Triton Blue WALLYOK12Z User manual

PROFESSIONAL MOVING HEAD USER MANUAL
WALLYOK12Z
KEEP THIS MANUAL FOR FUTURE NEEDS

XM1115-V1.0.0-NR
1
Contents
1. Features............................................................................................................................................................2
2. Fixture Overview.............................................................................................................................................3
3. SAFETY INSTRUCTIONS............................................................................................................................3
3.1) Important safety warns........................................................................................................................3
3.2) GENERAL GUIDELINES..................................................................................................................4
4. INSTALLATION INSTRUCTIONS..............................................................................................................5
4.1) Mounting the device.............................................................................................................................5
5. DMX-512 control connection.......................................................................................................................... 8
6. DMX-512 connection with DMX terminator ................................................................................................9
7. Projector DMX start address selection..........................................................................................................9
8. Control Board................................................................................................................................................10
8.1 FUNCTION.......................................................................................................................................... 11
8.1.1 Set DMX Address...................................................................................................................... 11
8.1.2 Dmx Value .................................................................................................................................12
8.1.3 Slave Mode................................................................................................................................12
8.1.4 Auto Program............................................................................................................................12
8.1.5 Sound Control........................................................................................................................... 12
8.2 Information...........................................................................................................................................12
8.2.1 Time information......................................................................................................................12
8.2.2 Temperature.Info......................................................................................................................14
8.2.3 Software Ver.............................................................................................................................. 14
8.3 PERSONALITY....................................................................................................................................14
8.3.1 Status Settings...........................................................................................................................14
8.3.2 Service Setting...........................................................................................................................16
8.3.3 Fans Control..............................................................................................................................17
8.3.4 Display Setting ..........................................................................................................................17
8.3.5 Temperature C/F.......................................................................................................................18
8.3.6 Initial Status ..............................................................................................................................18
8.3.7 Dimmer Modes..........................................................................................................................18
8.3.8 Reset Default.............................................................................................................................18
8.4 Reset Function...................................................................................................................................... 19
8.5 Effect Adjust..........................................................................................................................................19
8.5.1 Test Channel..............................................................................................................................19
8.5.2 Manual Control.........................................................................................................................19
8.5.3 Calibration ................................................................................................................................19
8.6 Users mode set ......................................................................................................................................19
8.6.1 User mode..................................................................................................................................20
8.6.2 Edit User Mode.........................................................................................................................20
8.7 Edit Prg................................................................................................................................................. 20
8.7.1 Select Programs ........................................................................................................................20
8.7.2 Edit Program.............................................................................................................................20
8.7.3 Edit Scenes ................................................................................................................................20
8.7.4 Rec. Controller..........................................................................................................................20
9. INSTRUCTIONS ON USE:..........................................................................................................................22
10. ERROR MESSAGE.................................................................................................................................... 25
11. CLEANINGAND MAINTENANCE.........................................................................................................25
12. TECHNICAL SPECIFICATIONS............................................................................................................. 26

XM1115-V1.0.0-NR
2
Thank you for your patronage. We are confident that our excellent products and service can
satisfy you. For your own safety, please read this user manual carefully before installing the
device.
In order to install , operate, and maintain the lighting safety and correctly. We suggest that the
installation and operation should be done by the verified technician and follow the instruction
strictly.
Every person involved with the installation, operation and maintenance of this device has to:
-be qualified
-follow carefully the instructions of this manual
INTRODUCTION:
Thank you for having chosen this professional moving head.
You will see you have acquired a powerful and versatile device.
Unpack the device. Inside the box you should find:
1. One XLR connection cable
2. Two omega clamps
3. One safety rope
4. Manual
Please check carefully that there is no damage caused by transportation. Should there be any,
consult your dealer and don’t install this device.
1. Features
·12 x 10W high power LEDs
·Extremely Long Life:100,000 Hr and low power consumption
·3 DMX channel mode: 20/17/24 channels
·Pan/tilt movement: 8 bit and 16 bit resolution
Forsmoothandpreciseresolution
Pan: 540°/630° optional, Tilt: 265°movement
High speed of pan/tilt movement, speed of pan/tilt movement is adjustable
Scan position memory, auto reposition after unexpected movement
·Strobe effect with 18 flashes per second and pulse effect
·General dimming and blackout for all four colors
·Excellent color mixing and rainbow effect
·Control board with full color LCD graphic display and touch-keyboard
·Dimmer intensity from 0%~100%
·Display: Can be changed 180° reverse to fit for different installation position.
·Rechargeable Back up Battrty for Display
·Preset program: 7 built in programs can be called up via DMX controller
·Software-upload by optional accessory via DMX line

