Trotec TTW 25000 S User manual

TRT-BA-TTW25000S-TTW35000S-TC220915TTRT01-011-EN
TTW 25000 S / TTW 35000 S
EN
INSTRUCTIONS
WIND MACHINE

2 EN
wind machine TTW 25000 S / TTW 35000 S
Table of contents
Notes regarding the instructions .........................................2
Safety .....................................................................................2
Information about the device................................................5
Transport and storage...........................................................6
Assembly and start-up..........................................................6
Operation ...............................................................................8
Errors and faults....................................................................8
Maintenance ..........................................................................9
Technical annex...................................................................10
Disposal ...............................................................................12
Notes regarding the instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
Wear safety glasses
Information marked with this symbol indicates that you
should wear eye protection.
You can download the current version of the instructions and
the EUdeclaration of conformity via the following link:
TTW 25000 S
https://hub.trotec.com/?id=42732
TTW 35000 S
https://hub.trotec.com/?id=42733
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
Warning
Do not tilt the fan during operation.
Make sure to always switch the device off, before
adjusting the inclination angle.
Please observe the warning on the device.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Only put up the device in an upright, stable position on firm
ground.
• Let the device dry out after a wet clean. Do not operate it
when wet.

EN 3
wind machine TTW 25000 S / TTW 35000 S
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not cover the device during operation.
• Do not sit on the device.
• This appliance is not a toy. Keep away from children and
animals.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The mains connection must correspond to the
specifications in the Technical annex.
• Insert the mains plug into a properly fused mains socket.
• Observe the technical data when selecting extensions to
the power cable. Completely unroll the extension cable.
Avoid electrical overload.
• Never use just one extension cable for the simultaneous
operation of several fans.
• Do not kink the cable and prevent contact with oil, grease,
chemicals, hot surfaces or sharp and abrasive objects.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
annex.
• Make sure that the air inlet and outlet are not obstructed.
• Make sure that there are no loose items or dirt located in
the immediate surroundings of air inlet and air outlet.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Make sure that the suction side is kept free of dirt and
loose objects.
• Do not transport the device during operation.
• Do not tilt the fan during operation.
Make sure to always switch the device off, before
adjusting the inclination angle.
Intended use
Use the wind machine TTW25000S/ TTW35000S for air
circulation whilst adhering to the technical data and the safety
instructions.
The device was designed for the generation of a powerful,
large-volume air circulation, e.g. for the accelerated drying of
buildings and rooms. The device is suited for both indoor and
outdoor use.
Any use other than the intended use is regarded as misuse.
Reasonably foreseeable misuse
The wind machine TTW25000S/ TTW35000S is not suited for
the installation in fluids or on flooded or boggy grounds.
Do not use this device in immediate proximity to bathtubs,
showers or swimming pools.
Any unauthorised changes, modifications or alterations to the
device are forbidden.

4 EN
wind machine TTW 25000 S / TTW 35000 S
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when using high-
performance fans.
• have read and understood the instructions, especially the
Safety chapter.
Safety signs and labels on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the device:
STOP
Do not tilt during operation!
To tilt the device correctly and fix the inclination angle of the
fan, proceed as described under Assembly and start-up.
Safety symbol Meaning
Wear eye protection when you are near
the device.
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Do not touch the mains plug with wet or damp hands.
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning of electrical voltage
Risk of electric shock!
Risk of an electric shock if the device comes into
contact with water!
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Only operate the device when the brakes are locked
and the inclination adjustment mechanism is engaged!
Caution
Risk of injury from parts being whirled up!
Use suitable eye protection when you operate the
device.
Caution
Risk of injury due to parts being whirled up by the
strong air current.
Before switching the device on, make sure that there
are no loose parts (clothing, hair etc.) located near the
air inlet or outlet!
Note
Do not use abrasive cleaners or solvents to clean the
device.

