Tuohy WORKSTYLES Series User manual

WORKSTYLES
INSTALLATION INSTRUCTIONS

TABLE OF CONTENTS
STRUCTURE PANEL ASSEMBLY. . . . . . . . . . . . . . . . . . . 1
ELECTRICAL ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . 2
COVER PANEL / TOP AND END CAP ASSEMBLY . . . . . 3
DATA PLATE ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . 4
PANEL MOUNTED CANTILEVER CONNECTION . . . . . . 4
BASE ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CASEGOOD ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . 6
CREDENZA TOP ATTACHMENT . . . . . . . . . . . . . . . . . . . 7
OFFSET CREDENZA TOP ATTACHMENT . . . . . . . . . . 8
RUNOFF ATTACHMENT. . . . . . . . . . . . . . . . . . . . . . . . . . 9
CUBBIES AND SURFACE SHELVING . . . . . . . . . . . . . . 10
TABLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
LOUNGE SEATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
FACE ADJUSTMENTS / DRAWER
INSTALLATION / REMOVAL. . . . . . . . . . . . . . . . . . . . . . 13

1
STRUCTURE PANEL ASSEMBLY
1/4-20 x 4"
HEX BOLT 1/4-20 x 2"
HEX BOLT
1/4-20
TINNERMAN
NUT
1/4-20
TINNERMAN
NUT
1/4-20 x 1 3/4"
HEX BOLT
WASHER
8-32 x 5/16"
PAN HEAD
SCREW
FIG 1 - STRAIGHT FRAME
CONNECTION
FIG 2 - CORNER FRAME
CONNECTION
FIG 5 - TOP TILE RETAINER
CONNECTION
FIG 3 - OPTIONAL FOOT
CONNECTION
(UNDERSIDE VIEW)
FIG 1
FIG 2
FIG 5
FIG 3
(OPTIONAL
FOOT)
SPACER
FIG 4 - WALL MOUNTED
Z-CLIP CONNECTION
8-32 x 5/16"
PAN HEAD
SCREW
FIG 4
FIG 6 - MIDDLE TILE
RETAINER CONNECTION
(FOR DOUBLE PANELS)
FIG 7 - BOTTOM TILE
RETAINER CONNECTION
8-32 x 5/16"
PAN HEAD
SCREW
FIG 6
FIG 7
8-32 x 5/16"
PAN HEAD
SCREW
PANELS ARE MOUNTED
6" FROM THE FLOOR

2
ELECTRICAL ASSEMBLY
8-32 x 5/16"
PAN HEAD
SCREW
POWER OUTLET
CONNECTION
POWERWAY
MOUNTING BAR
CONNECTION
#10 X 5/8"
PAN HEAD
SCREW
IMPORTANT!
LOCKING CLIP
MUST BE FULLY
ENGAGED
INSTALLING
JUMPERS
WHEN INSTALLING METAL
PASSTHROUGH CABLES THOUGH 90
DEGREE CORNERS, INSTALL EACH
END THROUGH OUTSIDE OF
CONNECTOR WITH COVER OFF.
CORNER CABLE
CONNECTION

3
COVER PANEL / TOP AND END CAP ASSEMBLY
SINGLE PANEL
(X6 NEOPRENE PADS)
PANELS INSTALL BY TUCKING
TOPS OF PANELS IN AND
ALLOWING TO SETTLE INTO
LOWER RETENTION CLIPS
COVER PANEL
ATTACHMENT
TOP AND END CAP ATTACHMENT
(INSTALL END CAPS PRIOR TO TOP CAPS)
TOP CAP
ASSEMBLY
END CAP
ASSEMBLY
#6 X 3/4" PAN
HEAD SCREW
END CAP
RETAINER
#6 X 3/4" PAN
HEAD SCREW
TOP CAP
RETAINER
NEOPRENE
PADS
OPTIONAL
FEET
PANELS ARE MOUNTED 6"
FROM THE FLOOR
DOUBLE PANEL
(X8 NEOPRENE PADS)

4
DATA PLATE CONNECTION
PANEL MOUNTED CANTILEVER CONNECTION
(INSTALLERS RESPONSIBLE FOR WALL MOUNTED CANTILEVER CONNECTIONS)
(COVER PANELS HIDDEN)
PANEL MOUNTED
CANTILEVER
PANEL MOUNTED
CANTILEVER
INSERT CANTILEVERS INTO SLOTS
BETWEEN COVER PANELS AND
CONNECT TO STRUCTURE PANEL
FRAME.
DATA PLATE
CONNECTION
DETAIL
INSERT BOTTOM
AND PRESS DOWN
ON SPRING CLIP
AND SNAP INTO
PLACE

