PROFESSIONAL MOVING HEAD USER’S MANUAL

V 1200

KEEPTHIS MANUALFOR FUTURE NEEDS

For your own safety, please read this user manual carefully before installing the device.

Keepthisdeviceawayfromrainandmoisture!

Unplugmainsleadbeforeopeningthehousing.

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow carefully the instructions of this manual

INTRODUCTION:

Thank you for having chosen this professional moving head.

You will see you have acquired a powerful and versatile device.

Unpack the device. Inside the box you should find: the fixture device, a power cable, an

XLR connection cable, a safety cable and this manual. Please check carefully that there is no damage

caused by transportation. Should there be any, consult your dealer and don’t install this device.

Features

• pan 540°, tilt 265°

• colors :

• color wheel1 with 4 dichroic glass panes, 2 correction-filter + 1 UV-filter

• color wheel2 with 6 dichroic glass panes, for a total of 7 colors

• static gobo wheel has 5 static gobos plus open with different speed gobo shaking

• rotating gobo wheel has 5 rotating gobos plus open, all gobos can be easily replaceable and gobo

indexing

• strobe effect : 0~13 flashes per second or random strobe

• Stepless Zoom

• automatic program

• display : digital address and function setting

• High speed pan & tilt movements

•Control board with 4-digit display and foil-keyboard for adjusting the DMX-starting address,

Pan/tilt-Reverse, Program, Reset, lamp on/off, operating hours and etc

• digital display can be turn 180° reverse to fit for different installation position local or remote

resetting

•lamp switches ON/OFF locally

•auto test for all functions

•value of each DMX-channel can be displayed

- １- GS-SMS-Y1200-V1.0-02NR

• Editable program :

edit and save the program to the incorporated EEPROM through the front control panel or external

controller; can save maximum 48 scenes, and run the saved program by the “run” menu from the

front control panel

SAFETY INSTRUCTIONS

CAUTION

Be very careful during installation. Since you will be working with a dangerous

voltage you can suffer a life-threatening electric shock when touching live wires.

This device has left the factory in perfect condition. In order to maintain this condition and to ensure

a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning

notes written in this user manual.

IMPORTANT

Damages caused by the disregard of this user manual are not subject to warranty.

The dealer will not accept liability for any resulting defects or problems.

If the device has been exposed to temperature changes due to environmental changes, do not switch

it on immediately. The arising condensation could damage the device. Leave the device switched off

until it has reached room temperature.

This device falls under protection-class I. Therefore it is essential that the device be earthed.

The electric connection must carry out by qualified person.

Make sure that the available voltage is not higher than stated at the end of this manual.

Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case,

replacement of the cable must be done by an authorized dealer.

Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle

the power cord by the plug. Never pull out the plug by tugging the power cord.

During initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective, it should decrease gradually.

- ２- GS-SMS-Y1200-V1.0-02NR

CAUTION

Never touch the device during operation!

The housing may heat up

CAUTION

Never look directly into the light source,

as sensitive persons may suffer an epileptic shock.

Please be aware that damages caused by manual modifications to the device are not subject to

warranty. Keep away from children and non-professionals.

GENERAL GUIDELINES

This device is a lighting effect for professional use on stages, in discotheques, theatres, etc.

This fixture is only allowed to be operated with the max alternating current which stated in the

technical specifications in the last page of this manual, the device was designed for indoor use only.

Lighting effects are not designed for permanent operation. Consistent operation breaks may ensure

that the device will serve you for a long time without defects. Do not shake the device.

Avoid brute force when installing or operating the device.

While choosing the installation-spot, please make sure that the device is not exposed to extreme heat,

moisture or dust. The minimum distance between light-output from the

projector and the illuminated surface must be more than 0,5 meter.

Always fix the fixture with an appropriate safety cable if you use the clamp to hang up the fixture.

When fixing the device on a raised-from-the- ground support, be sure to use no less than screws and

nuts of M10 x 25 mm and insert them in the pre-arranged screw holes in the base of the fixture.

If you use the quick lock cam in hanging up the fixture, please make sure the 4 quick lock fasteners

turned in the quick lock holes correctly.