EN 5
wind machine TTW 25000 S / TTW 35000 S
Behaviour in the event of an emergency
1. Switch the device off.
2. Disconnect the device from the mains feed-in: Hold onto
the mains plug while pulling the power cable out of the
mains socket.
3. Do not reconnect a defective device to the mains.
Overheating protection
The device is equipped with an automatic overheating
protection.
If the motor overheats (exceeds the operating temperature), the
device will be switched off.
When the device has cooled down sufficiently, it will be
switched back on.
Information about the device
Device description
The wind machine TTW25000S/ TTW35000S was designed
for a high air volume flow. The device is designed for indoor and
outdoor air circulation tasks.
The ready-for-use device has a galvanized housing with
chassis, which supports the adjustable two-stage fan in an
inclinable drum. Thanks to the adjustable inclination angle, the
wind machine can be variably aligned up to a vertical flow
position.
The fan motor is equipped with an automatic overheating
protection, which interrupts the power supply as soon as the
device begins to overheat.
To make the device easier to transport, it is fitted with a
transport handle and two wheels. Two feet with rubber buffers
prevent the device from rolling away.
Device depiction
1
2
3
4
5
6
7
No. Designation
1Air outlet
2Wheels
3Power cable with Schuko plug
4Rotary switch for the fan stage
5Handwheel
6Chassis
7Feet

6 EN
wind machine TTW 25000 S / TTW 35000 S
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with a
transport handle and wheels.
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Only wheel the device on firm and level surfaces.
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
Storage
When the device is not being used, observe the following
storage conditions:
• Store the device in a dry location and protected from frost
and heat.
• If required, use a cover to protect the device from invasive
dust.
• Place no further devices or objects on top of the device to
prevent it from being damaged.
Assembly and start-up
Scope of delivery
• 1x Device
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Assembly
1. Unpack the device, the wheels and front feet.
2. Place the device on level ground and carefully tilt it
forward so that the tubular frame becomes accessible for
mounting the wheels.
3. Remove the screws from the wheel assembly.
4. Attach the wheel assembly to the bottom of the tubular
frame by aligning the holes in wheel assembly and tubular
frame.
5. Refit the screws.
Note
Make sure that the screws are tightened correctly and
do not get jammed.
6. Make sure that the wheels are running freely.
7. Then bring the device back into an upright position.
8. Remove the screws of the front feet.
9. Insert the front feet into the connecting pieces at the
bottom by aligning the holes in the feet and tubular frame.
10. Refit the screws.

EN 7
wind machine TTW 25000 S / TTW 35000 S
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the chapter
Technical annex.
D
B
C C
A
• If a defect at the fan could cause property damage, we
recommend the application of a suitable alarm system (air
pressure switch, temperature sensor etc.).
• Before starting the device, check the condition of the
power cable. If there are doubts as to their sound
condition, contact the customer service.
• Only put up the device in an upright, stable position on firm
ground.
• Make sure the device is only placed on firm, dry and
vibration-free ground.
• Make sure that extension cables are completely unrolled.
• Make sure that the air inlet and outlet are not obstructed.
• When positioning the device, keep a sufficient distance to
heat sources.
• Insert the mains plug into a properly fused mains socket.
Please proceed as follows to adjust the inclination angle of the
device:
1. Switch the device off by turning the rotary switch for the
fan stage(4) to the 0position.
2. Loosen the handwheel(5).
ðThe inclination angle can be adjusted in both directions
up to the stop.
3. Retighten the handwheel.
5
Note
Never go past the stop bolts when adjusting the fan
position! Do not remove the stop bolts!

8 EN
wind machine TTW 25000 S / TTW 35000 S
Operation
Operating elements
4
No. Designation Meaning
4Rotary switch
Fan stage
Setting the fan speed:
stage0=off
stage1=medium
stage2=high
Switching the device on
üThe device has been completely installed as described in
the Assembly and start-up chapter.
üThe suction area (on the rear of the device) is free from
dust, dirt and loose parts that can be drawn in.
üThe air outlet area is cleared from any obstacles.
1. Switch the device on by turning the rotary switch for the
fan stage(4) to the desired position.
ðNote: Keep the suction area and air outlet area in
view during operation. Switch off the device
immediately if you recognise any hazards or if loose
parts are drawn towards the fan.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
1. Switch the device off by turning the rotary switch for the
fan stage(4) to the 0position.
2. Hold onto the mains plug while pulling the power cable out
of the socket.
3. Clean the device according to the Maintenance chapter.
4. Store the device according to the Storage chapter.
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The fan is not running:
• Check whether the device is switched on.
• Check the power connection.
• Check the power cable and mains plug for damages.
• Check the on-site fusing.
The fan operates only for a brief period, then switches off:
• Check whether the protective grid at the air inlet is
obstructed in some way. If applicable, remove foreign
objects.
• The motor bearing might be damaged. Please contact the
customer service.
The motor or fan is noisy or runs unevenly:
• The fan is soiled. Clean the fan according to the
Maintenance chapter.
• The fan or the blower unit is damaged. Please contact the
customer service. If necessary, bring the device to an
authorized specialist electrical company or to Trotec for
repair.
• The motor bearing might be damaged. Please contact the
customer service. If necessary, bring the device to an
authorized specialist electrical company or to Trotec for
repair.
The fan produces grinding noises:
• The fan blades are dirty or foreign objects are located in
the rotation range of the fan. Clean the fan blades or the
blower unit according to the Maintenance chapter.
• The fan blades might be damaged. Please contact the
customer service. If necessary, bring the device to an
authorized specialist electrical company or to Trotec for
repair.