XM1115-V1.0.0-NR
3
2. Fixture Overview
3. SAFETY INSTRUCTIONS
3.1) Important safety warns
This device has left the factory in perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and
warning notes written in this user manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The
dealer will not accept liability for any resulting defects or problems.
If the device has been exposed to temperature changes due to environmental changes, do not
switch it on immediately. The arising condensation could damage the device. Leave the device
switched off until it has reached room temperature.
1: Leds
2: DC Switch- button
3: Microphone
4: Display
5: Mode/Esc-button
6: ENTER-button
7: Left-button
8: Down-button
9: Up-button
10: Right-button
11: Handle
12: Power switch
13: Fuse
14: Power In
15: Power Out
16: 3-Pin DMX Out
17: 3-Pin DMX In

XM1115-V1.0.0-NR
4
This device falls under protection-class I. Therefore it is essential that the device be earthed.
If protection screen,lens or ultraviolet screen in the fixture is apparently damaged or is damaged
to exceed their own effective degree, such as cracked and gashed, it must be replaced.
The electric connection must carry out by qualified person.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case,
replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only
handle the power cord by the plug. Never pull out the plug by tugging the power cord.
During initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced
by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
Please be aware that damages caused by manual modifications to the device are not subject
to warranty. Keep away from children and non-professionals.
3.2) GENERAL GUIDELINES
This device is a lighting effect for professional use on stages, in discotheques, theatres, etc., the
device was designed for indoor use only.
This fixture is only allowed to be operated with the max alternating current which stated in the
technical specifications in the last page of this manual.
Lighting effects are not designed for permanent operation. Consistent operation breaks may
ensure that the device will serve you for a long time without defects.
Do not shake the device.Avoid brute force when installing or operating the device.
While choosing the installation-spot, please make sure that the device is not exposed to extreme
heat, moisture or dust. Please don't project the beam onto combustible substances.The minimum
distance between light-output from the projector and the illuminated surface must be more than
0.5 meter.
If you use the quick lock cam in hanging up the fixture, please make sure the quick lock fasteners
turned in the quick lock holes correctly.

XM1115-V1.0.0-NR
5
Operate the device only after having familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional
operation.
Please use the original packaging if the device is to be transported.
For safety reasons, please be aware that all modifications on the device are forbidden.
If this device will be operated in any way different to the one described in this manual, the
product may suffer damages and the guarantee becomes void. Furthermore, any other operation
may lead to short-circuit, burns, electric shock, lamp explosion, crash, etc.
4. INSTALLATION INSTRUCTIONS
Do not operate this device with open cover
4.1) Mounting the device
The applicable temperature for the lighting is between -10°C to 45°C. Do not use the lighting
under or above the temperature.
The installation of the effect has to be built and constructed in a way that it can hold 10 times the
weight for 1 hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety rope.
Never stand directly below the device when mounting, removing or servicing the fixture.
The operator has to make sure the safety relating and machine technical installations are approved
by an expert before taking the device into operation for the first time.
These installations have to be approved by a skilled person once a year.
Overhead mounting requires extensive experience, including amongst others calculating
working load limits, installation material being used, and periodic safety inspection of all
installation material and the device. If you lack these qualifications, do not attempt the
installation yourself. Improper installation can result in bodily injury.
The electric connection must only be carried out by a qualified electrician.
Before mounting make sure that the installation area can hold a minimum point load of 10 times the device’s
weight.
Connect the fixture to the mains with the power plug.

