Tripp Lite B127A-1A1-BHBH User manual

1
HDMI over Cat6 Extender Kits,
Repeater and Receivers, 4K/60 Hz
Extender Kit Models: B127A-1A1-BHBH, B127A-1A1-BHPH,
B127A-2A1-BHBH, B127A-111-BHTH, B127A-111-BDTH
Receivers: B127A-1A0-BH, B127A-2A0-BH,
B127A-1P0-PH, B127A-110-BH
Repeater: B127A-010-H
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Owner's Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
Este manual está disponible en español en la página de Tripp Lite:
tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website
verfügbar: tripplite.com
21-03-127-933CC9-EN.indd 121-03-127-933CC9-EN.indd 1 3/24/2021 9:38:13 AM3/24/2021 9:38:13 AM

2
B127A-1A1-BHBH B127A-2A1-BHBH B127A-1A1-BHPH B127A-111-BHTH B127A-111-BDTH B127A-110-BH B127A-1A0-BH B127A-2A0-BH B127A-1P0-PH B127A-010-H
Local and Remote
Units (LR),
Remote Unit (R),
Repeater Unit (RT)
LR LR LR LR LR R R R R RT
External Power
Supplies (0 or 1) 1111110000
Mounting
Hardware YYYYYYYYYN
Package Contents
Product Features
B127A-1A1-BHBH
• HDMI over Cat6 Power over Cable (PoC) Extender Kit
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as
specified in HDMI 2.0, up to 230 ft. (70 m) from the source
• Built-in local HDMI port supports 4K @ 60 Hz signal
• Remote receiver unit features built-in equalization (EQ)
control and auto EDID image adjustment
• Supports up to 7.1-channel surround sound audio
• Receiver features built-in Toslink port for audio extraction function
21-03-127-933CC9-EN.indd 221-03-127-933CC9-EN.indd 2 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

3
Product Features
• Real-time video compression and decompression technology
• Receiver features built-in Toslink port for audio extraction
function
• Compatible with HDCP 2.2, High Dynamic Range (HDR)
and 36-bit color depth
• Plug and play—no software or drivers required
• Support bi-directional IR and USB 1.1 function by dip
switch selection
• Includes mounting hardware that enables both the local
transmitter and remote receiver units to be wall-mounted,
rack-mounted or pole-mounted
• Power over Cable (PoC) function allows external power supply
to be plugged in at either transmitter or receiver side and
provide power to both units
B127A-2A1-BHBH
• HDMI over Cat6 Power over Cable (PoC) Dual Output
Extender Kit
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as
specified in HDMI 2.0, up to 230 ft. (70m) from the source
to two displays
• Built-in local HDMI port supports 4K x 2K signal
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment
• Supports up to 7.1-channel surround sound audio
• Real-time video compression and decompression technology
21-03-127-933CC9-EN.indd 321-03-127-933CC9-EN.indd 3 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

4
Product Features
• Receiver features built-in Toslink port for audio extraction
function
• Compatible with HDCP 2.2, High Dynamic Range (HDR) and
36-bit color depth
• Plug and play—no software or drivers required
• Includes mounting hardware that enables both the local
transmitter and remote receiver units to be wall-mounted,
rack-mounted or pole-mounted
• Power over Cable (PoC) function allows external power supply
to be plugged in at either transmitter or receiver side and
provide power to both units
B127A-1A1-BHPH
• HDMI over Cat6 Power over Cable (PoC) Extender Kit with
Pigtail Receiver
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as specified
in HDMI 2.0, up to 230 ft. (70 m) from the source
• Built-in local HDMI port supports 4K @ 60 Hz signal
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment with 1 ft. HDMI male cable
• Supports up to 7.1-channel surround sound audio
• Compatible with HDCP 2.2, High Dynamic Range (HDR) and
36-bit color depth
• Plug and play—no software or drivers required
• Includes mounting hardware that enables the local transmitter
to be wall-mounted, rack-mounted or pole-mounted
21-03-127-933CC9-EN.indd 421-03-127-933CC9-EN.indd 4 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