Operate the device only after having familiarized with its functions. Do not permit operation by

persons not qualified for operating the device. Most damages are the result of unprofessional

operation.

Please use the original packaging if the device is to be transported.

- ３- GS-SMS-Y1200-V1.0-02NR

For safety reasons, please be aware that all modifications on the device are forbidden.

If this device will be operated in any way different to the one described in this manual, the product

may suffer damages and the guarantee becomes void. Furthermore, any other operation may lead to

short-circuit, burns, electric shock, lamp explosion, crash, etc.

INSTALLATION INSTRUCTIONS

a) Installing or replacing the lamp

h a higher wattage. They generate higher temperatures than which the device was designed for.

For the installation, you need one

MSR 1200 SA GY 22 lamp ;

Procedure :

1) Unscrew the 4 screws marked Y, X, W and Z on the back of the housing, holding the plate where

the lamp is underneath.

2) Gently pull the socket holder of the lamp housing in the middle.

3) Carefully insert the lamp into the socket. Please remember there is only one way to insert the lamp.

Gently slide the lamp and its lamp holder back into place and fasten the 4 screws.

4) On the access plate there are 3 small screws marked A, B and C. which are used to adjust the lamp

holder in the lamp housing. You can adjust the 3 screws to fine-turn the position of the lamp to get

the maximum light output as shown below.

BCA

Please remember the lamp is not a hot-restrike type, you must wait for approximately 10

minutes after having turned off the lamp before you can turn it back on again.

CAUTION

Do not operate this device with open cover

b) Mounting the device

- ４- GS-SMS-Y1200-V1.0-02NR

CAUTION

Please consider the EN 60598-2-17 and the other respective national norms during the

installation. The installation must only be carried out by a qualified person.

The installation of the effect has to be built and constructed in a way that it can hold 10 times the

weight for 1 hour without any harming deformation.

The installation must always be secured with a secondary safety attachment, e.g. an appropriate

safety cable.

Never stand directly below the device when mounting, removing or servicing the fixture.

The operator has to make sure the safety relating and machine technical installations are approved by

an expert before taking the device into operation for the first time.

These installations have to be approved by a skilled person once a year.

CAUTION

Before taking into operation for the first time,

the installation has to be approved by an expert.

Cautions:

The effect should be installed outside areas where persons may reach it, walk by or be seated.

CAUTION

When installing the device, make sure there is no highly

inflammable material within a distance of min. 0,5m

Overhead mounting requires extensive experience, including amongst others calculating

working load limits, installation material being used, and periodic safety inspection of all

installation material and the device. If you lack these qualifications, do not attempt the

installation yourself. Improper installation can result in bodily injury.

CAUTION

The electric connection must only be carried out by a qualified electrician.

Before mounting make sure that the installation area can hold a minimum point load of 10 times the

- ５- GS-SMS-Y1200-V1.0-02NR

device’s weight.

Connect the fixture to the mains with the power plug.

installation via the Omega holders

Screw one clamp each via a M12 screw and nut onto the Omega holders.

Insert the quick-lock fasteners of the first Omega holder into the respective holes on the

bottom of the device. Tighten the quick-lock fasteners fully clockwise. Install the second

Omega holder.

Pull the safety-rope through the holes on the bottom of the base and over the trussing

system or a safe fixation spot. Insert the end in the carabine and tighten the safety screw.

- ６- GS-SMS-Y1200-V1.0-02NR

DMX-512 control connection

Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other

side to the male 3-pin XLR input of the moving head. You can chain multiple

Moving head together through serial linking. The cable needed should be two core, screened cable

with XLR input and output connectors. Please refer to the diagram below.

DMX-512 connection with DMX terminator

For installations where the DMX cable has to run a long distance or is in an electrically noisy

environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in

preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply

an XLR plug with a 120 Ωresistor connected between pins 2 and 3,which is then plugged into the

output XLR socket of the last fixture in the chain. Please see illustrations below.