XM1115-V1.0.0-NR
6
Installation via the Omega holders
a) Fixed the clamp on the bracket by tighten up the M12 screw on the bracket to the Ф13 hole in
the middle of the bracket.
b) Insert the quick-lock fasteners of the first Omega holder into the respective holes on the
bottom of the device. Tighten the quick-lock fasteners fully clockwise.
c) Install the second Omega holder.
d) Pull the safety-rope through the holes on the bottom of the base and over the trussing system
or a safe fixation spot. Insert the end in the carabine and tighten the safety screw.
Notice: this step is quite important to ensure that the fixture will not drop out by the
damage of the clamp.

XM1115-V1.0.0-NR
7
Dimensional Drawings:

XM1115-V1.0.0-NR
8
Layout Drawings:
Mounting points
Be sure this fixture is kept at least 0.5m away from any flammable materials (decoration etc.).
Always use and install the supplied safety cable as a safety measure to prevent accidental damage
and/or injury in the event the clamp fails.
Overhead mounting requires extensive experience, including amongst others calculating working
load limits, a fine knowledge of the installation material being used, and periodic safety
inspection of all installation material and the fixture. If you lack these qualifications, do not
attempt the installation yourself. Improper installation can result in bodily injury.
5. DMX-512 control connection
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other
side to the male 3-pin XLR input of the moving head. You can chain multiple
Moving head together through serial linking. The cable needed should be two core, screened
cable with XLR input and output connectors. Please refer to the diagram below.

XM1115-V1.0.0-NR
9
Address41 Address21 Address1
6. DMX-512 connection with DMX terminator
For installations where the DMX cable has to run a long distance or is in an electrically noisy
environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in
preventing corruption of the digital control signal by electrical noise. The DMX terminator is
simply an XLR plug with a 120 Ωresistor connected between pins 2 and 3,which is then plugged
into the output XLR socket of the last fixture in the chain. Please see illustrations below.
7. Projector DMX start address selection
All fixtures should be given a DMX starting address when using a DMX signal, so that the
correct fixture responds to the correct control signals. This digital starting address is the channel
number from which the fixture starts to “listen” to the digital control information sent out from
the DMX controller. The allocation of this starting address is achieved by setting the correct
number on the display located on the base of the device.
You can set the same starting address for all fixtures or a group of fixtures, or make different
address for each fixture individually.
If you set the same address, all the units will start to “listen” to the same control signal from the
same channel number. In other words, changing the settings of one channel will affect all the
fixtures simultaneously.
If you set a different address, each unit will start to “listen” to the channel number you have set,
based on the quantity of control channels of the unit. That means changing the settings of one
channel will affect only the selected fixture.
In the case of the led move head, which is a 20 channel fixture, you should set the starting
address of the first unit to 1, the second unit to 21(20 + 1), the third unit to 41 (20+ 21), and so
on.

