TUYA SPF2000-W-TY User manual

SPF2000-W-TY Smart Pet Feeder
Quick Start Guide

Preface
Quick start by the following steps:
• Scan the QR Code behind the Pet Feeder with your smartphone or
search 'Smartlife' APP from App store to download.
• Make sure the Wi-Fi indicator is rapidly blinking. If not, please reset
the network con󽗉guration.
• Open your App, then click the '+' button at the top right corner of the
App to add devices.
• Select 'Pet Feeder' to add manually the Pet Feeder in "Small Home
Appliances" list.

Safety Notice
WARNING: Failure to follow these safety notices could result in 󽗉re,
electric shock, other injuries, or damage to the Smart Pet Feeder and
other property. Read all the safety notices below before using the
Smart Pet Feeder.
• Avoid high humidity or extreme temperatures.
• Avoid long exposure to direct sunlight or strong ultraviolet light.
• Do not drop or expose the unit to intense vibration.
• Do not disassemble or try to repair the unit yourself.
• Do not expose the unit or its accessories to 󽗊ammable liquids, gases
or other explosives.

Technical Speci󽗉cations
Hopper Capacity • 7.5L
Auto Feeding Time • 1-8 meals per day
Microphone • 10 meters, -30dBV/Pa
Speaker • 8 Ohm 1w
Power • DC power cord
• Backup batteries: 3 x D cell
Dimension • 230 x 230 x 500 mm
N. W. • 3.76 kgs
Color • White

Welcome
1
The Smart Pet Feeder allows you to feed remotely or apply schedules
for automatic feeding. With the voice recording function, it will loop
your voice 3 times when the food is delivered.
This guide will provide you with an overview of the product and help
you get through the initial setup.
• Wi-Fi Remote control -Tuya APP smartphone programmable
• Voice record & playback
• Automatic & manual feeding -built in display and buttons for manual
control and programming
• Accurate feeding - per day
• 7.5L food capacity -7.5L large capacity
• Key lock -Prevent mis-operation by pets or kids
• Dual power protective -Battery backup, continuous operation during
power or internet failure
Features:

APP Download:
Tips:
Please check the condition and the accessories of pet feeder after you
open the box.
1. Scan the QR Code behind the Pet Feeder with your smartphone.
2. Search 'Smartlife' APP from App store.
Recommend food size between 5 mm – 15 mm.
In the box
• Pet Feeder x 1
• Power Adapter x 1
• Quick Guide x 1
• Cord Hose Protector x 1
• Stand x 1
2

Wi-Fi indicator
The Wi-Fi status gives the following information:
Wi-Fi Status What it means
Flashing Pet Feeder has not joined the Internet.
Steady light Pet Feeder has joined the Internet.
Fault indicator lamp
The Fault indicator 󽗊ashes when one of the following happens:
• Network situation: the Pet Feeder cannot connect to the cloud
• Feeding situation: there is no food come out, or food doesn't come
out correctly.
3Get to know your device
Cover
Buttons & display
(Open the cover)
Microphone
Wi-Fi indicator
Fault indicator lamp
Food outlet
Bowl

Battery box
3 x D-size batteries. Please pay attention to the polarity. Please note
that the battery charging is for backup purpose only. If you wish to
control the pet feeder remotely, power supply is needed.
Speaker
Play sound.
Power switch
— for ON, ○ for OFF.
Power jack
Use the supplied power adapter.
Battery box
Speaker
Power switch
Power jack

Button Introduction:
Lock.
Hold the button for 6 seconds then release it to lock all
buttons. Hold it again for 6 seconds then release it to unlock.
Voice record/Reset network con󽗉guration.
Press once to enter/exit the recording. The longest recording
time is 10S.
Hold the button for 6 seconds then release it. The WIFI
indicator rapidly blinking to reset the network information.
Playback/Feed.
Press once to play/stop playing the voice record.
Hold the button for 6 seconds then release it to manually feed
once in 1 portion.
SET.
Enter/exit to set-up status.
UP.
Increase menu value. Hold the button, you can increase
quickly.
OK.
Con󽗉rm current setting and move to next setting.

Setup manually
• Setup system time
1. Press 'SET', the Hour of system time starts 󽗊ashing, press 'UP' to set
the hour, and then press 'OK' to con󽗉rm.
2. The Minute of system time starts flashing, press 'UP' to set the
minute, and then press 'OK' to confirm. After that, you can setup
automatic feeding.
Tip: The device will automatically synchronize the mobile phone time
after successful network con󽗉guration. Please wait for 1 ~ 2 minutes
• Setup automatic feeding
3. After system time’s setup, the 'MEALS' starts 󽗊ashing, press 'UP' to
setup meals, and then press 'OK' to con󽗉rm.
4. Then 'CURRENT' starts flashing, you can setup time and portion
of each meal one by one. The setting order is 'CURRENT' -> 'TIME' ->
'PORTION', and then move to the next meal. After setting all the meals,
the set-up status will exit.
Display Introduction:
M
EALS
:
P
ORTION
:
T
OTAL
:
TI
ME
:
CU
RRENT
:
Key lock Total Meals Battery Level
Total Meals
Feed Time
Current Portion
Total Portion History
Current Meal
System time

