Trust START-LINE SET ACDB-7000BC User manual

www.trust.com

START-LINE
SET ACDB-7000BC
Item 71086 Version 1.0
Visit www.trust.com for the
latest instructions
WIRELESS DOORBELL CHIME WITH
BUILD-IN TRANSMITTER
USER MANUAL
MULTI LANGUAGE

2
4
1
3

6
8
5
7

1 sec.
910
11 12

1413
15
1 sec.

16
7 sec.
1 sec.

ACDB-7000BC WIRELESS DOORBELL CHIME WITH BUILD-IN TRANSMITTER
1
1. Switch o the mains power (electric meter box)
First switch o the mains power before detaching the existing wiring.
2. Detach existing wires
Look for your existing wiring which most of the times leads to your electric meter box and detach
these from the existing installation.
The existing doorbell won’t be operational any more.
3. Switch on the mains power (electric meter box)
Do not contact any exposed wiring. Only touch the plastic housing of this product.
4. Open build-in transmitter
Put, for example a coin, in the insert to open the transmitter.
5. Connect transmitter
Connect the wires of the transmitter to the L and N outlets of the lustre terminal.
6. Connect existing wires
Connect the existing wires to the remaining L and N outlets of the lustre terminal.
7. Place chime receiver
Place the chime receiver in a socket.
8. Select melody
Press the [¯] button several times to select 1 of the 5 melodies. You can select a dierent melody for
each transmitter.
9. Select volume level
Press the volume button [ ] several times to select 1 of the 4 volume levels. You can select a dierent
volume level for each transmitter.
10. Activate learn-mode
When you have selected the desired volume level and melody, press the [LEARN] button for 1 second
to activate the learn-mode. The learn-mode will be active for 15 seconds and the LED-indicator will
blink slowly.
EN