5
Product Features
• Power over Cable (PoC) function allows external power supply
to be plugged into transmitter and provide power to both units
B127A-111-BHTH
• HDMI over Cat6 Power over Cable (PoC) daisy-chainable
Extender Kit
• Remote transceiver unit features built-in equalization (EQ)
control, auto EDID image adjustment and RJ45 expanding
port to be able to connect to next B127A-110-BH
• Transceiver features built-in Toslink port for audio
extraction function
• Real-time video compression and decompression technology
• Extends and expands a 4K x 2K (3840 x 2160) @ 60 Hz
signal, as specified in HDMI 2.0, in an over Cat6 installation,
allowing multiple monitors to be located at different points in
a chain by adding up to four B127A-110-BH units
• Extends a 4K (3840 x 2160) @ 60 Hz signal up to an
additional 230 ft. or a 1080p @ 60 Hz signal up to an
additional 230 ft. from each remote/repeater unit to the next
unit in the chain (in a full four-level daisy-chain installation), a
4K (3840 x 216) @ 60 Hz signal up to 920 ft. or a 1080p @
60 Hz signal up to 920 ft. from the source to the last remote
unit in the chain
• Increase the maximum transmission distance to 1,090 ft. by
adding a B127A-010-H signal booster to the first link of a
daisy-chain installation
Note: The signal booster will only work when used in the first link of
the daisy-chain installation.
21-03-127-933CC9-EN.indd 521-03-127-933CC9-EN.indd 5 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

6
Product Features
• Supports up to 7.1-channel surround sound audio
• Transceiver features built-in Toslink port for audio
extraction function
• Compatible with HDCP 2.2, High Dynamic Range (HDR)
and 36-bit color depth
• Plug and play—no software or drivers required
• Includes mounting hardware that enables the transmitter
and transceiver units to be wall-mounted, rack-mounted
or pole-mounted
• Power over Cable (PoC) function allows external power supply
to be plugged into either transmitter or receiver side and
provide power to connected units
B127A-110-BH
• HDMI over Cat6 Power over Cable (PoC) transceiver unit
• Works with the B127A-111-BHTH to extend a 4K x 2K
(3840 x 2160) @ 60 Hz signal, as specified in HDMI 2.0,
up to 230 ft. (70 m)
• This transceiver unit features built-in equalization (EQ) control
and auto EDID image adjustment and one RJ-45 expanding
port to be able to connect to next B127A-110-BH
• Transceiver features built-in Toslink port for audio
extraction function
• Compatible with HDCP 2.2, High Dynamic Range (HDR)
and 36-bit color depth
• Plug and play—no software or drivers required
• Bi-directional IR function
21-03-127-933CC9-EN.indd 621-03-127-933CC9-EN.indd 6 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

7
Product Features
• Real-time video compression and decompression technology
• Add a B127A-010-H signal booster for increased maximum
transmission distance. See B127A-111-BHTH for details.
B127A-111-BDTH
• DisplayPort to HDMI over Cat6 with Power over Cable (PoC)
daisy-chainable Extender Kit
• Extends audio/video signal from a DisplayPort source to an
HDMI display
• Remote transceiver unit features built-in equalization (EQ)
control, auto EDID image adjustment and RJ45 expanding
port to be able to connect to next B127A-110-BH
• Transceiver features built-in Toslink port for audio
extraction function
• Real-time video compression and decompression technology
• Extends and expands a 4K x 2K (3840 x 2160) @ 60 Hz
signal, as specified in HDMI 2.0, in an over Cat6 installation,
allowing multiple monitors to be located at different points in
a chain by adding up to four B127A-110-BH units
• Extends a 4K (3840 x 2160) @ 60 Hz signal up to an
additional 230 ft. or a 1080p @ 60 Hz signal up to an
additional 230 ft. from each remote/repeater unit to the next
unit in the chain (in a full four-level daisy-chain installation), a
4K (3840 x 216) @ 60 Hz signal up to 920 ft. or a 1080p @
60 Hz signal up to 920 ft. from the source to the last remote
unit in the chain
21-03-127-933CC9-EN.indd 721-03-127-933CC9-EN.indd 7 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

