TWAC Protectant User manual

TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
INSTALLATION
MANUAL
INSTALLATION
MANUAL

TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
CONTENTS
Introducing Protectant™ Termite Barriers 1 –10
Training Manual Requirements 11 –12
Training Protocol 13 –15
Service Penetrations 16 –18
Service Conduits 19 –20
Perimeter Barrier Installations 21 –34
Protection of Rendered Brick-Masonry 35
Masonry Block Installations 36
Construction Joints 37 –44
Slab Repairs 45
Retaining Wall Sheeting 47 –49
Ant Capping –Engaged Piers 50
Installation Drawings 51-92
Safety Training Procedures 93-138
Alternative Cladding Systems 139

P a g e | 1
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
THEWHITEANTCO.
Is proud to offer a complete protection system unlike any other barrier available on the
market today. Why?
Constructed from durable geotextile and further strengthened in Australia by the addition of a
patented termite resistant bonding agent, Protectant™ will:
Physically resist termites from entering the building
Termites will be repelled and killed
Additional protection is provided through the use of a termite resistant commercial
construction adhesive which fully bonds the system to the structure
No other system offers these benefits
Protectant™ is so versatile that every change
in construction method can be easily treated.
Anything else is a compromise!

P a g e | 2
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Who are we?
A 100% Australian business established in1995 by an established builder who
pioneered the development of a unique physical termite barrier system
Still proudly Australian owned with locally produced quality assured products
Rapidly expanding nationwide with our barriers in more than 50,000 buildings
Our research team work with the CSIRO, Department of Primary Industries and other
NATA accredited laboratories in an ongoing program to develop new products
A company that focuses on updating skills and training of all its employees and
associates
Until a few years ago we went about our business quietly, focusing mostly on Southeast
Queensland and Northern New South Wales in the confidence that when builders try our
products they will continue to buy from us……
We now supply to many of Australia’s leading builders across three states including: Hotondo
Homes, Hallmark Homes, Perry Homes, JG King, Mega Homes, Hamlan Homes, Cavalier
Homes, Dennis Family Homes and AV Jennings. Nevertheless, our standards also apply to
the individual builder with competitive pricing, quality products and personalised service.
Having expanded to meet the needs of national builders allows us to offer you the same
service.
How do you and your home buyers benefit when you choose the Protectant™ termite
barrier system?
A barrier system supplied, installed and warranted by the one company and tailored to
suit your individual requirements
A range of systems that hold a CodeMark Certificate of Conformity under the JAS-ANZ
Quality management system.
Quality, patented products with an outstanding guarantee
A support system that combines installers and technical management to ensure
minimal disruption to your building schedule
This gives you a unique barrier system without compromise

P a g e | 3
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
The WhiteAnt Co. System - Passive Termite barrier system
Product description
The White Ant Co System is a Stainless Steel/ PVC passive termite barrier system. This
system was covered by “The CSIRO Appraisal 224”. This appraisal has been independently
revaluated by ECOSPAN Pty Ltd, as the CSIRO system was phased out and now replaced by
the “CodeMark “ compliance system. Our company has engaged the services of: CertMark,
14/76 Wises Rd. Buderim QLD 4556. As an auditor for compliance with the BCA under the
“CodeMark System”, this process was completed on 18 January 2010 and final certification
was issued on 15 April 2010 with the certificate number CMA-CM40036.
General:
The Perimeter barriers, construction joints barriers, retaining walls, suspended floor barriers
and slab penetration collars are made from strip either stainless steel or PVC with all joins
adhered with an approved and tested flexible adhesive and used as a physical barrier to
prevent the concealed entry of subterranean termites into the structure. The perimeter barrier
is placed to finish at the face of the external brickwork or to the face of the applied finish
material and sealed to the slab with The White Ant Co. Pty Ltd approved adhesives or
adhesive coatings. The barrier is placed finished not less than 75mm above finished ground
level or not less than 25mm where concrete or similar materials abut the perimeter of the
structure. Where it is not possible to achieve a minimum inspection zone of 25 mm, a
secondary barrier must be installed.
The White Ant Co. System barrier may be cast into a concrete slab prior to pouring. Slab
penetration flanges are bonded to the slab penetration pipe with ADULETH TERMITICIDE
flexible adhesive and held in position on the pipe penetration, if necessary, by means of a PVC
collar. The slab penetration flange are placed at a mid slab depth and below the finished slab
height. The pipe penetration collars may be fitted prior to concrete pour or retrofitted.
The WhiteAnt Co. System Passive Termite barrier system
Product description
Components:
Stainless steel sheet at 0.2mm and a grade of 316
PVC minimum 1.00mm with a D shore of better than 80
ADULETH TERMITICIDE Termite resistant flexible adhesives
Attached is a copy of the Technical assessment of all of our termite management systems,
and as per the technical assessment for CodeMark, the materials used in both barrier systems
has a serviceable life that will exceed 50 years.

