Trust DS-4500X User manual

DS-4500X Wireless Laser Deskset
1
UK
Product information
Mouse
A: Right button
B: Scroll wheel Button
(Lit flashing: low battery)
C: Left button
D: Browser backward button
E: Browser forward button
F: Connect button
G: Battery compartment
I: Charging connection
J: Motion sensor
Keyboard
K: Standby button
L: Logon/off button
M: Office function keys button
N: Low battery LED
O: Scroll wheel
P: Open default homepage
Q: Open default email program
R: Open My computer
S: Search
T: Open MSN messenger
U: Open media player
V: Media play buttons
W: Battery compartment
X: Stand
Y: Palm rest
Z: Connect button
Cradle/Receiver
1:Receiving indicator
Lit steady: powered
Lit flashing: active
2: Mouse holder
3: Charging plates
4: Charging indicator
Lit steady: charging
Lit flashing: fully charged
5: Connect button
6: Power connector
7: USB, PS/2 combo cable
8:PS2 mouse connector
9:USB/PS2 keyboard converter
10: USB connector
Installation
1 Insert NiMH RECHARGEABLE batteries
2 Connect power to cradle
3 1) Put mouse in cradle
2) Indicator lit
charge batteries 8 hrs before 1st time use
4 Insert ALKALINE batteries
5 PC off
6
Connect PS2 plugs
- Mouse: green
- Keyboard: purple (with USB/PS2 converter)
This deskset can also be connected via USB (black). When use USB, do NOT connect any PS2
connectors!
7 1) Computer on
2) Receiving indicator lights
Windows 98SE needs Windows CD-ROM at startup when using USB connection
Connect Mouse
8 1) Press connect button
2) Receiving indicator flashing
9 Press connect button
Connect Keyboard
10 1) Press connect button

DS-4500X Wireless Laser Deskset
2
2) Receiving indicator flashing
11 Press connect button
The product is ready to use!
Install Easy Configure Program
12 Place Trust CD in CD-ROM drive
13 Install software
14 Follow onscreen instructions to finish
Reminder
Less performance
• Metal object close to or in between the device.
• Material of the surface which may cause sensor imprecision. Use a mousepad to avoid it.
• Follow step 8-9 and 10-11 to change channel in case of disturbace.
• Batteries (almost) empty.
• Another wireless device is close by.
General usage
• Adjust the speed of mouse pointer: (1) Open Windows Help (Start  Help). (2) Search “adjust the speed of
mouse pointer”. (3) Follow instructions
• Read the manual on CD for the use of the configuration program
• Install Trust Easy Configuration software on CD to configure the mouse buttons or hot keys
• Set Wheel Mode in configuration software to System default if experience problem using Enhanced scroll
mode
• Enable start application when system starts: go to Start-> Programs-> Trust-> DS-4500x wireless laser
deskset-> Startup setting
• Do not use old and new batteries at the same time, because the old batteries may deplete the new ones
• Keep mouse on cradle no longer than 48 hours
• Do not attempt to recharge alkaline batteries. There is a danger of them exploding
If you have any problems, go to www.trust.com/14529 for FAQ, software and manuals. This product may have
other item no. due to various keyboard layout, but they are basically the same as 14529’s.
For extensive service register at www.trust.com/register.

DS-4500X Wireless Laser Deskset
3
UK
Safety
• Do not open or repair this device.
• Keep this device away from liquids, such as water.
• Do not stare into the laser.
• This device meets the essential requirements and other relevant conditions of the applicable European
directives. The Declaration of Conformity (DoC) is available at www.trust.com/14529/ce
• If possible, dispose of the device at a recycling centre. Do not dispose of the device with the household
waste.
Wireless
• This wireless device works at a frequency of 27MHz. It meets the essential requirements and other relevant
conditions of R&TTE Directive 1999/5/EC and can be used in EU countries plus: EU candidates and
NO/CH/RU/HR/IS/UA. There are no limitations per channel for the above-mentioned countries. Go to
www.trust.com/14529 for an updated list of the countries where the use of this device is permitted.
• There may be restrictions for the use of this device outside of the EU. If this device is used outside of the EU,
check whether this device meets local regulations. Frequency: Mouse: 27.045MHz, Keyboard: 27.195MHz;
Bandwidth: 50KHz, Power: < 1mW.
• Nowadays, there are an increasing number of wireless products (video, audio, computer, etc.) which work in
the same frequency range as this device. It may, therefore, be possible that the functionality of this product
is limited by or is limiting for other wireless products. This can only be avoided by paying attention to the
distance between products and, where possible, by changing channels.
• Be careful when using wireless devices if you have a pacemaker or are dependent on other life-saving,
sensitive electronic equipment, because this product transmits radio signals.
Warranty & copyright
• This product has a two-year manufacturer's warranty which is effective from the date of purchase. For more
information see www.trust.com/warranty
• Reproduction of this manual or any part of it is prohibited without permission from Trust International B.V.
