Truvox Valet Upright Vac VUV-QD User manual

1
Userinstructions
ValetUprightVac –VUV-QD
Commercial singlemotorupright
vacuumcleaner
03-8218-0000 Issue303/10
CAUTION
–
READTHESEINSTRUCTIONS BEFOREUSINGTHEMACHINE
ORIGINALINSTRUCTIONS

2
PartsIdentification
Packing listItem QuantityItem Quantity
Valet UprightVac1Dusting brush1
Dust bag (inmachine)1Crevicetool1
Handle1Userinstructions1
Vacuumhose1
Telescopicwand 1
Ifanyofthe aboveitemsaremissing pleasecontact yoursupplierimmediately

3
Contents
1. Productinformation..................................................................................................................4
1.1 Important SafetyAdvice.....................................................................................................4
1.2 Guidelinesforthe operator.................................................................................................5
1.3 Transporting the machine...................................................................................................5
2. Preparing foruse......................................................................................................................5
2.1 Symbols&Markings...........................................................................................................5
2.2 Electricalconnection...........................................................................................................5
2.3 Howtoassemblethe vacuum.............................................................................................5
2.3.2 Attachingthe telescopicwand..........................................................................................6
3. Controls...................................................................................................................................6
4. Operation.................................................................................................................................6
4.1 Howtochange the dust bag...............................................................................................6
4.2 Handleadjustment.............................................................................................................6
4.3 Using the hoseand tools....................................................................................................6
4.4 Edge cleaning feature.........................................................................................................6
5. Storage....................................................................................................................................6
6. Maintenance............................................................................................................................6
6.1 Secondary Filter.................................................................................................................7
6.2 Replacing drivebelt............................................................................................................7
6.3 Replacing the agitatorassembly.........................................................................................7
6.4 Cleaningthe nozzlehose...................................................................................................8
6.5 Clearing the hose...............................................................................................................8
7. Aftersalesservice....................................................................................................................8
8. Guarantee................................................................................................................................9
9. WasteElectrical &ElectronicEquipment (WEEE).....................................................................9
10. TechnicalSpecification...........................................................................................................10
11. Faultdiagnosis.......................................................................................................................10
13. Declaration ofConformity.......................................................................................................15