P a g e | 4
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
The White Ant Co. termite management system offered for installation on your projects will
provide “whole of building protection against concealed entry by subterranean termites into the
structure” as per the Australian Standards code AS.3660.1 of 2016 and the total system
complies with the requirements of the BCA and the Queensland amendments related to
termite barrier systems.
Please review the following documents as compliance.
CodeMark™ Certificate of Conformity Number CMA-CM-40036
Technical Assessment of The White Ant Co Pty Ltd termite management systems for
Codemark.
Installation drawings are assessable on our website
http://www.protectantpestmanagement.com/ and / or an Installation Manual can be supplied on
request.
Please do not hesitate in contacting me if you have any further queries with reference to this
matter.
Regards
David Battistuzzi
31/01/2018

P a g e | 5
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Protectant™ Termite Barrier System
Product description
The Protectant™ Termite Barrier System is a specialised termite resistant impregnated
polyester fabric (polymer) termite barrier system. This system was covered by “CSIRO
Appraisal 321”. This appraisal has been independently revaluated by ECOSPAN Pty Ltd as
the CSIRO system was phased out and replaced by the “CodeMark “ compliance system. Our
company has engaged the services of: CertMark, 14/76 Wises Rd. Buderim QLD 4556. As
auditor for compliance with the BCA under the “Codemark System”, this process was
completed on 18 January 2010 and final certification was issued on 15 April 2010 with the
certificate number CMA-CM40036.
General:
The perimeter barriers, construction joints barriers, retaining walls, suspended floor barriers
and slab penetration collars are made from a polyester fabric (polymer) impregnated with a
termite resistant compound by a factory process or PVC collar with all joins adhered with an
approved and tested termite resistant flexible adhesive and used as a physical barrier to
prevent the concealed entry of subterranean termites into the structure. The perimeter barrier
is placed to finish at the face of the external brickwork or to the face of the applied finish
material and sealed to the slab with The White Ant Co. Pty Ltd approved adhesives or
adhesive coatings. The barrier is placed finished not less than 75mm above finished ground
level or not less than 25mm where concrete or similar materials abut the perimeter of the
structure. Where it is not possible to achieve a minimum inspection zone of 25 mm, a
secondary barrier must be installed.
The Protectant™ Polymer Termite Barrier System Perimeter barrier may be cast into a
concrete slab prior to pouring. Slab penetration flanges are bonded to the slab penetration
pipe with ADULETH TERMITICIDE flexible adhesive and held in position on the pipe
penetration if necessary by means of a PVC collar or cable tie. The slab penetration flange or
polymer fabric are placed at a mid slab depth and below the finished slab height. The pipe
penetration collars may be fitted prior to concrete pour or retrofitted.
Protectant™ Termite barrier system
Product description
Components:
Protectant™ polymer barrier impregnated with AD-TR-SC RED
PVC minimum 1.00mm with a D shore of better than 80
ADULETH TERMITICIDE Termite resistant flexible adhesives