8
Product Features
• Increase the maximum transmission distance to 1,090 ft. by
adding a B127A-010-H signal booster to the first link of a
daisy-chain installation
Note: The signal booster will only work when used in the first link of
the daisy-chain installation.
• Supports up to 7.1-channel surround sound audio
• Transceiver features built-in Toslink port for audio
extraction function
• Compatible with DisplayPort 1.2a, HDCP 2.2, High Dynamic
Range (HDR) and 36-bit color depth
• Plug and play—no software or drivers required
• Includes mounting hardware that enables the transmitter
and transceiver units to be wall-mounted, rack-mounted or
pole-mounted
• Power over Cable (PoC) function allows external power supply
to be plugged into either transmitter or receiver side and
provide power to connected units
B127A-1A0-BH
• HDMI over Cat6 Power over Cable (PoC)-Compatible Receiver
• Connects to a B127A-Series transmitter, switch or splitter
unit to extend a 4K x 2K (3840 x 2160) @ 60 Hz signal, as
specified in HDMI 2.0, up to 230 ft. (70m) from the source
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment
• Real-time video compression and decompression technology
21-03-127-933CC9-EN.indd 821-03-127-933CC9-EN.indd 8 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

9
Product Features
• Features built-in Toslink port for audio extraction function
• Supports up to 7.1-channel surround sound audio
• Compatible with HDCP 2.2, High Dynamic Range (HDR) and
36-bit color depth
• Plug and play—no software or drivers required
• Includes mounting hardware that enables the local transmitter
to be wall-mounted, rack-mounted or pole-mounted
• Power over Cable (PoC) function allows receiver unit to be
powered by a connected transmitter, switch or splitter unit
B127A-2A0-BH
• HDMI over Cat6 Power over Cable (PoC)-Compatible Dual
Output Receiver
• Connects to a B127A-Series transmitter, switch or splitter
unit to extend a 4K x 2K (3840 x 2160) @ 60 Hz signal, as
specified in HDMI 2.0, to two displays up to 230 ft. (70m)
from the source
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment
• Real-time video compression and decompression technology
• Features built-in Toslink port for audio extraction function
• Supports up to 7.1-channel surround sound audio
• Compatible with HDCP 2.2, High Dynamic Range (HDR) and
36-bit color depth
• Plug and play—no software or drivers required
21-03-127-933CC9-EN.indd 921-03-127-933CC9-EN.indd 9 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

10
Product Features
• Includes mounting hardware that enables the local transmitter
to be wall-mounted, rack-mounted or pole-mounted
• Power over Cable (PoC) function allows receiver unit to be
powered by a connected transmitter, switch or splitter unit
B127A-1P0-PH
• HDMI over Cat6 Power over Cable (PoC)-Compatible
Pigtail Receiver
• Connects to a B127A-Series transmitter, switch or splitter
unit to extend a 4K x 2K (3840 x 2160) @ 60 Hz signal, as
specified in HDMI 2.0, up to 230 ft. (70m) from the source
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment
• Real-time video compression and decompression technology
• Supports up to 7.1-channel surround sound audio
• Compatible with HDCP 2.2, High Dynamic Range (HDR) and
36-bit color depth
• Plug and play—no software or drivers required
• Power over Cable (PoC) function allows receiver unit to be
powered by a connected transmitter, switch or splitter unit
21-03-127-933CC9-EN.indd 1021-03-127-933CC9-EN.indd 10 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

11
B127A-010-H
• Over Cat6 signal repeater for B127A extenders
• Repeater unit extends the transmission of a 4K x 2K
(3840 x 2160) @ 60 Hz signal, as specified in HDMI 2.0,
up to a total of 400 ft. (120 m)
• Power over Cable (PoC) technology means no external
power is required to power the unit
• HCDP 2.2- and HDR-compliant
• Supports up to 7.1-channel surround sound audio
• Compatible with all B127A-Series products, including HDMI,
DisplayPort and USB-C models
• Plug and play—no software or drivers required
• Increase the maximum transmission distance to 1,090 ft. by
adding a B127A-010-H signal booster to the first link of a
B127A-111-BHTH and B127A-110-BH daisy-chain installation
Note: The signal booster will only work when used in the first link of
the daisy-chain installation.
Optional Accessories:
• N202-Series Cat6 24 AWG Solid Wire Patch Cables
• P569-XXX-CERT or P568-XXX-2A Series High-Speed
HDMI 2.0 Cables
Product Features
21-03-127-933CC9-EN.indd 1121-03-127-933CC9-EN.indd 11 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

