Tuxedo TP9KF-TUX User manual

Mar 2019-A
TP9KF-TUX
Two-Post Floor Plate Lift
(Symmetric)
9,000 lbs. Capacity
(2,250 lbs. Max per Arm)
INSTALLATION & OPERATION
MANUAL

２
TP9KF-TUX
Mar 2019-A
IMPORTANT NOTES
READ THE INSTALLATION AND OPERATION MANUAL IN ITS ENTIRETY BEFORE
ATTEMPTING TO INSTALL THE LIFT.
·Do not install this lift on any surface other than concrete, conforming to minimum specifications.
·Do not install this lift over expansion joints or cracks. Check with building architect.
·Do not install this lift on a second floor with a basement beneath without written authorization from
building architect.
·Do not install this lift outdoors unless special consideration has been made to protect the power unit
from inclement weather conditions.
·A level floor is recommended for proper installation and operation. Concrete should be a minimum
of 4-1/4”thickness and 3,000 psi tensile strength with steal or fiber mesh reinforcement.
·The lift is intended to raise theentire body of the vehicle. Do not attempt to lift only partof the vehicle.
Improper use of this equipment could result in damage to the lift, yourself or other property.
·The lift is intended to lift vehicles only. It is not designed to lift any person or equipment containing
persons.
·Users of this equipment should be qualified, responsible and should follow the operation and safety
guidelines set forth in this manual.
·For specifications on concrete pads, please call for technical assistance.
·Improper installation can cause damage or injury.The Manufacturer will NOTassume liability for loss
or damage of any kind, expressed or implied, resulting from improper installation or use of this
product.
DEFINITION
Surface Mounted, Two-Post, Open Top Lift w/ Floor Plate, Hydraulic ‘chain-over’Drive, 9,000 lbs.
Capacity.
The name / model numbers are designated below:
·Model number TP9KF-TUX - Symmetric Swing Arm configuration
BASIC SPECIFICATIONS
Model Description
(Floor Plate) Capacity Lifting Time Overall Height
Overall
Width
Lifting
Height
Between
Posts
TP9KF-TUX Symmetric 9,000 lbs. 50 Sec 112”141”72”110-7/16”

３
TP9KF-TUX
Mar 2019-A
PREPARATION
The installation of this lift is relatively simple and can be accomplished by 2 men in a few hours. The
following tools and equipment are needed:
·12 quarts of Non-Detergent / Non-Foaming Hydraulic Oil - SAE-10, AW 32 or equivalent
·Chalk line and 12’Tape Measure
·4ft. Level
·Rotary Hammer Drill with 3/4”Masonry Drill Bit. (Core Drill Rebar Cutter also recommended)
·Hammer and Hex Key Wrench Set
·Metric Sockets and Open Wrench set - 13mm-30mm
·Medium Adjustable Wrench and Medium Pipe Wrench
·Crow Bar for Shim Installation and Medium Flat Screwdriver
·Locking, Needle Nose and Snap Ring Pliers
GENERAL INFORMATION
1. Carefully remove the crating and packing materials.
CAUTION! Be careful when cutting steel banding material as items may become loose and fall
causing personal harm or injury.
2. Identify the components and check for damage or shortages.
Please contact your distributor immediately, if any damages or shortages are discovered.
Packing:
·The lift assembly is packaged into two columns as one piece, as shown in (Fig.1).
·Every column comes with its cylinder, carriage, cables & chains, lifting arms, swivel pads, height
extensions, hoses and ‘drive-over’floor plate with the hardware box located in one of the columns.
·The electric-hydraulic motor pump is packaged separately and banded to top of lift.
Fig. 1

４
TP9KF-TUX
Mar 2019-A

５
TP9KF‐TUX
Mar 2019‐A
INSTALLATION INSTRUCTIONS
STEP 1: (Selecting Site) Before installing your new lift, check the following:
1. LIFT LOCATION: Always use architects plans when available. Check layout dimension against floor
plan requirements making sure that adequate space is available (Figs. 2, 3 & 4).
Fig. 2
(Elevation Layout)
2. OVERHEAD OBSTRUCTIONS: The area where the lift is located should be free of overhead
obstructions such as heaters, building supports, electrical lines, etc. (Fig 2.)