P a g e | 6
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Attached is a copy of the Technical assessment of all of our termite management systems,
and as per the technical assessment for CodeMark, the materials used in both barrier systems
has a serviceable life that will exceed 50 years.
In summary:
The Protectant™ Polymer termite management system offered for installation on your projects
will provide whole of building protection against concealed entry by subterranean termites into
the structure” as per the Australian Standards code AS 3660.1 of 2016 and the total system
complies with the requirements of the BCA and the Queensland amendments related to
termite barrier systems.
Please review the following documents as compliance.
CodeMark™ Certificate of Conformity Number CMA-CM40036
Technical Assessment of The White Ant Co Pty Ltd termite management systems for
Codemark.
Installation drawings are assessable on our website
http://www.protectantpestmanagement.com/ and / or an Installation Manual can be supplied on
request.
Please do not hesitate in contacting me if you have any further queries with reference to this
matter.
Regards
David Battistuzzi
31/01/2018

P a g e | 7
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036

P a g e | 8
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Protectant™ Termite Barrier Systems
THEWHITEANTCO
Constructed from durable geotextile strengthened by the impregnation
with a patented termite resistant bonding agent
Termites are repelled and killed
Fully bonded to both concrete and brickwork
No other system offers all these benefits
15 year warranty on product and installation
Complete coverage of cavity area
Flexibility for all construction methods

P a g e | 9
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Protectant™ Penetrations
Permanently set into concrete
Permanently fixed to pipe penetrations
Fixed with termite resistant adhesive
Protectant™ Wall Sheeting
Completely sealed to retaining walls
Ease of installation
Special bonding material
Repels and kills termites

P a g e | 10
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Protectant™ Strip Shielding
Barrier bonded to brickwork
Ease of installation
Repels and kills termites

P a g e | 11
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
TECHNICAL & TRAINING MANUAL
This Technical and Training Manual is the property of The White Ant Co Pty Ltd and its contents are
specific to the installation of the products referred to within the manual. At no time may the contents of
the manual be given to others or discussed outside The White Ant Co Pty Ltd. Should your involvement
with The White Ant Co Pty Ltd cease, this manual must be returned to a company representative.
The Technical and Training Manual gives instruction on the basic installation techniques required for
the correct installation of The White Ant Co Pty Ltd’s range of products. Should an installer be unsure
of any installation they are required to contact a White Ant Co Pty Ltd supervisor, manager or the
Technical and Training Manager for assistance.
The White Ant Co Pty Ltd's range of products have been tested and appraised by ABSAC, CSIRO and
Department of Primary Industry and Fisheries (Qld) as a physical termite barrier system and should be
installed accordingly. The White Ant Co Pty Ltd's range of systems hold a CodeMark™Certificate of
Conformity under the JAS-ANZ Quality management system.
The CSIRO appraisals –224 and 321 –refer to the White Ant Co. System for the installation of
stainless steel, aluminium, PVC and the Protectant™ Polymer Termite Barrier System products
respectively to be used in conjunction with the adhesives ADSOL ADHESIVE and ADULETH
TERMITICIDE. The adhesives may never be considered as a termite barrier without the use of one of
the appraised products.
While the use of the products has been heavily researched and the application techniques proven over
a number of years, ongoing research, development and testing may result in changes. Should a
change be made, an update to the manual will be provided. Any update is to be placed into the manual
and the redundant sections removed. Updates will be provided when necessary. It is the responsibility
of regional managers and trainers to ensure all installers are made aware of any alterations and ensure
the version and date of the manuals are current.
The products are designed to provide a continuous and complete physical termite barrier. Should it not
be possible to install a complete barrier due to the type of construction, you must note on the relevant
paper work any incomplete areas, to ensure the extensive warranty of The White Ant Co Pty Ltd is not
compromised.
While this manual provides the instructions required to install the products in a manner to ensure the
efficacy of the system, be aware that the presentation of the completed installation, yourself and your
vehicle are equally important. An installation that looks to be professionally installed by a well
presented and competent tradesperson will ensure faith in both the product and yourself.
While not recognised as a trade, who else on any site can provide a physical termite barrier that is
guaranteed to work? You are the company representative on any installation and it is up to you to
ensure that continuity of work is achieved for both yourself and The White Ant Co Pty Ltd.
PREREQUISITE FOR LICENCE APPROVAL
Before any work can be commenced for The White Ant Co Pty Ltd it is a requirement
that the Job Safety Analysis included in the manual be signed and returned to the
Technical Manager. Failure to accept the conditions of the Job Safety Analysis or failure
to comply with the conditions during the course of installation will result in instant
dismissal.

