SE, you may need to download and install the
USB hot fix. Please go to this link for download and installation instructions:
http://support.microsoft.com/kb/q240075. Once the hot fix is installed, follow the
installation instructions in Section 2.
Can I connect or disconnect the KVM cables while the computers are turned
on?
Yes, you can connect or disconnect the KVM cables while the computers are
turned on, because the interface is Hot-Pluggable.
Yes, the KVM switch will restore the keyboard settings when switching
between computers. (i.e.: Caps Lock, Num Lock, etc.)
Go to Section 3 Operation for more information.
If you still encounter problems or have any questions regarding the TK-803R/
TK-1603R please contact TRENDnet's Technical Support Department.
Will the KVM switch restore the keyboard settings when switching between
computers?
How do I switch from one computer to another with the KVM switch?
You can switch PCs by pressing the push button on the KVM switch or by
using the Hot-Key commands.
How to upgrade new firmware to my KVM switch?
Please go to the TRENDnet website (www.trendnet.com) to check if there is a
new firmware available for your KVM switch and follow the installation procedure
to perform the update.

Limited Warranty
TRENDnet warrants its products against defects in material and
workmanship, under normal use and service, for the following lengths of
time from the date of purchase.
TK-803R/TK-1603R - 2-Year Warranty
If a product does not operate as warranted above during the applicable
warranty period, TRENDnet shall, at its option and expense, repair the
defective product or part, deliver to customer an equivalent product or
part to replace the defective item, or refund to customer the purchase
price paid for the defective product. All products that are replaced will
become the property of TRENDnet. Replacement products may be new
or reconditioned.
TRENDnet shall not be responsible for any software, firmware,
information, or memory data of customer contained in, stored on, or
integrated with any products returned to TRENDnet pursuant to any
warranty.
There are no user serviceable parts inside the product. Do not remove
or attempt to service the product by any unauthorized service center.
This warranty is voided if (i) the product has been modified or repaired
by any unauthorized service center, (ii) the product was subject to
accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within
the applicable warranty period for a Return Material Authorization (RMA)
number, accompanied by a copy of the dated proof of the purchase.
Products returned to TRENDnet must be pre-authorized by TRENDnet
with RMA number marked on the outside of the package, and sent
prepaid, insured and packaged appropriately for safe shipment.
9

WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT
OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE
REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR
REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES
ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR
USE OF TRENDnet'S PRODUCTS.
TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS
TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED
DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY
CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,
IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE
BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,
FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW
TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY
LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT
OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION
OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY
TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE
PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR
DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of
the state of California.
AC/DC Power Adapter, Cooling Fan,Power Supply, and Cables carry a
1 Year Warranty
10

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.

Copyright ©2006. All Rights Reserved. TRENDnet.
20675 Manhattan Place
Torrance, CA 90501
USA
TRENDnet Technical Support
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
US Canada
24/7 Tech Support
Toll Free Telephone: [phone]
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: [phone]
.
. . . . .