4
IMPORTANT
READTHESEINSTRUCTIONSCAREFULLYAND RETAINFORFUTUREREFERENCE
1.Productinformation
Thesecommercialuprightvacuumcleanersare
designed forthe collection of dust inindoor
areas. Theyshouldnot be used inoutdoorareas.
Werecommend thatanyusernotfamiliarwith
carpetcleaning shouldread theseuser
instructionsfullybeforeusing the machine. Ifyou
haveanyqueriespleasecontact the supplierwho
you purchased the machine fromorTruvox
Internationalon the contactdetailsprovided at
the back.
Thismachine mustonlybe used forthe
manufacturer’sapproved application.Donot
use the machine whereitissuspected thatthe
carpet, floororupholstery containshealth
endangering dustordebrissuchasasbestosor
chemicalwaste.Ifthisissuspected do not
proceed,contactyoursupervisor,supplieror
TruvoxInternationalforadvice.
The following instructionscontainimportant
information aboutthe machine and safetyadvice
forthe operator.
Equipmentmustbe operated,serviced and
maintained inaccordancewiththe
manufacturer’sinstructions.Ifin doubtcontact
thesupplier ofyourmachine.
Theseinstructionsarevalidforthe following
models:
Valet UprightVac
1.1ImportantSafetyAdvice
When using electrical equipmentbasicsafety
precautionsshouldbe followed including the
following.
•Read allinstructionscarefullybeforeuse.
•Thisapplianceissuitableforcommercialuse,
forexampleinhotels,schools,hospitals,
factories,shops,offices,rentalbusinessesand
otherthan normal housekeeping purposes.
•Thismachine isnotintended foruseby
persons(including children)withreduced
physical,sensory ormentalcapabilities,orlack
ofexperienceand knowledge,unlessthey
havebeen given supervision orinstruction
concerning useofthe machine byaperson
responsiblefortheirsafety.
•Keep children and unauthorised personsaway
fromthe machinewhen inuse.
•Children shouldbe supervised toensurethat
theydo not playwiththe appliance.
•Beforeusing the appliance,check thatthe
mainspowervoltage correspondswiththe
voltage shownon the rating plate.
•Allpartsaretobe positioned asindicated inthe
instructionsbeforeusing the machine.
•Do not operatethe machine ifitmalfunctionsor
isdamaged inanyway.Contactan authorised
serviceagent forrepairoradjustment.
•Do notoperateswitchesortouchthe mains
plug withwethandsasthismaycauseelectric
shock.
•Whenunplugging pulltheplug,notthe supply
cord.
•Do notpull orcarry bythe supplycord.Do not
usecordasahandle,closedooron cordor
pullcordaround sharpedgesorcorners.
•Keep hair,looseclothing,fingersand allparts
of bodyawayfromopeningsand moving parts.
•Keep cordawayfromheated surfaces.
•Do not usewherehazardousdust ispresent.
•Do not useinan explosiveatmosphere.
•Do not pickup oilorotherflammablematerial.
•Do not usetopickup moistureoranyliquids.
•Do notleavethe machine connected tothe
electricitysupplywhen notinuse,always
removethe plug fromthe socket-outlet.
•Switchoffthe machine beforeremoving the
plug.
•Keep the powersupplycordclearofmoving
parts.During operation hazardmayoccur
whenrunning the machine overthe power
supplycord.
•The powersupplycordmustberegularly
inspected forsignsofdamage.Ifthe power
supplycordisdamaged,itshall onlybe
replaced bythe manufacturer,itsserviceagent
orasimilarqualified person inordertoavoida
hazard.
•Onlyreplacethe supplycordwiththe type
specified intheinstruction manual.
•Do notoperatethe machine withadamaged
supplycordorplug,orafterthe machine
malfunctionsorisdamaged inanyway.
Contactan authorised ServiceAgentforrepair
oradjustment.
•The plug ofthe powersupplycordmustbe
removed fromthe socket-outletbefore
commencing cleaning ofthe machine or
undertaking maintenanceoperations.
•Do not kinkortwist the powercord.

