Tunturi Pure Compact Smith User manual

COMPACT SMITH
140610
GB
IMPORTANT: Please read this manual before commencing assembly of this product.
NL BELANGRIJK: Lees deze handleiding aandachtig door alvorens dit product te monteren.
FR IMPORTANT :Veuillez lire attentivement les instructions avant l’assemblage du produit
I IMPORTANTE: leggere il presente manuale prima di iniziare a montare il prodotto.
DE WICHTIG: Bitte lesen Sie dieses Handbuch, bevor Sie mit der Montage dieses Produkts beginnen
ES IMPORTANTE: Lea este manual antes de comenzar a ensamblar el producto.
RU ВНИМАНИЕ: Пожалуйста, прочтите данное руководство перед сборкой изделия.

Tunturi Pure Strength www.tunturi-fitness
.com
1
Table of Contents / Inhoudsopgave / Tables des Matieres / Sommario
/ Inhalt / Índice / Содержание
1. English P 2
2. Nederlands P 12
3. Français P 22
4. Italiano P 32
5. Deutsch P 42
6. Español P 52
7. Русский язык P 62

Tunturi Pure Strength www.tunturi-fitness
.com
2
IMPORTANT SAFETY PRECAUTIONS
This bench is built for optimum safety. However, certain precautions apply whenever
you operate a piece of exercise equipment. Be sure to read the entire manual before
you assemble or use your bench. In particular, note the following safety precautions:
1. Keep children and pets away from the bench at all times. Do not leave children
unattended in the same room with the bench. The bench is not a toy and therefore
parents and guardians should be aware of the natural tendency for children to
play, leading to situations and behaviour for which the bench is not intended.
2. If children are allowed to use the bench their physical/mental development and
above all, temperament should be taken into account. Constant supervision is
therefore needed.
3. Only one person at a time should use the bench.
4. If the user experiences dizziness, nausea, chest pain or any other abnormal
symptoms, STOP the workout at once. Consult a physician immediately. Injuries
may occur due to incorrect or excessive exercise.
5. Position the bench on a clear levelled surface which is clear of all obstacles as not
to restrict movement whilst exercising. DO NOT use the bench near water or
outdoors.
6. Keep hands away from all moving parts
7. Always wear appropriate clothing when exercising. DO NOT wear robes or other
clothing that could become caught in the bench. Running or aerobic shoes are also
required when using the bench.
8. Use the bench only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
9. Do not place any sharp objects around the bench
10. Disabled persons should not use the machine without a qualified person or
physician in attendance.
11. Before using the bench to exercise, always do stretching exercises to properly
warm up.
12. Never use the bench if it is not functioning properly.
13. This product is intended for H=Domestic use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. TUNTURI NEW FITNESS B.V. ASSUMES NO RESPONSIBILITY
FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

Tunturi Pure Strength www.tunturi-fitness
.com
3
IMPORTANT ASSEMBLY INFORMATION
Tools Required for Assembling the Bench: Two Adjustable Wrenches and
Allen Wrenches.
NOTE: It is strongly recommended that this machine is assembled by two
or more people to avoid possible injury.
Ensure Carriage Bolts are inserted through the SQUARE holes on
components that need to be assembled. Attach washer only to end of the
Carriage Bolt.
Use Allen Bolts or Hex Bolts inserted through the ROUND hole on
components that need to be assembled.
Always wait until all bolts are assembled onto the bench before tightening the
bolts. Do not fasten each bolt right after it is installed
Fasten Nuts and Bolts
Securely tighten all Nuts and Bolts after all
components have been assembled in current and
previous steps.
NOTE: Do not over tighten any component with
pivotal function.
Make sure all pivotal components are able to move
freely.
Do not tighten all Nuts and Bolts in this step.

Tunturi Pure Strength www.tunturi-fitness
.com
4
WARNING LABEL PLACEMENT
Warning label affixed here.

Tunturi Pure Strength www.tunturi-fitness
.com
5
CARE AND MAINTENANCE
1. Lubricate moving parts with WD-40 or light oil periodically.
2. Inspect and tighten all parts before using the equipment.
3. The machine can be cleaned using a damp cloth and mild non-abrasive
detergent.
DO NOT use solvents.
4. Examine the equipment regularly for signs of damages or wear.
5. Replace any defective components immediately and/or keep the equipment out
of use until repair.
6. Failure to examine regularly may affect the safety level of the equipment.
WEIGHT CAPACITY AND DIMENSION
1. Maximum weight on bench (including user weight) : 270kg
2. Maximum weight on Weight Bar: 135kg
3. Maximum weight on Leg Developer weight post: 45kg
4. Maximum weight on each Weight Storage Post (part #1): 90kg
5. Assembled Dimension (L x W x H): 199cm x 181cm x 200cm
6. Folded Assembled Dimension: (L x W x H): 87cm x 181cm x 200cm
BACKREST ADJUSTMENT ANGLES
Backrest decline adjustment angle ranges from -13
0
to 58
0
.

