TUYA SPF-1010-TY User manual

SPF-1010-TY Smart Pet Feeder
Quick Start Guide

Preface
Quick start by the following steps:
• Remove the cover and scan the QR Code with your smartphone or
search 'Smartlife' APP from App store to download.
• Make sure the Wi-Fi indicator is rapidly blinking. If not, please reset it.
• Open your App, then click the '+' button at the top right corner of the
App to add devices.
• Select 'Pet Feeder' to add manually the Pet Feeder in "Small Home
Appliances" list.
If you want more details about network pairing, please refer to chapter
4.

Safety Notice
WARNING: Failure to follow these safety notices could result in 󽗉re,
electric shock, other injuries, or damage to the Smart Pet Feeder and
other property. Read all the safety notices below before using the
Smart Pet Feeder.
• Avoid high humidity or extreme temperatures.
• Avoid long exposure to direct sunlight or strong ultraviolet light.
• Do not drop or expose the unit to intense vibration.
• Do not disassemble or try to repair the unit yourself.
• Do not expose the unit or its accessories to 󽗊ammable liquids, gases
or other explosives.

Technical Speci󽗉cations
Hopper Capacity • 4 L
Auto Feeding Time • 1-20 meals per day
Power • DC power cord
• Backup batteries: 3 x D cell
Dimension • 240 x 340 x 300 mm
N. W. • 1.3 kg
Color • White

Welcome
1
The Smart Pet Feeder allows you to feed your pet remotely or apply
schedules for automatic feeding. You can get the feeding information
anywhere at any time.
This guide will provide you with an overview of the product and help
you get through the initial setup.
• Wi-Fi Remote control -Tuya APP smartphone programmable.
• Automatic & manual feeding
• Accurate feeding -Schedule up to 20 feeds per day
• 4L food capacity -4L large capacity
• Dual power protective -Battery backup, continuous operation during
power or internet failure
Features:

APP Download:
Tips:
Please check the condition and the accessories of pet feeder after you
open the box.
1. Remove the cover and scan the QR Code with your smartphone.
2. Search 'Smartlife' APP from App store.
Dry and solid pet food only, recommed food diameter between 5
to 10mm.
In the box
• Pet Feeder x 1
• Power Adapter x 1
• Quick Guide x 1
2

3Get to know your device
Cover
Button & indicator
(Open the cover)
Food outlet
Bowl

Battery box
3 x D-size batteries. Please pay attention to the polarity. Please note
that the battery charging is for backup purpose only. If you wish to
control the pet feeder remotely, power supply is needed.
Power switch
— for ON, ○ for OFF.
Power jack
Use the supplied power adapter.
Battery box
Power switch
Power jack

OK Button:
• Tap once to feed once in 1 portion
• Reset the network con󽗉guration
Hold the 'OK' button for 5 seconds until the power indicator 󽗊ashes
once to reset. The device will enter the EZ pair mode at the 󽗉rst reset.
If resetting the device again in the EZ pair mode, it will change to AP
pair mode.
Wi-Fi indicator
The Wi-Fi status gives the following information:
Wi-Fi Status What it means
Rapidly blink EZ pair mode.
Slowly blink AP pair mode.
Steady light Pet Feeder has join the Internet.
Wi-Fi indicator
Power
indicator
OK Button
• EZ pair mode (Default): Quick pair devices. You can set all devices to
this mode, and then add devices in batches on your phone.
• AP pair mode: If you would like to pair one specific device during
many devices. Please refer to FAQ1 to con󽗉gure network in this mode.

To get started, you will need:
• Connect your phone to the 2.4Ghz Wi-Fi network.
• A mobile phone with a mobile APP installed.
Then follow the steps below:
1. Power on the Smart Pet Feeder.
2. Make sure the Wi-Fi indicator is rapidly blinking. If not, please reset
it.
4Get started
1. Open your App.
2. Login with an existing account. If you are a new user, you need to
create an account at 󽗉rst.
3. Please click the '+' button at the top right corner of the App to add
devices.
4. Select 'Pet Feeder' to add manually the Pet Feeder in "Small Home
Appliances" list.
4.1 Add devices

5. Enter your home Wi-Fi account and password (Only support 2.4Ghz
Wi-Fi), then tap "Next" button.
6. Place the router, mobile phone, and Pet Feeder as close as possible.
Con󽗉 rm the indicator on your device is rapidly blink, then tap "Next"
to wait for connection.
7. After the device has been added, you can use to rename the
device. (If failed, please refer to FAQ2 to troubleshoot)
7. After the device has been added, you can use to rename the

4.2 App Overview:
Home:
1.Device list
You can check the added device, tap one to enter control board
2. Location information
Information about your local weather conditions, outdoor
temperature, PM
3.Home management
Add or delete home and manage home names, rooms, locations, and
members
4.Room management
Manage room. You can create rooms and assign devices to each room
5.Voice control (Temporarily not available on App)
Smart: Create smart scene and add automatic function(Temporarily
not available)
Me: App settings and FAQ about the app
Home management
Device List
Add Device
Voice Control Location
Information
Room
Management

Automatic feed
Total portion
Device settings
Manually feed
Feeding records
Add schedule for
automatic feed
Control board:
Select the target Pet Feeder in device list then enter the control board
• Automatic feed
Tap to edit the schedule for the automatic feed. Schedule supports
up to 20 items. The error of the schedule is about 30 seconds.
• Manually feed
Tap to feed manually. The maximum number of portion is 20 at a
time.

1. Con󽗉 gure the network in AP mode.
1. Reset the device in EZ pair mode, it will switch to AP pair mode. The
indicator on your device will blink slowly.
2. Then switch the network configuration mode to AP mode at the
upper right corner of the APP when you add the device.
3. Place the router, mobile phone and Pet Feeder as close as possible.
Confirm the indicator on your device is slowly blink, then tap "Next"
to wait for connection.
5FAQ

4. After the device has been added, you can use to rename the
device. (If failed, please refer to FAQ2 to troubleshoot)
- Con󽗉 rm that both the location permission of phone system and the
App are enabled.
4. After the device has been added, you can use to rename the
2. Wi-Fi con󽗉 guration of the device failed
- Con󽗉 rm the entered router password is correct.
- Ensure that the DHCP service is enabled for the router. If not, the IP
address will be occupied.
- Please con󽗉 rm the Wi-Fi network is stable:
Put the phone besides your device and make sure they are in the same
network environment, try to open a website to judge if the network can
be used.
- If your router supports both 2.4Ghz and 5Ghz, please enable the
2.4Ghz channel and add device under 2.4G Wi-Fi channel. You can
follow the following step on the App to con󽗉 gure the router.

- If you have already upgrate the iOS system to 14, you need to enable
the "Local network" of the App.
- If it still does not work, it is recommended to change the router and
try again.
3. Device o󽗌ine
- Con󽗉rm whether the Pet Feeder is powered on.
- Please confirm whether the home Wi-Fi network is normal, or
whether the Wi-Fi name and password has been modi󽗉ed.
- If there still have problems after the above checking, it is
recommended to remove the device or change the router to add it
again.
