Skil PWRCORE 20 SC5358E-01 User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Owner’s Manual before using this product. Save these instructions for future reference.
For Customer Service 1300-017-545 OR www.skil.com.au
Charger
Model: SC5358E-01
QC5360E-01
TM

2
1
Defect
Indicator
Charging
Indicator
Defect
Indicator
Charging
Indicator
2SPECIFICATIONS
Rated Input 220-240V~ 50-60Hz 60W
Rated output 20V
Battery Compatibility 2.5Ah:
BY5197E-03
5.0Ah:
BY5196E-03
Charging Time 2.5Ah: 75min 5.0Ah: 150min
Recommended Charging Temperature 4°C ~ 40°C
Recommended Storage Temperature -20°C ~ 50°C
Weight 0.51kg
Rated Input 220-240V~ 50-60Hz 150W
Rated output 21V
Battery Compatibility 2.5Ah:
BY5197E-03
5.0Ah:
BY5196E-03
Charging Time 2.5Ah: 40min 5.0Ah: 60min
Recommended Charging Temperature 4°C ~ 40°C
Recommended Storage Temperature -20°C ~ 50°C
Weight 0.79kg

3
ʿƖʽ
ˀƖʾ˂
3
76
4 5
8
9a
9b
SC5358E-01 QC5360E-01
Defect
Indicator
Charging
Indicator
Defect
Indicator
Charging
Indicator

4
9
9
c
d

5
• Do not touch the contacts in the
charger
• Do not expose tool/charger/battery
to rain
• Do not charge battery in damp or wet
environments
• Do not use charger when damaged
• Do not use battery when damaged; it
should be replaced immediately
• Do not disassemble charger
• Do not attempt to recharge non-
rechargeable batteries with the
charger
• Permitted ambient temperature
(charger):
-when charging 4...40°C
-during operation –20...+50°C
-during storage –20...+50°C
EXPLANATION OF SYMBOLS ON
CHARGER
3Read the instruction manual before
use
4Only use the charger indoors
5Double insulation (no earth wire
required)
6Do not dispose of electric tools and
batteries together with household
waste material
7Time lag fuse (SC5358E-01)
8Time lag fuse (QC5360E-01)
USE
• Charging battery 9
-remove battery from tool
-connect charger to power source as
illustrated 9a
-both lights turn on for 1 second and
then turn o again 9b
-insert battery into charger as
illustrated 9c
-green light starts ashing indicating
that the battery is being charged
9b
-when the battery is fully charged
and green light turns on 9d
-remove battery from charger as
illustrated 9d
-QC5360E-01 charges a fully-
depleted 2.5Ah battery pack to
approximately 25% capacity in 6.25
minutes
! remove battery from charger
after charging period has ended
thereby lengthening the service
INTRODUCTION
• This charger is intended for charging
SKIL battery packs BY5197E-03
BY5196E-03
• This tool is not intended for
professional use
• Read and save this instruction manual
3
SAFETY
SPECIFIC SAFETY
INSTRUCTIONS FOR
CHARGERS
• This charger can be used by
children aged 8 and above and
by persons who have physical,
sensory or mental limitations or a
lack of experience or knowledge
if a person responsible for their
safety supervises them or has
instructed them in the safe
operation of the charger and
they understand the associated
dangers (otherwise, there is a danger
of operating errors and injuries)
• Supervise children (this will ensure
that children do not play with the
charger)
• Cleaning and user maintenance
of the battery charger shall not
be made by children without
supervision
• Always check that the supply voltage
is the same as the voltage indicated
on the nameplate of the charger
• In case of electrical or mechanical
malfunction, immediately switch o
the tool or unplug charger from power
source
• If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualied
persons in order to avoid a hazard.
• Recommendation that the tools
always be supplied via residual
current device with rated residual
current of 30 mA or less
• Only use SKIL battery packs
BY5197E-03 BY5196E-03 with this
charger

