Rear view safety RVS-770615 User manual

1
TM

• 2 Color CCD Infra-red Weather Proof Cameras
• 1-7" F LCD Color Monitor wi/Universal Mount/Stand & Wire
• 1-3 Channel Multiplexer Control Unit
• 2-66’ Extension Cable for Cameras
• Remote Control
• 1 Power Connection Wire
• 1 Double RCA + Power Converter
(to connect external audio, video and power)
• 1 Screw Kit for installation
What’s in the Box?

3
Table of Contents
Introduction...................................................................................4
Safety Information....................................................................5-7
Before Beginning Installation ......................................................8
Installation Guide..........................................................................9
Wiring Camera & Monitor....................................................10-11
Installation Diagram ...................................................................12
Installing the Monitor ................................................................13
Monitor Operation......................................................................14
Splitting & Splicing ....................................................................15
Positioning ................................................................................. 16
Multiplexer ..................................................................................17
Monitor Dimensions ...................................................................18
Monitor Specifications ...............................................................19
Camera Dimensions ....................................................................20
Camera Specifications.................................................................21
roubleshooting..........................................................................22
Warranty ......................................................................................23
Disclaimer ....................................................................................24

REAR VIEW SAFETY
4
Introduction
Congratulations on purc asing a Rear View Backup Camera
System. Wit t is manual you will be able to properly install
and operate t e unit.
T e Backup Camera System is intended to be installed as a
supplement aid to your standard rear view mirror t at already
exists in your ve icle. T e Backup Camera System s ould not
be used as a substitute for t e standard rear view mirror or
for any ot er mirror t at exists in your ve icle.
In some jurisdictions, it is unlawful for a person to drive a
motor ve icle equipped wit a TV viewer or screen located
forward of t e back of t e driver’s seat or in any location
t at is visible, directly or indirectly, to t e driver w ile
operating t e ve icle.
Please read all of t e installation instructions
carefully before installing t e product. Improper
installation will void manufacturer’s warranty.

5
Reverse With Confidence™
Safety Information
Ple se re d the entire m nu l nd follow the instructions
nd w rnings c refully. F ilure to do so c n c use serious
d m ge nd/or injury, including loss of life. Be sure to obey
ll pplic ble loc l tr ffic nd motor vehicle regul tions s
it pert ins to this product. Improper inst ll tion will void
m nuf cturer’s w rr nty.
USAGE
•The Rear View Camera System
is designed to help the driver
safely detect people and/or
objects helping to avoid
damage or injury. However,
you the driver, must use it
properly. Use of this system is
not a substitute for safe,
proper or legal driving.
•Never back up while looking
at the monitor alone. You
should always check behind
and around the vehicle when
backing up, in the same way
as you would if the vehicle
did not have the Rear View
Camera System. If you back
up while looking only at the
monitor, you may cause
damage or injury. Always
back up slowly.
•The Rear View Camera Sys-
tem is not intended for use
during exstensive back-up
maneuvers or backing into
cross traffic or pedestrian
walkways.
•Please, always remember,
the area displayed by the
Rear View Camera System is
limited. It does not display
the entire panorama that is
behind you.

REAR VIEW SAFETY
6
INSTALLTION
•Electric shock or product
malfunction may occur if
this product is installed
incorrectly.
•Use this product within
the voltage range specified.
Failure to do so can cause
electronic shock or product
malfunction.
•Take special care when
cleaning the monitor.
•Make sure to firmly affix the
product before use.
•If smoke or a burning smell
is detected, disconnect the
system immediately.
•Where the power cable may
touch a metal case, cover the
cable with a friction tape. A
short circuit or disconnected
wire may cause a fire.
• While installing the Rear
View System be careful with
the wire positioning in order
to avoid wire damage
The Rear View System should
only be used when the vehi-
cle is in reverse.
Do not watch movies or
operate the monitor while
driving; as it may cause an
accident.
Do not install the monitor
where it may obstruct drivers
view or obstruct an air bag
device.
Dropping the unit may cause
possible mechanical failure.
Safety Information

