TruXedo Truxport Quick start guide

P/N 1118056 REV D
___ 1 ___
Owners & Installation Manual
READ INSTRUCTIONS - Failure to assemble cover properly will void warranty.
Damaged or missing parts?
Call 1-877-878-9336
Mon - Fri 8 am - 5 pm CT
Parts will be shipped to you factory direct.
Do not return kit to place of purchase.
Tools Required:
1/2” Socket
3/8” Drive Ratchet
Scissor
Specify length or make and
model of vehicle to inquire
about headers, cover, side
rails, or bows.
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com

___ 2 ___ P/N 1118056 REV D
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com
1Remove rear cargo plugs from cargo rails. Reinstall
after TruXedo side rails are installed, see step 12.
Remove cargo cleats
if equipped.
Slide three female clamp halves
(item 4) into the driver side and
passenger side cargo rail.
23
Item Part # Description
1. 1705550 Screw Hex HD_5/16-18 x 2 1/4
2. 1700428 Washer, 5/16”
3. 1705547 Clamp Half, Male
4. 1704595 Clamp Half, Female
Replacement Parts List
1
2
4
3
After TruXedo side rails are installed
the cargo cleats can be reinstalled,
see step 12.

___ 3 ___
Set cover assembly on front
bulkhead:
6
7
place three clamps on each
side rail to keep rails in place
parallel to bulkhead
- Place side rails on truck bed rails.
- Assemble rear clamps as shown.
This will hold side rails in place.
- Insert side rail corner plugs in front header.
Install weather seal on cab end
corner plugs: 5
weather seal
corner plug
insert
insert
rear clamp
P/N 1118056 REV D
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com
4
place in outside
groove
place in middle
groove
place in inside
groove
Detail 8a
Detail 8b
Detail 8c
Place remaining clamps. Notice: Each clamp assembly, starting at the front
then to back, has a special groove alignment. See detail 8a, 8b,and 8c.

weather
seal
10
9
___ 4 ___
Tighten Center Clamps:
Tighten rear
clamps:
Tighten front clamps:
11
12 Install weather seal on
tailgate corner plugs:
corner plug
P/N 1118056 REV D
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com
Align cover with pickup bed:
8
center
on
beD
position
side rail
align grooves in
clamp with grooves
in side rail
align top clamp
in middle groove
setting.
align top clamp
in outside groove
setting.
align top clamp in
the inside groove
setting.
leave 1/8” clearance
between tailgate header
and side rails.
top view
1/8”
1/8”
cover not shown
for clarity
13
reinstall cargo
cleats and cargo
rear plugs.
center
side
rails
and
tailgate
header
on
pickup
bed
align grooves in
clamp with grooves
in side rail
clamp

___ 5 ___
P/N 1118056 REV D
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com
Close cover:
Open cover:
14
16
• To prevent accidental release of tailgate header, ensure header is securely latched to side rails on
both sides of pickup bed before driving vehicle.
• To prevent wind lift, secure loop and hook fasteners along entire length of both side rails before
driving vehicle.
!
Cover tension: There is no need to adjust cover length tension. The Latch Assembly is set to the correct
tension. Any modication done to this will VOID warranty.
For ease of operation, periodically
clean with high pressure water to
remove dirt and dust.
15
latch assembly
Keeping cover taut:
Periodically or as needed, pull cover tight across width
of pickup bed, secure loop and hook on side rails.
Cover may appear loose or relaxed in cooler or cold conditions.
Cover may appear tight in warmer or hot conditions.
Use both hands to close!!!
space wide
Latch not fully engaged!!!
Latch fully engaged!!!
Both latches must be fully engaged!!!
D
Secure loop to hook
fasteners on one side
rail by pressing edge of
cover along full length
of rail.
E
Pull cover tight across
width of pickup bed.
Secure loop and hook
fasteners on opposite
side rail.
A
Release retainer
straps, and unroll cover
over pickup bed. Open
tailgate.
B
With tailgate open,
hook tailgate header
into header stops on
both sides of vehicle.
C
Rotate tailgate header
down until both latches
engage. Listen for
double click.
Tailgate
Header Header
Stop
Dretainer
straps
C
With tailgate open, press downward
on rst latch to release.
To release second latch, repeat
process on opposite side. Place
free hand on tailgate
header to control header
movement on release.
Roll up cover. Do Not
disengage loop and hook
fasteners prior to rolling up cover.
AB
First Latch Second Latch
Latch
Engaged
Tailgate
Header
Tailgate
Header Always secure
cover at front of pickup
bed with both retainer straps
when cover is open.
“Opened cover must be rolled
tight, securely cinched down,
and away from the cab and
window with both retainer straps
when driving vehicle”. DO NOT
STOW COVER AGAINST
TRUCK CAB OR BACK
WINDOW.