12
Disclaimer
Before installation, please check the following settings of your
source(s) and TV/monitor(s):
1. Set display to 60 Hz. Double-check factory settings, as
default can be set to a lower frequency (Hz) than advertised.
2. Ensure the input setting of your monitor is set at HDMI 2.0.
Some displays may have default setting at HDMI 1.4.
3. Verify your monitor has the HDR feature enabled. Some
displays may have this feature disabled as a factory setting.
4. Check if the Ultra HD (UHD) Deep Color setting is enabled on
your TV/monitor. Confirm with your TV/monitor manufacturer
which HDMI ports support UHD Deep Color.
Note: Check USB/IR DIP switch, as the default setting is set to IR.
This only applies to the B127A-1A1-BHBH.
Note: To connect a local monitor to your installation, the UHD Deep
Color setting may need to be disabled on your local TV/monitor
(depending make/mode) to achieve 4K @ 60 Hz resolution.
21-03-127-933CC9-EN.indd 1221-03-127-933CC9-EN.indd 12 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

13
Mounting Instructions (select models only)
The B127A-1A1-BHBH, B127A-2A1-BHBH,
B127A-1A1-BHPH, B127A-111-BHTH, B127A-111-BDTH,
B127A-1A0-BH, B127A-2A0-BH and B127A-110-BH include
mounting hardware that allows for a variety of mounting methods.
The following images illustrate how the included mounting
brackets can be attached for different installations.
Notes:
• The model shown in the below images is for illustrative purposes only.
Your product may vary by model number, size or port orientation. The
mounting options for all over IP units are the same.
• Only the transmitter unit in the B127A-1A1-BHPH can be mounted.
The receiver is a pigtail-type unit that cannot be mounted.
Wall-Mount
19” Rack-Mount Pole-Mount
21-03-127-933CC9-EN.indd 1321-03-127-933CC9-EN.indd 13 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

14
Standard Extender Kit Installation
Notes:
• Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
• To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a
gauge (AWG) size higher than 24 AWG will result in shorter extension
distance. Higher-gauge cabling, such as 26 AWG, has a more limited
transmission capability than lower-gauge cabling. All Tripp Lite
N202-Series Cat6 cables are made with 24 AWG solid wire cabling.
• The installation diagram shows a B127A-1A1-BHBH unit.
• External power is not required for remote receiver units due to Power
over Cable (PoC) technology incorporated in the transmitter units.
B127A-1A1-BHBH
extender kit
IR Control
Pad IR Sensor
HDR Player
LOCAL / TRANSMITTER REMOTE / RECEIVER
Monitor
TV
USB Keyboard
USB Mouse
Up to 230 ft. Cat6 solid cable at 4K/60 Hz
Up to 15 ft. HDMI 2.0 cable at 4K/60 Hz
Micro-USB cable
Toslink cable
IR Control
Pad IR
Sensor
21-03-127-933CC9-EN.indd 1421-03-127-933CC9-EN.indd 14 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

15
Standard Extender Kit Installation
1. Make sure all equipment in the installation—such as TVs,
Blu-ray™ players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the HDMI source to
the INPUT port on the local transmitter unit.
3. Optional for B127A-1A1-BHBH: Using an HDMI 2.0 cable
(such as Tripp Lite P569-XXX-CERT or P568-XXX-2A Series
cables), connect a local monitor to the LOCALOUT port on
the B127A-1A1-BHBH local transmitter unit.
4. Optional: For extended range, connect a B127A-010-H
signal repeater unit to the transmitter and receiver via
Cat6 cabling. See B127A-010-H product features for
more information.
5. Using Cat6 cable, connect the RJ45 port on the local
transmitter unit to the RJ45 port on the remote receiver unit.
6. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the remote receiver
unit’s HDMI port to a monitor.
7. Turn on the power to your connected TVs/monitors.
21-03-127-933CC9-EN.indd 1521-03-127-933CC9-EN.indd 15 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

16
Standard Extender Kit Installation
8. Connect the external power supply to either the transmitter
or receiver unit. Plug it into an available wall outlet or a
Tripp Lite surge protector, power distribution unit (PDU) or
uninterruptible power supply (UPS). The POWER (green)
LED on the local transmitter unit will illuminate to indicate
the unit is receiving power from the external power supply.
The POWER (green) LED on the remote receiver unit will
illuminate to indicate the unit is receiving power from the
local transmitter unit through PoC technology.
9. Turn on the power to the HDMI source.
10. The orange RJ45 LED will illuminate on both the local
transmitter and remote receiver units to indicate a signal is
being received from the source to display. The screen should
now display on the connected monitor(s).
21-03-127-933CC9-EN.indd 1621-03-127-933CC9-EN.indd 16 3/24/2021 9:38:14 AM3/24/2021 9:38:14 AM