XM1115-V1.0.0-NR
10
8. Control Board
The Control Board offers several features: you can simply set the starting address , run the
pre-programmed program or make a reset.
The main menu is accessed by pressing the -button until the display starts flashing.
Browse through the menu by pressing the -button , -button , -button or
-button. Press the Enter-button in order to select the desired menu. You can change the
selection by pressing the the -button , -button , -button or -button.
Confirm every selection by pressing the -button. You can leave every mode by pressing the
-button. The functions provided are described in the following sections. it will exit from
flash 10 seconds after the last keypress. Press this key under edit mode, . The functions provided
are described in the following sections.
To access the display menu via the internal battery, press the DC switch button for 2seconds;
To shut off the display immediately, choose the commend " Reset All" menu and press
"Enter" button, otherwise, the display will automatically switch off about 1 minute from
last button press.
Function
Set Dmx Address
Dmx Value
Slave Mode
Auto Program
Sound Control
A001~AXXX
ALL……
Slave1,Slave2,Slave3
Master / Alone
Master / Alone
DMX address setting
DMX value display
Slave setting
Auto program
Music control
Time Information.
Current Time
Total Run TIme
Last Run Time
LastRun Password
Clean Last Run
XXXX(Hours)
XXXX(Hours)
XXXX(Hours)
Password=XXX
ON/OFF
Power on running time
Fixture running time
Fixture Last times clear
Timer Password 038
Clear Fixture Last time
Temperature. Info Head Temp. XXX /℃℉Temp. Info
Information
Software Ver V1.0.0…… Software version
Status Settings
Addr via DMX
No DMX Mode
Pan Reverse
Tilt Reverse
Pan Degree
Feedback
Movement Speed
Mic Sensitivity.
Hibernation
ON/OFF
Close/Hold/Auto/Music
ON/OFF
ON/OFF
630/540
ON/OFF
Speed 1~ 4
0~99%
OFF, 01M~99M，15M
Add. via DMX
Auto run if no DMX
Pan Reverse movement
Tilt Reverse movement
Pan Degree Select
Movement Feedback
Movement Mode Select
Sensitivity of Mic.
Stand by Mode
Service Setting Service Pass
RDM PID
Password=XXX
XXXXXX
Service Password“=050”
RDM PID Code
Personality
Fans Control
Auto
High
Low
Fans Speed select

XM1115-V1.0.0-NR
11
Display Setting
Shutoff Time
Display Reverse
Key Lock
Disp Flash
02~60m 05m
ON/OFF
ON/OFF
ON /OFF
Display shutoff time
Reverse 180 degree
Key Lock
Disp Flash
Temperature C/F Celsius
Fahrenheit
Temperature switch between
/℃℉
Initial Status PAN =XXX Initial effect position
Dimmer Modes
Standard
Stage
TV
Architectural
Theatre
Standard
Stage
TV
Architectural
Theatre
Reset Default ON/OFF Restore factory set.
Reset
Function
Reset ALL
Reset Pan^Tilt
Reset Zoom
Reset all motors
Reset Pan/Tilt
Reset Zoom
Test Channel AUTO …… Test function
Manual Control AUTO =XXX
: Fine adjustment of the lamp
Effect Adjust
Calibration
Calibrate Password
Color wheel=XXX
:
Password “050”
Calbrate and adjust the effects
to standard/right position
User Mode
Standard Mode
Basic Mode
Extended Mode
User Mode A
User Mode B
User Mode C
User’s mode to change
channel numbers
User Mode
Set
Edit User ModeA
Edit User ModeB
Edit User ModeC
Max Channel = XX
PAN = CH01
:
Preset User modes
Select Program
Prog. Part 1 = Program 1 ~ 10 Program 1
Prog. Part 2 = Program 1 ~ 10 Program 2
Prog. Part 3 = Program 1 ~ 10 Program 3
Select programs to be run
Edit Program
Program 1
:
Program 10
Program Test
Step 01=SCxxx
Step 64=SCxxx
Testing program
Program in loop
Save and exit
Edit Scenes
Edit Scene 001
~ Edit Scene
250
Pan,Tilt,……
--Fade Time--
--Scene Time--
Input By Out
Save and automatically return
manual scenes edit
Edit Prg
Rec Controler XX~XX Automat. scenes rec
Default settings shaded
8.1 FUNCTION
8.1.1 Set DMX Address
With this function, you can adjust the desired DMX-address via the Control Board.
1. Access the main menu.
2. Tap the <Up/Down>button until“Set DMX Address”is displayed.

