trig TY96 User manual

TY96/97 CS-STAN Installation Guide
10 November 2016
Document Control
Title:
TY96/97 CS-STAN Installation
Guide
Identifier:
SUP/TY96/004
Issue:
Issue 1.0
Issue Date:
10 November 2016
Author:
Lindsey Christie
Authority:
James Forbes
CCB Category:
2
File Name:
SUP TY96 004 Issue 1 0
Printed on:
19/01/2017 10:39:00

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 1
CONTENTS
1. PREFACE.......................................................................................................................................2
1.1 PURPOSE....................................................................................................................................2
1.2 SCOPE........................................................................................................................................2
1.3 LIMITATIONS.............................................................................................................................2
1.4 CHANGES FROM PREVIOUS ISSUE..............................................................................................2
1.5 CHANGES FORECAST.................................................................................................................2
1.6 DOCUMENT CROSS-REFERENCES ..............................................................................................2
1.6.1 Internal Documents ..........................................................................................................2
1.6.2 External Documents .........................................................................................................3
2. INTRODUCTION..........................................................................................................................4
3. CHANGE DETAILS......................................................................................................................5
3.1 DESCRIPTION OF CHANGE .........................................................................................................5
3.2 ACCEPTABLE METHODS,TECHNIQUES AND PRACTICES.............................................................5
3.3 CONTINUED AIRWORTHINESS INSTRUCTIONS............................................................................5
3.4 ACCEPTABLE MEANS OF COMPLIANCE......................................................................................6
3.5 FORM 123..................................................................................................................................6
3.5.1 Form 123 Example ...........................................................................................................7
3.5.2 Form 123 Completion Instructions...................................................................................8

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 2
1. Preface
1.1 Purpose
This document provides guidance for those planning to install a Trig TY96/97 VHF Radio under CS-
STAN, Subpart B CS-SC001a.
1.2 Scope
CS-STAN Installation of VHF is applicable to any Non-complex motor powered EASA Aircraft, with
a maximum cruising speed in ISA conditions below 250kts, non-complex rotorcraft and any ELA2
aircraft. Non-complex as defined in https://www.easa.europa.eu/easa-and-you/general-
aviation/operations-general-aviation
Complex motor-powered aircraft’ shall mean:
(i) an aeroplane:
with a maximum certificated take-off mass exceeding 5 700 kg, or
certificated for a maximum passenger seating configuration of more than nineteen, or
certificated for operation with a minimum crew of at least two pilots, or
equipped with (a) turbojet engine(s) or more than one turboprop engine, or
(ii) a helicopter certificated:
for a maximum take-off mass exceeding 3 175 kg, or
for a maximum passenger seating configuration of more than nine, or
for operation with a minimum crew of at least two pilots, or
(iii) a tilt rotor aircraft;
1.3 Limitations
CS-STAN cannot be used to extend the operational capability of the aircraft, ie: VFR upgraded to IFR.
New installations are limited to VFR operation
An existing IFR radio can be exchanged with a replacement IFR radio.
In the case of rotorcraft approved for NVIS, if cockpit panels are to be inserted, the change cannot be
considered a standard change.
1.4 Changes from Previous Issue
None, this is the first issue
1.5 Changes Forecast
None.
1.6 Document Cross-References
1.6.1 Internal Documents
01238-00
TY96/97 VHF Radio Installation Manual
Issue AD
01239-00
TY96 Operating Manual
Issue AB

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 3
1.6.2 External Documents
CS-STAN
Certification Specifications for Standard Changes and
Standard Repairs
Issue 1
AC 43-13-2B
FAA Advisory Circular AC 43-13-2B Chapter 2

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 4
2. Introduction
This guide describes the process of installing a TY96/97 VHF radio, using the EASA document
‘Certification Specifications for Standard Changes and Standard Repairs’, more commonly referred to
as CS-STAN. EASA delivered CS-STAN as a more affordable and much faster alternative to the old
EASA Minor Change process
CS-STAN removes the need for any interaction with EASA to complete the change, and no EASA
admin fee. CS-STAN can be used to complete a wide variety of installations, including transponders,
radios, antenna, moving map systems… the list goes on.