5
•Takecarewhen using amachine nearthe top
of stairstoavoidoverbalancing.
1.2Guidelines fortheoperator
WARNING
Operatorsmustbe fullytrained inthe
useofthe machine inaccordancewith
theseinstructions,abletoperformuser
maintenanceand selectthe correct accessories.
•Operatorsshouldbephysicallycapableto
manoeuvre,transportand operatethe
machines.
•Operatorsshouldbe abletorecogniseunusual
operation ofthe machine and reportany
problems.
•Onlyusethe machine onfirmlevelsurfaces.
•Wearsuitablefootweartoavoidslipping.
•Wearsuitableclothingtokeep dryand warm.
•Wherepossibleimplementjob rotation and
adequaterestperiodstoavoidcontinuoususe
of the samemuscles.
•Do not leavemachine running unattended
•Do not smokewhen using the machine.
•Do notputanyobjectsintoopenings.Do not
usewithanyopening blocked:keep free of
dust, debris,hair,oranything thatmayreduce
airflow.
CAUTION -Thismachine isforindoor
dry useonlyandshouldnotbe usedor
stored outdoorsorinwet conditions.
CAUTION -Ifit issuspected thatthereis
hazardousdustorflammablematerials
stop cleaning the area immediatelyand
consult yoursuperior.
WARNING Onlyuseaccessoriesand
sparepartsprovided withthe machine or
thoseapproved bythe manufacturer.
The useofotheraccessoriesmayimpair
the safetyofthe machine.
•Ensurethe machine isswitched off before
adding orchanging accessories.
1.3Transportingthemachine
CAUTION –Incorrectlifting techniques
mayresultinpersonalinjury, where
applicabledo notlift large and heavy
machineswithout assistance. Weadvisethatthe
manual handling regulationsarefollowed.
Pleaserefertothe technicaltablefordetailson
weight ofmachine.
When transporting the machine ensurethatall
components,tanksand removablepartsare
securelyfastened,and thatthe supplycordand
plug arenot trailing. Detachhoseand wandfrom
machine whereapplicable.
Takeextremecarewhen moving the machine up
ordownstepsorstairs.
2.Preparing foruse
2.1Symbols&Markings
WARNING
2.2Electrical connection
Beforeconnecting the machine tothe power
supply,check thatyoursupplyvoltage
correspondswiththatmarked on the ratinglabel.
The powersupplycordplusanyextension leads
shouldnotexceed 30mintotal.The cross-
section ofanyextension cablewiring mustbe at
least 2,5mm².
Shouldan extension cordbe used,ensurecord
rating isadequateforthe equipment.Do notuse
extension cordincoiled condition asthiscould
result inoverheating of the cord.
UK only
The supplycordfor230vmodelsisfitted witha
plug containing a13 ampfuse.Shouldthe fuse
requirereplacementit must onlybe replaced bya
13 ampfuseconforming toBS1362,and the fuse
covermust be refitted. Ifthe fusecoverislost the
plug mustnotbe useduntil the correct
replacement coverisfitted.
IMPORTANT -Ifthe supplycordisdamaged,it
mustonlybe replaced byasuitablecord
availablefromthe manufactureroran authorised
serviceagent.
WARNING –THISAPPLIANCEMUST BE
EARTHED
2.3How toassemblethevacuum
WARNING-Before undertaking
assemblyorchanging of
accessories/toolsswitchoff machine
and unplug fromtheelectricitysupply.
2.3.1Attaching thehandle
•Afterfirstremoving the handle
screw,inserthandleintothe hole
on top ofthe vacuumcleaner.
Ensuring the hosehangeris
positioned atthe rearofthe
machine (Fig1).
•Line up the smallholeon the
handlewiththe smallholeon the
vacuumcleanerand insertthe
screw.Makesurethe screwis
tightened securely.
Fig 1.

6
2.3.2Attaching thetelescopicwand
•Pushthe wandontothe hoseattachment.
•Insertthe wand intothe quick drawattachment
holderpositioned on the side ofthe machine.
3.Controls
•Toturnthe vacuumon, pushthe switchlocated
on the dust compartmenttothe (I)position.
•Toturnthe vacuumoff, pushthe switchlocated
on the dust compartmenton the (0)position.
4.Operation
4.1How tochangethedustbag
Always operatethevacuumcleaner with a
dustbaginstalled.
•Unplug the vacuumcleaner.Removethe used
bag fromthebag holder(Fig.2).
•Attachthe newdustbag ontothe bag holder
(Fig. 3).
•Spread outtheendofthe newdustbag (Fig.
4).
•Reinsertthe tab on the end ofthe dustcover
intothe grooveon the dustcompartment
housing.Press itintoplaceand fasten the dust
covertightly(Fig. 5).
4.2Handleadjustment
The handleon thisvacuumcleanercan be setto
one of three positions–upright, middle,orlow.
Toreleasethe handle, step on the pedal atthe
leftrearcornerofthe vacuumcleaner
1.Middleposition–fornormal cleaning
2.Upright position –forwhen cleaning toolsare
used orforstorage. Handlelocksinthis
position.
3.Lowposition –forcleaning underfurniture.
*Onceinthemiddleposition,step on the pedal
at the left rearcornerofthe vacuumand pull
back the handleagaintoplacethe vacuumtothe
lowposition.
4.3Usingthehose and tools
Whenusing the hoseand toolspleaseensurethe
handleislocked intothe upright position and that
the brushhead istilted upwardstopreventthe
brushrunning inplaceonthe carpet.
The Valet Upright Vacisequipped withon-board
cleaning toolsincluding telescopicwand, stretch
hose, dusting brushand acrevicetool.
1.Removethe extension wand fromthe bodyof
the vacuumcleanerand attachanytools
ontothe end ofthe wand.
4.4Edgecleaning feature
The edge cleaning featureprovidesimproved
cleaning of carpetsnearwallsand stationary
furniture. Formaximumedge cleaning,usethe
leftside of the vacuumnearwallsorstationary
furniture.
5.Storage
•Afterusecheck the bag.
Iffull,replacethe bag.
•Wind the supplycord
ensuring thatthe plug is
nottrailing on the floor
(Fig6).
•Storethe machine inadry
indoorarea only.
6.Maintenance
WARNING -Before undertaking
maintenance operationsor
adjustmentsswitchoff machineand
unplugfromtheelectricitysupply.
The machine requiresminimummaintenance
apartfromthe following checksbythe operator.
•Supplycord–Regularlyinspectsheath,plug
and cordanchoragefordamage orloose
connection.
•Bodyofthe machine –Clean withadamp
cloth.
Fig 2 Fig 3
Fig 4 Fig 5
Fig 6

