TV One C2-2450A User manual

C2-2450AOPERATION MANUAL
C2-2450A
Video Processor Operation Manual

C2-2450AOPERATION MANUAL

C2-2450AOPERATION MANUAL
TABLE OF CONTENTS
1 DISCLAIMER................................................................................................ 1
1.1 Regulatory Agency Acceptance...........................................................................1
1.2 FCC Statement....................................................................................................1
1.3 Manual Version Information.................................................................................2
1.4 Manual Copyright Notice.....................................................................................2
2 IMPORTANT SAFETY INSTRUCTION......................................................... 3
3 CAPABILITY, DEVICE FEATURES AND PRODUCT FEATURES............. 13
3.1 Device Capabilities............................................................................................ 13
3.2 Device Features................................................................................................13
4 PRODUCT IMAGE...................................................................................... 15
5 FRONT PANEL CONTROLS...................................................................... 16
5.1 Button controls ..................................................................................................16
5.2 Multi-directional switch......................................................................................16
5.3 Advanced menus...............................................................................................16
5.4 Special button combinations and functions........................................................17
5.4.1 Locking front panel buttons & IR remote control................................................17
5.4.2 Restore power-on settings................................................................................. 17
5.4.3 Factory Reset....................................................................................................17
6 VIDEO INPUTS AND OUTPUTS................................................................ 18
6.1 Computer inputs................................................................................................18
6.2 Computer outputs..............................................................................................18
7 UNPACKING AND INSTALLATION............................................................ 19
7.1 Shipping Carton.................................................................................................19
7.2 Important Safety Instructions.............................................................................19
7.3 Initial Operation Check Using Factory Default Settings......................................19
7.3.1 Initial operation and test.................................................................................... 19
8 INFRA-RED REMOTE CONTROL.............................................................. 21
9 MENU LAYOUT AND SETTINGS ADJUSTMENT...................................... 22
9.1 The High Level Menu Structure......................................................................... 22
9.2 Group Names and Descriptions......................................................................... 23
9.3 Items Associated with theAdjust Blend Sub Menu............................................ 23
9.3.1 ‘Aspect adjust’ = ‘Pixel’......................................................................................27
9.3.2 ‘Aspect adjust’ = ‘Advanced’..............................................................................28
9.3.3 ‘Aspect adjust’ = ‘Simple’................................................................................... 29

C2-2450AOPERATION MANUAL
9.4 Items Associated with theAdjust sources group................................................29
9.4.1 Menu items common to all inputs......................................................................30
9.4.2 DVI Source Menu Items.................................................................................... 33
9.4.3 RGB Source Menu Items................................................................................... 35
9.4.4 CV & YC Source Menu Items............................................................................ 36
9.4.5 Still Image Store / Testcard Source Menu Items................................................37
9.5 Items associated with theAdjust ethernet group................................................37
9.6 Items associated with theAdjust resolutions group............................................38
9.7 Items Associated with theSystem group...........................................................41
10 RS232 PORT.............................................................................................. 45
10.1 Connection........................................................................................................45
10.2 Communications protocol.................................................................................. 45
11 RS232 / IP CONTROL SPECIFICATION.................................................... 46
11.1 Communication protocol basics......................................................................... 46
11.2 Packet format....................................................................................................47
11.3 Function list.......................................................................................................49
11.4 Examples .......................................................................................................... 56
11.5 Reading and writing macros..............................................................................57
11.5.1 Reading a previously stored Macro...................................................................57
11.5.2 Writing to a macro.............................................................................................58
11.5.3 Run and Restore macros................................................................................... 58
12 EDGE-BLENDING SETUP.......................................................................... 60
12.1 Introduction .......................................................................................................60
12.2 Edge-blending requirements..............................................................................61
12.3 Basic setup of the two projectors.......................................................................62
12.4 Connections to the scaler(s) and projectors.......................................................62
12.5 Initial setup........................................................................................................63
12.6 Edge-blending activation ................................................................................... 64
12.7 Edge-blending overlap / size .............................................................................64
12.8 Edge-blending guide lines ................................................................................. 65
12.9 Alignment of projectors......................................................................................66
12.10 Gamma correction.............................................................................................68
12.11 Brightness compensation .................................................................................. 68
12.12 Aspect ratio adjustment.....................................................................................69
12.13 Locking both outputs together...........................................................................69
12.14 Other setup approaches.................................................................................... 70