P a g e | 12
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
PROCEDURES
●Comply with all site requirements such as site safety inductions, personal protective
equipment and reasonable directions from the builder / supervisor.
●The workplace health and safety requirements of The White Ant Co Pty Ltd must be
followed at all times.
●Before commencing work ensure the site safety analysis is complete –your safety is
your responsibility.
●If you have any doubt regarding finished ground or external slab levels, check with the
builder as this will save yourself and others unnecessary work later.
●All installations from penetrations to perimeter barriers will only be as good as the
preparation carried out –dust, mortar and concrete slurry will ensure the installation will
fail:
●Clean the slab edge using a wire brush
●Use a bolster / chisel to remove slurry and mortar
●Fill cavities with ADULETH TERMITICIDE, if severe, paint with ADSOL
first, as this will bond any loose material you have been unable to
remove
●Check for drummy sections of the slab that may have been caused by
frame fixing.
●All installations are to be carried out to the requirements of The White Ant Co Pty Ltd –
not to the builder’s request. Should a builder insist on an installation that is not to
specification or he refuses to allow a complete installation, contact a supervisor and
supply the builder with a site instruction to prevent any warranty issues at a later time –
you are the expert in this field.
●On completion of the installation you must be confident that you have installed a
complete termite barrier that will:
Physically prevent termites from entering the building
Is well presented
Leave a clean site for following tradespeople
●While installing the penetration protection, check that the reinforcing mesh has not been
cut which could indicate a construction/key joint is to be installed.
●If there is a step down in the slab, inform a supervisor that it exists or notify the builder
that protection will be required –he may not be aware of the requirements.

P a g e | 13
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
TRAINING PROTOCOL
The White Ant Co Pty Ltd with its physical termite barrier system, bases its future on
the supply and complete installation of a distinctive range of products including the
Protectant™ Barrier System.
To ensure our place in the market continues to grow, and our products and service are
seen to be equal or superior to any others available, we must maintain a high level of
efficiency, availability and a professionalism that our competitors can only aspire to.
If The White Ant Co Pty Ltd is to increase its position the primary goal must be to supply
the market with a team of termite barrier specialists who have been selected and fully
trained for the position.
TRAINEE SELECTION
●Preferably a trainee should possess a knowledge of physical barrier systems
●Have some knowledge of termites in their area of installation
●Must have at least a basic knowledge of how a building is constructed
●Have sufficient self confidence to liaise with builders and other trades to
ensure a complete barrier system is installed
●Maintain a professional presentation of both themselves and equipment
●Have accurate and legible reporting skills
●Be prepared to adhere to company policy regarding:
Workplace Health And Safety
Insurance requirements
Work records
A trainee will not install The White Ant Co Pty Ltd products unsupervised until an Accredited
Installer’s Licence has been issued.
LICENCE APPLICATION
An Installer’s Licence will not be issued until the following criteria have been met:
●Understanding of the barrier components has been achieved
●Understanding of how and why the barrier is installed
●Competency in the standard installation types for the area
●The certificates of currency for the relevant insurances have been
forwarded to The White Ant Co Pty Ltd
●Knowledge of varying types of installations has been achieved
from the training manual
●A minimum of five (5) quality audits have been forwarded to
The White Ant Co Pty Ltd –the quality audits need to be signed by either
a Regional Manager or the Technical Manager
When the listed criteria have been satisfied a Level 1 –Accredited Installer’s Licence will be
issued by The White Ant Co Pty Ltd.
AREA MANAGER

