Tunturi C65 F User manual

www.tunturi.com
Attention, Achtung, Attention, Attentie, Attenzione, Atención, Giv akt, Huomio
- Please read this Owner’s manual before assembling this product.
- Bitte lesen Sie dieses Handbuch durch, bevor Sie mit er Montage dieses Produkts beginnen.
- Veuillez lire ce manuel avant de commencer le montage de ce produit.
- Leest u deze handleiding voordat u dit apparaat installeert.
- Leggere questo manuale prima di assemblare questo prodotto.
- Lea este manual antes de montar este producto
- Läs bruksanvisningen innan du monterar denna produkt
- Lue tämä käsikirja ennen kokoamista tuotetta
WWW
C65 F Crosstrainer
EN957
Class HB
Made in China
RoHS
2011/65/EU
i
SN:
HOME USE
MAX USER WEIGHT: 135 KGS
300 LBS
INPUT: AC 110 - 220~240V
SKU: 20TCF65000
Crosstrainer C65-F
50-60HZ 2.3 Amp.
GB User manual 24 - 31
