Tuohy Tryg User manual

INSTALLATION GUIDE
Tryg Tables
April 1, 2017

1
#9 x 1 3/4"
Flat Head
Screw
Tryg Table Assembly
(One Piece Top)
Steel
Pin
#10 x 1"
Pan Head
Screw
1/4-20 x 3/4"
Flat Head
Socket Cap
Screw

2
Base Assembly
Steel
Pin
Alignment
Pins (x4) #9 x 1 3/4"
Flat Head
Screws
Use alignment pins (X4) to align base plate to base.
Predrill holes for #9 x 1 3/4" flat head screws.
Screw base plate to base using
#9 x 1 3/4" flat head screws.
Remove alignment pins.

3
Metal Support Bar Attachment
1/4-20 x 3/4"
Flat Head
Socket Cap
Screw
Shoulder
Bolt
Nut
Washer
(Underside View)
Attach center bars to
center base plate.
Center Bar Attachment
Screw support bars to
underside of base plates using
1/4-20 x 3/4" flat head socket
cap screws.

4
Top Attachment
Attach top using #10 x 1" Pan Head Screws.
#10 x 1"
Pan Head
Screw

5
#9 x 1 3/4"
Flat Head
Screw
Tryg Table Assembly
(Two Piece Top and Center Base)
Steel
Pin
#10 x 1"
Pan Head
Screw
1/4-20 x 3/4"
Flat Head
Socket Cap
Screw

6
Base Assembly
Steel
Pin
Alignment
Pins (x4)
#9 x 1 3/4"
Flat Head
Screws
Use alignment pins (X4) to align
base plate to base. Predrill holes
for #9 x 1 3/4" flat head screws.
Screw base plates to bases using
#9 x 1 3/4" flat head screws.
Remove alignment pins.

7
Metal Support Bar Attachment
1/4-20 x 3/4"
Flat Head
Socket Cap
Screw
Shoulder
Bolt
Nut
Washer
(Underside View)
Attach center bars to
center base plate.
Center Bar Attachment
Screw support bars to
underside of base plates using
1/4-20 x 3/4" flat head socket
cap screws.
Outer Bar Two
Piece Connection
Slide connector bar
between bars. Align
holes. Screw to
underside of center
plate with 1/4-20 x 3/4"
flat head socket cap
screws

8
Top Attachment
Connect two piece top using joint connectors.
Attach top to base using #10 x 1" Pan Head Screws.
#10 x 1"
Pan Head
Screw
(Underside View)
Joint Connectors Detail
Access Door
Attachment