C2-2450AOPERATION MANUAL
13 EDGE-BLENDING TOOL............................................................................ 73
13.1 Configuration.....................................................................................................73
13.2 Communications................................................................................................73
13.3 Video setup.......................................................................................................74
13.4 Mapping the scaler to a screen.......................................................................... 75
13.5 Cropping the image...........................................................................................76
13.6 Setting the blend width......................................................................................76
13.7 Further individual adjustment............................................................................. 77
13.8 Gamma and Black Level Adjustments...............................................................78
13.9 Brightness compensation .................................................................................. 78
14 WINDOWS CONTROL PANEL................................................................... 80
14.1 Opening screens...............................................................................................80
14.1.1 Selecting a serial port connection......................................................................80
14.1.2 Selecting an Ethernet connection......................................................................80
14.2 Connecting to a unit........................................................................................... 81
14.3 Application menu’s............................................................................................ 83
14.3.1 File menu .......................................................................................................... 83
14.3.2 Communications menu......................................................................................83
14.3.3 Tools menu .......................................................................................................84
14.3.4 Resolution menu...............................................................................................84
14.4 Scripting tool......................................................................................................84
14.5 Image Loader....................................................................................................85
14.5.1 Loading Still Images / Testcards........................................................................86
14.5.2 Loading Logos...................................................................................................87
14.5.3 Maximum Image size – how large can my Logo / Still Image / Testcardbe? .....88
14.6 Resolution Editor...............................................................................................88
15 TROUBLESHOOTING AND TECHNICAL SUPPORT ................................ 92
15.1 There is no picture on the Output......................................................................92
15.2 The image is shifted and not fully viewable........................................................92
15.3 The output resolutions no longer appear as expected.......................................92
15.4 There is excessive flicker on the Output............................................................ 93
15.5 The Output image is distorted............................................................................ 93
15.6 Some colors appear to be incorrect on the CV/YC output..................................93
15.7 How can I reduce color smearing on CV connections?......................................93
15.8 I can no longer adjust the Output image resolution............................................ 93
15.9 The picture on the video display is black and white........................................... 93

C2-2450AOPERATION MANUAL
15.10 The picture on the video display is green........................................................... 93
15.11 The RGB input is selected but the image is rolling or pink.................................94
15.12 The video signal from my DVD player does not appear to work.........................94
15.13 The output from the 1T-CT-464 is blue..............................................................94
15.14 No video present from the UTP output...............................................................94
16 RETURN PROCEDURE............................................................................. 95
16.1 Are you sure there's a fault?..............................................................................95
16.2 To return a unit for repair................................................................................... 95
17 WARRANTY POLICY ................................................................................. 97
18 CONNECTOR PINOUTS............................................................................ 98
18.1 DVI-I connector .................................................................................................98
18.2 HD15 connector................................................................................................98
19 SPECIFICATIONS...................................................................................... 99
19.1 Computer Input..................................................................................................99
19.2 Computer Outputs.............................................................................................99
19.3 Scaling / sampling / memory..............................................................................99
19.4 Warranty............................................................................................................ 99
19.5 Regulatory Compliance................................................................................... 100
19.6 Environmental .................................................................................................100
19.7 Power Requirement......................................................................................... 100
19.8 Control Methods..............................................................................................100
19.9 Mechanical......................................................................................................100
19.10 Optional Accessories....................................................................................... 100
20 CONTACT INFORMATION....................................................................... 101

C2-2450AOPERATION MANUAL
1
1 DISCLAIMER
This product is intended for professional and/or home use. This product is not
intended for use in a medical environment and does not have the required
certifications for such use. Similarly, use aboard any aircraft or spacecraft while in
flight or as an adjunct to any surface, airborne or marine navigation system or any
offshore marine activity, including control of any watercraft, or any use similar to
those specifically herein mentioned is prohibited. Use in the aforementioned
circumstances would require additional testing and certification.
You have not become the owner of any software - you have merely purchased the
right to use the software. You may make one copy of the software for your own use.
Other copies will be deemed a breach of copyright.
No warranty is made either expressed or implied including but not limited to any
implied warranties of merchantability or fitness for a particular purpose. In no event
shall the supplier or manufacturer of this product be liable for errors found within, or
be liable for any direct, indirect or consequential damages or loss in connection with
the purchase or use of this hardware software or manual. The sole and exclusive
liability to the supplier and manufacturer regardless of the form of action shall not
exceed the replacement cost of the materials described herein.
By using this equipment you have indicated that you have agreed to the terms listed
above. If you do not wish to agree or the above terms are contrary to your
conditions of purchase you may return the equipment, unused, to your supplier. All
trademarks and copyrights are acknowledged. E&OE.
1.1 Regulatory Agency Acceptance
European ‘CE’ Mark Statement
Emissions: BS EN 61000-6-3:2001 (Generic Immunity Standard for Residential,
Commercial and Light Industrial)
Immunity: BS EN 61000-6-1:2001 (Generic Immunity Standard for Residential,
Commercial and Light Industrial)
1.2 FCC Statement
Class A Device: This equipment has been tested and found to comply with the
limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits
are designed to provide a reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the Instruction Manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his own expense.

