Tuohy Carina User manual

INSTALLATION GUIDE
Carina Tables
December 18, 2019

Table of Contents
Base Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power Drawer Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Subtop Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Top Trim Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Top Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Panel Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1
BASE ASSEMBLY
1. Set bases in desired location, level bases
2. Attach base sections using #9 x 1-1/4" Flat Head Screws
#9 x 1-1/4"
Flat Head Screws
#9 x 1-1/4"
Flat Head Screws
#9 x 5/8" Pan
Head Screws
* Attach angle irons to base with
# 9 x 5/8" Pan Head Screws
End Base
End Base
Center Base
(quantity may
differ than what
is shown.)

2
POWER DRAWER INSTALLATION
* Skip to page 3 for tables with no power drawers.
End panels must be removed for power
drawer installation. Remove by undoing
cam bolts and sliding panel off.
* Power drawers are labeled for location. Place drawers in
correct location and attach drawer cable chains to
support shelving using #9 x 5/8 Pan Head Screws.
* Table should be wired once
cables are attached to support
shelves for full access to run wires.
Allow drawers to hang
over the edge of the base
and rest on the floor to
attach cable chains.
Chains on long side of table attach to top of
support shelf, chain on short end of table
attaches to underside of support shelf.
Attach using #9 x 5/8 Pan Head Screws.
Chains on short ends of table
are to run under chains on
long sides of table.

3
SUBTOP ATTACHMENT
* Place subtop onto base assembly and join
together using field joints (see details A and B)
* Screw subtop to base using #9 x 5/8" Pan Head Screws.
Attach drawer to subtop
screwing through angle
bracket into subtop using
#9 x 5/8" Pan Head
Screws 3/8" gap above drawer.
Properly installed drawer leaves
approximately 3/8" gap above drawer,
and 1/16 gap on each side of drawer.
1/16" equally spaced gaps
on each side of drawer.
Join subtops using
field joints.
(See details A & B) Screw subtop to base
using #9 x 5/8" Pan
Head Screws.
Field Joints
Detail A
Detail B
(Top Surface)

4
TOP TRIM ATTACHMENT
* Trim and subtop are labeled to allow trim to fit properly.
Place trim in correct location matching the labels
and screw into subtop using #6 x 5/8 Flat Head Screws.
Attach trim to subtop
using #6 x 5/8 Flat
Head Screws
TOP ATTACHMENT
* Veneer and Laminate Fenix tops: Screw up through subtop using # 10 x 2" Flat Head Screws.
* Glass, Stone, and Avonite tops attach to subtop using silicone adhesive.
Metal overhangs
subtop by 1/4"
Do NOT put screws
over drawers.
Edge Profile

5
PANEL ATTACHMENT
* Re-attach end panels prior to
installing side panels
Re-attach end
panels if they
were removed for
power drawer
access.
Snap side panels into
place by bringing panel in
towards base and locking
down into place aligning
with button fixes.
Button fixes
lock by
sliding part
A down
onto part B.
Part A
Part B