６
TP9KF‐TUX
Mar 2019‐A
Fig. 3
(Swing Arm & Column Layout)
Fig. 4
(Column / Floor Layout)
(
134
-
5/8”
)

７
TP9KF-TUX
Mar 2019-A
3. DEFECTIVE CONCRETE: Visually inspect the site where the lifts will be installed and check for
cracked or defective concrete. (Details on Page 4)
4. FLOOR REQUIREMENTS: The lift should be installed on a 3000 PSI concrete with minimum of 4-1/4”
thickness. The Floor should be level with-in gradients of ≦1/4”within area of the two columns = 135”
x 18”).
(See Details for Foundation Anchoring Requirements & Anchoring Tips on Page 4)
STEP 2: (Unloading & Unpacking)
1. After unloading the lift, place it near the intended installation location.
2. Remove the shipping bands and packing materials from the unit.
3. Remove the packing brackets and bolts holding the two columns together. (Do not discard bolts, they
may be used in the assembly of the lift )
4. Take out the drive-over floor plate, lifting arms, swivel pads, height extensions, hardware box, etc.,
from the column. Check the quantity of each item with the parts list. If anything is missing, please
contact your dealer at once.
STEP 3: (Site Layout)
1. Determine which side will be the approach side.
2. Now determine which side you prefer the power unit to be located on. The
MAIN column has the power-unit mounting bracket attached to the side, as
shown in (Fig. 5).
Note: the power unit column can be located on either side. It is helpful
to try and locate the power side on the driver side of the vehicle when
loaded on the lift, in order to save steps during operation.
3. Once a location is determined, use a carpenter’s chalk line to layout a grid
for the column locations. (See Fig. 4)
Fig. 5
4. After the post locations are marked, use a chalk or crayon to make an outline of the posts on the floor
at each location using the post base plates as a template.
5. Double check all dimensions and make sure that the layout is perfectly square.

８
TP9KF‐TUX
Mar 2019‐A
STEP 4: (Installing MAIN COLUMN w/ Power Unit Bracket)
1. Before proceeding, double check measurements and make certain that the bases of each column are
square and aligned with the chalk line.
2. Ensure Top Cap is pre-installed to the top of the Main column. Raise the column to a vertical position.
3. Using the base plate on the MAIN column as a guide, drill each anchor hole into concrete using a
rotary hammer drill and 3/4” concrete drill-bit. To assure full holding power, do not ream the hole or
allow the drill to wobble. (See Anchoring Details on Page 4)
4. After drilling, remove dust thoroughly from each hole using compressed air and/or wire brush. Make
certain that the column remains aligned with the chalk line during this process.
5. Assemble the washers and nuts on the anchors then tap into each hole with a block of wood or rubber
hammer until the washer rests against the base plate. Be sure that if shimming
is required that enough threads are left exposed.
6. Using a level, check column plumb for every side (Fig. 6). If shimming is
required, use supplied Shim stock or 3/4” washers, placing shims as close
as possible to the hole locations. This will prevent bending column bases.
7. With the shims and anchor bolts in place, tighten by securing the nut to
the base then turning 2-3 full turns clockwise. Ensure anchor bolts are
tightened to a minimum of 130 ft-lbs. of torque. DO NOT use an impact
wrench for this procedure.
Fig. 6
STEP 5: (Installing OFFSIDE COLUMN)
1. Raise OFFSIDE column and position at the designated chalk locations, ensuring the Top Cap is pre-
installed to the top of the OFFSIDE column. NOTE: DO NOT ANCHOR TO FLOOR AT THIS TIME.
2. Using the drive-over floor plate as a guide, make sure the distance between the two columns is
correct and that the mounting bolts/holes align to the floor plate’s slotted holes, as shown below in
(Figs. 7 & 8).
Fig. 7 Fig. 8
3. Remove the drive-over floor plate, after checking for proper hole alignment at each end.
NOTE: Floor Plate will be installed after Cable & Hose routing is completed.

９
TP9KF‐TUX
Mar 2019‐A
STEP 5: (Installing OFFSIDE COLUMN) Cont.
4. Using a tape measure, ensure the diagonal distance between the opposite corners of the base plates
on the columns are within equal dimensions (+/-) 1/4” to ensure the lifting arms will be in square.
5. Secure OFFSIDE column to the floor following the same procedures as outlined in STEP 4.
STEP 6: (Installing POWER UNIT)
1. Attach the power unit to the mount bracket on the side of the Main
Column using bolts, nuts and washers supplied (Fig. 9).
2. Remove the vent plug from the power unit and fill the reservoir with
hydraulic oil. Make sure the funnel used to fill the power unit is
clean.
Suggestion: Use Non-Detergent / Non-Foaming Hydraulic Oil - SAE-10,
AW 32 or equivalent. The unit holds approximately ten
quarts of fluid.
Fig. 9
STEP 7: (Installing / Routing EQUALIZER CABLES)
1. Raise and lock each carriage on the first safety latch engagement, approximately 30” high.
2. Make sure that the safety locks on each column are fully engaged before attempting to route equalizer
cables.
3. Be sure each carriage is at the same height by measuring from the top of the base to the bottom of the
carriage. This difference should be within 1/4”.
4. Route the first cable (See Figs. 10-13). Screw the nut on the cable stud so that half the threads pass
through the nut. Pull the other end of the cable and screw the nut on it also. Then tighten both nuts.
Fig. 10 Fig. 11 Fig. 12
(See Fig. 13 next page, for Cable Routing Diagram)

１０
TP9KF-TUX
Mar 2019-A
STEP 7: (Installing / Routing EQUALIZER CABLES) Cont.
Cable Routing Diagram
Fig. 13
5. Repeat above for the second cable.
6. Adjust each equalizer cable to approximately 1/2”side-to-side play. Ensure that each cable has
equal tension. Check the carriage height to ensure both carriages are sitting on the same latch.