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 5
3. Change Details
3.1 Description of Change
This change involves removing an existing radio if applicable, and installing a Trig Avionics TY96/97
VHF Radio.
The processes involved in the change includes pre-testing of any existing installation; verification of
the suitability of the existing power supply wiring; installing the TY96/97 and post-installation testing
as defined in the TY96/97 VHF Installation Manual.
If replacing an existing radio; the original mounting tray will need to be removed and the dedicated
TY96/97 tray must be installed. The connector will also need to be replaced. The existing antenna can
be re-used –provided it is in serviceable condition. Otherwise, need to be replaced or repaired. An
antenna can be replaced under the CS-STAN Section CS-SC004a.
3.2 Radio Selection
The minimum output power specified for the radio is sufficient for the operation depending on the
maximum flight level of the aircraft. The table below is valid for standard antenna installations antenna
type and position) with standard cable length less than 4m and 2 connectors.
Maximum aircraft Flight Level
(FL)
Minimum output power (W)
Trig Radio Selection
Up to 100
4
TY96 (10W nominal output
power)
100 to 150
6
150 to 200
8
200 to 250
10
250 to 300
12
TY97 (16W nominal output
power)
300 to 400
16
For different installations (cable length, connectors), the required output power needs to be assessed by
additional analysis.
For aircraft flying below FL250 the TY96 (nominal power of 10W) is sufficient. For aircraft flying
above FL250 and up to FL400, the 16W TY97 Radio must be installed.
3.3 Acceptable installation methods, techniques and Practices
The installation and return to service test must be carried out in accordance with the TY96/97
Installation manual, available on the Trig website at http://www.trig-avionics.com/products/ty96/
The TY96/97 meets all requirements of CS-STAN as laid out in Section 3 of CS-SC001a; certified to
ETSO 2C169a, capable of both 8.33KHz and 25Khz spacing.
In CS-STAN, It is stated that the installer must ensure that the radio is suitable for environmental
conditions to be expected during normal operation. The TY96/97 is certified for wide variety
environmental stress, as detailed in the TY96/97 Installation Manual.
3.4 Continued Airworthiness Instructions
An approved aircraft maintenance program will normally include periodic functional checks of the
communications radio installation.

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 6
Other than for periodic functional checks required by the regulations, the TY96/97 VHF Radio has
been designed and manufactured to allow “on condition maintenance”. This means that there are no
periodic service requirements necessary to maintain continued airworthiness, and no maintenance is
required until the equipment does not properly perform its intended function.
3.5 Acceptable Means of Compliance
The Installation must be carried out by an EASA Part M or EASA Part 145 organisation. The work
required includes an entry in the aircraft log book and the completion of a Form 123. Below is an
example of the Form 123, which can be used as a template;
3.6 Form 123
The original Form 123 remains with the legal or natural person responsible for the embodiment of the
SC/SR. The aircraft owner should retain a copy of this form. The aircraft owner should be provided
with copies of the documents referenced in box 6 marked with an asterisk '*'.

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 7
3.6.1 Form 123 Example
Enter Company name/Logo and address
Form
123
Issue
1.0
Revision
0
EASA Form 123 —Standard Change/Standard Repair
(SC/SR) embodiment record
1. SC/SR number(s):
2. SC/SR title & description:
INSTALLATION OF VHF 8.33KHz COM EQUIPMENT
3.Applicability:
Enter Aircraft Registration, make and model.
4. List of parts (description/Part-No/Qty):
REMOVED COM p/n xxxx, s/n xxxx VHF COM. (if replacing an existing COM)
FITTED TY96 Kit p/n 01227-00-01, s/n xxxxx VHF 8.33KHz Capable COM
5. Operational limitations/affected aircraft manuals. Copies of these manuals are provided to the
aircraft owner:
TY96 Operation Manual PN 01239-00
6. Documents used for the development and embodiment of this SC/SR:
TY96 VHF Radio Installation Manual PN 01238-00*
TY96 Operation Manual PN 01239-00*
* -Copies of the documents marked with an asterisk are handed to the aircraft owner.
7. Instructions for continuing airworthiness. Copies of these manuals are provided to the aircraft
owner:
TY96 VHF Radio Installation Manual PN 01238-00
8.Other information: NA
9a. ☑This SC complies with the criteria established in 21A.90B(a) and with chapter(s) ..............CS-
001a........ of Certification Specifications CS-STAN.
9b. □ This SR complies with the criteria established in 21A.431B(a) and with
chapter(s)..........NA................ of Certification Specifications CS-STAN.
10. Date of SC/SR embodiment:
Enter date
11. Identification data and signature for the person responsible
for the embodiment of the SC/SR:
Enter Work Pack ID and Signature
12. Signature of the aircraft owner. This signature attests that all relevant documentation is handed
over from the organisation to the aircraft owner, and therefore, the latter becomes aware of any
impact or limitations on operations or additional continuing airworthiness requirements which may
apply to the aircraft due to the embodiment of the change/repair.
Name: Signature: Date:

TY96/97 CS-STAN Installation Guide 10 November 2016
SUP/TY96/004 Issue 1.0
______________________
Trig Avionics Limited Page 8
3.6.2 Form 123 Completion Instructions
Use English or the official language of the State of registry to fill in the form.
1. Identify the SC/SR with a unique number and reference this number in the aircraft logbook.
2. Specify the applicable EASA CS-SC/SR chapter, title & revision.
3. Identify the a/c serial number and aircraft type.
4. List the parts' numbers and parts' description for the parts installed. Refer to an auxiliary document if
necessary.
5. Identify affected aircraft manuals.
6. Refer to the documentation developed to support the SC/SR and its embodiment, including design
data required by the CS-SC/SR: design definition, documents recording the showing of compliance
with the Certification Specifications or any test result, etc. The documents' references should quote
their revision/issue.
7. Identify instructions for continuing airworthiness that need to be considered for the aircraft
Maintenance programme review.
8. To be used as deemed necessary by the installer.
9a.,Standard Change –tick and identify applicable section of CS-STAN
9b.,Standard Repair
10. Enter Date.
11. Give full name details and certificate reference used for issuing the aircraft release to service.
12. Aircraft owner must print name, sign and date.