To get started, you will need:
• A Wi-Fi network.
• A mobile phone with a mobile APP installed.
Then follow the steps below:
1. Power on the Smart Pet Feeder.
2.Make sure the Wi-Fi indicator lamp is rapidly blinking. If not, please
reset the network con󽗉guration.
4Get started
1. Open your App
2. Login with an existing account. If you are a new user, you need to
create an account at 󽗉rst
3. Please click the '+' button at the top right corner of the App to add
devices
4.Select 'Pet Feeder' to add manually the Pet Feeder in "Small Home
Appliances" list
4.1 Add devices

5. Confirm your Wi-Fi indicator is rapidly blinking. Then enter your
home Wi-Fi account and password(Only support 2.4Ghz Wi-Fi)
6. Place the router, mobile phone, and Pet Feeder as close as possible
7. Waiting for connection
8. After the device has been added, you can use to rename the
device.

4.2 WiFi Network Configuration
FAQS:
1. Device not responding :
Please con󽗉rm your WI-FI is 2.4 Ghz and the password is correct.

2.More device-pairing FAQS:
Connecting your device
How to connect
Step 1: Add device
1. Connect your device to the power source and turn it on
2. Open the App, select '+' on the top right of the home page to add
device. At the net-pairing page, select the type of product
3. Make sure the device is in net-pairing status: the Wi-Fi indicator
light blinks quickly (twice a second)
- Please refer to the operation instructions found above the 'Con󽗉rm
indicator light blinks rapidly' button on 'how to make the indicator
light blinks rapidly'.
- Please press and hold the power button for 5 seconds to reset the
device if the product doesn't have a reset button;
- For devices such as the light which do not have a switch, please
connect it to the light holder and operate the switch 3 times (on-o󽗈-on-
o󽗈-on), stop at a light on condition in which the light blinks quickly;
- If the product has a reset button, please press the reset button
directly.
- It is recommended to check the operation manual in order to
connect the device to the network quickly.

Step 2: Enter Wi-Fi Password
Select the Wi-Fi through which the device can connect to the
Internet, and enter the Wi-Fi password. Then click 'OK' to proceed to
net-pairing. Only 2.4G Wi-Fi is supported at this moment, please check
if the Wi-Fi network is 2.4G.
Finally, wait a few seconds until it displays that network has
successfully been paired.
Troubleshooting for failure in connecting the network (failed to add
device)
1. Make sure the device has been connected to the power source and
turned on.
2. Make sure the device has been in net-pairing status.
3. Make sure that the device, the phone and the router are close to
each other.
4. Make sure that the device, the phone and the router are close to
each other.

5. Make sure the router password is correct.
6. Make sure the device has been added using 2.4G WiFi band. Enable
the Wi-Fi broadcast function and do not set it to hidden mode.
7. Make sure that the encryption method of the router's wireless
setting is WPA2-PSK and the authentication type is AES, or both are set
as automatic. 11nonly is not allowed in wireless mode.
8. Make sure the Wi-Fi name does not contain any Chinese
characters.
9. If the number of the router's connected devices reaches the limit,

try to turn o󽗈 some device's Wi-Fi functions and con󽗉gure it again.
10. If the router has enabled the wireless MAC address 󽗉lter, try to
remove the device from the router's MAC 󽗉lter list to ensure the device
is not prohibited by the router to connect to the network.

What if the device is o󽗈 line
1. Please make sure the device has been powered on;
2. Please check if the network is stable. Checking method: put a
mobile phone or an iPad next to the device and make sure they are
connected to the same network, then try to open a web page;
3. Please make sure the home Wi-Fi network is working well, or
whether the Wi-Fi name, password, etc have been modi󽗉ed. If so, reset
the device and add it again. (How to remove the device: Open the APP
and enter the device control page, click '...' button on the top right
hand corner, click on the bottom of the page 'Remove device');
4. Please try to reboot the router and wait 3 minutes to observe the
status of the device;
5. If the network is in good condition and shows no sign of
modi󽗉cations after troubleshooting, please go to the device's control
page and click the '…' button in the upper right hand corner to get
into the 'More' page. Then, click 'Feedback' and enter the issue you
encountered and provide your Router model, we will handle it ASAP.

4.3 App Overview:
Home:
1.Device list
You can check the added device, tap one to enter control board
2. Location information
Information about your local weather conditions, outdoor
temperature, PM
3.Home management
Add or delete home and manage home names, rooms, locations, and
members
4.Room management
Manage room. You can create rooms and assign devices to each room
5.Voice control (Temporarily not available on App)
Smart: Create smart scene and add automatic function(Temporarily
not available)
Me: App settings and FAQ about the app
Home management
Device List
Add Device
Voice Control Location
Information
Room
Management