7
Fig 7 Fig 8
6.1Secondary Filter
YourTruvoxvacuumcleanerisequipped witha
secondary filterand aHEPAfilter.Thesefilters
capturefine dust particlesand protectthe motor
fromdirt.Accumulated dirtinthe dust
compartment willbe collected on thisfilterand
mayrestrictmotorperformance.It isimportantto
inspect and change thesefiltersregularly.
ToChangeSecondary Filter:
1.Unplug the vacuumcleaner.Removethe bag
compartment coverand the bag.
2.Removethe secondary filterand replacewith
anewfilter(Fig. 7).
3.Replacethe bag and bag compartment
cover.
NOTE: Secondary filterscannot be washed
and used again.
TochangetheHEPAfilter
1.Unplug the vacuumcleaner. Removethe bag
compartment coverand the bag.
2.Removethe HEPA filterand replacewitha
newfilter(Fig.8).
3.Replacethe bag and bag compartment
cover.
6.2Replacingdrive belt
CAUTION: Unplug the vacuumcleanerbefore
performing anyofthesesteps.
Remove theBottomPlate.
1.Placevacuumcleanerinthe lowposition by
using the handlereleasepedal.Then,turnthe
vacuumcleanerover, exposing the underside.
2.Removethe screwsholding the lowerplatein
place.
3.Removethe bottomplate.
Replacing thebelt.
1.Turnthe unitoverand removethe lowerplate
asdescribed inthe preceding section.
2.Removethe agitatorholder(Fig.9).Takeout
the agitatorassemblyand removebelt fromthe
agitatorpulleyand the motordriveshaft (Fig.
10 &11).
3.Loop the newbeltaround the agitatorpulley
and the motordriveshaft.
4.Reinsertthe agitatorassemblybackinto
housing (Fig12). Turnthe agitatorassemblyby
hand,making surethe beltisnottwisted and
allrotating partsmovesmoothly(Fig. 13).
5.Reinsertthe agitatorholder.Besurethatthe
agitatorholderisinplacebeforefastening the
lowerplate.
6.Hookthe front end oflowerplatetothe tworibs
atthe frontend ofthe housing.Pressthe lower
plateintoplaceand replacescrewstoholdit.
NOTE:Toensuremaximumcleaning efficiency,
the beltshouldbe checked regularlytobe sureit
isingood condition.Checktosee ifthe beltis
stretched,cracked,orifexcessiveslipping is
occurring.Replaceitif needed.
6.3Replacing theagitatorassembly
Brushesshouldbe replaced when theyareworn
orwhen the bristledoesnottouchacardthatis
heldacrossthe nozzle.You shouldreplaceall
fourbrushesatthe sametimeinorderto
maintaingood cleaning efficiency.
RemoveE-clipfirstfromagitatorshaftbyusing
screwdriver.Then removethe end cap atright
end byholding the agitatorassembly. Pullout the
agitatorshaft fromthe left end.
NOTE:Takecarenottodeformthe agitatorshaft.
Nowthe brushescan be removedeasily.After
inserting the newbrushes,re-install the agitator
pulleyand agitatorholder,making suretheyare
completelyand firmlyinserted.Reinstall other
partsfollowing the stepsinreverse.
Besurethe end capsandfiltersareinplace
beforefitting the E-clipback intoplace.Reinstall
the agitatorassemblyasdescribed inpreceding
section.
Fig 9Fig10 Fig 11
Fig12 Fig13