17
Standard Extender Kit Installation
Notes:
• Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
• To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a
gauge (AWG) size higher than 24 AWG will result in shorter extension
distance. Higher-gauge cabling, such as 26 AWG, has a more limited
transmission capability than lower-gauge cabling. All Tripp Lite N202-
Series Cat6 cables are made with 24 AWG solid wire cabling.
• The installation diagram shows a B127A-2A1-BHBH unit.
• External power is not required for remote receiver units due to Power
over Cable (PoC) technology incorporated in the transmitter units.
INPUTOUTPUT 2OUTPUT 1
DC 24V, 1A
DC 24V, 1A
OUTPUTINPUTLOCAL

Up to 230 ft. (70 m) Cat6 cable at 4K/60Hz
Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60Hz
Toslink cable
Up to 230 ft. (70 m) at 4K/60Hz

 


LOCAL / TRANSMITTER REMOTE / RECEIVER
B127A-2A1-BHBH
extender kit
HDR Player
Monitor TV
TV
21-03-127-933CC9-EN.indd 1721-03-127-933CC9-EN.indd 17 3/24/2021 9:38:15 AM3/24/2021 9:38:15 AM

18
Standard Extender Kit Installation
1. Make sure all equipment in the installation—such as TVs,
Blu-ray players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the HDMI source to
the INPUT port on the local transmitter unit.
3. Optional for B127A-2A1-BHBH: Using an HDMI 2.0 cable
(such as Tripp Lite P569-XXX-CERT or P568-XXX-2A Series
cables), connect a local monitor to the LOCALOUT port on
the B127A-2A1-BHBH local transmitter unit.
4. Optional: For extended range, connect a B127A-010-H
signal repeater unit to the transmitter and receiver via
Cat6 cabling. See B127A-010-H product features for more
information.
5. Using Cat6 cable, connect the RJ45 port on the local
transmitter unit to the RJ45 port on the remote receiver unit.
6. Using HDMI 2.0 cables (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the remote receiver
unit’s dual HDMI ports to the monitor(s).
7. Turn on the power to your connected TVs/monitors.
21-03-127-933CC9-EN.indd 1821-03-127-933CC9-EN.indd 18 3/24/2021 9:38:15 AM3/24/2021 9:38:15 AM

19
Standard Extender Kit Installation
8. Connect the external power supply to either the transmitter
or receiver unit. Plug it into an available wall outlet or a
Tripp Lite surge protector, power distribution unit (PDU) or
uninterruptible power supply (UPS). The POWER (green)
LED on the local transmitter unit will illuminate to indicate
the unit is receiving power from the external power supply.
The POWER (green) LED on the remote receiver unit will
illuminate to indicate the unit is receiving power from the
local transmitter unit through PoC technology.
9. Turn on the power to the HDMI source.
10. The orange RJ45 LED will illuminate on both the local
transmitter and remote receiver units to indicate a signal is
being received from the source to display. The screen should
now display on the connected monitor(s).
21-03-127-933CC9-EN.indd 1921-03-127-933CC9-EN.indd 19 3/24/2021 9:38:15 AM3/24/2021 9:38:15 AM

20
Standard Extender Kit Installation
Notes:
• Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
• To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a
gauge (AWG) size higher than 24 AWG will result in shorter extension
distance. Higher-gauge cabling, such as 26 AWG, has a more limited
transmission capability than lower-gauge cabling. All Tripp Lite
N202-Series Cat6 cables are made with 24 AWG solid wire cabling.
• The installation diagram shows a B127A-1A1-BHPH unit.
• External power is not required for remote receiver units due to Power
over Cable (PoC) technology incorporated in the transmitter units.
B127A-1A1-BHPH
extender kit
IR Control
Pad IR Sensor
HDR Player
LOCAL / TRANSMITTER REMOTE / RECEIVER
Monitor
TV
Up to 230 ft. Cat6 solid cable at 4K/60 Hz
Up to 15 ft. HDMI 2.0 cable at 4K/60 Hz
Micro-USB cable
21-03-127-933CC9-EN.indd 2021-03-127-933CC9-EN.indd 20 3/24/2021 9:38:15 AM3/24/2021 9:38:15 AM
