Tripp Lite U444-06N-H4GUC2 User manual

1
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Owner’s Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
USB-C Multiport Hub Adapter
with 4K HDMI, USB-A and
Gigabit Ethernet Hub Ports,
100W PD 3.0 Charging, Black
Model: U444-06N-H4GUC2
USB Type-C™ and USB-C™ are trademarks of USB
Implementers Forum
Español 8 • Français 15 • Русский 22

2
• USB-C Multiport Hub Adapter, Black
• Owner’s Manual
• P568-Series High-Speed HDMI Cables
• U322-Series USB 3.0 A/B Cables
• U420-Series USB-C Cables
• N201-Series Cat6 Gigabit Snagless Patch Cables
Package Contents
Optional Accessories

3
Product Features
• Supports USB-C DisplayPort 1.4 Alternate Mode for
connecting a 4K HDMI display via a USB-C port
• Supports Ultra High Definition (UHD) resolutions up
to 3840 x 2160 @ 60 Hz (4:4:4) when plugged
into a DP 1.4 host
• Supports UHD resolutions up to 3840 x 2160 @
30 Hz when plugged into a DP 1.2 host
• Supports High Dynamic Range (HDR) for richer
contrast and expanded color accuracy
• RJ45 port supports true 10/100/1000 Mbps
Gigabit Ethernet network speeds
• USB-A port supports USB 3.1 Gen 1 data transfer
speeds up to 5 Gbps and charging up to
7.5W (5V 1.5A)
• USB-C port supports USB 3.1 Gen 1 data transfer
speeds up to 5 Gbps and 100W PD 3.0 charging
• Supports HDCP 2.2 and is backward compatible
with previous generations
• Plug-and-play operation with no software or external
power required

4
Installation
Note: When the hub is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a network
connection will be automatically established. If no connection
is made, you can manually establish one by going to your
computer’s network settings page. For example, on a Mac™,
you would navigate to the Network section found in System
Preferences, click “Assist Me” to get to the Network Setup
Assistant, then follow the prompts to establish a connection.
1. Connect the built-in USB-C cable to the USB-C
Thunderbolt™ 3 port on your laptop, tablet or other
compatible device.
2. Connect the HDMI port to your display with a
user-supplied HDMI cable.
3. Connect a USB peripheral, such as a thumb drive
or MP3 player, to the USB-A port.
4. Connect the RJ45 port to a Gigabit Ethernet
network with a user-supplied UTP cable.
5. Connect a USB-C device to the Power Delivery
port with a user-supplied USB-C cable. You can
also charge the host device by connecting its wall
charger to this port.

5
Input Connector
USB USB-C (Male)
Output Connectors
4K Video HDMI (Female)
Ethernet RJ45 (Female)
USB 3.1 Gen 1
(5 Gbps)
USB-A (Female),
USB-C (Female)
Display
HDMI
(with DP 1.4 Host)
3840 x 2160 (4K x 2K) @
60 Hz
HDMI
(with DP 1.2 Host)
3840 x 2160 (4K x 2K) @
30 Hz
Network
Ethernet 10/100/1000 Mbps
(1 Gbps)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Storage Temperature 14° to 158°F (-10° to 70°C)
Relative Humidity 10% to 90% RH
Power Requirements
USB-C Power
Delivery Port
PD 3.0 Charging up to
100W (20V 5A)
USB-A Port Supports Charging up to
7.5W (5V 1.5A)
Specifications

6
Warranty and
Product Registration
3-Year Limited Warranty
Seller warrants this product, if used in accordance with
all applicable instructions, to be free from original defects
in material and workmanship for a period of 3 years
from the date of initial purchase. If the product should
prove defective in material or workmanship within that
period, Seller will repair or replace the product, at its sole
discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR
OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE,
ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS
WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY
SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED
BY APPLICABLE LAW, ALL IMPLIED WARRANTIES,
INCLUDING ALL WARRANTIES OF MERCHANTABILITY
OR FITNESS, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD SET FORTH ABOVE; AND THIS
WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL
AND CONSEQUENTIAL DAMAGES. (Some states do not
allow limitations on how long an implied warranty lasts,
and some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may have
other rights which vary from jurisdiction to jurisdiction.)

7
Warranty and
Product Registration
WARNING: The individual user should take care to
determine prior to use whether this device is suitable,
adequate or safe for the use intended. Since individual
applications are subject to great variation, the
manufacturer makes no representation or warranty as to
the suitability or fitness of these devices for any specific
application.
Product Registration
Visit tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions
apply. See website for details.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
Photos and illustrations may differ slightly from actual
products.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
20-05-246 93-3CAD_RevA

8
1111 W. 35th Street, Chicago, IL 60609, EE UU
tripplite.com/support
Copyright © 2020 Tripp Lite. Todos los derechos reservados.
Manual del Propietario
Adaptador de Hub Multipuerto
USB-C con Puertos de Hub
4K HDMI, USB-A y Gigabit
Ethernet, Carga PD 3.0 de
100W, Negro
Modelo: U444-06N-H4GUC2
USB Tipo C™ y USB C™ son marcas comerciales registradas
del USB Implementers Forum
English 1 • Français 15 • Русский 22

9
• Adaptador de Hub Multipuerto USB-C, Negro
• Manual del Propietario
• Cables HDMI de Alta Velocidad Serie P568
• Cables USB 3.0 A/B Serie U322
• Cables USB C de la Serie U420
• Cables Patch Snagless Cat6 Gigabit Serie N201
Contenido del Empaque
Accesorios Opcionales

10
Características del Producto
• Soporta USB-C DisplayPort 1.4 de Modo Alterno
para conectar una pantalla 4K HDMI mediante un
puerto USB-C
• Soporta resoluciones de Ultra Alta Definición (UHD)
hasta 3840 x 2160 @ 60 Hz (4:4:4) cuando se
enchufa en un host DP 1.4
• Soporta resoluciones de UHD de hasta 3840 x
2160 @ 30 Hz cuando se enchufa en un host DP
1.2
• Soporta Alto Rango Dinámico [HDR] para contraste
más rico y precisión de color expandida
• El puerto RJ45 soporta velocidades reales de red
Gigabit Ethernet de 10/100/1000 Mbps
• El puerto USB-A soporta velocidades de
transferencia de datos USB 3.1 Gen 1 de hasta 5
Gbps y carga de hasta
7.5W (5V 1.5A)
• El puerto USB-C soporta velocidades de
transferencia de datos USB 3.1 Gen 1 de hasta to
5 Gbps y 100W de carga PD 3.0
• Soporta HDCP 2.2 y es compatible con
generaciones anteriores
• Operación de conectar y usar sin necesidad de
software o alimentación externa