P a g e | 14
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Through experience, existing Area Managers will have displayed all the requirements of an
Accredited Installer with the added responsibilities of:
●Business growth by attracting builders
●Ability to problem solve on complex installations and arrive at
a solution that meets both specification and the builder’s expectations
●Quoting complex domestic plans and achieving a viable outcome for
the builder and The White Ant Co Pty Ltd
●Quote basic commercial buildings
●Effective stock control to meet area requirements
●Effective time management for work on time for the manager and
installer
●Through quality audits by other managers (Area, Regional & Technical) be seen
to maintain a high quality of installations in all building types
An installer moving to Area Manager level or an existing Area Manager who is seen to have
achieved the requirements will have achieved a Level 2 as an Accredited Installer of The
White Ant Co Pty Ltd system.
TECHNICAL ASSISTANT/TRAINER
In instances where a licenced installer has demonstrated a complete knowledge of the
products and the systems of installation and has the ability to accurately audit the installations
of others, they may be considered for a Level 3 licence.
A trainer must also demonstrate both the knowledge and ability to convey information in a
manner that is understood by others.

P a g e | 15
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
REGIONAL MANAGER
Regional Managers have been or are appointed through extensive knowledge of physical
termite barrier systems, a demonstrated commitment to business growth and continued
maintenance of the company ethics and goals for the future.
This is achieved by:
●Regular audits of both Area Managers and Accredited Installers
●Striving to gain new business by developing a prospect from an initial approach
to achieving that business
●Competently quoting complex domestic and commercial plans to win a contract
●Assisting with training of installers and furthering the training of existing
personnel
●Effective time management
●Reliably delivered and accurate reporting of business activities for their general
area and Area Manager achievements
Having achieved the requirements of Installer and Area Manager, a Regional Manager will
have achieved a Level 4 accreditation.
All licences will be valid for three years.
Assistance is always available through any of the managers. If you are unsure of
specifications, requirements or policy be sure to ask, as a guess may lead to a costly mistake
and reflect on your position.
To ensure that all installers are maintaining an acceptable level in all facets of
The White Ant Co Pty Ltd policies, regular quality audits are to be carried out.
Should an installation not meet the required standard the fault will be demonstrated and
rectification carried out by the specific installer.
Should an installer be found to repeat poor installations or if the discovered fault is of a severe
nature a downgrade of licence level or dismissal may result.
Compliance with the training protocol is the expected minimum that personnel of The White
Ant Co Pty Ltd are required to achieve. Failure to maintain the company policy standards may
result in a loss of current accreditation level.
David Battistuzzi
Technical & Field Operations Manager

P a g e | 16
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
SERVICE PENETRATIONS
PRE - POUR PENETRATION PROTECTION

P a g e | 17
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
PRE-POUR PENETRATIONS
Penetrations are to be fitted no later than the day before the slab pour.
Do not attempt to install penetrations until the moisture membrane and reinforcing mesh
have been placed.
Cut the reinforcing mesh back 65mm from all pipes and remove tape or caps from pipes.
Take care when removing caps as the drainage pipe work may be under pressure and
the cap may blow off when disturbed.

P a g e | 18
TWAC Installation Manual Ver: 0118 CodeMark™ CMA-CM40036
Do not cut starter or corner bars.
Push the flange in a single movement to the required position at mid slab height.
Apply White Ant Co tape from above the reinforcing mesh spiralled to the top of the pipe.
Reapply any tape or caps that have been removed to ensure concrete cannot enter the
pipe during the pour.
Check that the reinforcing has been cut back sufficiently from the pipe and that all pipes
and conduits have been treated.