Address39 Address20 Address1

Projector DMX start address selection

All fixtures should be given a DMX starting address when using a DMX signal, so that the correct

fixture responds to the correct control signals. This digital starting address is the channel number

from which the fixture starts to “listen” to the digital control information sent out from the DMX

controller. The allocation of this starting address is achieved by setting the correct number on the

display located on the base of the device.

- ７- GS-SMS-Y1200-V1.0-02NR

You can set the same starting address for all fixtures or a group of fixtures , or make different

address for each fixture individually.

If you set the same address, all the units will start to “listen” to the same control signal from the same

channel number. In other words, changing the settings of one channel will affect all the fixtures

simultaneously.

If you set a different address, each unit will start to “listen” to the channel number you have set,

based on the quantity of control channels of the unit. That means changing the settings of one

channel will affect only the selected fixture.

In the case of the spot head, which is a 10 channel fixture, you should set the starting address of the

first unit to 1, the second unit to 20 (19 + 1), the third to 39 (20 + 19), and so on.

Note:

After switching on, the machine will automatically detect whether DMX 512 data is received or not. If the data is

received, the display will show "A.001" with the actually set address. If there is no data received at the DMX-input,

the display flashes "A001" with the actually set address. This situation can occur if:

- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the machine.

- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap in the

input connector.

Control Board

The Control Board offers several features: you can simply set the starting address, switch on and off the lamp, run

the pre-programmed program or make a reset.

The main menu is accessed by pressing the Mode/esc-button until the display starts flashing . Browse through the

menu by pressing the Up-button. Press the Enter-button in order to select the desired menu. You can change the

selection by pressing the Up-button. Confirm every selection by pressing the Enter-button. You can leave every

mode by pressing the Mode/esc-button . The functions provided are described in the following sections.

- ８- GS-SMS-Y1200-V1.0-02NR

Set DMX address DMX setting

Value display DMX value display

Set to Slave Set to slave

Auto program Auto program

Function

Mode

Music control Music control

Power on time XXXX Individual fixture running

time

Machine on time XXXX Fixture running time

Lamp on time XXXX Lamp running time

Lamp off time XXXX Lamp closed time

Time information

Clear Lamp time (“Please wait……”) Clear lamp time

System Temp XX ℃Ambient timeTemp. Info.

Near lamp Temp XXX℃Temp in lamp chamber

Unit model

Unit code

Company WEB

Product Info.

Company Tel

Unit model

Unit code

Company WEB

Company Tel

Informat

ion

Software version IC01-Ver1.0 …..

ICXX-Ver9.9

Software version of each IC

Reverse movement

Effect Set

Pan Reverse

Tilt Reverse

Blackout moving

Blackout colors

Blackout Gobos

ON/OFF

Scan fine select ON/OFF

Blackout while pan/tilt

moving or color/gobo wheel

moving

Status choose Addr. via DMX

Master or Alone

Auto if no DMX

Music if no DMX

ON/OFF

Master/Alone

ON/OFF

Add. resetable via DMX

Master/ Alnow switch

Auto run if no DMX

Music control if no DMX

Lamp control Lamp on or off

Lamp on by power on

Lamp on via DMX

Lamp off via DMX

Lamp off if no DMX

Lamp ignited temp.

Max lamp off temp.

ON/OFF

Lamp on/off

Lamp on with power on

Lamp on via DMX

Lamp off via DMX

Lamp off if no DMX

Max. lamp on temp.

Max lamp off temp.

Display set Display close time

Display intensity

05 M

20~99%

Display close time

LCD brightness

Personali

Init effect PAN Moving

Save and Active

PAN Moving=XXX

(“Please wait……”)

Initial effect position

- ９- GS-SMS-Y1200-V1.0-02NR

Mic sensitivity 0~99% Sensitivity of Mic.