8
6.4Cleaningthenozzlehose
CAUTION: Unplug the vacuumcleanerbefore
performing anyofthesesteps.
The nozzlehose,located on the back ofthe
vacuumcleaner,carriesthe dirtfromthe nozzle
tothe filterbag.Thehosealsofunctionsasthe
attachment cleaninghose.
Ifthe hoseshouldbecomeclogged:
1.Pulloutand turnthe lidofthe hose
attachmentopening.Removethe clog or
blockage (Fig.14).
2.Ifthe abovestep isnot enough, removehose
cuff fromthe nozzleinlet(Fig.15).Turnthe
unitoverand unscrewandremovethe
bottomplate(see "HowToRemoveBottom
Plate.").Checknozzleinlettube for
obstructions.Cleartube and reinstall the
bottomplate.
IMPORTANT -Shouldthemachinefailto
operatecontactTruvoxCustomerService
Department forrapidattention.
6.5Clearingthehose
•Removethe quickdrawwand fromtheside of
the machine.
•Disconnect the quickdrawclean out by
pressing the twolatches on eitherside (Fig16).
•Straightenthe lowerpart ofthe hoseand clear
anyblockages(Fig17).
7.After sales service
Truvoxmachinesarehigh qualitymachinesthat
havebeen tested forsafetybyauthorised
technicians. Itisalwaysapparent that afterlonger
working periods, electricaland mechanical
componentswillshowsignsofwearand tearor
ageing.
Underextremeorspecialised conditionsand/or
insufficient maintenance, shortermaintenance
intervalsarenecessary. UseonlyoriginalTruvox
spareparts. Use ofother spare partswill
invalidateall warrantyand liabilityclaims.
Shouldyou requireaftersalesserviceplease
contactthe supplierfromwhomyou purchased
the machine,who will arrange service. Repairs
and servicing of Truvoxproductsshouldonlybe
performedbytrained staff. Improperrepairscan
causeconsiderabledangerstothe user.
Fig 14 Fig 15
Fig 16 Fig17

9
8.Guarantee
Yourproductisguaranteed forone yearfromthe
dateoforiginalpurchase, orhirepurchase,
against defectsinmaterialsorworkmanship
during manufacture.Withinthe guarantee period
weundertakeat ourdiscretion,torepairor
replacefree of charge tothe purchaser, anypart
found tobe defective, subjecttothe following
conditions.
CONDITIONS
1.Claimsmade underthe termsof the
guarantee must be supported bythe original
invoice/billof saleissuedat the timeof sale,
orthe machine Serial No.
2.Forclaimsunderthisguarantee contactthe
supplierfromwhomyou purchased the
product who willarrange the appropriate
action.Do notinitiallyreturnthe product as
thiscouldresultintransit damage.
3.NeitherTruvoxnoritsdistributorshall be
liableforanyincidental orconsequentialloss.
4.Thisguarantee isgoverned bythe lawsof
England.
5.Thisguarantee doesnot coveranyof the
following:
-Periodicmaintenance, and repairor
replacement of partsdue tonormalwearand
tear.
-Damage caused byaccident, misuseor
neglect,orthe fitting of otherthan genuine
Truvoxparts.
-Defectsinotherthan genuine Truvoxparts,
orrepairs,modificationsoradjustments
performedbyotherthan aTruvoxservice
engineerorauthorised serviceagent.
-Costsand risksoftransport relating directly
orindirectlytothe guarantee ofthisproduct.
-Consumableitemssuchas, brushes, drive
discs, filtersand vacuumskirts.
Thisguarantee doesnot affectyourstatutory
rights, oryourrightsagainst the supplierarising
fromtheirsalesorpurchasecontract.
TruvoxInternationalLimited policy isone of
continual product development and wereserve
the righttoalterspecificationswithout priornotice
9.WasteElectrical &ElectronicEquipment
(WEEE)
Do not disposeofthisdevicewithunsorted
waste. Improperdisposalmay
be harmfultothe environment
and human health.
Pleaserefertoyourlocal waste
authorityforinformation on
returnand collection systemsin
yourarea.

