Tripp Lite B310-701-4K User manual

1
7-Port 4K 60 Hz
Multi-Format
Presentation Switch
Model: B310-701-4K
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Owner’s Manual
Español 17 • Français 33 • Русский 49 • Deutsch 65
20-06-151 933CBD.indb 120-06-151 933CBD.indb 1 10/13/2020 1:21:52 PM10/13/2020 1:21:52 PM

2
Package Contents
• B310-701-4K Multi-Format Presentation Switch
• IR Remote Control
• IR Receiver Head Cable
• International Power Supply (Input: 100-240V) with North America,
Europe, U.K. and Australia Plug Adapters
• Mounting Hardware
• Seamlessly switch between multiple video sources to an HDMI-compliant
display using the front-panel pushbuttons or the IR remote control.
• Supports HDMI resolutions up to 4096 x 2160 @ 60 Hz 4:4:4;
DisplayPort resolutions up to 3840 x 2160 @ 60 Hz; VGA resolutions up
to 1280 x 768 @ 60 Hz; YPbPr resolutions up to 1920 x 1080 @ 60 Hz;
AV resolutions up to 1280 x 720 @ 60 Hz.
• Both digital, Toslink and coaxial, and analog, R/L, audio outputs work
simultaneously.
• Front-panel USB port supports the connection of U-disk for audio (MP3),
video (MP4, WMA), picture (JPG, BMP) / text (English Text).
• Sends analog video signals to the HD display using the scaler function.
• Supports High Dynamic Range (HDR) for richer contrast and expanded
color accuracy and 36-bit (12bpp) deep color.
• Memory function stores the last output source and displays it once the
unit is powered on again.
• HDCP 2.2 and HDR compliant.
Optional Accessories
Package Features
• P569-XXX-CERT Series High-Speed HDMI Cables
• P580-Series DisplayPort Cables
• P502-Series VGA Coaxial Cables
• A008-Series Component Video Gold Cables
• P312-Series 3.5mm Audio Cables
• A102-Series Toslink Cables
20-06-151 933CBD.indb 220-06-151 933CBD.indb 2 10/13/2020 1:21:52 PM10/13/2020 1:21:52 PM

3
Panel Description
Front Panel:
1Power Button: Turns the unit on/off
2Power LED: Illuminates red to indicate the unit is powered on
3Manual Pushbuttons: Refer to the Operation section for pushbutton
functions
4IR Receiver: Receives information from the IR remote control
5IR Port: Connector for the IR Receiver Head Cable (included)
6USB-A Port: Connector for a USB peripheral device
Rear Panel:
7DisplayPort In: Connect a DisplayPort source
8HDMI In: Connect up to three HDMI sources
9VGA In: Connect a VGA source
10 YPbPr In: Connect a component source
11 AV In: Connect a AV source
12 Audio In: Connect the audio input from the analog video input source
13 Toslink/Coaxial: Connect either port to a digital audio output device
14 R/L: Connect to an analog audio output device
15 HDMI Out: Connect an HDMI-compliant display
16 DC In: Connect the included external power supply
Power Source Up Down Left Right OK Menu IR IR EXT USB In
DC 5V, 2A
HDMI OutLRCoaxialToslinkAudio InVGA InHDMI In 3HDMI In 2HDMI In 1 AV InY Pr
PbDisplayPort In
Power Source Up Down Left Right OK Menu IR IR EXT USB In
DC 5V, 2A
HDMI OutLRCoaxialToslinkAudio InVGA InHDMI In 3HDMI In 2HDMI In 1 AV InY Pr
PbDisplayPort In
1
8 10 11 12 13 14 15 167 9
23 4 5 6
20-06-151 933CBD.indb 320-06-151 933CBD.indb 3 10/13/2020 1:21:53 PM10/13/2020 1:21:53 PM