7
Reverse With Confidence™
Safety Information
IN NO EVENT SHALL SELLE O MANUFACTU E BE
LIABLE FO ANY DI ECT O CONSEQUENTIAL DAMAGES OF
ANY NATU E, O LOSSES O EXPENSES ESULTING F OM
ANY DEFECTIVE P ODUCT O THE USE OF ANY P ODUCT.
If you have questions about this product, contact:
Customer Service:
ear View Safety
1797 Atlantic Avenue
Brooklyn, NY 11233
Tel: [phone]

REAR VIEW SAFETY
8
Before Beginning Installation
Before drilling please check that no cable or wiring is on the
other side of the wall. Please clamp all wires securely to reduce
the possibility of them being damaged while vehicle is in use.
Keep all cables away from hot or moving parts and electrical
noisy components.
We recommend doing benchm rk test before inst ll tion
to insure th t ll components re working properly.
Step 1: Choose the monitor and camera locations.
Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm)
hole should be drilled for passing camera cable through vehicles
walls. Install split grommets where applicable
Step 3: Once all cables and wiring have been properly placed
routed, perform a system function test by temporarily connecting
he system. If the system seems to not be operating properly see
troubleshooting
Before Beginning Installation

9
Reverse With Confidence™
Installation Guide
C mer
1. Attach camera bracket close to rear marker lights, centered
on vehicle.
2. Attach camera to bracket using screws provided and adjust
the angle.
C ble
1. Be sure to position the cable properly. The aviation camera
cable uses aircraft grade connectors which means the camera
cable can be exposed to all weather elements, do not run the
cable over sharp edges, do not kink the cable and keep away
from HOT and rotating parts.
2. Fasten all cable and secure all excess cable.
Monitor
1. To Attach the Pedestal mount to the dashboard or
to the headliner using self-tapping screws and/or
adhesive pad.
2. Attach monitor to mount, and adjust mounting angle to allow
optimum driver viewing comfort. (see figure 1.1 on page 12)

REAR VIEW SAFETY
10
Wiring Camera & Monitor
•When installing a ONE (1)
camera setup, connect camera
extension cable from the rear
view camera to port # labeled
“backup” (most systems port 3)
Connect red 12V+ wire to igni-
tion power source and black
wire 12V- to chassis ground. Do
not use white and yellow wires.
•The blue wire is the REVERSE
trigger wire. In typical rear-view
installations, connecting this
wire to the vehicle’s backup
light circuit will activate the
rear-view image whenever the
vehicle shifts into reverse.
•Before drilling, be sure no cable
or wire is on the other side.
•Feed as much cable as possible
into vehicle and clamp
securely. This reduces the
possibility of cable being
hooked or snagged.
•Camera: Drill a 20mm (0.8in)
diameter hole into
vehicle body near the camera
and bracket. Insert camera
cable into vehicle (be careful
not to kink cable) and fit
grommet into hole. Apply
sealant around grommet to
increase resistance to water
penetration. Connect camera
to the camera extension cable
which runs inside the vehicle.
•The camera system can be wired
to be powered “ON” the entire
time the vehicle is activated and
this is typical in RV and some
Commercial applications.
•The camera and monitor can
always be activated by manu-
ally pushing the power button
on monitor this is in addition to
utilizing the positive triggers.
Note: If connecting power
directly to battery, the camera
is always ON and therefor can
drain battery, therefore its
recommended to connect
power to an ignition switched
accessory power source.

11
Reverse With Confidence™
Wiring Camera & Monitor
•Audio works on two ports of
multiplexer and positive triggers
must be triggered for audio to
operate. #3 Port labeled “backup”
(blue trigger) #2 port labeled
“DVD” (white Trigger).
•When installing a TWO (2)
camera setup, use ports #3 and
#2 and use positive triggers
Blue and White.
•There is a built-in voltage
regulator for our systems which
can handle 12-24 volts real
consumption is 10 to 30 Volts.
•When installing all THREE (3)
cameras, use all three ports and
connect all positive triggers to
appropriate connections.
✦To automatically have camera
and monitor turn ON when
vehicle activates, simply twist
B UE positive trigger 12V+ to
Red Power line 12V+ and wire
to ignition power which can
be an accessory switch/fuse
line and black wire 12V- to
chassis ground.
✦Infrared technology built into
camera IRs are activated auto-
matically according to the
lighting conditions.
✦When using the postive trigger
functions (blue, yellow & white
wires) each trigger function
needs to work on a seperate
12V+ source i.e. the Yellow
and White wires can be wired
to a turn signal circuit etc.
✦Grid lines function can be
turned on/off by pushing
MENU 8 times and than select
ON/OFF

