TruXedo TRUXPORT Pro X15 User manual

It is the responsibility of the owner/user to read this manual and comply
with the operating procedures. The owner/user is also responsible
for inspecting the TruXedo cover, and for having parts repaired or
replaced when worn or damaged.
Failure to follow safety instructions and warning labels could result in
failure of your cover system and/or personal injury.
• Always wear safety glasses and/or other necessary protective
equipment when installing your TruXedo truck bed cover.
• These instructions are complete for most pickup models.
Additional instructions are included, if required for your truck.
Please read entire manual before installing your TruXedo
truck bed cover.
- Polyester/Vinyl cover can be hand washed with mild soap and water
or cleaned in a car wash. Thoroughly rinse cover to remove any
soap residue. For more maintenance info see page 7.
- It is recommended that you periodically check your Pro X15 cover
to make sure it is securely attached to your truck bed. Inspect
the clamps and front mounting bolts to ensure they were properly
installed and have not come loose or knocked out of adjustment
during operation. Covers that are used with high frequency or that
are subject to vibrations and impact from rough roadways can require
adjustment.
OWNER/USER RESPONSIBILITIES
MESSAGES TO INSTALLER
1. Do not place objects on or against cover or framework.
2. Do not tie cargo to tonneau cover framework.
3. Never allow children or pets to occupy pickup box
while cover is closed.
4. Cover is not airtight. Special care is required to
keep cargo clean and dry.
5. Fabric cover won’t prevent theft of contents inside
truck box.
6. Cover must be rolled fully open and secured with
safety straps when towing vehicle backwards.
7. DO NOT stow rolled cover against cab window.
8. Cover must be rolled fully open and secured with
safety straps if any part of the truck bed cover is
worn or damaged.
SAFETY INSTRUCTIONS
COVER MAINTENANCE
SOFT ROLL-UP TRUCK BED COVER
OWNER’S MANUAL
Pro X15
1
Warranty registration must be on le and/or proof of original
purchase (detailed and dated receipt) required for warranty
to be effective.

Components:
ABC D
E
Tools Required
1/2”
6x
3:
Correct
1:
B
2: If your pickup has factory bed caps you will need to install the
bulkhead seal supplied in the shipping box.
Bulkhead Seal
Bulkhead on
on inside of
truck bed.
Position Bulkhead seal
ush with the inside
edge of Bulkhead.
INSTALLING Pro X15 RAILS:
2
Cab
Position side rails. See step 4 and
5 for side rail position and clamping.
FRONT(Cab)

B B
ATTENTION: LIP OF
X15 RAIL SITS
ON TOP OF TRUCK
BED RAIL.
Truck Bed Rail.
4:
REAR (Tailgate)
FRONT(Cab)
3/8”
Approx.
3/8”Approx.
Compress foam seals approximately 50%
Align rail so foam is compressed
equally on both sides.
B
Tighten clamps
securely on
X15 rails before
driving vehicle.
WARNING
!
LEVEL
5:
ADJUSTABLE
CLAMP
6: Repeat steps 3-5 on passenger side for item C. Proceed to step 7 when complete.
Approx.
6-7in. on most
truck beds
It is recommended to close tailgate when positioning the rails.
INSTALLING Pro X15 RAILS CONT:
Approx.
6-7in. on most
truck beds
3
Adjust this part of the clamp upward
or downward to achieve a level rail.
LEVEL
For best results, rmly apply
downward pressure on rail while
tightening clamps.

7:
Note: The Pro X15 rail may need to be
tilted upward slightly to allow the screw
head to drop into oblong hole.
8: Slide header guides into lock position.
LEFT RIGHT
BUnhook and roll cover to the tailgate.
9:
CLOSING THE COVER:
INSTALLING COVER ASSEMBLY:
Front
Front
LOCKING COVER ASSEMBLY TO RAILS:
In some instances, the rail may need
to be forced up slightly for the header
guide to slide into position under the
rails.
4
Slide until you hear a CLICK!
Position cover roll to the front near the cab. Rotate header and screw head into oblong hole as
shown.
After front header is locked into place, rotate the header stabilizer screws clockwise until the front
header is secured with no back and forth movement.
Driver Side Shown Passenger Side Shown

B
B B
NOTE: If you have a locking
tailgate, truck bed cover is
secured until tailgate
is unlocked and opened.
11:
10:
A
A
A
B
1. Open tailgate
2. Pull latch on driver side to unlatch cover.
3. Roll Cover to front and secure with retainer straps.
13:
12:
CLOSING THE COVER CONT:
OPENING THE COVER:
Close tailgate, then cover
Tailgate
Note: Small wrinkles may be present after closing
cover for rst time. Remove wrinkles by pulling cover
material from each side. For best results have cover
unlatched. Relatch rear header after adjustments have
been made.
IMPORTANT:
Before driving vehicle, secure hook and
loop fastener by running your hand down
entire length of each X15 rail. This will
prevent wind lifting the cover and causing
damage.
SETTING HOOK AND LOOP FASTENER:
5
For cover to roll up evenly, make sure
control straps are evenly spaced on
driver and passenger side.
Control Straps
Rear Header
Tailgate