EN 9
wind machine TTW 25000 S / TTW 35000 S
The device vibrates heavily:
• Check the floor space of the fan. Position the device on a
level and firm surface.
• Check the screwed connections, particularly between
blower unit and tubular frame. If necessary, retighten the
screws.
• Check the fan blades for dirt and clean them if required.
• There might be an imbalance in the fan blades. Please
contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.
The fan changes its position during operation:
• Check the parking brakes for tight fit and retighten them if
necessary.
The air flow rate is low:
• Check whether the protective grid is blocked and clean it if
required.
The device still does not operate correctly after these
checks:
Please contact the customer service. If necessary, bring the
device to an authorised specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Cleaning the fan and device interior
• Check fan and protective grid for perfect condition before
and after each application.
• Clean the fan at regular intervals.
• Use compressed air to remove particles, lint, dust and dirt
from motor, impeller and protective grid. Do not in any
event use a high-pressure cleaner to clean the fan.
• If required during cleaning, remove the protective grid by
unscrewing the eight screws, and put it back in its original
place after the work has been completed.

10 EN
wind machine TTW 25000 S / TTW 35000 S
Technical annex Technical data
Parameter Value
Model TTW 25000 S TTW 35000 S TTW 35000 S UK
Article number 1.510.004.020 1.510.004.025 1.510.014.026
Air volume:
level1:
level2:
21000 m3/h
27600 m3/h
24600 m3/h
32400 m3/h
246003/h
324003/h
Max. air pressure 160 Pa 160 Pa 160 Pa
Voltage 230V/ 50Hz 230V/ 50Hz 110V/ 50Hz
Power input:
level1:
level2:
520W
650W
620W
750W
630W
820W
Fusing 16A 16A 16A
Transport medium temperature max. 40°C max. 40°C max. 40°C
Sound level:
stage1:
level2:
65dB(A)
75 dB(A)
65 dB(A)
75 dB(A)
65 dB(A)
75 dB(A)
Type of protection IP20 IP20 IP20
Mobility Wheeled Wheeled Wheeled
Dimensions (L x W x H) 1060x 525x 1140mm 1290x 380x 1210mm 1290x 380x 1210mm
Minimum distance to walls and other
objects
top(A):
rear/ suction side(B):
At the sides(C):
front(D):
50 cm
3 m
50 cm
50 cm
50 cm
3 m
50 cm
50 cm
50 cm
3 m
50 cm
50 cm
Weight 44kg 49kg 49kg

EN 11
wind machine TTW 25000 S / TTW 35000 S
Wiring diagram
Overview and list of spare parts
Info
The position numbers of the spare parts differ from
those describing the positions of the components
mentioned in these instructions.
1
2
2
3
4
89
5
6
7
No. Designation No. Designation No. Designation
1 Fan wheel 4 Wheels (pair) 7 Front feet (pair)
2 Protective grid 5 Switches 8 Inclination handwheel
3 Motor 6 Button/rotary control 9 Power cable

12 EN
wind machine TTW 25000 S / TTW 35000 S
Disposal
Always dispose of packing materials in an environmentally
friendly manner and in accordance with the applicable local
disposal regulations.
The icon with the crossed-out waste bin on waste
electrical or electronic equipment is taken from Directive
2012/19/EU. It states that this device must not be disposed of
with the household waste at the end of its life. You will find
collection points for free return of waste electrical and electronic
equipment in your vicinity. The addresses can be obtained from
your municipality or local administration. You can also find out
about other return options that apply for many EU countries on
the website https://hub.trotec.com/?id=45090. Otherwise,
please contact an official recycling centre for electronic and
electrical equipment authorised for your country.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
Only for United Kingdom
According to Waste Electrical and Electronic Equipment
Regulations 2013 (SI2013/3113) (as amended) devices that are
no longer usable must be collected separately and disposed of
in an environmentally friendly manner.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