XM1115-V1.0.0-NR
12
3. Press ENTER, the display will show “Set DMX Address”.
4. Tap the <Up/Down>button，the display will show “A001~AXXX”
5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu.
8.1.2 Dmx Value
With this function you can display the DMX 512 value of each channel. The display
automatically shows the channel with a value changing.
1. Access the main menu.
2. Tap the <Up/Down>button until“Dmx Value”is displayed.
3. Press ENTER, the display will show “Dmx Value”.
4. Tap the <Up/Down>button，choose each channel.
5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu.
8.1.3 Slave Mode
With this function, you can define the device as slave.
1. Access the main menu.
2. Tap the <Up/Down>button until“Slave Mode”is displayed.
3. Press ENTER, the display will show“Slave Mode”.
4. Tap the <Up/Down>button，the display will show “Slave1”, ”Slave2”, ”Slave3”.
5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu.
8.1.4 Auto Program
With this function, you can run the internal program. You can select the desired program under
“Select program”. You can set the number of steps under “Edit program”. You can edit the
individual scenes under “Edit scenes”. With this function, you can run the individual scenes
either automatically, i.e. with the adjusted Step-Time.
1. Access the main menu.
2. Tap the <Up/Down>button until“Auto Program”is displayed.
3. Press ENTER, the display will show“Auto Program”.
4. Tap the <Up/Down>button，the display will show “Master1”, ” Alone”.
5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu.
8.1.5 Sound Control
With this function, you can run the internal program sound-controlled.
1. Access the main menu.
2. Tap the <Up/Down>button until“Sound Control”is displayed.
3. Press <ENTER>, the display will show“Sound Control”.
4. Tap the <Up/Down>button，the display will show “Master1”, ” Alone”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.2 Information
8.2.1 Time information
Current Time
With this function, you can display the temporary running time of the device from the last
power on. The display shows “XXXX”, “XXXX” stands for the number of hours. The
counter is resetted after turning the device off.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until the display will show “Time Information”. Press ENTER,

XM1115-V1.0.0-NR
13
the display will show “Time Information”.
2. Press <Up/Down>, the display will show “Current Time”.
3. Press< ENTER>, the display will show“Current Time”.
4. The display will show “XXXX”(Hours) ；
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Total Run Time
With this function, you can display the running time of the device. The display shows
“XXXX”, “XXXX” stands for the number of hours.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until the display will show “Time Information”. Press ENTER,
the display will show “Time Information”.
2. Press <Up/Down>, the display will show “Total Run Time”.
3. Press< ENTER>, the display will show“Total Run Time”.
4. The display will show “XXXX”(Hours) ；
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Last Run Time
With this function, you can display last the running time of the lamp. The display shows
“XXXX”, “XXXX” stands for the number of hours
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until the display will show “Time Information”. Press ENTER,
the display will show “Time Information”.
2. Press <Up/Down>, the display will show “Last Run Time”.
3. Press< ENTER>, the display will show“Last Run Time”.
4. The display will show “XXXX”(Hours) ；
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
LastRun Password
With this function, you can display the timer password.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until the display will show “Time Information”. Press ENTER,
the display will show “Time Information”.
2. Press <Up/Down>, the display will show “LastRun Password”.
3. Press< ENTER>, the display will show“LastRun Password”. The time password is 038.
4. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Clean Last Run
With this function, you can clear last run time of the fixture. The display shows “ON” or
“OFF”, Press “Enter” to confirm.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until the display will show “Time Information”. Press ENTER,
the display will show “Time Information”.

XM1115-V1.0.0-NR
14
2. Press <Up/Down>, the display will show “Clean Last Run”.
3. At“L-Timer Password”menu input right password, Press< ENTER>, the display will
show “Clean Last Run”.
4. The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.2.2 Temperature.Info
Head Temp.
With this function you can display the temperature on the display board of the base (near
CMY-filter) in Celsius.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”. Tap
the <Up/Down>button until“Temperature.Info”is displayed. Press ENTER, the display
will show “Temperature.Info”.
2. Press <Up/Down>, the display will show “Head Temp.”.
3. Press< ENTER>, the display will show“Head Temp.”.
4. The display show “XXX °C/ °F”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.2.3 Software Ver
With this function, you can display the software version of the device.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Information”is displayed. Press ENTER, the display will show “Information”.
2. Press <Up/Down>, the display will show “Software Ver”.
3. Press< ENTER>, the display will show“Software Ver”.
4. The display show “Ver x.x”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3 PERSONALITY
8.3.1 Status Settings
Addr via DMX
With this function, you can adjust the desired DMX-address via an external controller.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show “Addr via DMX”.
3. Press< ENTER>, the display will show“Addr via DMX”.
4. The display show “ON”,Press <Up/Down>, the display will show “OFF”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
No DMX Mode
With this function, when the drive is not DMX signal, it runs automatism, close, hold and
music, the default is hold.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.