C2-2450AOPERATION MANUAL
2
Caution: This equipment is intended for use in the manner prescribed in the
Instruction Manual. Any user changes or modifications not expressly approved by
TV One Multimedia Solutions could void the user’s authority to operate the
equipment. Connecting this equipment to external devices requires no specially
shielded cabling for FCC compliance. The Instruction Manual shows or describes
the proper connection of this equipment for operation that insures FCC compliance.
Direct all inquiries regarding FCC compliance to:
TV One Multimedia Solutions
1350 Jamike Drive
Erlanger, KY 41018
859.282.7303
859.282.8225 (Fax)
1.3 Manual Version Information
Version: 2.7
Release Date: May, 2009
1.4 Manual Copyright Notice
This Operation Manual is the intellectual property of TV One, ©2006, 2007, 2008,
2009. No portion of this manual may be copied or reproduced in any manner or by
any means, including, but not limited to electronic and electro-mechanical, without
the express written permission of TV One.

C2-2450AOPERATION MANUAL
3
2 IMPORTANT SAFETY INSTRUCTION
To insure the best from this product, please read this manual carefully. Keep it in a
safe place for future reference.
To reduce the risk of electric shock, do not remove the cover from the unit.
No user serviceable parts inside. Refer servicing to qualified personnel.
2.1 Power and connections
This unit must be connected to a mains socket outlet with a protective earth
connection.
This unit is not disconnected from the AC power source as long as it is connected
to the wall outlet. The off state for this unit is called standby mode. In standby
mode the unit is designed to consume a reduced quantity of power compared to
normal operating modes.
When not using the unit for a long period of time, insure that the AC power cord is
disconnected from the wall outlet.
The AC wall outlet should be installed near to the unit and be easily accessible.
Do not plug in or attempt to operate an obviously damaged unit.
2.2 Water and moisture
To reduce the risk of fire and personal injury, operation of this device outdoors
and/or exposure to rain, water or excessive moisture is expressly prohibited.
The apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
2.3 General care
Do not force switches or external connections.
When moving the unit, disconnect the serial port connections first then the power
cable and finally the interconnecting cables to other devices.
Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this
may damage the unit. Use a clean dry cloth.
2.4 Location
Installation of this unit should be in a cool dry place, away from sources of
excessive heat, vibration, dust, moisture and cold.

C2-2450AOPERATION MANUAL
4
2.5 Ventilation
Slots and openings in the sides of the unit are provided for ventilation. To ensure
reliable operation, avoid obstruction of these openings and ensure the unit is
installed in a well-ventilated area.
2.6 Intellectual property
Some IC chips in this product include confidential and/or trade secret property.
Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer,
reverse assemble or decompile the contents thereof.

C2-2450AOPERATION MANUAL
5
2 IMPORTANT: CONSIGNES DE SECURITE
Afin de tirer le meilleur de ce produit, merci de lire attentivement ce manuel.
Gardez-le dans un endroit sûr pour pouvoir le consulter à nouveau.
Afin de réduire le risque de choc électrique, ne retirez pas l’unité de sa protection.
Aucune pièce réparable par l’utilisateur à l’intérieur. Référez-vous à des personnes
qualifiées.
2.1 Alimentation électrique et connexions
Il faut brancher l'appareil sur une prise du secteur disposant d'une mise à la terre.
Cette unité n’est pas déconnectée de la source de courant électrique tant qu’elle
est connectée à la prise murale. Le mode éteint de cette unité est appelé mode de
veille. En mode de veille, cette unité est conçue pour consommer une quantité
réduite de courant par rapport aux modes normaux d’utilisation.
Lorsque vous n’utilisez pas l’unité pendant une longue période, assurez-vous que
le câble d’alimentation électrique est déconnecté de la prise murale.
La prise murale de courant doit être installée près de l’unité et aisément accessible.
Ne branchez pas et n’essayez pas d’utiliser une unité visiblement endommagée.
2.2 Eau et humidité
Pour réduire les risques d’incendie et de dommages corporels, l’utilisation de cet
appareil à l’extérieur et/ou son exposition à la pluie, l’eau ou une humidité
excessive est expressément interdite.
L’appareil ne doit pas être exposé aux gouttes ou aux éclaboussures et aucun objet
contenant de l’eau, comme par exemple un vase, ne doit être posé sur l’appareil.
2.3 Entretien général
Ne forcez pas les boutons ou connexions externes.
Lorsque vous déplacez l’unité, déconnectez d’abord les connexions de ports en
série puis le câble d’alimentation et enfin les câbles de connexion avec d’autres
appareils.
N’essayez pas de nettoyer l’unité avec des dissolvants chimiques ou des produits
nettoyants en aérosol, car cela peut endommager l’unité. Utilisez un chiffon propre
et sec.
2.4 Emplacement