REAR VIEW SAFETY
12
Installation Diagram
Connection of U Bracket Connection of
Flushmount Bracket
On Select Models
Figure 1.1 Figure 1.2
Figure 1.3 Figure 1.4

13
Reverse With Confidence™
Installing the Monitor
1
2
3
4
5
20m Extension Cable
20m Extension Cable
Multiplexer
Monitor
Camera 2
Camera 3
Camera 1
1. DC12 -24 (red)
2. Ground (black)
3. Port #3 (blue)
4. Port #2 (white)
5. Port #1 (yellow)
3 Amp Fuse
ideo Out

REAR VIEW SAFETY
14
Monitor Operation
MENU
REV
CAM
▼
▼
POWER
ON / OFF
MENU/
SELECTION
BUTTON
CAMERA
SELECTION
DOWN
ARROW
UP
ARROW
ROTATION
IMAGER
(Exit when in
MENU mode)
• To turn on the monitor, press “ON” button.
• To adjust brightness, press “MENU” 1 time and use arrows
• To adjust contr st, press “MENU” 2 times and use arrows
•To adjust s tur tion, press “MENU” 3 times and use arrows
•To adjust sh rpness, press “MENU” 4 times and use arrows
•To adjust volume, press “MENU” 5 times and use arrows
•To change l ngu ge, press “MENU” 6 times and use arrows
•To activate rot te im ge option, press “MENU” 7 times and use arrows.
When on, to rotate image, press, “ROTATION IMAGER” button
•To adjust dist nce grid, press “MENU” 8 times and use arrows
•To adjust grid position, press “MENU” 9 times and use arrows
•To activate d y/night option, press “MENU” 10 times and use arrows
•To reset your system, press “MENU” 11 times and use arrows
•To view images on other cameras, press “CAMERA SE ECTION”
1 time for camera one, 2 times for camera two and 3 times for camera three.

15
Reverse With Confidence™
Splitting & Splicing
Installing & Splitting Embedded Monitor
Inst lling sun shield: Put shade cover on
the display. Inst lling b ck cover: Put the
monitor with shade cover in the back cover
(only for embedded monitor)
Splitting b ck cover: Hold monitor with 2
hands and detach with fingers, as indicated
by arrows. (only for embedded monitor)
Splitting sun shield: Take the monitor with
the left hand and detach with right hand as
indicated by the white arrow. (see below)
Splicing
1. Red - Power (+)
2. Yellow - ideo
3. Green - Mirror / Normal Imaging
4. White - Audio
5. Black - Ground (-)
1.
2.
3.
4.
5.

REAR VIEW SAFETY
16
Positioning
Re r C mer s Positioning

17
Reverse With Confidence™
Multiplexer
Port #1 Port #2 Port #3
or D D Backup

REAR VIEW SAFETY
18
Monitor Dimensions
with sun shade
5.25”
7”
Some Models
Power
On/Off
Menu/
Selection
Button
Camera
Selection
Down
Arrow
Up
Arrow
Rotation
Imager
(Exit in
Menu
Mode)
power
video select
down/up
menu
mirror/normal

19
Reverse With Confidence™
Monitor Specifications
TFT LCD Digital Monitor
Screen Size 7”
Dot Resolution 800Hx 3 (RGB) 480V
Display Format 16:9 / 500:1
Display Brightness 400cd/m2
Viewing Angle U:50° / D:60° / R:70°
Video Input 3 channel
Video Source 1Vp-p, 75Ω
Power Supply DC 12V-24V (+/- 10%)
Power Consumption 5W
Operating Temperature -30°C ~ +80° C
Video System Auto NTSC/PA
Overall Dimensions 7” x 5”Hx 1”D
Weight 400G
Impact Rating 5G
Dot Pitch 0.192Hx 0.1805V
Sync System Internal

REAR VIEW SAFETY
20
Camera Dimensions
3”
3.25”
Re r C mer