B
COVER TENSION ADJUSTMENT
AUTOMATIC
TENSION
CONTROL
•Spring plunger compensates for material expansion &
contraction caused by temperature changes.
•Check cover tension after installation, seasonally, and after
extreme temperature changes.
•For best performance, adjust tension regularly to protect
your cover against wind wear.
B
15:
Set tension during warmest/sunniest part of day.
1 With the cover closed, release hook and loop fastener from both side rails
near cab.
2 Check compression of both spring plungers in both rear header stops. Roll
cover open and make adjustments.
3 If cover is still too loose then re-adjust. Repeat until satisfactory tension
has been achieved.
Adjust HERE
B
!
14:
Secure
CAUTION
Before driving with cover open, BOTH STRAPS MUST
BE SECURED TO RETAINING LOOPS. Failure to do so
could cause accidental release of the cover, resulting in
personal injury or property damage.
CAUTION
ROLL COVER TIGHT AND SECURE BOTH RETAINER
STRAPS. DO NOT STOW COVER AGAINST CAB WINDOW.
Approx: 1/8in Plunger showing
6

HEADER WILL NOT LATCH:
Check Pro X15 rails to make sure they are level. See Step 5.
Make sure the rear header seal is not caught between side rail & rear header.
Check position of side rails on truck bed, they may be positioned incorrectly. See Step 4.
Make sure cover has proper tension. See Step 15.
THE COVER IS TOO TIGHT OR TOO LOOSE:
See Step 12 and 15.
SIDE RAILS TIP DOWNWARD OR UPWARD:
- Reposition clamp up or down, refer to step 5.
- In some cases, a small shim can be used to tip rails upward. Contact customer service for shim pack (1118036).
COVER LEAKS WATER:
- Cover is not designed to be fully water tight.
- Make sure clamps are tight and rails are positioned correctly.
- Extra seal can be added to help block water intrusions.
TOP OF COVER POOLS WATER:
- Certain amount of water pooling is normal with fabric covers.
- The cross tubes are not arched, therefore some water pooling may occur and is normal. This will not affect perfrom-
ace or the water management properties in this fabric.
- Make sure cover is pulled tight on each side and automatic tension control
is properly adjusted.
COVER ROLLS UP CROOKED:
- Make sure control straps are evenly set. See Step 13.
TROUBLESHOOTING
TROUBLESHOOTING FABRIC/ FABRIC CARE
1. Fabric top surface has wrinkles after rolling cover closed.
- Pull fabric taut from each side. For best results, the help of a second person pulling on the opposite side is
preferable.
2. Fabric top surface sags between cross tubes.
- Adjustment to automatic tension control may be required, refer to Step 15.
3. Wind lifts up edge of fabric.
- Make sure to engage hook and loop on driver and passenger side after closing the cover. This may need to be
done periodically when taking long trips.
4. Excessive fabric utter while driving.
- Check fabric tension, refer to Step 15.
- Make sure hook and loop fasteners are set, see step 12.
5. Snow and Ice accumulation on top surface.
- Use broom or brush to remove loose snow and ice. Do not use sharp or pointed tools to remove snow
and ice .
- Direct sunlight will help melt snow and ice from top surface.
6. How to Clean Fabric.
- Soap, water, and soft ne bristle brush.
7

TruXedo®Pro X15 Replacement Parts
1
11 5
3”
2
27
12
10
26
15
20
3
2
7
8
54
6
9
16
16
16
18
19
21
22
24
25
13
14
23
14
13
17
23
28
25
11 1705052 End Plug, 1” OD
12 ___*___ Aluminum Cross Tubes
13 1704660 Header Stop
14 1704658 Tension Control Housing & Spring Tension
15 1705787 Header Insert Safety Clip
16 ___*___ Hook and Loop Fasteners
17 1704709 Washer Plastic 5/16dia x 1.25 Rd
18 1705392 Aluminum Clamp Single (1)
1705391 Aluminum Clamp Pack (6)
19 ___*___ Pro X15 Rail, Passenger’s Side
20 ___*___ Pro X15 Rail, Driver’s Side
21 1705727 Flat Spring, 5/8” x 3 7/8”
22 1704213 Latch Assembled
23 1702926 Cap Screw, 5/16” x 7/8”
24 1118193 Rear Side Rail End Plugs w/Seal Pro X15 (Set of Two)
25 1705629 Square Head Screw (#1 Drive)
26 1118192 Rear Header End Plugs Pro X15 (Set of Two)
27 ___*___ Black Rear Header
28 1118248 Front Side Rail End Plugs w/Seal Pro X15 (Set of Two)
29 1117428 Front Header Stabilizer.
30 1703332 Pin, Hitch_1/16” Dia.x 1-5/16” long.
1___*___ TruXedo®Pro X15 Replacement Cover
2___*___ Black Front Header
3___*___ Header Seal Front
41118191 Front Header End Plugs ProX15 (Set of Two)
51704707 Header Guide
61704689 Machine Screw 1/4-20 X 9/16”
7___*___ Safety Strap
81117594 Header Guide Retainer Assembly
9___*___ Extruded Retainer Loop
10 ___*___ Header Seal Rear
* Please specify length or make and model of vehicle.
3
8
29
30