C2-2450AOPERATION MANUAL
6
L’installation de cette unité doit se faire dans un endroit frais et sec, éloigné de
sources excessives de chaleur, de vibrations, de poussière, d’humidité et de froid.
2.5 Aération
Les rainures et les ouvertures sur les cotés de l’unité servent à l’aérer. Pour
permettre une utilisation sûre, évitez d’obstruer ces ouvertures et assurez-vous que
l’unité est installée dans un endroit bien aéré.
2.6 Propriété intellectuelle
Certaines puces IC dans ce produit contiennent des éléments propriétaires
confidentiels et/ou des secrets commerciaux. Vous ne devez donc pas copier,
modifier, adapter, traduire, distribuer, démonter, désassembler, ou décomposer leur
contenu.

C2-2450AOPERATION MANUAL
7
2 INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Para sacar el mejor provecho de este producto, léase este manual con
detenimiento. Guárdelo en un lugar seguro para poder hacerle referencia en el
futuro.
Para reducir el riesgo de calambre, no quite la cubierta del aparato.
No hay piezas utilizables dentro. Remítase todo mantenimiento a personal
cualificado.
2.1 Corriente y conexiones
Esta unidad debe estar conectada a una toma de corriente eléctrica con una
conexión a tierra de protección.
Mientras esté conectada a una toma de electricidad, el aparato seguirá conectado
a la fuente de corriente CA. A la posición de «off» de este aparato se le denomina
posición de espera. En la posición de espera, el aparato está diseñado a consumir
una cantidad reducida de electricidad en comparación con los modos de operación
normales.
Asegúrese de desconectar el cable de corriente CA de la toma de la pared cuando
no va a utilizar el aparato por un periodo largo de tiempo.
La toma CA de la pared ha de estar instalada cerca del aparato y debe ser
fácilmente accesible.
No enchufe ni intente operar un aparato que esté evidentemente dañado.
2.2 Agua y humedad
Para reducir el riesgo de fuego o de daños personales, se prohíbe la utilización de
este aparato en el exterior y/o su exposición a la lluvia, al agua o a atmósferas de
excesiva humedad.
El aparato no debe situarse cerca de zonas en las que haya riesgo de goteo o
salpicaduras. Tampoco deben colocarse objetos que contengan agua (jarrones, por
ejemplo) en el mismo.
2.3 Cuidado general
No forzar interruptores o conexiones externas.
Al mover el aparato, desconecte las conexiones del puerto en serie primero, luego
el cable de electricidad y finalmente los cables interconectados a otros aparatos.
No intente limpiar el aparato con disolventes químicos o productos de limpieza
aerosol, ya que podrían dañar el aparato. Utiliza un paño limpio y seco.

C2-2450AOPERATION MANUAL
8
2.4 Ubicación
Este aparato se debe instalar en un lugar seco y fresco, lejos de fuentes de calor
excesivas, la vibración, el polvo, la humedad y el frío.
2.5 Ventilación
El aparato viene provisto de ranuras y agujeros en los lados para la ventilación.
Para asegurar una operación eficaz, se debe evitar la obstrucción de estos
agujeros y también asegurar que el aparato se instale en una zona con adecuada
ventilación.
2.6 Propiedad intelectual
Algunos chips con circuito integrado de este producto incluyen propiedad
confidencial y/o propiedad de secreto comercial. Por lo tanto queda prohibido
copiar, modificar, adaptar, traducir, distribuir, usar técnicas retroactivas, desmontar,
o recopilar los contenidos del mismo.

