Model #: BP48V48RT4U
Shallow-Depth External Battery Pack For UPS Systems
Highlights
Extends runtime of select compatible Tripp Lite UPS Systems with 48 VDC
external battery connector
Shallow-depth rackmount case design is ideal for extended runtime
applications in wiring closets
Daisy-chain capability supports the connection of multiple external battery
packs
Simple 4U rackmount installation
Description
BP48V48RT4U shallow-depth rackmount external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite
UPS systems. Supports configuration in rackmount applications using only 4 rack spaces (4U). Includes heavy gauge cabling with high current DC
connector for simple installation. Additional output connector allows multiple BP48V48RT4U battery packs to be daisy-chained to the UPS for even
longer extended run operation. Includes hardware for 2-post rackmount installation and supports optional 4-post rackmount installation with addition
of 4POSTRAILKIT accessory kit. Ideal for installation in wiring closet applications.
COMPATIBLE UPS SYSTEMS - SMART1500CRMXL, SMART2200CRMXL, SMART3000CRMXL, and other Tripp Lite UPS systems that specify
the use of this battery pack. (Note: BP48V48RT4U, SMART2200CRMXL and SMART3000CRMXL include hardware for 2-post rackmount
installation; most other rackmount UPS systems and battery packs include hardware for 4-post rackmount installation.)
Applications
Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Ideal for wiring closet applications.
Additional battery packs may be ordered at time of original UPS purchase or sourced at a later date to extend runtime performance if site
power conditions deteriorate and longer battery runtime is desired.
Package Includes
BP48V48RT4U External Battery Pack
2-Post Rackmount Hardware
Owner's Manual with Warranty Information
Features
Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems
Shallow-depth design (16.75 inch depth) allows for ease of installation in wiring closets
Supports rackmount installation using only 4 rack spaces (4U)
Set of input/output connectors allows multiple BP48V48RT4U battery packs to be daisy-chained to the UPS for even longer extended run
operation
Includes heavy-gauge cabling with high-current DC connectors for simple installation
Specifications

OUTPUT
Overload protection 180A DC output fuse system
BATTERY
Expandable battery runtime Includes a second input/output connector to daisy-chain multiple BP48V48RT4U battery packs
DC system voltage (VDC) 48
Connects to UPS via Attached 20.5 inch cabling with UPS specific DC connector (52.1 cm length, 4 gauge cable)
Typical battery lifespan 4-6 years typical (North America)
PHYSICAL
Shipping weight (lbs) 169.8
Shipping weight (kg) 76.4
Unit Dimensions (HWD/in) 7 x 17.3 x 16.75
Unit Dimensions (HWD/cm) 17.78 x 44 x 42.5
Shipping Dimensions
(HWD/in)
14.4 x 25.2 x 22.8
Shipping Dimensions
(HWD/cm)
36.6 x 64 x 58
Unit weight (lbs) 143.3
Unit weight (kg) 64.5
Material of construction Black steel cabinet
Form factors supported 4U rack/tower
WARRANTY
Product Warranty Period
(U.S. & Canada)
2-year limited warranty
Product Warranty Period
(International)
1-year limited warranty
Product Warranty Period
(Mexico)
1-year limited warranty
Product Warranty Period
(Puerto Rico)
1-year limited warranty
Optional Coverage 3 year, 5 year, next day, on-site warranty coverage available
Related Items
Optional Products
Product Type Related Model Description Qty.
Extended Warranties WEXT3-BP48V48 3-Year Extended Warranty - For BP48V48RT4U 1
Extended Warranties WEXT5-BP48V48 5-Year Extended Warranty - For BP48V48RT4U 1
Rackmount/Wallmount Kits 4POSTRAILKIT Enables 4-Post Rackmount Installation of Select Rackmount UPS
Systems
1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3810.
