Truvox VBU User manual

UK-UPGRADEVBU-REV.00 (0119)
Upgrade VBU to VBUII User Guide
Latch Kit: 05-4759-000
THIS USER GUIDE SHOULD ALWAYS BE USED IN CONJUNCTION WITH THE USER MANUAL
Unzip and open the bag
compartment.
Remove the used vacuum bag
by pulling the green bag collar
tab away from the vacuum.
Firstly, ensure that the
machine is switched off.
Slide the bag out of the bag
holder which automatically
seals the bag opening and place
to one side.
Lay the machine on the floor and
undo the 4 screws surround the
vacuum bag holder using a cross-
head screwdriver.
Remove the vacuum bag
holder.
Remove the rubber gasket.
Remove the bag compartment.
Please note that the battery clamp
is currently positioned beneath the
lug on the handle duct.

UK-UPGRADEVBU-REV.00 (0119)
Please note that the latch is
also not symmetrical.
The battery clamp will be
positioned between (1) and (2)
when assembled.
Hold the latch against the
reverse side of the handle duct.
Note latch orientation.
Unscrew the 2 screws in the
battery clamp.
Remove the battery and battery
clamp.
Please note that the battery
clamp is not symmetrical.
Hold the battery clamp to the
handle duct without releasing
the latch.
Ensure that the latch and the
battery clamp are aligned
correctly as shown.
Secure the battery clamp to
the latch by screwing the 2
screws.



UK-UPGRADEVBU-REV.00 (0119)
Attach the battery to the
machine as shown so that the
latch makes a “Click” noise.
The battery is now removable.
To remove the battery, pull up
Return the machine to an upright
position and slot on the open
dust bag. Then Zip up the bag
compartment.
Lay the vacuum on its back and fit
the bag compartment (1) onto
the machine then replace the
rubber gasket (2) so that the
screw holes are aligned.
Replace the dust bag holder.
Secure the 4 screws
surrounding the vacuum bag
holder.