5
BASE ASSEMBLY
1/4-20 x 1/2" BHSCS
(STAINLESS STEEL)
1/4-20 x 1/2"
BHSCS
(BLACK)
1/4-20
T-NUT
LEG CONNECTION
ARM / CENTER LEG
CONNECTION
* ARMS INSTALLED AT EACH
CASEGOOD SEAM
* CENTER LEG INSTALLED WHEN
OVERALL WIDTH IS MORE
THAN 96"
Typical T-Nut Fastener Installation Instructions
These General Instructions Shall Apply to
All Bracket and Plate Connections that
Require T-Nut Fasteners as Part of the
Connection.
- Insert 1/4-20 x 1/2" BSCS Thru Hole in
Plate / Bracket & Thread T-Nut 2-Turns
Onto Bolt. Repeat for Rest of Connection
Holes.
- Next, Align All T-Nuts so that they Match
the Extrusion Being Connected & Depress
Into Channel.
- Should Look Like This Before Further
Tightening Takes Place.
ATTENTION :
- As Initial Tightening of Each BSCS
Begins, T-Nuts Must Pivot in Channel
Engaging the Shoulders of T-Nut Against
the Walls of the Channel.
- Pay Special Attention that Each T-Nut
"Engages" Before Continuing to Tighten
Each Bolt.
-Repeat Until All Bolts Have Been
Tightened.
CORRECT INCORRECT
Shoulders Did Not Engage
Into Sides of Channel.
90 DEGREE ANGLE
CONNECTION
1/4-20 x 1/2"
BHSCS
(BLACK)
1/4-20
T-NUT
1/4-20 x 1/2"
BHSCS
(BLACK)
1/4-20
T-NUT
TWO PIECE
CONNECTION

6
CASEGOOD ASSEMBLY
MULTIPIECE CASEGOOD
CONNECTION
CASEGOOD TO
BASE ASSEMBLY
#10 x 3/4"
PAN HEADS
#9 x 1 3/4"
FLAT HEAD
SCREWS
[ TIP: BASES ARE BEST ATTACHED WHILE
CASEGOODS ARE LAYING ON BACKS. USE
SPACERS OR BLOCKING (NOT PROVIDED)
FOR CASEGOODS THAT ARE DIFFERENT
DEPTHS.]

7
CREDENZA TOP ATTACHMENT
#9 x 1 3/4"
FLAT HEAD
SCREWS
#10 x 1"
PAN HEAD
SCREWS
SEAT PADS
ATTACH WITH
TWO SIDED TAPE
MULTIPIECE CREDENZA
FIELD JOINT DETAIL
(UNDERSIDE VIEW)

8
OFFSET CREDENZA TOP ATTACHMENT
#9 x 1 3/4"
FLAT HEAD
SCREWS
1/4-20 x 1/2"
FLAT HEAD
SCREWS
#14 x 1"
FLAT HEAD
SCREWS
TAPE
SQUARES

9
RUNOFF ATTACHMENT
RUNOFF LEG
ATTACHMENT
(UNDERSIDE VIEW)
BRIDGE PLATE
ATTACHMENT
(UNDERSIDE VIEW)
#10 x 1"
PAN HEAD
SCREWS
#10 x 1"
PAN HEAD
SCREWS

10
CUBBIES AND SURFACE SHELVING
SURFACE
SHELVING SITS ON
WORKSURFACE
#9 x 1 3/4"
FLAT HEAD
SCREWS
CUBBY ATTACHMENT
INSTALLER TO PREDRILL HOLES INTO
SIDE OF TOWER AND ATTACH TO CUBBY
WITH #9 x 1 3/4" FLAT HEAD SCREWS

11
TABLES
TABLE TOP CONNECTION
(UNDERSIDE VIEW)
#12 x 1"
PAN HEADS
HEIGHT ADJUSTABLE TABLE
TOP CONNECTION
(UNDERSIDE VIEW)
DO NOT LIFT TIERED
TABLES BY TOPS -
DAMAGE WILL OCCUR!!
#12 x 1"
PAN HEADS

12
LOUNGE SEATING
LOUNGE ASSEMBLY
(UNDERSIDE VIEW)
* SEE 90° CONNECTION DETAIL ON PAGE 5
#10 x 3/4"
PAN HEADS


Side-to-side adjustment Rear side-to-side adjustment
1Rotate side-to-side adjustment left or
right equally on both locking devices. Drawer
front moves in the same direction as rotation.
2After front side-to-side adjustment is
made with the locking devices, rotate the
rear side-to-side adjustment left or right
to re-align the back of the drawer box with
the front. Drawer back moves in the same
direction as rotation.
Maximum 1.5 (1/16") to left or right in both front and rear (tool-free)
NOTE: Side-to-side adjustment not available on T51.x8xx locking devices
R
L
R
L
Drawer
front
L
R
L R
0
0
Height adjustment Tilt adjustment
1Press up on adjustment tab
2Push towards back of drawer
Maximum 3(1/8") rise of drawer front (tool-free)
Rotate the tilt adjustment lever on the rear of
each runner to lift the back of the drawer and
tilt the top of the drawer front forward
Maximum 5(3/16") rise of drawer back (tool-free)
NOTE: Height and tilt adjustments available with all combinations of locking devices and runners
1
2
Drawer insertion
Extend the concealed runners fully. Place the drawer on the runners and
close. The locking devices automatically engage with the runners. Make
adjustments if necessary.
Drawer removal
1
2
1Squeeze orange handles on locking devices
2Pull drawer straight out and up