___ 6 ___
Replacement Parts
P/N 1118056 REV D
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com
1
2
3
4
8
6
23
16
19
17
10
11
7
13
9
5
23
14 15
12
24
16
22
18
1_______ Truxport®Cover
2_______ Bow
31705421 Corner Plug
4_______ Cab End Header
51705420 Corner Plug
6 _______ Passenger’s Side Rail
71116028 Retainer Clips
81705548 Clamp Assembly
9______ Driver’s Side Rail
10 1703569 End Plug, Driver Side
11 1703570 End Plug, Pass. Side
12 1705422 Large Rear Header Eng Plug Driver Side
13 1705423 Large Rear Header End Plug Pass. Side
14 1704536 Small Rear Header End Plug Driver side
15 1704537 Small Rear Header End Plug Pass.
16 1703568 Four Corners Weather Seal
17 1117868 Latch Driver Side
18 1117869 Latch Passenger side.
19 1703560 Flat Head Cap Screw
20 Tailgate Header
21 _______ Hook Fastener
22 _______ Rear Header Seal
23 1705629 Self-Drilling Screw sq Dr., #6 X 3/8”
24 1703750 Decal Dual Latch
25 1118160 Retainer Strap
26 1705761 Retainer Loop
* Please specify length or make and model of vehicle.
*
*
*
*
*
*
*
16
16
24
*
8
23
23
21
21
19
20
7
26
25

1. Do not place objects on or against cover or framework.
2. Do not tie cargo to TruXport framework.
3. Never allow children or pets to occupy pickup box while
cover is closed.
4. Cover is not airtight. Special care is required to keep
cargo clean and dry.
5. Fabric cover won’t prevent theft of contents inside truck
box.
6. Cover must be rolled fully open and secured with retainer
straps when towing vehicle backwards.
7. Rolled opened cover must be tightly rolled, securely
cinched down with both retainer straps, and away
from the cab and window. DO NOT STOW COVER
AGAINST TRUCK CAB OR BACK WINDOW.
8. Cover must be rolled fully open and secured with retainer
straps if any part of the truck bed cover is worn or
damaged.
SAFETY INSTRUCTIONS
Warranty registration must be on le and/
or proof of original purchase (detailed and
dated receipt) required for warranty to be
effective.
Register online at www.truxedo.com
FIVE YEAR WARRANTY
TruXedo, Inc. warrants that all new, unused products are free
from defects in material and workmanship. This Five Year Limited
Warranty is effective if the product is properly installed and used
for the purpose intended. It applies to the original buyer only.
TruXedo’s obligation under this Warranty is limited to repairing,
or at its option, replacing any part that is returned, transportation
prepaid, to TruXedo, Inc., Yankton, South Dakota, if the product is,
in our judgment, defective. All materials must be accompanied by
an RMA (Returned Material Authorization) number requested by
and authorized in advance of returning the materials. TruXedo, Inc.
shall not be liable or responsible to supply or pay labor to replace
any part found defective, nor shall it be liable for any damages of
any kind or nature to person, product, or property.
Thereare noWarranties forused productsor productsthat havebeen
repaired, altered, modied, subjected to misuse, negligence, accident
or ordinary wear and tear. Warranty registration must be on le and/
or proof of original purchase (detailed and dated receipt) required
for warranty to be valid. Register online at www.truxedo.com
It is the responsibility of the owner/user to read this manual and
comply with the operating procedures. The owner/user is also
responsible for inspecting their TruXport®cover, and for having
parts repaired or replaced when worn or damaged.
Failure to follow safety instructions and warning labels could result
in failure of your cover system and/or personal injury.
• Always wear safety glasses and/or other necessary protective
equipment when installing your TruXport®.
• These instructions are complete for most pickup models.
Additional instructions are included, if required for your pickup.
Please read entire manual before installing your TruXport®.
Vinyl cover can be hand washed with mild soap and water or cleaned
in a car wash. Thoroughly rinse cover to remove any soap residue.
Recommended to use the tested and approved Protex cleaner
or any vinyl protectant made for truck bed covers. Never use
any vinyl conditioners (ie, Armor All®) that contain
silicone, petroleum, or citrus based products on
your truck bed cover as they may crack and shrink
the vinyl.
DIRECT ALL WARRANTY CLAIMS TO TRUXEDO, INC. AT 1-877-878-9336
Questions?
Call our friendly customer service staff
at TruXedo, Inc. Toll Free:
1-877-878-9336
Mon - Fri 8 am - 5 pm CT
COVER MAINTENANCE
MESSAGES TO INSTALLER
OWNER/USER RESPONSIBILITIES
___ 7 ___
WARNING
Tighten clamps securely on side rails before driving
vehicle, to prevent cover from blowing off.
!
TruXedo, Inc.
P.O. Box 1078, 2209 Kellen Gross Dr., Yankton, South Dakota 57078
Call Toll Free: 1-877-TRUXEDO (1-877-878-9336) Fax: [phone]
Visit Us Online: http://www.truxedo.com P/N 1118056 REV D