Tunturi Pure Strength www.tunturi-fitness
.com
6
Folding Bench
1. Pull out the U-shaped Lock Pin (#28) and then drop the Pin into the hole on Leg
Developer to lock the Leg Developer (#7) in position.
2. Loosen and pull out Lock Knob (#51) to slide the Backrest Board to lowest position.
3. Pull down the Lock Rod Handle (#24) to move the Lock Rod out of the lock hole;
raise and fold up the Main Seat Support (#2). Release the Lock Rod Handle and
bounce Lock Rod back to the lock hole to lock the Main Seat Support in vertical
position.
4. To un-fold bench, just pull down the Lock Rod Handle to move the Lock Rod out
the lock hole, and then pull down the Main Seat Support, release the Lock Rod
Handle to bounce the Lock Rod back to the lock hole.

Tunturi Pure Strength www.tunturi-fitness
.com
7
PARTS LIST
KEY
NO. DESCRIPTION SIZE QUANTITY
1 Weight Storage Post 2
2 Main Seat Support 1
3 Sliding Block 1
4 Seat Support 1
5 Backrest Support 1
6 Leg Developer Holder 1
7 Leg Developer 1
8 Incline Support 2
9 Arm Curl Stand 1
10 Fold Up Bracket 1
11 Foam Tube Ø 25mm x 410mm 3
12 Weight Post Sleeve Ø 30mm x 200mm 3
13 Cross Brace 1
14 Upright Base 2
15 Left Upright 1
16 Right Upright 1
17 Guide Rod 2
18 Safety Stop Frame 2
19 Left Lower Safety Catch 1
20 Right Lower Safety Catch Ø 12mm x 164mm 1
21 Lifting Sleeve 1
22 Bracket 160mm x38mm 2
23 Weight Bar 1
24 Lock Rod Handle 1
25 Lock Rod Cap M18 x 18mm 1
26 Lock Rod Ø 16mm x M10 x 135mm 1
27 Spring Ø 11.5mm x 78mm 1
28 U-shaped Lock Pin 1
29 Sleeve 50mm x 70mm 2
30 Sleeve 50mm x 45mm 1
31 Wight Post Sleeve Ø 28mm x 200mm 3
32 Sliding Sleeve Ø 55mm x Ø 46mm 4
33 Main Seat Support Floor Cap 1
34 End Cap 60mm x 30mm 2
35 End Cap Ø 25mm 5
36 End Cap Ø 19mm 2
37 Rubber Bumper Ø30mmx Ø25mmx30mm 1
38 Flat End Cap 38mm x 38mm 2
39 End Cap 45mm x 45mm 3

Tunturi Pure Strength www.tunturi-fitness
.com
8
40 End Cap 38mm x 38mm 1
41 End Cap Ø 19mm x 50mm 2
42 End Cap 40mm x 20mm 4
43 Bushing Ø 50mm x Ø 16mm 2
44 Foam Roll End Cap 6
45 Foam Roll 6
46 Weight Post Sleeve Ø 50mm x 335mm 2
47 Weight Post Sleeve Ø 50mm x 210mm 3
48 Spring Clip Ø 49mm 5
49 Spring Clip Ø 24.5mm 5
50 Lock Knob M18 x Ø 10mm 1
51 Lock Knob M18 x Ø 12mm 1
52 Spring Ø 12mm x 55mm 1
53 Axle Ø16mm x M10 x 59mm 1
54 Cover Cap M8 2
55 Cover Cap M10 23
56 Cover Cap M12 10
57 Quick Release Lock Pin 1
58 Ball Bearings Sleeve 4
59 Cover Panel 4
60 Base Floor Cap 4
61 Lock Rod Handle Cap 1
62 Seat Pad 1
63 Backrest Board 1
64 Arm Curl Pad 1
65 Bushing Ø 25mm x Ø 21.8mm 6
66 Ball Bearings LB254058 4
67 Hex Bolt M12 x 100mm 1
68 Hex Bolt M12 x 95mm 2
69 Hex Bolt M12 x 185mm 2
70 Hex Bolt M10 x 85mm 2
71 Hex Bolt M10 x 50mm 2
72 Hex Bolt M10 x 40mm 2
73 Hex Bolt M8 x 30mm 1
74 Carriage Bolt M10 x 110mm 4
75 Carriage Bolt M10 x 60mm 8
76 Allen Bolt M10 x 20mm 3
77 Allen Bolt M8 x 45mm 1
78 Allen Bolt M8 x 20mm 8
79 Phillips Screw M6 x 55mm 6
80 Phillips Screw M6 x 7mm 4
81 Phillips Screw M6 x 10mm 1
82 Allen Bolt M8 x 10mm 4

Tunturi Pure Strength www.tunturi-fitness
.com
9
83 Phillips Self Tapping Screw ST4.0 x 9mm 8
84 Washer Ø 12mm x Ø 6.4mm 12
85 Washer Ø 16mm x Ø8.4mm 11
86 Washer Ø 20mm x Ø10.5mm 25
87 Washer Ø 24mm x Ø13.5mm 10
88 Washer Ø 38mm x Ø21mm 1
89 Washer Ø 25mm x Ø11mm 1
90 Aircraft Nut M12 5
91 Aircraft Nut M10 17
92 Aircraft Nut M8 1
93 Aircraft Nut M6 6
Allen Wrench (Tool) 4# 1
Allen Wrench (Tool) 5# 1
Allen Wrench (Tool) 6# 2