XM1115-V1.0.0-NR
15
2. Press <Up/Down>, the display will show “No DMX Mode”.
3. Press< ENTER>, the display will show“No DMX Mode”.
4. The display show “Hold”,Press <Up/Down>, the display will show “Close”, “Auto”,
“Music”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Pan Reverse
With this function you can reverse the Pan-movement.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show “Pan Reverse”.
3. Press< ENTER>, the display will show“Pan Reverse”.
4. The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Tilt Reverse
With this function you can reverse the Tilt-movement.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Tilt Reverse”.
3. Press< ENTER>, the display will show“Tilt Reverse”.
4. The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Pan Degree
With this function, you can select pan degree for 630 or 540.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Pan Degree”.
3. Press< ENTER>, the display will show“Pan Degree”.
4. The display show “540”,Press <Up/Down>, the display will show “630”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Feedback
With this function, you can feedback switch of pan movement or tilt movement.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Feedback”.
3. Press< ENTER>, the display will show“Feedback”.
4. The display show “ON”,Press <Up/Down>, the display will show “OFF”.

XM1115-V1.0.0-NR
16
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Movement Speed
With this function, you can select scan mode from 1 to 4.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Movement Speed”.
3. Press< ENTER>, the display will show“Movement Speed”.
4. The display show “Speed 1”,Press <Up/Down>, the display will show “Speed 2”,
“Speed 3”, “Speed 4”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Mic Sensitivity
With this function, the default is 70%, you can select the desired microphone sensitivity
from 0 % to 99 %.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Mic Sensitivity”.
3. Press< ENTER>, the display will show“Mic Sensitivity”.
4. The display show “70%”,Press <Up/Down>, the display will show “0~99%”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Hibernation ——Standby mode
The lamp and step motors will be power off if the fixture stay without DMX signal for 15
mins (Factory default).And the fixture will be reset before working once it receive DMX
signal again.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Status settings”. Press ENTER, the
display will show “Status settings”.
2. Press <Up/Down>, the display will show“Hibernation”.
3. Press< ENTER>, the display will show“Hibernation”.
4. The display show “15M”,Press <Up/Down>, the display will show “01M”，
“02M”…. “99M”or“OFF”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.2 Service Setting
Service Pass——The Password for this function is “50”.
RDM PID—— With this function you can call up various submenus via RDM.
This device is RDM ready. RDM stands for "remote device management" and makes
remote control of devices connected to the DMX-bus. ANSI E1.20-2006 by ESTA specifies
the RDM standard as an extension of the DMX512 protocol.

XM1115-V1.0.0-NR
17
Manual settings like adjusting the DMX starting address are no longer needed. This is
especially useful when the device is installed in a remote area.
RDM ready and conventional DMX devices can be operated in one DMX line. The RDM
protocol sends own packages in the DMX512 data feed and does not influence conventional
devices.
If DMX splitters are used and RDM control is to be used, these splitters must support RDM.
The number and type of RDM parameters depend on the RDM controller being used.
8.3.3 Fans Control
With this function, you can set the speed of the running fans. The selections have Auto、high and
low.
1. Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”.
2. Press <Up/Down>, the display will show“Fans Control”.
3. Press< ENTER>, the display will show“Fans Control”.
4. The display show “Auto”,Press <Up/Down>, the display will show “High”, “Low”.
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.4 Display Setting
Shut off time
With this function you can shut off the color LCD display after 2 to 59 minutes. Turn the
encoder in order to select the desired shut off time. The default is 5 minute.
Display Reverse
With this function you can the entire display to be flipped by 180˚to allow for better view
when the fixture is hung from truss or a ceiling. This function is disabled as default.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”. Tap
the <Up/Down>button until the display will show “Display Setting”. Press ENTER,
the display will show “Display Setting”.
2．Press <Up/Down>, the display will show“Display Reverse”.
3．Press< ENTER>, the display will show“Display Reverse”.
4．The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Key Lock
With this function you can activate the automatic keylock status. If this function is activated,
the keys will be locked automatically after exiting the edit mode for 15 seconds. keeping
press the [MENU] key for 3seconds if you do not need this function.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Display Setting”. Press ENTER, the
display will show “Display Setting”.
2．Press <Up/Down>, the display will show“Key Lock”.
3．Press< ENTER>, the display will show“Key Lock”.