Reset default ON/OFF Restore factory settings

Reset

function

Reset All

Reset Scan

Reset Colors

Reset Gobos

Reset Shutter

Reset Others

Reset all motors &return to home

Reset only motors for pan/tilt

Reset only motors for colors

Reset only motors for gobo

Reset only motors for shutter

and/or dimmer

Reset other motors

Test channel PAN Moving …… Automatically test the function

Lamp adjustment PAN Moving

Save Active

PAN Moving=XXX

(“Please wait……”)

Lamp adjustment

Effect

Adjust

Wheel adjustment Color wheel

Save and Active

Color wheel=XXX

(“Please wait……”)

Wheel adjustment

User mode User A seetings

User B settings

User C settings

User’s mode

Users

Mode

Set

Preset User mode PAN

Save and Active

PAN = CH NO.01

(“Please wait……”)

Preset User modes

Select Programs Program 1

Program 10

Select programs to be run

Edit program Program 1

Program 10

Program Test

Start step

End step

(“STEP

XX”)

Start

step=xxx

Testing program

Program in loop

End

step=xxx

Save and exit

Edit scenes Edit Scene 001

~ Edit Scene 250

Input by outside

Save and Active

Secne Time

,Pan,Tilt,……

TIME=X

X.XS

Pan=xxx,

Save and automatically return

manual scenes edit

Edit

Program

Auto scenes Rec. XX~XX Automated recording scenes

INSTRUCTIONS ON USE:

DMX channel´s functions and their values (19 DMX channels):

Channel 1 - Color Wheel 1:

0-13 Open / white

14-27 Light blue

28-41 Salmon pink

42-55 Blue

- １０ - GS-SMS-Y1200-V1.0-02NR

56-69 Yellow Green

70-83 Light Yellow

84-97 Magenta

98-111 Orange

112-127 Purple

128-187 Forwards rainbow effect from fast to slow

188-193 No rotation

194-255 Backwards rainbow effect from slow to fast

Channel 2 - Rotating gobos, cont. rotation :

0-14 Open

15-29 Rot. gobo 1

30-44 Rot. gobo 2

45-59 Rot. gobo 3

60-74 Rot. gobo 4

75-106 Gobo 1 shake slow to fast

107-138 Gobo 2 shake slow to fast

139-170 Gobo 3 shake slow to fast

171-202 Gobo 4 shake slow to fast

203-255 Rot. gobo wheel cont. rotation slow to fast

Channel 3 - Rotating gobo index, rotating gobo rotation :

0-127 Gobo indexing

128-187 Forwards gobo rotation from fast to slow

188-193 No rotation

194-255 Backwards gobo rotation from slow to fast

Channel 4 - Fixed Gobos :

0-14 Open

15-29 Fix gobo 1

30-44 Fix gobo 2

45-59 Fix gobo 3

60-74 Fix gobo 4

75-89 Fix gobo 5

90-113 Gobo 1 shake slow to fast

114-137 Gobo 2 shake slow to fast

138-161 Gobo 3 shake slow to fast

162-185 Gobo 4 shake slow to fast

186-209 Gobo 5 shake slow to fast

210-255 Fix gobo wheel cont. rotation slow to fast

- １１ - GS-SMS-Y1200-V1.0-02NR

Channel 5 - PAN movement 8bit :

Channel 6 - TILT movement 8bit :

Channel 7 - Speed pan/tilt movement:

0-14 max speed

15-225 max to min speed

226-235 blackout by movement

236-245 blackout by all wheel changing

246-255 no function

Channel 8 - prism/prisms macros:

0-25 open

26-51 3 facet prism

52-77 5 facet prism

78-103 7 facet prism

104-127 trapezoid prism

128-135 Macro 1

136-143 Macro 2

144-151 Macro 3

152-159 Macro 4

160-167 Macro 5

168-175 Macro 6

176-183 Macro 7

184-191 Macro 8

192-199 Macro 9

200-207 Macro 10

208-215 Macro 11

216-223 Macro 12

224-231 Macro 13

232-239 Macro 14

240-247 Macro 15

248-255 Macro 16

Channel 9 - Rotating prism index, rotating prism rotation :

0-127 Prism indexing

128-187 Forwards Prism rotation from fast to slow

188-193 No rotation

194-255 Backwards Prism rotation from slow to fast

Channel 10 - Shutter, strobe:

0-31 Shutter closed

32-63 Dimmer control (shutter open)

- １２ - GS-SMS-Y1200-V1.0-02NR

64-95 Strobe effect slow to fast

96-127 No function (shutter open)

128-159 Pulse-effect in sequences

160-191 No function (shutter open)