C2-2450AOPERATION MANUAL
9
2 WICHTIGE SICHERHEITSVORSCHRIFTEN
Lesen Sie diese Bedienungsanleitung bitte sorgfältig, um Ihr Produkt optimal
nützen zu können, und bewahren Sie sie zum späteren Nachschlagen an einem
sicheren Ort auf.
Entfernen Sie bitte keinesfalls die Abdeckung, um der Gefahr eines Stromschlags
vorzubeugen.
Im Inneren des Geräts befinden sich keine Teile, die vom Benutzer gewartet
werden können. Lassen Sie Wartungsarbeiten nur von Fachpersonal durchführen.
2.1 Stromversorgung und anschlüsse
Das Gerät muss an eine geerdete Netzsteckdose angeschlossen werden.
Solange das Gerät mit einer Steckdose verbunden ist, bleibt die Stromversorgung
aufrecht. Der Ausschaltzustand des Geräts wird als Standbymodus bezeichnet. Im
Standbymodus verbraucht das Gerät weniger Strom als in den üblichen
Betriebsarten.
Wird das Gerät über einen längeren Zeitraum hinweg nicht verwendet, ziehen Sie
bitte das Stromkabel aus der Steckdose.
Die Steckdose sollte sich in der Nähe des Geräts befinden und leicht zugänglich
sein.
Verbinden Sie ein offensichtlich beschädigtes Gerät keinesfalls mit einer Steckdose
und versuchen Sie auch nicht, es zu bedienen.
2.2 Wasser und feuchtigkeit
Um die Gefahr eines Brandes oder einer Körperverletzung zu verringern, ist es
ausdrücklich verboten, dieses Gerät im Freien in Betrieb zu nehmen und/oder es
Regen, Wasser oder hoher Feuchtigkeit auszusetzen.
Das Gerät darf keinen Tropfen oder Spritzern ausgesetzt werden und es dürfen
keine mit Flüssigkeiten gefüllte Behälter, wie Vasen, auf das Gerät gestellt werden.
2.3 Allgemeine pflege
Wenden Sie bei der Handhabung von Schaltern und Anschlüssen keine Gewalt an.
Beim Umstellen des Geräts entfernen Sie zuerst die seriellen Anschlüsse, dann das
Stromkabel und zum Schluss die Verbindungskabel zu anderen Geräten.
Versuchen Sie keinesfalls, das Gerät mit chemischen Lösungsmitteln oder
Sprayreinigern zu reinigen, da dies das Gerät beschädigen könnte. Verwenden Sie
ein sauberes, trockenes Tuch.

C2-2450AOPERATION MANUAL
10
2.3 Aufstellung
Das Gerät sollte an einem kühlen, trockenen Ort aufgestellt werden, fern von
übermäßiger Wärme, Vibrationen, Staub, Feuchtigkeit und Kälte.
2.5 Belüftung
Seitliche Schlitze und Öffnungen sorgen für die Belüftung des Geräts. Um die
ordnungsgemäße Belüftung zu gewährleisten, dürfen diese Öffnungen nicht
verdeckt werden. Sorgen Sie außerdem dafür, dass das Gerät an einem gut
belüfteten Ort aufgestellt wird.
2.6 Gewerbliches eigentum
Einige integrierte Schaltkreise in diesem Produkt enthalten vertrauliche
Informationen und/oder Betriebsgeheimnisse. Sie dürfen daher diese Inhalte nicht
kopieren, modifizieren, adaptieren, übersetzen, verteilen, rückentwickeln,
rückassemblieren oder dekompilieren.