6
life of the battery
IMPORTANT:
-if red light starts ashing after
inserting a battery, this means that
the battery is damaged and should
be replaced 9b
-if red light turns on after inserting
a battery, this may mean that
the battery is too cold or too hot
(charger only charges batteries
when its temperature is between
4°C and 40°C) 9b
-the lithium-ion battery can be
charged at any time (interrupting
the charging procedure does not
damage the battery)
-the lithium-ion battery does not
have to be empty before charging
(no “memory-eect” as with nickel-
cadmium batteries)
-while charging, the charger and the
battery may become warm to touch;
this is normal and does not indicate
a problem
-ensure that the outside surface of
the battery is clean and dry before
inserting into charger
-if you anticipate long periods of non-
use for the tool, it is best to unplug
the charger from its power source
-a signicantly reduced working
period after charging indicates that
the battery is worn out and should
be replaced
MAINTENANCE
• Keep charger clean
-clean charging contacts in charger
with alcohol or contact cleaner
! unplug charger from power
source before cleaning
ENVIRONMENT
• Do not dispose of electric
tools, batteries, accessories
and packaging together with
household waste material. The
electric tools, accessories and
packaging should be sorted for
environmental-friendly recycling
! prior to disposal protect battery
terminals with heavy tape to
prevent short-circuit

7
benets to you given by this warranty are
in addition to other rights and remedies
imposed by State and Federal legislation
that cannot be excluded. Our goods come
with guarantees that cannot be excluded
under the Australian Consumer Law.You
are entitled to a replacement or refund
for a major failure and compensation for
any other reasonably foreseeable loss
or damage.You are also entitled to have
the goods repaired or replaced if the
goods fail to be of acceptable quality and
the failure does not amount to a major
failure. Chervon Australia Pty Ltd, Unit
14, 5 Kelletts Road, Rowville, VIC. 3178.
Ph; 1300 01 SKIL (1300 01 7545). Email:
[email protected]
The following consumables have a
3-month warranty period:
Brushes Collets
Dust canisters Angle grinder
anges
Allen keys Chucks
WARRANTY
SKIL WARRANTY POLICY
For all SKIL warranty & enquiries, please
contact 1300 01 SKIL (1300 01 7545)
Monday to Friday 9:00am to 5:00pm EST
Chervon Australia Pty Ltd ABN 36 165
077 501 (“Chervon”) warrants to the
original domestic purchaser that this
product will be free from defects in
materials and workmanship for 5 years
from date of purchase, and any battery
or charger will be free from defects in
materials and workmanship for 3 years
from date of purchase. Please note SKIL
products are intended for DIY (Do It
Yourself) use only. SKIL Products are not
designed or intended for commercial or
trade use and if the products are used
in any commercial or trade applications,
the warranty will not apply. Consumables
will be covered by a 3-month warranty
and a complete list can be found inside
the manual. This SKIL product warranty
is only applicable to purchases from
authorised SKIL retailers.This warranty
will not apply to SKIL products that are
purchased from Amazon, eBay and any
other non-authorised online retailer. This
SKIL product warranty does not apply
to any parallel imported product and
does not apply to any SKIL products that
are not purchased from an authorised
SKIL retailer. To make a claim, return
the faulty item together with proof of
purchase directly to your closest service
agent or to the place of purchase. Any
handling and transportation costs (and
other expenses incurred in claiming this
warranty) are not covered by this warranty
and will not be borne by Chervon. The
replacement product or part or repaired
product will be made available for your
collection at an address nominated by
Chervon. Where a valid warranty claim is
made, Chervon will replace the defective
product or repair the fault.Where the
product is repaired, Chervon may use
refurbished parts.This warranty does not
cover normal wear and tear, misuse or
abuse. This warranty may also be further
limited or voided as specically detailed
in the product Manual. Chervon has no
other liability under this warranty. The

8
Industry leading battery
technology wraps each cell
with cooling material to keep
the battery powering on for
25% longer run time compare
to general battery technology.
SKIL’s patented technology
extends the battery life 2X
longer compare to general
battery technology.
LONGER
RUN TIME
PWRCORE 20™
LITHIUM
*
2X
BATTERY LIFE
PWRCORE 20™
LITHIUM
*
*