XM1115-V1.0.0-NR
18
4．The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
Disp Flash
With this function you can the entire display to be flipped by 180˚to allow for better view
when the fixture is hung from truss or a ceiling. This function is disabled as default.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show“Personality”. Tap the
<Up/Down>button until the display will show “Display Setting”. Press ENTER, the
display will show “Display Setting”.
2．Press <Up/Down>, the display will show“Disp Flash”.
3．Press< ENTER>, the display will show“Disp Flash”.
4．The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.5 Temperature C/F
With this function, Display the temperature for Celsius or Fahrenheit.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”.
2．Press <Up/Down>, the display will show“Temperature C/F”.
3．Press< ENTER>, the display will show“Temperature C/F”.
4．The display show “Celsius”,Press <Up/Down>, the display will show “Fahrenheit”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.6 Initial Status
With this function, Display initial effect position.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”.
2．Press <Up/Down>, the display will show“Initial Status”.
3．Press< ENTER>, the display will show“Initial Status”.
4．The display show “XXX”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.7 Dimmer Modes
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”.
2．Press <Up/Down>, the display will show“Dimmer Modes”.
3．Press< ENTER>, the display will show“Dimmer Modes”.
4．The display show “Standard”,Press <Up/Down>, the display will show “Stage”, “TV”,
“Architectural”, “Theatre”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.3.8 Reset Default
With this function, you can select restore factory set for ON or OFF, the default is OFF.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Personality”is displayed. Press ENTER, the display will show “Personality”.
2．Press <Up/Down>, the display will show“Reset Default”.
3．Press< ENTER>, the display will show“Reset Default”.

XM1115-V1.0.0-NR
19
4．The display show “OFF”,Press <Up/Down>, the display will show “ON”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.4 Reset Function
With this function you can reset the device via the Control Board. You can select the different
reset functions by turning the encoder.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Reset Function”is displayed. Press ENTER, the display will show“Reset Function”.
2．The display show “Reset All”, Press <Up/Down>, the display will show“Reset
Pan&Tilt”，“Reset Zoom”.
3．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.5 Effect Adjust
8.5.1 Test Channel
With this function you can test each channel on its (correct) function.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Effect Adjust”is displayed. Press ENTER, the display will show “Effect Adjust”.
2．Press <Up/Down>, the display will show “Test Channel”.
3．Press< ENTER>, the display will show “Test Channel”.
4．The display show “AUTO ……”frist channel, Press <Up/Down>, can choose other
channel.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.5.2 Manual Control
With this function, you can adjust the lamp more easily. All effects will be canceled, the shutter
opens and the dimmer intensity will be set to 100 %. With the individual functions, you can
focus the light on a flat surface (wall) and erform the fine lamp adjustment.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Effect Adjust”is displayed. Press ENTER, the display will show “Effect Adjust”.
2．Press <Up/Down>, the display will show “Manual control”.
3．Press< ENTER>, the display will show “Manual control”.
4．The display show “AUTO =XXX”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.5.3 Calibration
With this function, you can calibrate and adjust the effect wheels to their correct positions. The
password of calibrate values is 050.
1．Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until
“Effect Adjust”is displayed. Press ENTER, the display will show “Effect Adjust”.
2．Press <Up/Down>, the display will show “Calibration”.
3．Press< ENTER>, the display will show “Calibration”.
4．The display show “Color wheel=XXX”.
5．Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
8.6 Users mode set
In this menu, user can select different channels list by different sequence:
For example, after the user enter this manual, if select Auto Program = CH 22, means in this
User’s mode, the “Dimmer” is in Channel 16.