192-223 Random strobe effect slow to fast

224-255 No function (shutter open)

Channel 11 - Dimmer (intensity):

0-255 Intensity 0-100%

Channel 12 – Focus:

0-255 Continuous adjustment from far to near

Channel 13- Zoom:

0-63 Zoom 1

64-127 Zoom 2

128-191 Zoom 3

192-255 Zoom 4

Channel 14 – Iris:

0-191 Max. diameter to Min.diameter

192-223 Pulse closing fast to slow

224-255 Pulse opening slow to fast

Channel 15 - Color Wheel 2 :

0-13 Open / white

14-27 Red

28-41 Light blue

42-55 Pink

56-69 Dark Yellow

70-83 3200K correction filters

84-97 5600K correction filters

98-111 UV-filter

112-127 Green

128-187 Forwards rainbow effect from fast to slow

188-193 No rotation

194-255 Backwards rainbow effect from slow to fast

Channel 16 –Frost

0-191 Frost 0~100%

192-223 Pulse opening fast to slow

224-255 Pulse closing slow to fast

- １３ - GS-SMS-Y1200-V1.0-02NR

Channel 17 – Lamp on/off, reset, internal programs:

0-19 colour change normal by direction depend on distance

20-39 colour change to any position by direction depend on distance

40-59 Lamp on

60-79 Lamp switch off

80-99 Motor reset

100-119 Internal program 1

120-139 Internal program 2

140-159 Internal program 3

160-179 Internal program 4

180-199 Internal program 5

200-219 Internal program 6

220-239 Internal program 7

240-255 Internal program 8

Channel 18 – Pan fine 16bit

Channel 19 – Tilt fine 16bit

ERROR MESSAGE

When you turn on the fixture, it will make a reset first. The display may show “XXer” while there are problems

with one or more channels. “XX” stands for channel 1,2,3,5,6,7 who has the testing sensor for positioning .

For example, when the display shows “02Er”, it means there is some error in channel 2. If there are some errors on

channel 1, channel 2, channel 5 at the same time, you may see the error message “01Er”, “02Er”,”05Er” flash

repeated for 5 times, and then the fixture will generate a reset signal, all the stepper reset. If the fixture remain error

message after performing reset more than 3 times, it will detect whether the fixture has more than 3 errors. If the

fixture has more than 3 errors (including 3 errors), all the channels can not work properly; but if the fixture has less

than 3 errors, only the channels which have errors can not work properly, others can work as usual.

01Er:

(Color-wheel1 error) This message will appear after the reset of the fixture if the magnetic-indexing circuit

malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its drive circuit on the main

PCB). The color wheel is not located in the default position after the reset.

02Er:

(Rotating gobo-wheel error ) This message will appear after the reset of the fixture if the magnetic-indexing circuit

malfunctions(sensor failed or magnet missing) or the stepping-motor is defective (or its drive circuit on the main

PCB). The rotating gobo-wheel is not located in the default position after the reset.

03Er

(Rotating gobo indexing error) This message will appear after the reset of the fixture and if the magnetic-indexing

circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the

main PCB). The rotating gobo is not located in the default position after the reset.

04Er

(Static gobo-wheel error) This message will appear after the reset of the fixture if the yoke’s magnetic-indexing

- １４ - GS-SMS-Y1200-V1.0-02NR

circuit malfunction (sensor failed or magnet missing) or the stepping-motor is defective ( or its driving IC on the

main PCB). The Static gobo-wheel error is not located in the default position after the reset.

05Er

(PAN-yoke movement error) This message will appear after the reset of the fixture if the yoke’s magnetic-indexing

circuit malfunction (sensor failed or magnet missing) or the stepping-motor is defective ( or its driving IC on the

main PCB). The PAN-yoke is not located in the default position after the reset.

06Er:

(TILT-head movement error) This message will appear after the reset of the fixture if the head’s magnetic-indexing

circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driving IC on the

main PCB). The TILT-head is not located in the default position after the reset.

08Er

(Prism-wheel error) This message will appear after the reset of the fixture if the yoke’s magnetic-indexing circuit