10
10.Technical Specification
230 V~50 Hz, Class I construction.EnclosuretoIP20.With15msupplycordand 13Afused plug.
Model Valet UprightVacValet UprightVac
RefNo VUV-QDVUV-QD/EURO
Tankmaterial ABS ABS
Voltage a.c.V230 230
Frequency Hz50 50
No. ofmotors11
Motorrating W1200 1200
Capacity–dry L3.63.6
Construction class II
Protection IPIP20 IP20
Airflowl/sec52.552.5
kPa16.216.2
Vacuum mm/wg
1651 1651
Cablelengthm12 12
Size(lxwxh)cm35 x37 x114 35 x37 x114
Weightkg6.66.6
NoiseLevel (see
note1) dB(A)
79 79
1–Soundpressurelevelundernormaloperatingconditionsis79dB(A)whenmeasuredatadistanceof1
metrefrommachineand1.6metresabovethefloor.Measurementsrecordedusinghandheldmeter.
11.Faultdiagnosis
WARNING -Before undertakingmaintenanceoperationsoradjustmentsswitchoff
machineandunplugfromtheelectricitysupply.
The following simplechecksmaybeperformed bythe operator.
TroubleReason Remedy
Machine not working.Lack ofvoltage/electrical
supply. Check fuse*, supplycord, plug and socket outlet.
Lossofsuction Bag full.
Blocked hoseorwand.
Motornot working
Replacebag
Removeobstruction
Contact supplier
Motorisnot running Broken switch
Defectivepowercord
Defectivemotor
Contact supplier
Contact supplier
Contact supplier
*Ifthe fuseblowsseveral times, themachineshouldbe checked byan authorised ServiceAgent.

Drawing
Ref.
Part Number DESCRIPTION Qty Per
1 AEA0283582 Dust Compartment 1
2 AEA1403582 Boot Strain Relief 1
3 AE2363000 On/Off Switch 1
4 AK0073582 Cord Holder 1
5Set Screw M4*15 2
6 AEA0053582 Inner Switch Cover 1
7 Set Screw M4*15 6
8 U2-U11-088 Secondry Filter (Pack Of 5) 1
9 AEA0123582 Motor Cover Seal 1 1
10 AEA0133582 Motor Cover Seal 2 1
11 AEA0113582 Dust Compartment Seal 1
12 U2-U11-077 Paper Bag Set (Pack of 10) 1
13 AEA0023688 Dust Cover 1
14 AEA0333006 Latch Spring 1
15 AEA0043582 Dust Cover Release Handle 1
16 AEA0533582 Seal For Inner Switch Cover 1
17 AEA0233582 Motor Cover Holder Plate 1
18 AEA0223006 Support Strap 1
19 AEA0033582 Motor Cover 1
20 Set Screw (M4*18.5) 6
21 Set Screw (M4*16) 7
22 Set Screw (M4*6) 1
23 Washer 1
24 AE1903000 Board Cover 1
25 AE1893582 Board 1
26 E1A2623003 Arm Shaft Bushing Holder Plate 1
27 AEA0644000 Rear Wheel Assembly 1
34 AE2224000 Motor Cord 1
35 AE1783582 Wire Bushing 1
36 002027129 Zip Tie 1
37 AA0453000 Wire Connector (HW-C5) 1
38 AEA0953000 On-Board Tool Holder 1
39 Screw M4*12 8
40 AE0163008 Handle Fitting 1
41 AG0853000 Wiring Hammer 1
42 AC1383582 Swivel Inlet Gasket 1
43 & 71 U2-U11-090 Nozzle Hose and Handle Grip Assembly 1
49 Set Screw M5*12 2
52 AEA0103582 Hose Hanger 1
53 AEA0414582 Handle Assembly Complete 1
Spare Parts List
Model Ref.:- VUV-QD
Refer to Drawing 09-1120-0000 Sheet 1
U2-U11-090 Also includes assembly 71
SERIES A
Ref. Drawing 09-1120-0000 Dated 09th February 2010
Spare Parts List Issue 3 Dated 21 October 2011