C2-2450AOPERATION MANUAL
11
2 BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Lees deze handleiding zorgvuldig door om het beste uit uw product te halen.
Bewaar het op een veilige plek voor raadpleging in de toekomst.
Haal nooit het omhulsel van de eenheid af, dit om de kans op een elektrische schok
te verminderen. Maak het apparaat nooit open: er bevinden zich geen door de
gebruiker in te stellen onderdelen in het apparaat. Laat service en onderhoud over
aan een gekwalificeerde technicus.
2.1 Elektriciteit en aansluiting
Dit toestel moet worden aangesloten op een netcontactdoos met een
aardsluitingsbeveiliging.
Deze eenheid is niet van de wisselstroom voedingsbron gescheiden wanneer de
stekker nog in het stopcontact zit. Wanneer de eenheid uitstaat, staat deze nog in
de stand-by modus. In de stand-by modus vergt de eenheid minder stroom dan in
de normale "aan" modus.
Wanneer u de eenheid voor langere tijd niet gebruikt, zorg er dan voor dat de
stekker van het wisselstroomsnoer uit het stopcontact is getrokken.
Het wisselstroom stopcontact moet dichtbij de eenheid geïnstalleerd worden en
makkelijk toegankelijk zijn.
Als de eenheid duidelijk beschadigd is moet u deze nooit op het lichtnet aansluiten
of bedienen.
2.2 Water en vocht
Om het risiko op brand en persoonlijk letsel te beperken is het gebruik van dit
apparaat buiten en/of blootstelling aan regen, water of overdadige hoeveelheden
vocht uitdrukkelijk verboden.
Het apparaat mag niet worden blootgesteld aan druppels of bespatting en er mogen
geen objecten die gevuld zijn met vloeistoffen, zoals vazen, op het apparaat
geplaatst worden.
2.3 Algemeen onderhoud
Forceer schakelaars of externe aansluitingen nooit.
Bij verplaatsing van de eenheid, de seriële poortaansluitingen eerst loskoppelen,
dan de voedingskabel en als laatste de snoeren naar andere apparaten.
Probeer de eenheid nooit met chemische oplosmiddelen of schoonmaakmiddelen
in een spuitbus schoon te maken, omdat dit de eenheid kan beschadigen. Gebruik
een schone droge doek.

C2-2450AOPERATION MANUAL
12
2.4 Plaatsing
Deze eenheid moet geïnstalleerd worden op een koele droge plaats, uit de buurt
van bronnen van extreme hitte, vibraties, stof, vocht en kou.
2.5 Ventilatie
De sleuven en openingen aan de zijkant van de eenheid zijn voor ventilatie. Zorg er
voor dat de eenheid op een goed geventileerde plek geïnstalleerd wordt zodat deze
betrouwbaar werkt.
2.6 Intellectueel eigendom
Sommige IC chips in dit product bevatten vertrouwelijke informatie en/of
fabrieksgeheimen. U mag daarom de inhoud hiervan niet kopiëren, wijzigen,
aanpassen, vertalen, verspreiden, nabouwen, of decompileren

C2-2450AOPERATION MANUAL
13
3 CAPABILITY, DEVICE FEATURES AND PRODUCT
FEATURES
3.1 Device Capabilities
The C2-2450A uses the proprietary CORIO®2 Engine to perform its functions, being
the second generation of the successful CORIO®products. The CORIO®2
technology is a powerful toolset for any application requiring high quality video
signal conversion or image manipulation.
The unit features a single video processing and scaling engine, tailored to meet the
demands of an edge-blending system – when used with multiple units (one per
projector).
The unit offers enhanced functionality up to DVI resolutions of 1920x1200@60Hz
with full HDCP support on the DVI input and output.
Edge-blending adjustments such as gamma and black-level control aid the setup of
complex systems. Guide-lines can be activated from the front of the unit, as can
pure black and white signals to help the user achieve the best blends.
3.2 Device Features
General Topography
4:4:4 RGB / YUV sampling provides full bandwidth color which allows precise
keying where included in the unit’s capabilities. This can be achieved through the
transparent (soft) keys on the front of the unit. Each unit’s video inputs
accommodate multiple video and computer signal formats and resolutions – see
specifications at end of manual for full details.
Ultimate flexibility
The C2-2000 series’ output signal format flexibility assures that the Native
Resolution of virtually any display can be matched. Because of the resolution
calculator (included in the Windows® Control Panel), even new resolutions can be
added to the unit. Signal parameter adjustments can be made for each video input
and are stored in individual non-volatile memories for retrieval once the unit’s power
has been removed.
Simple Control
The unit can be controlled in various ways. One option is to control it from the front
panel. Another option would be to control the unit from an infra-red remote control.
It can also be controlled via RS-232 or via Ethernet using the Windows Control
Panel or Edge Blend Tool.
Upgradeability
All C2-2000 units benefit from firmware upgradeability, thus reducing product
obsolescence by allowing the installation of the latest version of firmware. This not

C2-2450AOPERATION MANUAL
14
only applies to the software used to control the unit, but also to the range of
resolutions stored inside the unit, the addition of new features, and upgrades to the
heart of the image processing hardware – the CORIO®2 scaling engine. See
http://www.tvone.com/support for more detail.