4
Installation
Note: Before installation, please make sure all devices you wish to connect are
powered off.
1. Connect all multi-format source devices to their respective ports (cables
sold separately).
Note: Make sure to connect the audio input for the analog video source.
2. Connect an HDMI-compliant display to the unit with user-supplied cables.
3. Connect speakers, amplifiers or sound bars to either the Toslink or coaxial
digital or R & L analog audio output ports.
4. (Optional) If using the remote control at a distance of more than 10 ft.
(3 m), attach the included IR Receiver Head Cable for increased range.
5. (Optional) Connect a USB peripheral to the available USB-A port on the
front of the unit.
6. Plug in the power adapter and turn on the unit using the Power button.
USB Device
Amplifier Out
5V Power Adapter
HDMI Display
4K/60Hz
DisplayPort Source
HDMI Source 1
YPbPr Source
HDMI Source 2 AV Source
HDMI Source 3 Amplifier In
VGA
Source
20-06-151 933CBD.indb 420-06-151 933CBD.indb 4 10/13/2020 1:21:53 PM10/13/2020 1:21:53 PM

5
IR Remote Control and Manual Front-Panel Pushbuttons
The B310-701-4K has two methods of control:
1. IR Remote Control
2. Manual Front-Panel Pushbuttons
Operation
There are seven manual pushbuttons on the unit (excluding the
power button).
Source: Input source selection menu/exit from current menu
This menu appears when the Source button is pressed. In this menu,
use the “Up” or “Down” arrows to select any input source, then press
the “OK” button.
20-06-151 933CBD.indb 520-06-151 933CBD.indb 5 10/13/2020 1:21:53 PM10/13/2020 1:21:53 PM

6
Operation
If there is no signal from the selected
source, the below message will display:
Up: Move up/Play button (when U-disk
is connected)
Down: Move down
Left: Move left (decrease)
Right: Move right (increase)
OK: Confirm current operation
Menu: Main OSD menu/Return to
previous menu screen
20-06-151 933CBD.indb 620-06-151 933CBD.indb 6 10/13/2020 1:21:53 PM10/13/2020 1:21:53 PM

7
Introduction of Menus
Press the “Menu” button to bring up the OSD menu. The functions in this
menu are used to adjust picture and sound settings.
Under the OSD Menu, there are three first-tier menus:
1. Picture
2. Sound
3. Option
20-06-151 933CBD.indb 720-06-151 933CBD.indb 7 10/13/2020 1:21:54 PM10/13/2020 1:21:54 PM

8
Introduction of Menus
Of the three menus, only the Picture menu will appear. To access the
Sound or Option menu, press the “Left” arrow button. Exit the OSD Menu
by pressing the “Source” button.
1. Picture Menu:
The Picture Menu has 5 sub-menus:
a. Picture Mode
b. Color Temperature
c. Aspect Ratio
d. OverScan
e. Screen
Select the desired sub-menu by pressing the “Up/Down” arrow buttons.
Invalid menu items will appear gray.
Note: The OverScan menu is only available when a VGA source is
connected. The Screen menu is not available for the VGA source.
Picture Mode:
The Picture Mode menu includes five options/settings:
i. Contrast
ii. Brightness
iii. Color
iv. Sharpness
v. Tint
The corresponding values can be adjusted by pressing the
“Left” or “Right” arrow button.
Note: Tint is only available to NTSC signal under AV.
20-06-151 933CBD.indb 820-06-151 933CBD.indb 8 10/13/2020 1:21:54 PM10/13/2020 1:21:54 PM

9
Picture Mode
20-06-151 933CBD.indb 920-06-151 933CBD.indb 9 10/13/2020 1:21:54 PM10/13/2020 1:21:54 PM

10
Color Temperature
The Color Temperature menu includes three options/settings:
I. Red
II. Green
III.Blue
The corresponding values can be adjusted by pressing the “Left” or “Right”
arrow button.
20-06-151 933CBD.indb 1020-06-151 933CBD.indb 10 10/13/2020 1:21:54 PM10/13/2020 1:21:54 PM