Drawing
Ref.
Part Number DESCRIPTION Qty Per
Refer to Drawing 09-1120-0000 Sheet 1
56 002AE00001 Zip Tie 1
61 Handle Screw M5*45 1
62 AEA1374582 Plastic Frame 1
63 Washer 4.2*14*1 1
64 AEA1563582 Cord Holder 1
65 Set Screw M4*21 2
77 AEAA034858 Quick Draw Wand Assembly 1
82 U2-U11-091 Quick Draw Attachment Holder 1
86 AE2403000 Wire Harness 1
87 AE2133000 Thermal Switch 1
88 AE2163000 EMI PC Board 1
89 AE2213582 Power Cord 1
90 AG1875000 Thermal Fuse 1
91 AE2373000 Terminal Block 1
93 AEA1363000 Quick Draw Wand Holder 1
94 BA00163582 Cord Retainer Hook Black 1
95 AEA1435000 Relief Valve Base Assembly 1
1 AEA0873000 Nozzle Hose 1
2 AEA1353006 Suction Fitting Collar 1
3 U2-U11-092 Nozzle Housing 1
4 U2-U11-093 Vac Motor Assembly 1
14 AEA1013582 Crevice Tool 1
15 AEA01933582 Round Brush 1
16 AEA0724000 Bottom Plate Assembly 1
23 AA0113000 Felt Packing 1
24 AK0883006 Vented Support Fitting 1
25 AE1593582 Belt (Single) 1
U2-U11-089 Belt (Pack of 10) 1
28 AA0514714 Pinned Brush Roll Assembly 1
46 U2-U11-094 Foot Pedal Assembly 1
Refer to Drawing 09-1120-0000 Sheet 2

13

14

15
13.DeclarationofConformity
ECDeclarationofConformity
We,TruvoxInternationalLtd.
of ThirdAvenue, Millbrook,
Southampton, Hampshire
England
SO15 0LE
declarethatthe machinery
Make:Commercialupright singlemotorvacuumcleaners
Type :Valet UprightVac
Model :VUV-QD…
Serial Number:from01000
YearofConstruction :2010
hasbeen manufactured using the following transposed harmonised European Standardsand
technicalspecifications.
Ref No Title
2006/42/ECMachinery Directiveand subsequent amendments
2006/95/ECThe LowVoltage Directiveand subsequent amendments
BS EN60335-1
BS EN60335-2-69
2004/108/ECThe EMCDirectiveand subsequent amendments
EN61000-3-2
EN61000-3-3
EN55014-1
EN55014-2
Signed in:SOUTHAMPTON,England
on the 29th dayof December2009
Signature:
Name:David Overell Technicalfile:VUV-QDIss. 1
Position :Managing DirectorMark Campbell
Product SupportManager

16
TruvoxInternationalLimited
ThirdAvenue, Millbrook, Southampton, HampshireSO15 0LE, England
Tel:[phone] Fax:[phone]
e-mail:[e-mail]:www.truvox.com
Authoriseddealer:
